- Page 1 USER GUIDE ® Gemini ® IntelliFresh Satellite Style varies See brewer user guide for brewing instructions READ AND SAVE THESE INSTRUCTIONS NOTICE TO INSTALLER: Please leave this booklet with the machine.
-
Page 2: Table Of Contents
Illustrated Parts/Recommended Parts........................IP123 Electrical Schematic (GEM3IF) ..........................ES29 Electrical Schematic (GEM3IF30) .........................ES30 Product Warranty..............................PW1 Contact Information Wilbur Curtis Co., Inc. 6913 Acco Street | Montebello, CA 90640 US Phone: 323-837-2300 | Toll Free: 800-421-6150 Email: csrassistance@wilburcurtis.com | Web: www.wilburcurtis.com . - 4:00 . -
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS Symbols This is the safety alert symbol. It is used to alert you to potential physical injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. DANGER - Indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING - Indicates a hazardous situation which, if not avoided, could result in death or serious injury. - Page 4 IMPORTANT SAFEGUARDS CE Requirements • This appliance must be installed in locations where it can be overseen by trained personnel. • • • • This appliance must not be cleaned by water jet. • instruction concerning use of the appliance in a safe way and if they understand the hazards involved. •...
-
Page 5: Intellifresh ® Features
INTELLIFRESH FEATURES ® IntelliFresh Function and Features The IntelliFresh Quality Timer system will alert you to when the coffee has exceeded the desired freshness time. The Quality Timer is activated by a connector on the satellite connecting to a corresponding connector on the brewer. -
Page 6: Cleaning Instructions
Mild solution of dish-washing detergent and warm water ™ • TABZ Z95 Coffee Equipment Cleaner Tablets (Curtis PN WC-79000) • One-Pro Beverage Equipment Cleaner WARNING: DO NOT immerse the satellite in water or any other liquid. Do not place the satellite in a dishwasher. - Page 7 CLEANING INSTRUCTIONS Cleaning the Faucet Parts and Site Gauge 10 Wash - Wash the lid and all faucet and gauge glass parts with the detergent solution. Clean the inside of the gauge glass with a gauge brush soaked with detergent solution. 11 Rinse - Thoroughly rinse all parts with clean, WASH warm water.
-
Page 8: Rough-In Drawing
ROUGH-IN DRAWINGS RD75 GEM3IF - Satellite Server 13.48 in [34.2 cm] 8.94 in [22.7 cm] 11.48 in 10.28 in 11.72 in [29.2 cm] [26.1 cm] [29.8 cm] 9.98 in [25.3 cm] 8.94 in 0.27 in [22.7 cm] [0.7 cm] GEM3IF, ROUGH-IN DRAWING 062317NC... - Page 9 ILLUSTRATED PARTS LIST IP123 GEM3IF - Exploded View Orange, decaf. handle When replacing the faucet shank, apply food grade lubricant (ITEM 23, not included) to both o-rings before installation. GEM3IF, ILLUSTRATED PARTS/RECOMMENDED PARTS 031020D...
- Page 10 GLASS, GAUGE 8” WC-37544 KIT, LED SENSOR GEM3IF WC-2010C SHIELD, GAUGE GLASS 3/4”D.X 8” WC-39746 LABEL, FRONT GEM3IF CURTIS LOGO WASHER, .188 ID X .188 THK BOTTOM GAUGE 16A* WC-736K KIT, CONTROL MODULE, UPM 120V GEM3IF WC-2006 GLASS GEN USE...
-
Page 11: Electrical Schematic (Gem3If)
ELECTRICAL SCHEMATICS ES29 GEM3IF Pin Assignments 120V HOT 120V NEUTRAL ELECTRICAL RATING TABLE TANK TEMPERATURE SENSOR # of TANK TEMPERATURE SENSOR Voltage Amps Wa s Hertz Model Conductor Phase HEATER/WARMER OUT Wires HEATER/WARMER OUT 0.55 50/60 LED (+) GEM3IFx 0.58 50/60 LED (-) 0.60... -
Page 12: Electrical Schematic (Gem3If30)
ELECTRICAL SCHEMATICS ES30 GEM3IF-30... -
Page 13: Product Warranty
Return Merchandise Authorization (RMA): All returned equipment must be properly re-packaged in the original carton and received by Curtis within 45 days following the issuance of a RMA. NO UNITS OR PARTS WILL BE ACCEPTED WITHOUT A RETURN MERCHANDISE AUTHORIZATION (RMA).
