- Page 1 ® CAUTION! – This product User’ s Guide is not intended for medical use or use on humans Shop online at omega.com ® e-mail: info@omega.com For latest product manuals: omegamanual.info OS130A SERIES OS136A Model Miniature Non-Contact Infrared Temperature Sensor/Transmitter...
- Page 2 Approach Directives. OMEGA will add the CE mark to every appropriate device upon certification. The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.
-
Page 3: Table Of Contents
OS136A Model Miniature Non-Contact Infrared Temperature Sensor/Transmitter Table of Contents Page Section Caution and Safety Information ..............iii Safety Warnings and IEC Symbols .............. iii Section 1 Introduction ..................1 Section 2 Installation ..................1 2.1 Unpacking .................. 1 2.2 Electrical Connection ..............2 Section 3 Operation .................. - Page 4 OS136A Model Miniature Non-Contact Infrared Temperature Sensor/Transmitter List of Figures Figure Description Page General Wiring Diagram ..............2 Optical Field of View ..............3 Mounting Bracket, OS100-MB ............4 Air Purge Collar, OS100-AP ............4 Stainless Steel Housing ..............5 Water/Air Cool Jacket, OS136-WC ..........
-
Page 5: Caution And Safety Information
OS136A Model Miniature Non-Contact Infrared Temperature Sensor/Transmitter CAUTION & SAFETY INFORMATION If the equipment is used in a manner not specified in this manual, the protection provided by the equipment may be impaired. The Installation category is one (1). There is no user replaceable fuse in this product. The output terminals of this product are for use with equipment (Digital meters, chart recorders, etc.) which have no accessible live parts. -
Page 6: Section 1 Introduction
1-800-622-2378 or 203-359-2208. We can also be reached on the internet at omega.com email: cservice@omega.com When you receive the shipment, inspect the container and the equipment for any signs of damage. Note any evidence of rough handling in transit. Immediately report any damage to the shipping agent. -
Page 7: Electrical Connection
Installation The following describes the ordering information: OS136 – * – ** , where - * means: -1 : -18 to 204ºC (0 to 400ºF) Temperature range -2 : 149 to 538ºC (300 to 1000ºF) Temperature range - ** means: -MA : 4 to 20 mA current output -V1 : 0 to 5 Vdc output -V2 : 0 to 10 Vdc output... -
Page 8: Section 3 Operation
Operation SECTION 3 – OPERATION 3.1 – Measuring Temperature Before starting to measure temperature, make sure the following check list is met: The Power and output connections are made (Fig 2-1) The target is larger than the optical field of view of the transmitter (Fig 3-1) Use the Laser Sighting accessory (Optional), to align the transmitter to the center of the target area. -
Page 9: Atmospheric Quality
Operation 3.3 - Atmospheric Quality Environments with smoke , dust, and fume dirty up the optical lens, and cause erroneous temperature readings. To keep the surface of the optical lens clean, the air purge collar accessory is recommended, OS136-AP (Fig 3-3). The following figures show the Mounting Bracket (OS136-MB), Air Purge Collar (OS136-AP), Stainless Steel Housing, Water/Air Cool Jacket (OS136-WC), and the Water/Air Cool Jacket Assembly. -
Page 10: Stainless Steel Housing
Operation 3/4-16 UNF LIGHT HEX KNURL 4.76 (3/16) WIDE 33.27 (1.31) 88.9 (3.5) 1.83m (6ft) DIMENSIONS mm (in) Figure 3-4. Stainless Steel Housing 1/8 NPT COMPRESSION 7.62 FITTING, 2 PLCS. (0.30) INLET OUTLET 85.09 (3.35) 3/4-16 UNF-2B 3/4-16 UNF Dimensions mm (in.) Figure 3-5. -
Page 11: Section 4 Laser Sight Accessory
Laser Sight Accessory SECTION 4 - LASER SIGHT ACCESSORY 4.1 – Warning and Caution CAUTION: You may receive harmful laser radiation exposure if you do not adhere to the warnings listed below: • USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HERE MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. -
Page 12: Laser Sighting Accessory, Os100-Ls
Laser Sight Accessory LASER WARNING LABEL DC POWER JACK OS136 LED LASER POWER LASER INDICATOR BEAM (0.75) ON/OFF 50.8 SWITCH (2.0) POWER CABLE BATTERY PACK Dimensions mm (in.) POWER SUPPLY Figure 4-1. Laser Sighting Accessory, OS100-LS ® LASER RADIATION DO NOT STARE INTO BEAM OR VIEW DIRECTLY WITH CAUTION OPTICAL INSTRUMENTS. -
Page 13: Section 5 Specifications
Specifications SECTION 5 – SPECIFICATIONS 5.1 - General Temperature Range: OS136A-1 -18 to 204ºC (0 to 400ºF) OS136A-2 149 to 538ºC (300 to 1000ºF) Accuracy: @22ºC (72ºF) ambient OS136A-1 3% of Rdg or 4.4ºC (8ºF) whichever is greater OS136A-2 3% of Rdg or 5.5ºC (10ºF) whichever is greater From 185 to 510ºC (365 to 950ºF) Repeatability: 1% of Rdg. -
Page 14: Laser Sight Accessory
Specifications 5.2 - Laser Sight Accessory Laser Wavelength (Color): 630 - 670 nm (Red) Operating Distance: Up to 9.1 m (30 ft.) Max. Laser Power Output: Less than 1 mW @ 22ºC ambient Class 2, EN60825-1/11.2001 European Classification: FDA Classification: Class II Laser Product. - Page 15 Department will issue an Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY does not apply to defects resulting from any action of the purchaser, including but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair, or unauthorized modification.
