WALL MOUNTING THE TV
First you will need a wall mount . Consult the provided table below to find the
appropriate mount for your TV .
Be sure the mount you choose is capable of supporting the weight of the TV .
To install your TV on a wall:
1 . Disconnect any cables connected to your TV .
2 . Place the TV face-down on a clean, flat, stable surface . Be sure the surface is
clear of debris that can scratch or damage the TV .
3 . If attached, remove the stands by loosening and removing the screws .
4 . Attach your TV and wall mount to the wall by carefully following the instructions
that came with your mount . Use only with a UL-listed wall mount bracket rated
for the weight/load of your TV .
TIP: Installing a TV on a wall requires lifting . To prevent injury or
damage to the TV, ask someone to help you .
WARNING: Do not use the screws that are included inside the wall
mount holes to mount TV .
Note: The image shown here is for illustrative purposes only and may be subject to change.
The actual number of ports and their locations may vary, depending on the model.
VQP65C-84
Screw Size M8
# of Screws (not included)
4
Hole Depth 15 mm
Hole Pattern 400 mm x 300 mm
Weight w/o Stand
41 . 0 1 lb (18 . 6 kg)
VQP75C-84
M8
4
15 mm
400 mm x 300 mm
58 .25 lb (26 . 4 2 kg)
