- Page 1 BFD66SL/BFD66W 60 cm Freestanding dishwasher...
- Page 2 USER MANUAL FOR YOUR BAUMATIC BFD66SL/BFD66W 60 cm freestanding dishwasher NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference; for you or any person not familiar with the operation of the appliance.
-
Page 3: Table Of Contents
Contents Environmental note Important safety information 5 – 7 Specifications 8 - 9 Product dimensions Product specifications Energy efficiency details Electrical details Description of the appliance 9 - 10 Control panel Using your dishwasher 10 - 19 Before first use Filling with dishwasher salt 10 - 11 Setting the water softener level... -
Page 4: Environmental Note
This should be undertaken by a competent person. Disable the door lock to make sure that children cannot get stuck inside the appliance. o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the... -
Page 5: Important Safety Information
General Safety o Repairs to your appliance must only be carried out by a Baumatic engineer or one of its authorised service agents. Any attempt by an inexperienced person to repair the appliance, could result in injury or damage to your dishwasher. - Page 6 This appliance is only designed to wash normal domestic washloads. If you use your dishwasher in any other way or it is incorrectly used, then Baumatic accepts no liability for any damage that might be caused and any guarantee will be void.
- Page 7 Child Safety o Your dishwasher should only be used by adults. You should not allow children in the area of the machine unsupervised. You should not let them touch the controls or play with the appliance. o It could be possible for a child or pet to gain access to the dishwasher if the door is left open.
-
Page 8: Specifications
Specifications Product dimensions Height: 820 - 855 mm Width: 595 mm Depth: 580 mm Product specifications o 12 Place settings o 8 functions: Normal Intensive Economy Glass Rinse Rapid Soak 3 in 1 o 4 Wash temperatures: 40°C, 45°C, 50°C, 60°C o 3 Rinse temperatures: 45°C 60°C, 70°C o LED display o Self-cleaning stainless steel microfilter... -
Page 9: Energy Efficiency Details
Energy efficiency details Energy efficiency class: Washing performance class: A Drying performance class: Electrical details Rated voltage: 230 Vac 50 Hz Supply connection: 13 A (double pole switched fused outlet with 3 mm contact gap) Description of the appliance Upper basket Cup shelf Spray arms Cutlery basket... -
Page 10: Control Panel
Control panel 1) ON/OFF button 2) Power on indicator neon 3) Rinse aid indicator neon 4) Salt indicator neon 5) Start/pause button 6) Program selection button 7) Program indicator neons Using your dishwasher Before first use o Install the appliance as per the installation instructions contained within this booklet. -
Page 11: Filling With Dishwasher Salt
Filling with dishwasher salt IMPORTANT: You should only use salt that is specially designed for use in a dishwasher. If any other type of salt is used in the appliance (in particular table salt), it will damage the water softener. o Ideally you should fill the water softener with salt, just before you are about to run a wash program. -
Page 12: Setting The Water Softener Level
o IMPORTANT: You do not need to pour 1 litre of water into the container when you subsequently fill the water softener with salt. Setting the water softener level It is possible to regulate the amount of salt that the water softener will release during a wash cycle. -
Page 13: Filling With Rinse Aid
Filling with rinse aid The rinse aid is released during the final rinse and it helps to prevent water from forming droplets on your dishes. These droplets will lead to spots and streaks being left on items after the wash program has completed. o Your dishwasher is designed to utilise liquid rinse aid. -
Page 14: Filling With Dishwasher Detergent
o You should continue to adjust the rinse aid level upwards until you get no water spots. o If you get cloudiness or streaking on your dishes, the rinse aid level is set too high and it is causing foaming during the wash cycle. -
Page 15: Loading The Upper Basket
Loading the upper basket The upper basket is most suited to washing delicate and light dishware, such as glasses, coffee & tea cups, saucers, plates, bowls and shallow pans (that are not heavily soiled). Cups Small serving bowl Large serving bowl Glasses Saucers Dish... - Page 16 Lower position o If the upper wheels are placed in the guide supports, then the basket is in the lower position. o For accommodating additional tumblers, cups and mugs. You can also place small, espresso sized cups on top of the side racks. You should take care to ensure that there is enough clearance between the top of the cups placed on top of the side racks and the underneath of the dishwasher interior.
-
Page 17: Loading The Lower Basket
IMPORTANT: Care should be taken to make sure that the spray arms can move freely when items have been loaded into the baskets. Loading the lower basket The lower basket is most suited to washing larger and more heavily soiled items, such as saucepans, saucepan lids and serving dishes. You can also load bowls and a variety of plates into the lower basket. -
Page 18: The Cutlery Basket
The cutlery basket Cutlery should be placed inside of the cutlery basket. The cutlery basket should then be placed in the appropriate position in the lower basket. Forks Soup spoons Dessert spoons Teaspoons Knives Serving spoon Ladle Serving fork o For the best washing performance, cutlery should be placed through the slots in the top of the cutlery basket. - Page 19 o Do not allow glasses to touch inside the dishwasher, otherwise damage may occur. o Small objects that are suitable for washing can be placed inside of the cutlery basket. The following items are NOT suitable for washing inside a dishwasher:- o Cutlery with a handle of mother-of-pearl, wood, horn or china.
-
Page 20: Program Table
Program table Program Program Description Detergent Water information of cycle pre/main consumption (litres) 3 in 1 For normally Pre-wash 3 in 1 tablets 17.2 soiled loads, such Pre-wash as pots, plates, Wash (45°C) glasses and lightly Rinse (70°C) soiled pans. Drying Standard daily cycle. -
Page 21: Setting A Wash Program
Setting a wash program Make sure that the before first use section has been followed. o Check whether the appliance needs rinse aid or salt adding to it. o Pull out the top and bottom baskets, then load them in accordance with the loading instructions. -
Page 22: Changing A Wash Program
Changing the wash program o Press the Start/pause button for more than three seconds. o Press the program selection button to choose an appropriate wash program for the load that you are washing. The program indicator neons will show you which wash program you have currently selected. -
Page 23: Rinse Aid And Salt Indicator Neons
o IMPORTANT: If you leave the door of the dishwasher shut and do not unload the dishwasher for a prolonged period of time, then you may get water droplets reforming on the washload. Rinse aid and salt indicator neons o The rinse aid and salt indicator neons on the control panel will let you know when the appliance needs rinse aid or salt adding to it. -
Page 24: Cleaning And Maintenance
Cleaning and maintenance IMPORTANT: The appliance should be disconnected from your mains supply before commencing any cleaning process. The filter system Your appliance is fitted with three levels of filtering; these are located in the base of the dishwasher for ease of access. Main filter Coarse filter Fine filter... -
Page 25: Cleaning The Filters
Cleaning the filters For best performance and results, the entire filter assembly should be thoroughly cleaned regularly (ideally after each wash cycle). 1. Turn the coarse filter anti-clockwise and then lift it upwards. Rinse out this section under a tap to remove any food debris that remains in it. -
Page 26: Cleaning The Spray Arms
Cleaning the spray arms The spray arms should be cleaned regularly, to prevent hard water deposits from clogging the spray arm jets and bearings. o IMPORTANT: Remove the lower basket before attempting to remove the lower spray arm. o To remove the spray arms, unscrew the nut and take out the washer that sits on top of the spray arms. -
Page 27: Cleaning The Door
Check that the outlet hose is not kinked or crushed and that it’s positioned correctly (as per the installation instructions). Normal and eco indicator neons flash o Longer heating time- not reaching the required temperature. Malfunction of the temperature sensor or heating element. Call Baumatic Customer Care. - Page 28 Call Baumatic Customer Care. IMPORTANT: If any other combination of the program indicator neons flash, you should not attempt to clear it yourself and contact the Baumatic Service Department. IF THE FAULT CODE REAPPEARS AFTER FOLLOWING THE ABOVE ADVICE AND CLEARING THE FAULT CODE.
-
Page 29: General Troubleshooting
Utensils are not Ensure that everything is loaded as secure in the baskets per Baumatic’s loading instructions. or something small has dropped into the basket Motor hums If the dishwasher is not going to be... - Page 30 Dishes and Improper program Select a more intense wash pans are not program. clean Improper loading Make sure that the spray arms and the detergent dispenser are not being impeded by large dishes. Spots and Extremely hard water filming on Low inlet glasses and temperature...
-
Page 31: Installation
Installation IMPORTANT: THIS INSTALLATION MUST BE COMPLETED BY A SUITABLY QUALIFIED PERSON. BAUMATIC ONLY SANCTION THE INSTALLATION GIVEN IN THIS INSTRUCTION MANUAL. YOU SHOULD DISPOSE OF ALL PACKAGING IN AN ENVIRONMENTALLY FRIENDLY MANNER. Positioning and levelling the appliance Remove all packaging from the outside and inside of the dishwasher. -
Page 32: Connecting To The Mains Water Supply
Adjust each of the four feet until the appliance is level. IMPORTANT: When the dishwasher is positioned in the location where it will be used. Make sure that all four feet are resting firmly on the floor, by pressing down on each corner and checking that the appliance stands still. -
Page 33: Water Outlet
Water outlet Secure the drain hose, so that it cannot move whilst the dishwasher is in use. Place the end of the drain hose on your drain pipe. Push it a short way down into your drain pipe. IMPORTANT: Do not insert the drain hose too deeply into the water pipe, as this may cause siphoning. -
Page 34: Before First Use
Consult the rating plate, located on the right hand side of the drop down door BEFORE making the electrical connections. Ensure that the voltage reaching the plug is the same as that on the rating plate. DO NOT REMOVE THE RATING PLATE AS THE INFORMATION ON IT IS IMPORTANT. -
Page 35: Contact Details
Czech Republic United Kingdom Baumatic CR spol s.r.o. Baumatic Ltd., Amperova 495 Baumatic Buildings, 46215, Librec 6 Bennet Road, Czech Republic Reading, Berkshire RG2 0QX +420 800 185 263 United Kingdom www.baumatic.cz Sales Telephone (0118) 933 6900 Slovak Republic Sales Fax Baumatic Slovakia, s.r.o.
