Installation Guide

Fan Power Board Replacement for Fx11–Fx12

iC7 Series Frequency Converters

1 Overview

1.1 Description

The fan power board replacement kit contains all components required to install a new fan power board in iC7 Series Frequency

Converters including:

•

Fx11 = FA11/FK11/FB11

•

Fx12 = FA12/FK12/FB12

1.2 Kit Number

Use these instructions with the following kits.

Table 1: Fan Power Board Replacement Kit

Number

176F3933

1.3 Items Supplied

The following parts are contained in the kit.

Table 2: Items Supplied in Fan Power Board Replacement Kits for Fx11-Fx12

Item

Fan power board

Installation instructions

Description

Fan power board for Fx11–Fx12

Quantity

AN361427403573en-000101 / 136R0260 | 1

Page 1 Fan Power Board Replacement for Fx11–Fx12 iC7 Series Frequency Converters 1 Overview 1.1 Description The fan power board replacement kit contains all components required to install a new fan power board in iC7 Series Frequency Converters including: • Fx11 = FA11/FK11/FB11 •...
Page 2: Installation
N O T I C E QUALIFIED PERSONNEL Only qualified, Danfoss authorized personnel are allowed to install the parts described in these installation instructions. Disassembly and reassembly of the frequency converter must be done in accordance with the service guide.
Page 3 MK803 MK802 MK101 MK100 MK102 Illustration 1: Fan Power Board Removal Remove 5 screws (T20) from the fan power board. Keep the screws for use with the new fan power board. Danfoss A/S © 2022.03 AN361427403573en-000101 / 136R0260 | 3...
Page 4 The number of screws varies based on the size of the cabinet. Close the door or install the front cover and fasten the screws (T25). The number of screws varies based on the size of the cabinet. 4 | Danfoss A/S © 2022.03 AN361427403573en-000101 / 136R0260...
Page 5 Fan Power Board Replacement for Fx11–Fx12 Installation Guide Installation Danfoss A/S © 2022.03 AN361427403573en-000101 / 136R0260 | 5...
Page 6 Danfoss reserves the right to alter its products without notice. This also applies to products ordered but not delivered provided that such alterations can be made without changes to form, fit or function of the product.
