- Page 1 USER MANUAL Drying cabinet DC7784HP.S.UK Read the user manual before using the machine...
- Page 2 ASKO offers you all these features. When you buy an ASKO product you can be sure that the inside is just as good as the outside and that the ethics and morality that go into building this product are just as high as the quality and function you are getting.
-
Page 3: Table Of Contents
CONTENTS THIS USER MANUAL START-UP IMPORTANT SAFETY INFORMATION 5 OPERATION FOR A GOOD ENVIRONMENT User tips Drying programmes Packaging materials Selection of drying programme Management of end-of-life drying cabinet Child lock DESCRIPTION OF THE DRYING CABINET 7 Starting drying programme Air fl... -
Page 4: This User Manual
THIS USER MANUAL The contents of this user manual describe function, operation and optimisation of drying programmes, as well as instructions for installation and maintenance. Alongside the User Manual there is a Service Manual. -
Page 5: Important Safety Information
If the power cord is damaged, it must be immediately replaced, and this must be done only by the manufacturer, the manufacturer's service agent or similarly qualifi ed persons in order to prevent danger. Follow ASKO instructions in repair and replacement of parts. -
Page 6: For A Good Environment
FOR A GOOD ENVIRONMENT PACKAGING MATERIALS MANAGEMENT OF END-OF- LIFE DRYING CABINET The packaging that protects the drying cabinet against damage in transit has been chosen When the drying cabinet has reached the end with concern for the environment in mind and is of its useful life, it must be taken to a recycling therefore recyclable. -
Page 7: Description Of The Drying Cabinet
DESCRIPTION OF THE DRYING CABINET The ASKO DC7784HP drying cabinet operate No exhaust-air connection is required. The according to the heat pump principle with a moisture condenses during the process, dehumidifi er instead of a conventional hot- and the water that is formed is conveyed to a air unit. -
Page 8: Air Flow In The Cabinet
AIR FLOW IN THE CABINET Air intake in 6 rows of holes Cleaning fi lter below the shoe rack Air return after dehumidifi cation Enters a duct in the back of the drying cabinet Dehumidifi er _____________________________ Make sure that shoes and similar items do not block the airfl... -
Page 9: Control Panel
CONTROL PANEL DISPLAY ON / OFF The display has two rows with 6 characters on each row. During the drying process the selected drying programme and a OK/START/STOP rolling bar indicating that the process is in progress are shown. UP ARROW DOWN ARROW FUNCTION OF THE BUTTON ON-OFF... -
Page 10: Language Setting
CONTROL PANEL LANGUAGE SETTING The following languages can be handled: English, Swedish, Norwegian, Danish, Finnish, Italian, French, German, Spanish, Portuguese and Dutch. Make sure that the main ON/OFF switch Step through to the desired language with the UP ARROW or DOWN ARROW on the drying cabinet is off... -
Page 11: Placement
PLACEMENT There must be an earthed socket within a distance of 2 m from the lower part of the drying cabinet. The drying cabinet has a 2 m long earthed lead with a plug connected at the bottom. The power socket should be located such that there is no need for an extension cable. -
Page 12: Unpacking
UNPACKING _________________________________ ____________________________________ Check that all transport securing devices Check to make sure that the product has have been removed before connecting not been damaged in transit. Any damage the drying cabinet. incurred in transit must be reported to the _________________________________ dealer within 7 days. -
Page 13: Rehanging Of Door
REHANGING OF DOOR The pictures below illustrate rehanging from right-hung door to left-hung. Rehanging kit For rehanging, a rehanging kit must be ordered from the supplier of the cabinet. The kit consists of a new upper hinge, as the left and right hinges are not interchangeable. The kit also includes a control cable for fi... - Page 14 Reconnection in the door Lay the door down with the in- side facing up on a non-dam- aging surface. Detach the inner plate (5) with magnetic strips, glove hangers and, if applicable, door hangers. Screws are beneath the magnetic strips. Move the insulation into posi- tion(6).
- Page 15 Lay the door in position Before laying the door in position, remove the lower hinge with pin and washer and lay it aside. Screw back the fi xing bolts as they contribute to the stability of the cabinet. Screw back Lower the retaining hinge...
- Page 16 Lower hinge mirror- Transfer the hinge to the inverted other side. The hinge must be mirror-inverted and the hinge pin must be un- screwed and refi tted on the other side of the hinge. Make sure that the hinge pin is tightened fi rmly. Transfer the door handle Transfer the handle (9) to the other side.
-
Page 17: Condensation Water
CONDENSATION WATER Condensation water may be removed in two ways, collected in a detachable water tank or via a hose to the fl oor drain. DETACHABLE WATER TANK _____________________________ The water tank is designed to be suffi ciently large for a complete wash by a comfortable margin. -
Page 18: Connection To Floor Drain
CONNECTION TO FLOOR DRAIN The drying cabinet is supplied from the factory with a hose to the detachable water tank. To change to removal of condensation water to the fl oor drain, proceed as follows: Hose to the de- tachable water tank Cabinet viewed from rear Position the drain... -
Page 19: Reconnection To Water Tank
Route the drain hose to the drain. If the drain is higher than the outlet on the cabinet, make sure that the hose runs to the fl oor in an arc and forms a trap. There is otherwise a risk of the condensation water fl owing back to the tray when the pump is not working. -
Page 20: Installation
INSTALLATION POSITIONING/ATTACHMENT ___________________________________ The drying cabinet is intended only for location indoors in a dry place. ¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯ ___________________________________ Fixing bracket The drying cabinet must not be placed in an environment in which high-pressure water is used for cleaning. ¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯ LEVELLING The drying cabinet must be level on Top of drying a fl... -
Page 21: Electrical Connection
ELECTRICAL CONNECTION The drying cabinet must be connected to a 230 V single-phase 50 Hz and protectively earthed wall socket. The drying cabinet is supplied ready for connection with a cable and an earthed plug. ____________________________________ The drying cabinet should be connected to an earthed wall socket using the connecting cable supplied and must not be permanently wired. -
Page 22: Start-Up
START-UP ____________________________ ________________________________ CAUTION Read this User Manual before using the drying Read the safety instructions on page 5 cabinet for the fi rst time. before using the cabinet. ¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯ ___________________________________ Make sure that the cabinet is fi rmly attached to the wall. See page 20. Make sure that no packaging material has been left behind. -
Page 23: Operation
OPERATION There are three sections with hangers in the cabinet. Each section has a number of rails for hanging items to dry. Hang the items in the drying cabinet according to how much space they require - not according to their weight. ... -
Page 24: User Tips
USER TIPS Always following the washing instructions on the item of clothing if present. If a fabric conditioner or anti-static agent is used, follow the manufacturer's instructions for use of this product. Remove washing that it is already dry. This will reduce drying time for remaining washing. _____________________________ ____________________________ CAUTION... -
Page 25: Drying Programmes
DRYING PROGRAMMES The drying cabinet is equipped with two automatic programmes for the drying process: NORMAL DRY EXTRA DRY The programmes automatically close the drying process when the fabrics are dry. SELECTION OF DRYING PROGRAMME NORMA DRY – Used for drying of items of normal thickness. ... -
Page 26: Starting Drying Programme
OPERATION STARTING DRYING PROGRAMME LAST USED DRYING PROGRAMME Press the on/off switch to the “ON” position - Indicated by the display lighting up and showing the last run programme. If you want this, press START/STOP. Or select another drying programme by stepping through with the buttons ARROW UP or ARROW DOWN. -
Page 27: Ending Drying Programme
END OF PROGRAMME When the cool-down period has ended, the drying process is fi nished, and the display shows “end” the text (fl ashing). When the START/STOP button is then pressed, the current programme ends and the display shows the last used programme. _____________________________ ____________________________ In standby mode the display goes off... -
Page 28: Setting Of Drying Programme
SETTING OF DRYING PROGRAMME There are ways of optimising the two automatic programmes of the drying cabinet for best possible results. The setting is adjusted on the control panel for the programme concerned. Adjustments must be made if it is found that the ... -
Page 29: Procedure
PROCEDURE Setting to optimise the drying cabinet's automatic programme is done using the buttons on the control panel when the drying cabinet is in programming mode. PROGRAMMING MODE Make sure that the main ON/OFF switch on the drying cabinet is turned off . The display is unlit. -
Page 30: Parameter List
SETTING OF DRYING PROGRAMME PARAMETER LIST Parameter Name Factory Designates pre-set value value P105 Language 1=Swedish Setting see page 10 P115 Child lock 0 = Child lock OFF On/Off 1 = Child lock ON P2071 Extra dry Control EXTRA DRY drying programme P2072 Normal dry 27... -
Page 31: Care
CARE CLEANING REPLACEMENT PART _____________________________ If the mains lead for any reason is damaged, it must be replaced. A genuine spare part can be obtained from the dealer who supplied the cabinet. Do not use high-pressure cleaning. ____________________________________ _____________________________ ____________________________ Cleaning and maintenance must not be A replacement lead may be installed only by performed by children without supervision. -
Page 32: Service
This information can be found on the drying cabinet located inside the cabinet. Identifi cation plate (inside) ASKO DC7784HP Name of the drying cabinet Article number Serial number (12 digits) The illustration shows the identifi... -
Page 33: Troubleshooting
TROUBLESHOOTING Questions Action The drying 1. Check that the mains lead is connected to a power socket. cabinet is not 2. Check that no fuse has tripped. working. 3. Have you pressed the start button? 4. Is the door closed? 5. - Page 34 Questions Action The display 1. Check that the door closes tightly so that the door switch is activated. shows CLOSE DOOR (Located at the bottom of the cabinet on the cover plate in front of the heat pump unit). 2. If necessary, try to tape the switch in position and check whether the warning on the display disappears.
-
Page 35: List Of Error Codes
LIST OF ERROR CODES Describes relevant error codes for this product. Name Description ERROR 03 Fault on moisture sensor Sensor is outside its measurement range Contact Service. ERROR 04 Max time process Max time for drying process exceeded (pre-set value 240 min can be changed with parameter P 2073). -
Page 36: Technical Data
TECHNICAL DATA Capacity: 5.0 kg laundry (cotton) Dewatering capacity: 22 g/min Electrical supply: Single-phase 220 - 240 V, 50 Hz, 10 A Power: 900 W Capacity of main fan: 945 m³/h (free blow) Capacity of sub-fan: 160 m³/h (free blow) Hanging length: 16 metres Dimensions: DC7784HP:... - Page 37 ENERGY CONSUMPTION AND DRYING TIMES IN DRYING OF SPUN LAUNDRY *) Programme Energy consumption Drying Temp. max kWh/kg laundry time NORMAL DRY 90 min 55 °C EXTRA DRY 120 min 55 °C _______________________________ *) Values may vary depending on: - spin speed - temperature, air humidity in the room - air circulation in the room (supply air, exhaust air) ¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯...
- Page 39 427001114 / 03...
- Page 40 Right to make changes reserved. ASKO DC7784HP UK en (02-19)
