Preface
This manual describes how to install and use the provided eight-
port Fast Ethernet Switch, which features that 10/100BASE-TX
ports automatically sense the presence of 100Mbps or 10Mbps
Ethernet networks. 100BASE-FX Multi-mode and Single-mode
fiber ports are also available for this product series.
To get the most out of this manual, you should have an
understanding of networking concepts such as bridging, IEEE
802.3 Ethernet and 100BASE-TX/FX Fast Ethernet, and local
area networks (LANs).
For more information about these topics, please refer to the
Appendix.
Fast EthernetSwitch
User's Guide
Fast Ethernet Switch
1
Advertisement
Table of Contents
Related Manuals for TRENDnet TE100-S86FX
Summary of Contents for TRENDnet TE100-S86FX
-
Page 1: Preface
Preface This manual describes how to install and use the provided eight- port Fast Ethernet Switch, which features that 10/100BASE-TX ports automatically sense the presence of 100Mbps or 10Mbps Ethernet networks. 100BASE-FX Multi-mode and Single-mode fiber ports are also available for this product series. -
Page 2: Table Of Contents
Eight Ports Ethernet Switch ...5 Product Features...7 Packing List...7 Front Panel ...8 Ports ...8 LEDs...10 Installation... 14 Selecting a Site for the Switch ...14 Connecting to Power...15 Connecting to Your Network...16 Specifications ... 17 Appendix A - Connector Pinouts ... 18 – Appendix B Introduction to LAN &... -
Page 3: Chapter Overview
A general overview of switching benefits and the features of the Switch this manual accompanied with. Installation Everything you need to know to install and configure the Switch with your network. Specifications The Switch ’ s specifications at a glance. -
Page 4: Introduction
Fast Ethernet as demands emerge. It also provides a low cost and flexible bandwidth solution directly to local workgroups where the majority of work is generated, reducing the need for expensive network equipment. Fast Ethernet Switch Fast Ethernet Switch ’ s existing... -
Page 5: Eight Ports Ethernet Switch
The eight-port Fast Ethernet switch offered here adds 100Mbps switching performance in a cost-effective desktop package. The Switch has RJ-45 ports, each a 10/100 port capable of autosensing both speed and half/full duplex mode. With the demand for fiber, this eight-port switch provides multi- mode fiber ports. - Page 6 Fast Ethernet Switch existing network with standard Ethernet applications, internetworking systems and client-side adapters to minimize migration costs. Fast Ethernet Switch User’s Guide...
-
Page 7: Product Features
Comprehensive array of LED indicators that communicate the status of the switch and troubleshooting information. Packing List When you unpack the switch, you should find the items listed below. Please inspect the contents, and report any apparent damage or missing items immediately to your authorized reseller. -
Page 8: Front Panel
Front Panel The front panel of the switch has eight ports and an array of LED indicators to provide you with instant feedback on the status of the switch. Figure 1: Front Panel Ports The TX ports of the switch automatically senses and adapts itself to the presence of both 10BASE-T and 100BASE-TX network standards. - Page 9 100 meters with Category 3, 4, or 5 STP/UTP cable. As for the length of FX fiber link between a switch and Data Terminal Equipment, FX is capable to span at least 2 Kilometers using 62.5/125-micron fiber-optic cable in full-duplex mode and 412 meters in half-duplex mode.
-
Page 10: Leds
The LED flashes when the port is transmitting or receiving data. 100: The middle LED comes on whenever the switch detects that the corresponding port is connected to a 100BASE-TX segment. Fast Ethernet Switch Fast Ethernet Switch... - Page 11 This LED comes on when the switch is connected to a power supply and turned on. Auto MDIX If connecting to an uplink port of a hub or another switch, any of the switch ’ s RJ-45 ports can be used. Fast EthernetSwitch User’s Guide...
-
Page 12: Activity Status
The LED flashes when the switch detects packet collisions on the port. Power This LED comes on when the switch is connected to a power supply and turned on. Activity Status TX: Transmit Data... -
Page 13: Dip Switch
100BASE-FX ports (Default setting). Half-Duplex: Toggle down to enable Half-Duplex mode for 100BASE-FX ports. There is no auto MDIX for fiber 100BASE-FX ports; thus the auto MDIX status does not apply to 100BASE-FX ports. Fast EthernetSwitch User’s Guide Fast Ethernet Switch... -
Page 14: Installation
(3V/M) field strength. Make sure that the switch receives adequate ventilation. Do not block the ventilation holes on the sides of the switch or the fan exhaust port on the rear of the switch. The power outlet should be within 1.8meter (6 feet) of the switch. -
Page 15: Connecting To Power
Connecting to Power Connect the supplied AC power cord to the receptacle on the back of the switch, and then plug the cord into a standard AC outlet with a voltage range from 100 to 250 VAC. Turn the Ethernet switch on by flipping the ON/OFF switch on the rear of the unit to the I (ON) position. -
Page 16: Connecting To Your Network
10/100BASE-TX ports Connect cables to computers or network segments into the RJ- 45 ports on the front of this switch. It does not matter which port you select. All the non-fiber ports support 10BASE-T or 100BASE-TX with full- or half-duplex. -
Page 17: Specifications
32 ~ 104 degrees F (0 ~ 40 degrees C) Temperature Humidity 10 ~ 90%, non-condensing Altitude 10,000 ft (3048 m) Emissions FCC part 15 Class A, CISPR Class A, Safety Fast EthernetSwitch User’s Guide Fast Ethernet Switch 2.8kg (6.2lb) 12 W VCCI-I CE Mark... -
Page 18: Appendix A - Connector Pinouts
Appendix A - Connector Pinouts Figure 4: RJ-45 Connector and Cable Pins The following table lists the pinout of the switch ’ s 10/100BASE-T/TX ports. Regular Ports Input Receive Data + Input Receive Data - Output Transmit Data + Output Transmit Data -... -
Page 19: Appendix B - Introduction To Lan & Ethernet
At times, multiple LANs ’ that are geographically dispersed may need to connect together and become so called Wide Area Network (WAN). Fast EthernetSwitch User’s Guide Fast Ethernet Switch... - Page 20 10Base-T technology to 100 Base-TX. It requires only minimal changes with existing cabling infrastructure. Fast Ethernet and its successors have been said to be the most cost effective and high-performance networking solutions of the future. Fast Ethernet Switch Fast Ethernet Switch User’s Guide...
- Page 21 Hub, also called repeater, only allows users to share Ethernet. Individuals of a shared network can only get a percentage of the available network bandwidth, therefore, a network of repeaters also named Fast EthernetSwitch User’s Guide Fast Ethernet Switch Shared Ethernet “ ”...
- Page 22 Switches The function of a switch is to connect separate networks together. A Switch maps the Ethernet addresses of the nodes residing on each network segment and then allows only the necessary traffic to pass through. When a packet is received by the...
