- Page 1 USER GUIDE G3 Gemini IntelliFresh Coffee Brewing ® ® System with FreshTrac Satellite ™ READ AND SAVE THESE INSTRUCTIONS NOTICE TO INSTALLER: Please leave this booklet with the machine.
-
Page 2: Table Of Contents
......................ES3 ......................ES5 ........................ES108 ......................................................................................................EC4 ..............................Contact Information Wilbur Curtis Co., Inc. 6913 Acco Street | Montebello, CA 90640 US Phone: 323-837-2300 | Toll Free: 800-421-6150 Email: csrassistance@wilburcurtis.com | Web: www.wilburcurtis.com . - 4:00 . PT Email: techsupport@wilburcurtis.com... -
Page 3: Fs68
KEY FEATURES/SPECIFICATIONS/SYSTEM REQUIREMENTS FS68 Key Features • • • • • • • Single, 1.5 Gallon w/IntelliFresh, DV 1 PH 120/220 V 13.5/13.5 A 2 X 1600 W 2/3W + G 1650/2800 W 50/60 Hz 4.5/10.0 Twin, 1.5 Gallon with IntelliFresh 1 PH 220 V 23.0/34.0 A... -
Page 4: Is2
INSTRUCTIONS could result in personal injury or void the warranty. • This appliance is designed for commercial use. Any service other than cleaning and preventive maintenance should be performed by an authorized Wilbur Curtis service technician. • serviceable parts inside. - Page 5 IMPORTANT SAFEGUARDS CE Requirements • This appliance must be installed in locations where it can be overseen by trained personnel. • • • • This appliance must not be cleaned by water jet. • instruction concerning use of the appliance in a safe way and if they understand the hazards involved. •...
-
Page 6: Ii2
INSTALLATION INSTRUCTIONS WARNING: WARNING: properly grounded. NOTICE: SPECIFICATIONS section. IMPORTANT: Installation Instructions Installation Requirements • A secure surface capable of supporting the weight of the appliance. • For units without an attached cord set: Appropriately sized, UL listed, grounding type power cable to meet enough •... -
Page 7: Ii1
INSTALLATION INSTRUCTIONS Installation Leveling WARNING: Use the leveling legs to level the brewer only. Do not use them to adjust brewer height. Do not extend them higher than necessary. Position the brewer on the counter top. Level it left to right and front to back by turning the bottom of the legs. - Page 8 INSTALLATION INSTRUCTIONS Connect the Brewer Wiring (cont.) Brewers With A Cord Set Attached - 12 Connect the power cord to the appropriate type of electrical outlet. WARNING: Connect the power cord to the appropriate type and size electrical outlet. If the electrical outlet is not compatible with the power cord, have it upgraded by a licensed electrician.
- Page 9 INSTALLATION INSTRUCTIONS 19 If the UCM is not already lit, push the ON/OFF button to the correct volume, the heating elements will turn on automatically. Depending on the incoming water water tank typically requires 20 to 30 minutes to the water has heated, “Ready to Brew” should be on the display.
-
Page 10: Oi50
OPERATING INSTRUCTIONS OI50 Brewing Instructions WARNING - TO AVOID SCALDING, AVOID SPLASHING. Keep body parts clear of the brewer during brewing. Do not remove the brew basket while “Brewing” appears on the display. NOTICE - Only use GEM3XIFT IntelliFresh ® satellites on GEMX series IntelliFresh brewers. - Page 11 NOTE: After the brew cycle is complete, if the GEMX satellite is transferred from the brewer to ¼ a Curtis IntelliFresh warmer stand, the following satellite settings will remain the same: Quality Timer, Warmer Default (heat setting) and Satellite (Intellifresh) Color Scheme.
- Page 12 CLEANING INSTRUCTIONS WARNING: HOT SURFACES - To avoid injury, allow the brewer and dispenser(s) to cool before cleaning. NOTICE - Do not use cleaning liquids, compounds or powders containing chlorine (bleach) or corrosives. USE OF THESE PRODUCTS WILL VOID THE WARRANTY. Cleaning The Brewer - Daily WARNING: DO NOT immerse the brewer in water or any other liquid.
- Page 13 CLEANING INSTRUCTIONS CI29 Cleaning the Satellite (Daily) WARNING: DO NOT immerse the satellite in water or any other liquid. Do not place the satellite in a dishwasher. Placing the satellite in a dishwasher will void the warranty. IMPORTANT: Clean the satellite daily to avoid the build up of coffee oil residue on the Intellifresh ®...
- Page 14 PROGRAMMING GUIDE To enter programming mode: With unit OFF, press and hold bottom right BREW button (4). Then press and release ON/OFF button (2). Continue to hold down BREW button until Enter Code appears. Label style may vary Enter 4 digit code. (factory default = 1-2-3-4) * “Ready”...
- Page 15 PROGRAMMING GUIDE Programming Options Some menus save and exit automatically when a parameter is updated. Other menus exit to the previous menu when a parameter is saved. To exit, press until EXIT appears on the display, then press Global Recipes Menu Select from the following coffee types: Gourmet STD (standard), Light Roast, Dark Roast, High Yield, Filter Pack or Decaf.
- Page 16 Banner Name - changes the banner name that appears on the display (the factory default is Curtis). No banner name appears when all blanks are entered. Once accessed, press to choose the letter to change.
- Page 17 PROGRAMMING GUIDE Programming Options (cont.) Brew Button Programming Menu until Exit appears on the display. Press to exit, then re-enter the Brew Button Program to program the next one. Brew by Volume - MEDIUM desired volume is reached, press the same BREW button again to stop the brew cycle and set the volume. Brew by Time - adjusts the amount of coffee brewed by time rather than by volume (the factory defaults are LARGE 5min-25sec., MEDIUM 3min-32sec., SMALL 1min-52sec).
- Page 18 ROUGH-IN DRAWINGS RD70 GEMXSIFT - Single Coffee Brewer W i t h hi gh vol um e br ew bas ket 0. 23 i n [ 0. 58 cm ] 11. 31 i n [ 28. 7 cm ] 10. 50 i n [ 26.
- Page 19 ROUGH-IN DRAWINGS RD70 GEMXTIFT - Twin Coffee Brewer W i t h hi gh vol um e br ew bas ket 0. 26 i n [ 0. 66 cm ] 11. 35 i n [ 28. 8 cm ] 18. 17 i n [ 46.
- Page 20 ROUGH-IN DRAWINGS RD72 GEM3XIFT - Satellite Server 9. 04 i n [ 23. 0 cm ] 9. 17 i n [ 23. 3 cm ] 4. 68 i n [ 11. 9 cm ] 11. 09 i n 11. 25 i n [ 28.
- Page 21 ILLUSTRATED PARTS/RECOMMENDED PARTS IP119 Supplies and Accessories - All Models WC-29050 - Spray Head CAB-1 - Cleaning Brush Sold individually or by the case GEMXSIFT - Main Chassis - Exploded View *Water tanks assembly, see section IP32 GEMXSIFT/GEMXTIFT - GENERIC, ILLUSTRATED PARTS/RECOMMENDED PARTS 121517NC...
- Page 22 HARNESS ASSY, DV CONVERSION GEMSS/ WC-58395 COVER, FRONT WC-13298 TP2S LABEL, BOTTOM DECK GEMXSIFT/ WC-390353 G4GEMXSIFT CURTIS WC-1412 CORD GRIP, 3/4” FOR METAL CORD TO .81”OD FAUCET, PS/HPS SERIES HOT WTR 1/2-20 UNF WC-61963 PLATE, HOLDER IF CONNECTORS GEMTIF WC-1809...
- Page 23 ILLUSTRATED PARTS LIST IP119 GEMXTIFT - Main Chassis - Exploded View Water tank assembly, see section IP26 1 1A 1 1B GEMXSIFT/GEMXTIFT - GENERIC, ILLUSTRATED PARTS/RECOMMENDED PARTS 121517NC...
- Page 24 LEG, 4” ADJUSTABLE 3/8-16 THRD ITALIAN GEMSS/GEMTS WC-3528 STYLE LABEL, UCM & OUTER OVERLAY 3-BATCH WC-390346 FAUCET, PS/HPS SERIES HOT WTR 1/2-20 UNF WC-1809 GEMXTIFT CURTIS AP/ALP LABEL, UCM OVERLAY 2-BATCH GEMXTIFT WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE WC-390347 CURTIS WC-5231...
-
Page 25: Ip26
ILLUSTRATED PARTS/RECOMMENDED PARTS IP26 WC-62033 - Tank Assembly WC-62033 - Tank Assembly - Parts List ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION WC-54287 TANK, ASSY TPS1T/GEMTS WC-4382 GUARD, SHOCK HTNG ELMNT DOUBLE WC-62033 TANK, COMPLETE GEMTS W/ULTEM FITTINGS THERMOSTAT, HI LIMIT HEATER CONTROL DPST WC-522 277V 40A... -
Page 26: Ip32
ILLUSTRATED PARTS LIST IP32 WC-62034 - Tank Assembly WC-62034 - Tank Assembly - Parts List ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION TANK, COMPLETE GEMSS DV W/ ULTEM THERMOSTAT, HI LIMIT HEATER CONTROL WC-62034 WC-522 FITINGS DPST 277V 40A WC-5853-102 COVER, TOP HEATING TANK GEN USE WC-43055... -
Page 27: Es3
ELECTRICAL SCHEMATICS GEMSIF63A1000 GEMSIF63A1000, ELECTRICAL SCHEMATIC 022717NC... -
Page 28: Es5
ELECTRICAL SCHEMATICS GEMTIF10A1000, GEMTIF10B1000... - Page 29 ELECTRICAL SCHEMATICS ES108 GEMXIFT...
- Page 30 TROUBLESHOOTING GUIDE WARNING: Electric Shock Hazard - Scald and Burn Hazard - IMPORTANT: always check all Valve Test Procedure Troubleshooting Guidelines • • • • Valve Test Procedure in either direction Water Not Hot Enough replace the temperature sensor Water Heats More Slowly Than Usual...
- Page 31 TROUBLESHOOTING GUIDE During Brewing No Power - Display Not Lit Water Tank Does Not Fill Brewer Does Not Start When Brew Button is Pressed Brewing Brewing Sensor Error Message...
- Page 32 TROUBLESHOOTING GUIDE Water Tank Does Not Fill IMPORTANT: Coffee/Tea Too Strong Dispenser Not Filled To Normal Level During Brewing Dispenser Not Filled To Normal Level During Brewing sure that the spray head is correctly aligned and that the tubing is routed properly to allow for maximum water...
- Page 33 TROUBLESHOOTING GUIDE All Of The Time No Water/Tea Flows From Brewer During Brewing Water Tank Does Not Fill Low Water Flow Warning Water Level Error Message Water Level Error Message...
- Page 34 TROUBLESHOOTING GUIDE Water Does Not Heat At All Check to see if the water level in the tank is in contact with the water level probe. If not, see Tank Does Not Fill. • The water will not heat unless it is in contact with the probe. If the water heats, but is not hot enough, see Water Not Hot Enough.
- Page 35 TROUBLESHOOTING GUIDE TG35 Satellite Does Not Heat NOTE reheat cold coffee. First check to see if one of the LED bars on the satellite indicates a bad heating element. The middle LED bar controller (replace the controller). Check to see if the Intellifresh LED on the front of the satellite comes on at the beginning of the brew cycle.
-
Page 36: Ec4
ERROR CODES System Fault Messages An error message will appear on the screen in the event of a malfunction under the following conditions: ERROR MESSAGE WARNING DESCRIPTION CAUSE Water Level Error G3 BREWER, ERROR CODES 042017A... - Page 37 Return Merchandise Authorization (RMA): All returned equipment must be properly re-packaged in the original carton and received by Curtis within 45 days following the issuance of a RMA. NO UNITS OR PARTS WILL BE ACCEPTED WITHOUT A RETURN MERCHANDISE AUTHORIZATION (RMA).
