HSLG OPERATOR INSTALLATION GUIDE
MODEL
REF
NO.
PART NO.
DESCRIPTION
2110-240
Intermediate Shaft Assembly
10
2100-765
Pulley Shaft
14
2200-213
Sprocket, 41-B-9, 5/8" bore
9
2200-309
Double Pulley, 7"
11
2200-233
Set Collar Set, 5/8"
92
2200-215
Precision Bearing, 5/8"
72
2200-333
Key, 3/16" x 1 1/2"
71
2100-1750
Key, 3/16" x 1 1/4"
12
2100-547
Brake Disc
2110-274
Clutch Shaft Assembly
30
2100-1008
Clutch Shaft
28
2200-294
Sprocket, 41-A-36, 1" bore
31
2100-669
Clutch Hub (pinned)
78
2100-1007
Clutch Hub (keyed)
79
2100-564
Clutch Facing
32
2200-306
Clutch Spring
33
2400-061
Hex Nut, 5/8"-18
89
2400-062
Jam Nut, 5/8"-18
81
2400-187
Thrust Washer, 1" x 1/8"
2400-088
Roll Pin, 3/16" x 1 3/8"
27
2200-292
Sprocket, 41-B-12, 5/8" bore
2200-215
Precision Bearing, 5/8"
11
2200-233
Set Collar, 5/8"
70
2400-238
Key, 3/16" x 1 1/4"
82
2400-273
Key, 3/16" x 1/4"
2110-236
Output Shaft Assembly
15
2100-917
Output Shaft, 1"
20
2220-022
Sprocket, 41-A-24 with Bearing
93
2200-119
Bearing only for 41-A-24 Sprocket
21
2110-131
Shifter Block with Pins
25
2200-274
Pillow Block Bearing, 1"
97
2100-1737
Pillow Block Retaining Plate
37
2200-014
Set Collar, 1" x 3/8" LTB
26
2200-091
Set Collar, 1" x 5/8" LTB
73
2400-201
Key, 1/4" x 1 1/2"
16
2200-968
Sprocket, 40-B-22, 1" bore
2400-026
Spring Pin, 3/16" x 1"
(Predrilled for Pillow Block)
18
2110-700
Idler Assembly
6
2520-173R
Rotary Limit Box Assembly
2500-764
Limit Switch
2100-057
Standard Limit Shaft
2200-030
Limit Nut
2100-261
Detent Plate
2110-162
Limit Box Enclosure with Cover
2100-756
Limit Box Cover only
2200-029
Flange Bearing, 1/2" ID
2200-193
E-Ring, 1/2"
2400-203
Spring Washer, 1/2"
7
2200-008
Limit Drive Sprocket, 48-B-10, 1/2" bore
For Drives up to 30 feet wide:
2200-008
Limit Box Sprocket, 48-B-10, 1/2" bore
2200-654
#48 Chain, per foot, 27 Links required
For Drives from 31 to 45 feet wide:
2200-041
Limit Box Sprocket, 48-B-15, 1/2" bore
2200-654
#48 Chain, per foot, 29 Links required
For Drives over 45 feet wide:
2200-276
Limit Box Sprocket, 48-B-20, 1/2" bore
2200-654
#48 Chain, per foot, 30 Links required
34
2200-202
#40 Chain, per foot
36
2400-038
U-Bolt, 4 5/8"
2510-064 Three-Button Station with Lead
Wires
102
2100-1756
Control Box Mounting Plate
103
2100-1781
Accessory Shelf for Single Phase
Models only
HSLG
MECHANICAL PARTS LIST
- 26 -
REF
NO.
PART NO.
DESCRIPTION
Motors
95
2500-2307
1/2 HP, 115V, 1 Phase
2500-2308
1/2 HP, 208/230V, 1 Phase
2500-2309
3/4 HP, 115V, 1 Phase
2500-2310
3/4 HP, 208/230V, 1 Phase
2500-2311
1 HP, 115V, 1 Phase
2500-2312
1 HP, 208/230V, 1 Phase
2500-2313
1/2 HP, 208/230/460V, 3 Phase
2500-2314
3/4 HP, 208/230/460V, 3 Phase
2500-2315
1 HP, 208/230/460V, 3 Phase
Capacitors
2500-2336
Capacitor for 2500-2307 Motor
2500-2337
Capacitor for 2500-2308 Motor
2500-1926
Capacitor #1 for 2500-2309 Motor
2500-1930
Capacitor #2 for 2500-2309 Motor
2500-1931
Capacitor for 2500-2310 Motor
2500-2338
Capacitor for 2500-2311 Motor
2500-1932
Capacitor for 2500-2312 Motor
Magnetic Brakes (includes 41, 42, 44, 45 and 46)
40
2510-398
115V
2510-399
230V
2510-400
460V
41
2220-983
Brake and Puck Assembly
42
2500-177
Brake Solenoid, 230 VAC
2500-178
Brake Solenoid, 115 VAC
2500-1351
Brake Solenoid, 460 VAC
44
2200-243
Brake Spring (short)
46
2100-548
Brake Rod
45
2100-541
Brake Plate
13
2100-2091
Bracket for Brake
1
2120-359-BT
Enclosure Assembly Complete with Door
2120-360-BT
Door Assembly only
2300-716
Stop/Reset Button Cover
2110-643
Lock Assembly with Keys
2200-540
Replacement Key
53
2110-234
Rail Assembly
3
2100-573
Spacer Plate
94
2200-207
Double Pulley, 2"
29
2400-149
Chain, #41, 30 Links
22
2120-132
Shifter Lever
23
2100-910
Locking Disconnect Lever
24
2200-291
Disconnect Spring
19
2100-657-BT
Rain Cover
75
2400-088
Roll Pin
87
2100-2007
Gate Bracket
88
2400-170
U-Bolt, 3"
84
2100-258
Chain Tension Bolt, 1/2"
85
2200-306
Clutch/Chain Tension Spring
86
2400-090
Hex Nut, 1/2"-13 (4)
2400-045
Flat Washer, 1/2"
2500-867
Alarm, 24VAC
5
2200-234
V-Belt, 28"
2100-553
Bearing Spacer
90
2200-150
#41 Chain, per foot (20 links required)
76
2200-027
#41 Master Link
2100-656-BT
Side Plate, 1/2"
2100-059-BT
Side Plate, 3/16"
96
2200-006
#40 Master Link
8
2200-654
#48 Chain, per foot (27 links required)
77
2200-010
#48 Master Link
91
2400-422
5/16-18 U-Nut (4)
100
2510-248
Stop/Reset Button and Bracket Assembly
2100-1760
Stop/Reset Button Mounting Bracket
2500-1495
Stop/Reset Button
101
2510-251-D
Power On/Off Disconnect Assembly
with Receptacles (115V Models only)
2500-1956
115VAC Duplex Receptacles only
2500-1957
115VAC Switch only
2510-252-D
Power On/Off Disconnect Assembly
for 230VAC Models
2500-2205
230VAC Switch only
101
2510-294
Power On/Off Disconnect Assembly
for 3 Phase Operators
2500-034
Power Switch only
