- Page 1 Apeos™ 4570 Apeos 3570 Reference Guide Appendix October 2021 GM1358E1-1 Edition1 FUJIFILM Business Innovation Corp.
- Page 2 Preface A guide describing the emulation mode, direct print, web applications, troubleshooting, etc. This manual may not be edited, modified or copied in whole or part without the written consent of the publisher. Parts of this manual is subject to change without prior notice. ...
- Page 3 Appendix Emulation When using the emulation mode, you can get the print results similar to those of other companies' printers. Overview of Emulation Feature This machine is compatible with following emulation mode. Emulation mode Printer to be emulated ESC/P VP-1000 PC-PR201H PC-PR201H HP-CLJ5500 (color), HP-LJ4200 (black and white)
-
Page 4: Print Function
Print function Emulation mode N Pages Form Barcode ART IV Up to 2048 ESC/P Up to 64 PC-PR201H Up to 64 HP-GL, HP-GL/2 *1 :In case of no storage, there are up to 64. N Pages 2 pages are available. Form You can register standard forms and print the registered forms by synthesizing them into print data. -
Page 5: Emulation Mode
Associated Device Menu Log in to Administrator Mode. Emulation mode [Port Settings] [Allocate Memory] [Delete Form] ART IV ESC/P PC-PR201H HP-GL, HP-GL/2 Port Settings Set in > [Device] > [Network Settings] > [Port Settings]. Enable port (USB/LPD/IPP/Port9100/WSD) Launch the port to be used in the emulation mode. Allocate Memory Set in >... -
Page 6: Printable Area
Store/Delete Programming Store the current Items details in [Custom Settings] and delete stored memory. Default Programming Set the default values. HP-GL, HP-GL/2 Emulation-specific Matters Printable area Margin XR Long side Margin YU (Top right X, Top right Y) Short side (Bottom left X, Bottom left Y) (0,0) Paper size... - Page 7 Margin YU Short side Margin XR (Top right X, Top right Y) Long side (Bottom left X, Bottom left Y) (0,0) Paper size Printable area Paper Paper length Coordinate value (1/7200″) size (1/7200″) Margin Printable area Top right corner Margin direction direction...
-
Page 8: Auto Layout
When the size is A3 and the starting point is the bottom left (16798,11876) Width (16442,11520) Length (0,0) Standard origin (0,0) Paper origin Paper size Paper Hard Clip area （＝ ） Printable area Standard Hard Clip area （＝ ） Standard Printable area of this machine is the Hard Clip area. - Page 9 [Area Determine Mode] [Auto] Selected automatically. The priority order is [PS] -> [IW] -> [IP] -> [Adapted]. [IW] Area specified by the last IW command within the data is the object area. [IP] Area specified by all IP commands is the object area. [Adapted] Object area is determined automatically.
- Page 10 Item combination examples in Auto Layout [Zoom Mode]: [Paper Size], [Zoom]: ON Image is reduced/enlarged within the printed area and printed. Paper size Printable area Object area determined in “Area Judgement Mode” Drawn object area ( = Print area) ...
- Page 11 [Zoom Mode]: [Coordinate Area], [Zoom]: ON Image is reduced/enlarged within the printed area and printed. Paper size Printable area Object area determined in “Area Judgement Mode” Drawn object area ( = Print area) [Zoom Mode]: [Coordinate Area], [Zoom]: OFF Image is printed in the actual size.
- Page 12 If [Zoom Mode] is [Paper Size], the document size is determined based on the drawn object area. If [Zoom Mode] is [Coordinate Area], the document size is determined based on the starting point of the drawn object area. Determination method example If [Auto Layout] = ON, [Original Size] = [Auto Detect], [Zoom Mode] = [Paper Size], [Area Determine Mode] = [IP] and [Paper Margin] = 10 mm, and [Pen Attributes] of [Pen Width] = 0.1 mm IP-8399,-5938,8399,5938;...
- Page 13 How to determine the reduction rate If [Original Size] is [Auto Detect] and [Zoom Mode] is [Paper Size] Reduction rate is determined by the drawn object area and [Paper Size]. Hard Clip area is [Paper]. If Auto Layout is [Auto Layout], the document is placed at the center of the paper. ...
- Page 14 Items Item descriptions are ESC=ESC/P, PC=PC-PR201H, PCL=PCL, HP=HP-GL, and HP-GL/22. Note You can set the items also in Internet Services. Items Item Number Specification value Document [0] : Postcard size [3] : A3 [4] : A4 [5] : A5 [14] : JIS B4 [15] : JIS B5 [21] : 8.5 x 14"...
- Page 15 Items Item Number Specification value Paper size [3] : A3 If “Paper [4] : A4 supply tray” [5] : A5 is “Auto” or [14] : JIS B4 “Tray 5 [15] : JIS B5 (bypass)” [99] : Auto [101] : A size Paper size [3] : A3 If “Paper...
- Page 16 Items Item Number Specification value Depth mode [1] : Grey scale [2] : Black pen Note This setting is valid for black and white printers. Auto Layout [0] : ON [1] : OFF Palette [0] : Command priority [1] : Panel specification Number of [1] to [250] : 1 to 250...
- Page 17 Items Item Number Specification value Paper [0] : No cut sheet feeder (left) position [1] : With cut sheet feeder (center) Note Note This If there is no cut sheet feeder, the number of lines cannot be specified by VFU is fed when FF (page break specified command) is received.
- Page 18 Items Item Number Specification value Kanji font [0] : Mincho [1] : Gothic Note Note This is not reflected These fonts are also applied to 2-byte half width characters. extension [0] : Stroke comman [1] : Mincho d is sent. [2] : Gothic Note These fonts are also applied to 2-byte half width...
- Page 19 Items Item Number Specification value Default font [30] : Albertus Medium [31] : Albertus Extra Bold [32] : Clarendon Condensed [33] : Coronet [34] : Marigold [35] : Arial [36] : Arial Italic [37] : Arial Bold [38] : Arial Bold Italic [39] : Times New [40] : Times New Italic [41] : Times New Bold...
- Page 20 Items Item Number Specification value Default [0] : Roman 8 symbol [1] : ISO 8859-1 Latin 1 [2] : ISO 8859-2 Latin 2 [3] : ISO 8859-9 Latin 5 [4] : ISO 8859-10 Latin 6 [5] : PC-8 [6] : PC-8 DN [7] : PC-775 [8] : PC-850 [9] : PC-852...
- Page 21 Items Item Number Specification value 2 page mode 21 [0] : None [1] : Forward direction [2] : Backward direction Note If horizontal is specified in “Document size”, the result is the same for both “Forward direction” and “Backward direction”. Kanji code [0] : Epson [1] : Toshiba...
- Page 22 Items Item Number Specification value Page length [0] : 11 inches [1] : 12 inches 1 inch [0] : None perforation [1] : Yes skip Note You can have 1 inch between each page. This specification is enabled only if “No cut sheet ...
- Page 23 Items Item Number Specification value Ejection [0] : OFF command (SP) [1] : ON Note (SP0 You can specify the command to indicate the end of drawing. Drawing is ended when the command specified here is received, and paper is ejected. (NR) ...
- Page 24 Items Item Number Specification value Form [0] : None composition [1] to [64] : No.1 to No.64 Note Note This is not The form name displayed even after the form is reflected deleted after specifying the form. In this case, the form is not composed.
- Page 25 Items Item Number Specification value Line end [0] : OFF process [1] : Add LF at the end [2] : Add CR at the beginning [3] : CR-xx Note With “CR-xx”, add LF at the end when CR and add CR ...
-
Page 26: Direct Print
Items Item Number Specification value Pen color Item Number for No.00 is 950. [0] to [255] : 0 to 255 (color) Note This setting is valid for color printers. Pen intensity - Item Number for No.00 is 950. [0] to [100] : 0 to 100 (intensity) Note This setting is valid for black and white printers. - Page 27 Items Items Item Number Specification value DocuWorks Number of [1] to [999] : 1 to 999 outputs Note If printing using lpr commands, the specification of the number of outputs is made with lpr commands. Due to this, this setting will be invalid. 2 sided [0] : None [1] : Long side binding...
-
Page 28: Web Applications
Web Applications This function allows you to access Web servers via networks from the browser included with this machine in order to store or display data. Access an external service and display an external service screen linked with this machine ... - Page 29 Select the server number to register. Enter the server URL and tap on [OK]. Note When connecting by specifying the Web browser version for Web Applications, specify the version between the protocol type (http, https, etc.) and the colon. For example, enter “http-v4:// www.example.com”...
- Page 30 Note Even if you specify [No], user ID and password may be required at the time of access. If [Remote] is set to > [Device] > [Authentication/Accounting] > [Authentication/Security Settings] > [Authentication] > [Authentication/Accounting Settings], the machine accesses to external services using user information authenticated with the machine after selecting [No].
-
Page 31: Folding Position Adjustment
Booklet Fold Position Adjustment Confirm the printed sample, measure the misalignment between the folding and staple. Enter the misalignment value by referring to the image on the screen and the folding position is adjusted. Fold Position If the page with the line is longer If the page without the line is longer... - Page 32 How to Enter the Misalignment Fold Position If the page with the line is longer If the page without the line is longer ・ ・ Select [Left Side of Fold is Longer] Select [Right Side of Fold is Longer] and enter the amount of and enter the amount of misalignment.
- Page 33 When Adjusting the Fold to the Any Length You need to enter the value calculated based on measured value and the target value. The calculating method is the following. Value to enter (A) = 210 + (“measured value” - “target value”) Value to enter (B) = “measured value”...
-
Page 34: Operation Mode Setting
Tel/Fax Switching Kit This is the optional kit to switch telephone and fax receiving automatically. Note Depending on the connected telephone line and TA, this may not work normally. When the machine connected to the private branch exchange, confirm whether the electrical specification is same as it of NIPPON TELEGRAPH AND TELEPHONE CORPORATION (NTT). - Page 35 Note To use this function, set “Fax transfer setting” in the DIP switch to “Enable”. This function is available only when you receive a call from the other party. If the telephone tries to transfer to the fax machine when it starts sending, the beep sounds and the line is cut without transferring.
-
Page 36: Basic Operations
Function Setting Operation mode Switches the operation mode. setting Fax priority mode Phone priority Phone-only mode mode Ringing time setting For the fax priority mode or the phone priority mode, set the ringing time when receiving a call. 18 seconds 12 seconds 24 seconds 30 seconds... -
Page 37: Troubleshooting
When Receiving a Phone When the phone rings, pick up the handset and speak. When Receiving a Fax When the fax priority mode is set: the fax is transferred to the fax machine automatically. When the phone priority mode is set: The phone rings. -
Page 38: Machine Trouble
Machine Trouble Symptom Cause/Remedy The machine is not The power cord may have been unplugged or may not be firmly powered on. plugged in. Switch the machine power off, and then reconnect the power cord to the power outlet and the machine. Then switch the machine power on. Connect the machine to a power outlet that supplies the proper rated voltage or current. -
Page 39: Image Quality Trouble
Image Quality Trouble Symptom Cause/Remedy Output is too light The paper is not appropriate for the machine. Confirm the paper tray (faded or unclear). setting and load appropriate paper. The paper is damp. Replace the paper. Change the paper type setting and try printing again. No toner may be left in the toner cartridge. - Page 40 Symptom Cause/Remedy Printing can be rubbed off The paper type of the selected paper tray is not appropriate. Change with your finger. the paper type setting and try printing again. Toner is not fused to the Some special types of paper cannot be fused. Replace with the paper.
- Page 41 Symptom Cause/Remedy White patches appear on Change the paper type setting and try printing again. output. Adjust the image transfer in > [Device] > [Maintenance] > [Image Images are partially Quality] > [Adjust Image Transfer] > [Enter Sample Number and blanked-out.
- Page 42 Symptom Cause/Remedy There is vertical uneven Log in to Administrator Mode and adjust the uneven density in > density against paper feed [Device] > [Maintenance] > [Image Quality] > [Density Uniformity direction. Adjustment]. For logging in to Administrator Mode, refer to “Logging in to Authentication Mode”...
-
Page 43: Trouble During Copying
Symptom Cause/Remedy Lead edge of paper is The paper is damp. Replace the paper. folded over when the Reduce the paper loaded in the Bypass Tray to 30 sheets or less. paper is fed from the Change the paper loading orientation. Feed paper from Paper Tray 1, Bypass Tray. -
Page 44: Trouble During Printing
Trouble during Printing Symptom Cause/Remedy The Note on status display Check the error message displayed in the Control Panel and take lamp is blinking. action to resolve the error. Unable to print. Check whether the machine’s IP address is set correctly. Check the data-reception control setting. -
Page 45: Trouble During Faxing
Trouble during Faxing Symptom Cause/Remedy A Transmission Report - Check the “Transmission Results” in the Transmission Report - Job Job Undelivered is output. Undelivered and take an appropriate action. If an error code is displayed, refer to Error Code Search on the support page on our official website to take action to resolve the error. - Page 46 Symptom Cause/Remedy Unable to communicate Additional services for Lines 1 to 3 are not set correctly. Check the line (general fax). contract (caller ID display and Dial-In) concluded with your telephone company and configure settings. The contract with NTT for the number display is required to use the caller ID distribution feature.
- Page 47 Symptom Cause/Remedy Unable to communicate The number of simultaneous connections for IP fax (SIP) is one. The (IP fax (SIP)). machine cannot send and receive at the same time. After reception of an IP fax (SIP) is completed, try sending it again. After transmission of an IP fax (SIP) is completed, request the sender to send it again.
-
Page 48: Trouble During Scanning
Symptom Cause/Remedy Communication/call, Decrease the value for [Prioritize IP Packets] of the machine according other than IP fax (SIP) to your network environment. communication, in the IP fax (SIP) machine is connected to the voice network if the telephone network is slow when IP and data networks are operated separately. - Page 49 Symptom Cause/Remedy Unable to open files If the files are saved in TIFF format, they can be opened using TIFF though color documents Viewer. If you can view PDF in your environment, save the files in PDF have been scanned. format.
- Page 50 Symptom Cause/Remedy You cannot call from a The telephone line is not connected to the LINE terminal of this telephone or fax machine. machine. Connected to the LINE terminal of this machine. The telephone line may have been unplugged. Confirm whether it is connected correctly.
- Page 51 Symptom Cause/Remedy Even if you dial “*” “*” “*” “Fax transfer setting” is set to “Disabled”. (The factory default is with the telephone, the “Disabled”.) Specify “Enabled”. fax is not transferred to The dial type is set to “DP”. Dial “*” “*” “*” (“*” for three times) after the fax machine.
- Page 52 Error Code Remedy 081, 091 Check if the LDAP server used for Login to Remote Accounts is set up correctly. Check the Active Directory server is powered on. Check the Active Directory settings. Check that the device is connected to a network. 110, 202, 704 Register again from the beginning.
- Page 53 Updatings for Add-on Application Trouble Message Measure Unable to connect to A communication error occurred when connecting to the server using server the Internet. Check the following items. Check network settings LAN cable connection Some services cannot be DNS server address settings ...
-
Page 54: Setting Restore Tool
This function is used to backup setting data, etc. in computers connected through networks in case data is lost due to the machine's storage malfunction. Download the setting restore tool from our official website. https://www.fujifilm.com/fb/ 2.10 License This product contains open source software, for which third parties own the rights (hereinafter referred to as “OSS”). -
Page 55: Job History
2.11 Job History The page count obtained in the job history and the meters and counters on the machine may not match. Use the acquired data as a guide. The job history may be lost due to troubles of the machine or due to storage replacement or initialization. - Page 56 SIQA_sheet_A3_simplex...
- Page 57 SIQA_sheet_A3_simplex...
- Page 58 SIQA_sheet_A3_duplex...
- Page 59 SIQA_sheet_A3_duplex...
- Page 60 SIQA_sheet_11x17_simplex...
- Page 61 SIQA_sheet_11x17_simplex...
- Page 62 SIQA_sheet_11x17_duplex...
- Page 63 SIQA_sheet_11x17_duplex...
