Thru-the-Wall
Room Air Conditioner
with optional Electric Heat
Thank you for selecting Soleus Air.
To ensure proper operation, please read this manual & keep it for future reference.
Model :
KTW-08/10/12/12H
Installation Instructions
and Owner's Manual
This manual must be left with the owner
of the equipment.
© 2008 Soleus Air International
Advertisement
Table of Contents
Related Manuals for Soleus Air KTW-08
Summary of Contents for Soleus Air KTW-08
-
Page 1: Installation Instructions
Thru-the-Wall Room Air Conditioner with optional Electric Heat Thank you for selecting Soleus Air. To ensure proper operation, please read this manual & keep it for future reference. Installation Instructions and Owner’s Manual This manual must be left with the owner... -
Page 3: Table Of Contents
Unpacking The Unit ... 1 Operating Instructions ... 1 Installation Instructions ..2 Wiring ..5 Air Conditioner Features... 6 Additional Things You Should Know..9 Normal Operating Sounds and Conditions ... Obtaining Service ... 1 ... 1 Spec Data Warranty... -
Page 4: Important Note To The Owner
IMPORTANT NOTE TO THE OWNER This equipment is to be serviced by professionally trained personnel only. If this equipment is improperly installed, adjusted or altered by an unqualified person, a safety hazard may result. IMPORTANT NOTE TO THE SERVICER Read this manual and familiarize yourself with the specific items which must be adhered to before attempting to service this unit. -
Page 5: Installation Instructions
WARNING To prevent electrical shock, property damage, personal injury, or death, do not remove grounding prong from plug. Follow all operating instructions. Installation Instructions To ensure that the unit operates safely and efficiently, it must be installed, operated, and maintained according to these installation and operating instructions and all local codes and ordinances, or, in their absence, with the latest edition of the National Electrical Code. - Page 6 Figure 3 3. Remove shipping pads inside air conditioner next to compressor. (See Figure B.) Figure B 4. Carefully slide the chassis into the sleeve. Ensure that the ground wire is not pinched or in the path of the condenser fan.
- Page 7 To replace front grille: Hook the tabs on the front grille even with the tabs on the case and snap into place. Replace the screws and filter. Refer to Page 4, Figure A. VENT CONTROL AND AIR DIRECTION (See Figure E) The vent control is located behind the front grille on the right side of the air discharge area.
-
Page 8: Wiring
If air is obstructed and/or deflected back into the unit, the air conditioner’s compressor may cycle on and off rapidly. This could cause damage to the compressor. -
Page 9: Air Conditioner Features
Air Conditioner Features LOWERS TEMPERATURE OR TIME RAISES TEMPERATURE OR TIME SETS FAN SPEED SETS MODE LOWERS TEMPERATURE OR TIME RAISES TEMPERATURE OR TIME SETS FAN SPEED SETS MODE LOWERS TEMPERATURE OR TIME NOTE: The remote control will work normally after reset 5 senconds. -
Page 10: To Change Temperature Setting
Air Conditioner Features TO TURN UNIT ON: TO CHANGE TEMPERATURE SETTING: Note: Tap or hold either up(^) or down(v) button until the desired temperature is seen on display. This temperature will be automatically maintained anywhere between 60F (16 C) and 90F (32 C) for cooling mode. The Temperature will be automatically maintained anywhere between 55F (13 C) and 80F (27 C) for heating mode. - Page 11 Air Conditioner Features (continued) TO OPERATE ON FAN ONLY: Note: Use this function only when cooling is not desired, such as for room air circulation. You can choose any fan speed you prefer,EXCEPT AUTO FAN. During this function, the display will show the actual current temperature, not the set temperature as in the cooling mode.
-
Page 12: Additional Things You Should Know
Air Conditioner Features (continued) HEATING FEATURE (on some models) Note: This feature can be used with any combination of FAN Speeds, Timer, or Sleep Modes. When in the “Heat” Mode, the fan will run continuously while heat is needed. The temperature will automatically be maintained anywhere between 55°F (13°C) and 80°F (27°C). -
Page 13: Normal Operating Sounds And Conditions
OUTDOOR COIL CLEANING The coils on the outdoor side of the air conditioner should be checked regularly. For cleaning outside coil, remove the 6 screws that mount the condenser coil top cover to condenser shroud. - Page 14 Rated Current Cooling (Amperage) Rated Current Heating (Amperate) EER/C.O.P Noise Level dB (A) (H/M/L) Design Pressure (PSIG) (H/L) Dimension (W*H*D) Packing Dimension (W*H*D) Net/Gross Weight (Lb) Refrigerant Charge (Oz) KTW-08 KTW-10 1/115V/60Hz 1/115V/60Hz 8000 10000 58/56/54 58/56/54 400 psi/170psi 400 psi/170psi 25.98x15.62x16.88...
-
Page 15: Warranty
This warranty does not apply to repairs or replacements necessitated by any cause beyond the control of Soleus International including, but not limited to, any malfunction, defect or failure caused by or resulting from unauthorized service or parts, improper maintenance, operation contrary to furnished instructions, shipping or transit accidents, modification or repair by the user, abuse, misuse, neglect, accident, incorrect power line voltage, fire, flood or other Acts of God, or normal wear and tear.
