- Page 1 Quick-Charge Battery Charger TLG 1750 B3 QUICK-CHARGE BATTERY CHARGER Operating instructions KOMPERNASS GMBH BURGSTRASSE 21 · D-44867 BOCHUM www.kompernass.com ID-Nr.: TLG 1750 B3-09/11-V2 IAN: 71662...
- Page 2 TLG 1750 B3...
-
Page 3: Table Of Contents
Content Page Intended Use Items supplied Description of the appliance Technical data Safety information Commissioning Charging batteries Average charging times Charging the USB device Troubleshooting Cleaning Disposal Warranty and Service Importer Read the operating instructions carefully before using the appliance for the first time and preserve this booklet for later reference. -
Page 4: Intended Use
QUICK-CHARGE BATTERY CHARGER Intended Use The Rapid Battery Charger is intended exclusively for... • charging Ni-Cd and Ni-MH rechargeable batte- ries of the sizes AA/Mignon and AAA/Micro • for the charging of battery-operated devices with a USB interface, such as MP3 Player •... -
Page 5: Items Supplied
Items supplied • Rapid Battery Charger • Power adapter • Vehicle adapter • Storage bag (not illustrated) • This operating manual Description of the appliance AC adapter, car adapter connection Control lamps Selector switch Ni-MH/Ni-Cd USB ports Charging slots Power adapter Vehicle adapter - 3 -... -
Page 6: Technical Data
Technical data Power adapter Input: 100 - 240 V ~ 60/50 Hz, 420 mA Output: 12 V 1800 mA, 21.6 VA Charging component Input: 12 -13.8 V 1800 mA Maximum charging current: AA / Mignon batteries: 1750 mA Ni-MH; 700 mA Ni-Cd AAA / Micro batteries: 750 mA Ni-MH;... -
Page 7: Safety Information
Safety information • This device has not been designed for use by people (including children) with restricted physical, sensory or intellectual abilities or lack of experience and/or knowledge, unless they are supervised by a responsible person (for their own safety) or have received instructions on how to use the device. - Page 8 Risk of electric shock! • Only connect the device to a properly installed and earthed mains socket. The mains voltage must agree with that stated on the device’s specification plate. • Damaged adapters or mains cables should be exchanged immediately by an authorised technician or the Customer Service in order to avoid risks.
- Page 9 • You must not open or repair the device’s housing. This can be dangerous and renders the warranty null and void. • Protect the device from moisture and sprayed water. Therefore do not place any objects filled with water (e.g. vases) on or near the device. Risk of fire! •...
- Page 10 • Due to the charging current, only batteries with appropriate capacities may be charged: Ni-MH batteries: - AA min. 1750 mAh/max. 2700 mAh - AAA min. 750 mAh/max. 1000 mAh Ni-Cd batteries: - AA min. 700 mAh/max. 1000 mAh - AAA min. 300 mAh/max. 600 mAh •...
- Page 11 • Use the Rapid Battery Charger exclusively with the supplied power adapter resp. vehicle-adapter. Do not use the power adapter and the vehicle- adapter with appliances other than the Rapid Battery Charger. Should you do so, the Rapid Battery Charger, vehicle-adapter, power adapter, batteries and the other appliance could be irreparably damaged.
- Page 12 • Always store batteries out of the reach of children! There is a danger that children could swallow batteries! Due to the poisonous content of batteries there is a danger to life! • When charging batteries never leave the Universal Battery Charger unsupervised. •...
- Page 13 Thunder storms! Devices connected to mains power can be damaged during a thunder storm. If there is a thunder storm, always remove the mains plug from the socket. For damage caused by ... • opening the housings of the Rapid Battery Charger, power adapter or vehicle-adapter •...
- Page 14 Notes on handling batteries The device uses batteries. Please note the following on handling batteries: Risk of explosion! Do not throw batteries into a fire. Do not recharge batteries. • Never open, solder or weld batteries. There is a risk of explosion and injury! •...
-
Page 15: Commissioning
Commissioning Stationary operation • Remove all components – Rapid Battery Charger, power adapter , vehicle-adapter batteries – from the packaging. • Before taking the Rapid Battery Charger into use, check that all items are complete/available and free of visible damage. •... - Page 16 Mobile operation With the supplied vehicle-adapter you can also connect the Rapid Battery Charger to the 12-V cigar lighter socket of a vehicle or into the 12-V on-board power supply socket of a vehicle. Thereby, you simply use the vehicle-adapter instead of the power adapter Warning!
- Page 17 Note: Also ensure that all possible soiling (e.g. remains of ash) is removed from the inside of the cigar lighter socket! Otherwise, it could lead to a malfunction in the operation of the Rapid Battery Charger with the vehicle-adapter • Insert the low-tension plug of the vehicle-adapter into the power adapter connection of the Rapid Battery Charger.
- Page 18 Note: It is possible that the cigar-lighter only functions with a switched-on vehicle ignition. If you are unsure, consult the vehicle handbook. Caution! For vehicles in which the cigar lighter resp. onboard power sockets also function with a switched-off vehicle ignition: Only use the Rapid Battery Charger with the engine running.
-
Page 19: Charging Batteries
Charging batteries Danger! Charge exclusively rapid rechargable batteries of the types "Ni-Cd" and "Ni-MH". NEVER recharge batteries of other types or non-rechargable batteries. These are not suit- able for recharging. This could irreparably damage the Rapid Battery Charger and the inserted batteries. - Page 20 • Place the selector switch into the position Ni-MH if you want to charge Ni-MH batteries. • Place the selector switch into the position Ni-Cd if you want to charge Ni-Cd batteries. • Insert the batteries into the charging slots Note: This appliance is equipped with an individual shaft monitor, which allows it to charge 1 to 4...
- Page 21 The various displays have the following meanings: • The control lamp blinks red: - Defective batteries or non-rechargeable batteries have been identified. Remove the inserted batteries from the Rapid Battery Charger. • The control lamp does not glow: - The batteries have not been inserted correctly into the charging slots •...
-
Page 22: Average Charging Times
• Unplug the AC adapter from the mains power socket or the car adapter from the cigar lighter socket and allow the batteries to cool down. Afterwards you can remove the charged batteries from the Rapid Battery Charger. Average charging times Depending on the type, age and remaining charge in the batteries, the charging process can take various lengths of time. - Page 23 Type Typ AAA Capacity Ni-MH Ni-Cd 900 mAh 100 min. 300 mAh 90 min. Timer Control In addition, this battery charger has a timer control which, after 2 hours, automatically switches it over to the maintenance charge. This serves as an additional protection against overcharging should the charge completion identifier not react, possibly due to a defective battery.
-
Page 24: Charging The Usb Device
Charging the USB device Warning! Check to ensure that the current consumption of the USB device is not higher than 500 mA. Further information is provided in the operating manual of your USB device. • Insert the USB connector of the USB device into the USB port of the charger. -
Page 25: Troubleshooting
Troubleshooting The Rapid Battery Charger displays no functions With mains power operation: • Check to see if the low-tension plug on the cable of the power adapter is correctly inserted into the power adapter connection • Check to see if the power socket into which the power adapter has been inserted is "live". - Page 26 The inserted batteries are not being charged: • Check that the batteries are being inserted in accord with their polarity. • Check to see if you have inserted batteries suit- able for charging into the Rapid Battery Charger. Exclusively suitable for recharging are Ni-Cd and Ni-MH batteries with the sizes AA/Mignon and AAA/Micro and designated as suitable for rapid charging.
-
Page 27: Cleaning
Cleaning Risk of injury from electric shock: • Never immerse the device’s parts into water or other liquids! • Do not allow liquid to penetrate the housing. Cleaning the housing: Attention: Never use petroleum, solvents or aggressive cleaning agents, they may damage the hou- sing surfaces! •... -
Page 28: Disposal
Disposal Never dispose of the device in the normal household rubbish. Dispose of the device using an approved disposal company or using local disposal facilities. This product is subject to European Directive 2002/96/EC. Please follow the currently valid regulations. In case of doubt, contact your disposal facilities. - Page 29 Disposal of batteries! Batteries must not be disposed of in the household waste. Every consumer is legally obliged to dispose of batteries at a collection site of his community / city district or at a retail store. This obligation is intended to ensure that batteries are disposed of in an environmentally safe fashion.
-
Page 30: Warranty And Service
Warranty and Service The warranty for this appliance is for 3 years from the date of purchase. The appliance has been manufactured with care and meticulously examined before delivery. Please retain your receipt as proof of purchase. In the event of a warranty claim, please make contact by telephone with our Service Depart- ment. - Page 31 The warranty period will not be extended by repairs made under warranty. This applies also to replaced and repaired parts. Any damage and defects extant on purchase must be reported immediately after un- packing the appliance, at the latest, two days after the purchase date.
-
Page 32: Importer
Importer KOMPERNASS GMBH BURGSTRASSE 21 44867 BOCHUM, GERMANY www.kompernass.com - 30 -...
