Read this guide thoroughly. It contains important
safety information.
Minimum recommended operator's age: 16 years old.
Keep this Operator's Guide in the vehicle.
6 1 9
9 0 0
9 3 2
Original Instructions

Advertisement

Table of Contents
loading

Related Manuals for BRP ski-doo Skandic 2018 Series

Summary of Contents for BRP ski-doo Skandic 2018 Series

  • Page 1 2018 Skandic Series Read this guide thoroughly. It contains important safety information. Minimum recommended operator’s age: 16 years old. Keep this Operator’s Guide in the vehicle. 6 1 9 9 0 0 9 3 2 Original Instructions...
  • Page 2 REV-XP™ D.E.S.S.™ HPG™ Ski-Doo ® eDrive™ ROTAX ® TRA™ III 619900932 en KD/LG ®™ and the BRP logo are trademarks of Bombardier Recreational Products Inc. or its affiliates. ©2017 Bombardier Recreational Products Inc. and BRP US Inc. All rights reserved.

  • Page 3: Foreword

    Bombardier Recreational Products your new vehicle was prepared to your Inc. (BRP) warranty and a network of entire satisfaction. authorized Ski-Doo snowmobile deal- ers ready to provide the parts, service Know Before you Go or accessories you may require.

  • Page 4: Safety Messages

    The safety alert symbol indicates in this guide may occur. BRP reserves a potential injury hazard. the right at any time to discontinue or change specifications, designs, fea- WARNING tures, models or equipment without incurring any obligation upon itself.

  • Page 5: Table Of Contents

    Effects of Having a Studded Track on the Life of the Snowmobile ..26 Installation of Studs on BRP Approved Tracks ....... . 26 Inspection of a Studded Track .
  • Page 6 TABLE OF CONTENTS CONTROLS, INSTRUMENTS AND EQUIPMENT (cont’d) 7) Multifunction Switch ............43 8) Gearshift Lever ..
  • Page 7 TABLE OF CONTENTS MAINTENANCE FIRST INSPECTION..............78 MAINTENANCE SCHEDULE .
  • Page 8 TABLE OF CONTENTS MONITORING SYSTEM ............128 Pilot Lamps, Messages and Beeper Codes ........ . 128 WARRANTY LIMITED WARRANTY...

  • Page 9: Safety Information

    SAFETY INFORMATION ________ ________ SAFETY INFORMATION...

  • Page 10: General Precautions

    Do not make unauthorized modifica- tions, or use attachments or acces- To prevent serious injury or death from sories that are not approved by BRP. carbon monoxide: Since these changes have not been – Never run the vehicle in poorly ven-...

  • Page 11: Special Safety Messages

    – BRP recommends the operator has at least 16 years old of age. – It is very important to inform any operator, regardless of his experience, of the handling characteristics of this snowmobile.
  • Page 12 SPECIAL SAFETY MESSAGES – Speeding can be fatal. In many cases, you cannot react or respond quickly enough to the unexpected. Always ride at a speed which is suitable to the trail, weather conditions and your own ability. Know your local rules. Speed limit may be in effect and meant to be observed.
  • Page 13 – You may stud the track on this vehicle model. However, you MUST only use the BRP approved type stud for use on Ski-Doo snowmobiles. DO NOT EVER use conventional studs, the track thickness is thinner compared to some other tracks.

  • Page 14: Active Technologies (Itc) (600 Ace / 900 Ace)

    ACTIVE TECHNOLOGIES (iTC) (600 ACE / 900 ACE) Introduction Sport Mode NOTE: Some functions or features de- In sport mode, maximum engine scribed in this section may not apply to power is available throughout the en- every model, or may be available as an gine operational range.

  • Page 15: Riding The Vehicle

    RIDING THE VEHICLE Each operator has a responsibility to Before Starting the Engine ensure the safety of other recreation- 1. Remove snow and ice from body in- ists or bystanders. cluding lights, seat, footrests, con- You are responsible for proper opera- trols and instruments.

  • Page 16: How To Ride

    RIDING THE VEHICLE NOTE: You may need to detach tether 2. Check the engine cut-off switch (by cord your clothes to check lights. In pulling tether cord cap) and emer- such a case, attach cord as soon as you gency engine stop switch opera- get back at the controls of the snow- tion.
  • Page 17 RIDING THE VEHICLE ways be carried or worn. Goggles or a Generally, the riding position for best face shield that attaches to the helmet balance and control is sitting. How- are indispensable. ever, the posting, kneeling or standing positions are also used under certain Hands should be protected by a pair conditions.

  • Page 18: Carrying A Passenger

    On snowmobiles allowing two passen- gers, if you have an adult and a child for passenger, BRP recommends that the child sits in the center location. This mmo2008-003-004 allows an adult sitting in the rear seat...

  • Page 19: Terrain/Riding Variations

    RIDING THE VEHICLE WARNING WARNING When riding with a passenger: – Passengers must only sit on designated passenger seats. – Braking ability and steering Never allow anyone to sit be- control are reduced. Decrease tween the handlebar and the speed and allow extra space to operator.
  • Page 20 RIDING THE VEHICLE Deep Snow Hard Packed Snow In deep “powder” snow, your vehicle Don't underestimate hard packed could begin to “bog” down. If this oc- snow. It can be difficult to negotiate curs, turn in as wide an arc as possible as both skis and track do not have as and look for a firmer base.
  • Page 21 RIDING THE VEHICLE Side Hill – Europe: www.avalanches.org – Canada: www.avalanche.ca When crossing a side hill or travers- ing up or downhill, certain procedures Slush must be followed. All riders should lean towards the slope as required for Slush should be avoided at all times. stability.
  • Page 22 RIDING THE VEHICLE Unseen Obstruction surfaces, “body english” is the key to turning. Leaning towards the inside of There may be obstructions hidden the turn and positioning body weight beneath the snow. Driving off es- on the inside foot will create a “bank- tablished trails and in the woods re- ing”...

  • Page 23: Environment

    RIDING THE VEHICLE Railroad Crossing Signals Never ride on railroad tracks. It is il- If you intend to stop, raise either hand legal. Railroad tracks and railroad straight above your head. A left turn is rights-of-way are private property. A indicated by extending your left hand snowmobile is no match for a train.
  • Page 24 RIDING THE VEHICLE ture of our sport. Help us lead it down Light Treading in no way suggests you the right path! From all of us at BRP, should curb your appetite for snowmo- thank you for doing your share.
  • Page 25 RIDING THE VEHICLE Respecting the areas where we ride... wherever they may be... is the only way to ensure their future enjoyment. That's one major reason why we know you'll agree that Light Treading is smart sledding! And there are more. Enjoying the opportunity to see winter and all its natural majestic wonders, is an experience cherished by snow-...

  • Page 26: Traction Enhancing Products

    BRP for special studs installation. adaptation period. If your snowmobile is equipped with traction enhancing products, be sure to take plenty of time...

  • Page 27: Acceleration

    TRACTION ENHANCING PRODUCTS Acceleration Using studs on the track will allow your sled to accelerate better on packed snow and ice but will have no notice- able effect on soft snow. This can cause sudden variations in traction under certain conditions. WARNING To prevent surprises that could OVERSTEERING...

  • Page 28: Important Safety Rules

    The use of traction enhancing products To ensure safe and proper installation, can increase the load and the stress on BRP recommends to have the studs in- certain snowmobile components, as stalled by your dealer. well as the vibration level. This can –...

  • Page 29: Inspection Of A Studded Track

    TRACTION ENHANCING PRODUCTS – Tears in the track (particularly WARNING around traction holes on studded – See an authorized Ski-Doo tracks) dealer for current specific stud- – Lugs that are broken or torn off, ex- ding availability and applica- posing portions of rods tions.

  • Page 30: Important On-Product Labels

    IMPORTANT ON-PRODUCT LABELS Hang Tag mmo2015-010-100 TYPICAL . Operating, servicing and WARNING maintaining an off-road vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm.
  • Page 31 IMPORTANT ON-PRODUCT LABELS mmo2011-007-006_d mmo2009-004-006_b TYPICAL ________ ________ SAFETY INFORMATION...
  • Page 32 IMPORTANT ON-PRODUCT LABELS This vehicle is designed for one (1) • Read and understand all safety labels, operator and as many passengers as there operator's guide and watch your safety DVD are seats with straps or handgrips installed on the vehicle conforming to SSCC before operation.
  • Page 33 IMPORTANT ON-PRODUCT LABELS WARNING This guard must ALWAYS be in place when engine is running. Beware of rotating parts _ they could cause injuries or catch your clothing. 516004595A 516004595A että kaikki suojat on suljettu LABEL 4 516003926 LABEL 5 516004961 LABEL 6 that all the protections are closed...
  • Page 34 IMPORTANT ON-PRODUCT LABELS 516004960 LABEL 7 - NORTH AMERICAN MODELS WARNING – Always use a securely fastened rigid tow bar to tow. – Always reduce your speed when towing. – NEVER sit nor exceed maximum load capacity in cargo area. –...
  • Page 35 IMPORTANT ON-PRODUCT LABELS CAPACITOR Capacitor May Spark If Shorted. -Spark can ignite fuel vapors. -Keep objects away from poles. -When removing from vehicle, always discharge properly. 516005682 LABEL 9 516006206 LABEL 13 - E-TEC MODELS WARNING AVERTISSEMENT mmo2006-003-007_a LABEL 10 - EUROPEAN MODELS mmo2008-003-007 LABEL 14 516005111...
  • Page 36 IMPORTANT ON-PRODUCT LABELS 516003919 ON PULLEY GUARD - EUROPEAN MODELS Always electrically disconnect both fuel injectors prior to testing for ignition spark. Otherwise, fuel vapors may ignite in presence of a spark creating a fire hazard. 5583A 516003923 516005583A ON FUEL INJECTORS - E-TEC MODELS EN-516003923-Dec LABEL 15 - EUROPEAN MODELS 516003925...

  • Page 37: Compliance Labels

    BRP recommends the use of its XPS approved lubricant or equivalent. Damages caused by oil which is not suitable for this engine may not be covered by the BRP limited warranty. See the operator’ s guide. 516007443 516007443 IN ENGINE COMPARTMENT...
  • Page 38 IMPORTANT ON-PRODUCT LABELS OCTANE mmo2013-002-002 LOCATED ON FUEL CAP - ON 600 HO E-TEC ENGINE (IN COUNTRIES USING PUMP POSTED AKI (RON+MON)/2 OCTANE RATINGS) OCTANE mmo2010-002-014_en mmo2013-002-005 LABEL 3 LOCATED ON FUEL CAP - ON 550F, 600 ACE AND 900 ACE ENGINES (IN COUNTRIES USING RON OCTANE RATINGS) 516005503A LABEL 4...

  • Page 39: Vehicle Information

    VEHICLE INFORMATION _______________...

  • Page 40: Controls, Instruments And Equipment

    CONTROLS, INSTRUMENTS AND EQUIPMENT NOTE: Some features may not apply to your model or could be optional. NOTE: Some vehicle safety labels are not shown on illustrations. For information VEHICLE SAFETY LABELS on vehicle safety labels, refer to subsection. mmo2011-007-005_a mmo2011-007-006_a ______________...

  • Page 41: Handlebar

    CONTROLS, INSTRUMENTS AND EQUIPMENT mmo2015-008-002_b mmo2008-008-011_b TYPICAL - LH SIDE OF FUEL TANK - 600 ACE TYPICAL AND 900 ACE ONLY 1. Throttle lever 2. To accelerate 1) Handlebar 3. To decelerate The handlebar controls the steering WARNING of the snowmobile. As the handlebar Test the throttle lever operation is rotated to right or left, the skis are turned right or left to steer the snow-...

  • Page 42: Brake Lever

    CONTROLS, INSTRUMENTS AND EQUIPMENT WARNING Test the throttle lever operation each time before starting the en- gine. The lever must return to its the rest position once released. Otherwise, do not start engine. Switching from Thumb to Finger Throttle Position mmo2015-008-100_a CAUTION It is highly recom- IF WANTED, CONTINUE TO ROTATE THE...

  • Page 43: Parking Brake Lever

    CONTROLS, INSTRUMENTS AND EQUIPMENT mmo2014-004-001_a mmo2009-005-006_a TYPICAL 1. Brake lever TYPICAL — ENGAGE MECHANISM 2. To apply brake Step 1: Apply and hold regular brake Step 2: Lock brake lever using parking brake lever 4) Parking Brake Lever Parking brake lever is located on the LH To Release Parking Brake side of handlebar.

  • Page 44: Emergency Engine Stop Switch

    CONTROLS, INSTRUMENTS AND EQUIPMENT MONITORING SYSTEM refer to The Ski-Doo learning key, limits the D.E.S.S. malfunction codes informa- speed of the snowmobile and the en- tion. gine torque, therefore enabling first time users and less experienced op- The tether cord cap has an integrated erators to learn how to operate the D.E.S.S.

  • Page 45: Multifunction Switch

    CONTROLS, INSTRUMENTS AND EQUIPMENT mmo2014-004-001_c ALL MODELS EXCEPT 550F mmo2016-008-201_a 1. Start button ON POSITION 2. Headlights dimmer switch 3. Heated grips All operators of the snowmobile 4. Heated throttle lever should familiarize themselves with the 5. Mode/set button function of the emergency engine stop 5 5 5 5 5 5 5 5 0 0 0 0 F F F F switch by using it several times on first outing and whenever stopping the en-...
  • Page 46 CONTROLS, INSTRUMENTS AND EQUIPMENT 5 5 5 5 5 5 5 5 0 0 0 0 F F F F M M M M o o o o d d d d e e e e l l l l s s s s Heated Grips and Throttle Lever Switch E E E E - - - - T T T T E E E E C C C C...

  • Page 47: Gearshift Lever

    CONTROLS, INSTRUMENTS AND EQUIPMENT 5 5 5 5 5 5 5 5 0 0 0 0 F F F F M M M M o o o o d d d d e e e e l l l l s s s s GEARBOX OPERATION Refer to OPERATING INSTRUCTIONS...

  • Page 48: Front Bumper And Rack Rail

    CONTROLS, INSTRUMENTS AND EQUIPMENT mmo2009-004-013_a TYPICAL 1. Rear rack rail NOTICE Do not use skis to pull or lift snowmobile. 12) Gauge WARNING 609900806-003_a TYPICAL Never adjust or set functions on 1. Tool kit the multifunction gauge while rid- ing the vehicle. 11) Front Bumper and Rack Rail Gauge Description...
  • Page 49 CONTROLS, INSTRUMENTS AND EQUIPMENT 1) Speedometer 3) Digital Display Measures vehicle speed (in miles per hour or kilometers per hour depending on the setting). mmo2008-003-013_h 1. Digital display WARNING Never adjust or set functions on the multifunction gauge while rid- ing the vehicle, you could lose con- mmo2008-003-014 trol.
  • Page 50 CONTROLS, INSTRUMENTS AND EQUIPMENT PILOT LAMP(S) BEEPER DESCRIPTION Two stroke engine: Injection oil level is low. Stop vehicle in a safe place then, replenish injection oil reservoir. 4 short Four stroke engines: Low engine oil pressure. Stop vehicle beeps every in a safe place then, check oil level.
  • Page 51 CONTROLS, INSTRUMENTS AND EQUIPMENT Gauge Features AVAILABLE INDICATIONS IN NUMERICAL DISPLAY Functions WT 550F 600 HO E-TEC 600 ACE 900 ACE A) Odometer B) Trip meter “A” or “B” N.A. C) Trip hour meter N.A. D) Fuel level E) E-TEC engine storage mode N.A.
  • Page 52 CONTROLS, INSTRUMENTS AND EQUIPMENT A) Odometer Records the total distance travelled. 5 5 5 5 5 5 5 5 0 0 0 0 F F F F The odometer is displayed on the digi- tal display. 6 6 6 6 0 0 0 0 0 0 0 0 H H H H O O O O E E E E - - - - T T T T E E E E C C C C a a a a n n n n d d d d 6 6 6 6 0 0 0 0 0 0 0 0 A A A A C C C C E E E E M M M M o o o o d d d d e e e e l l l l s s s s Press the SET (S) button to select mmo2008-003-013_j odometer mode.

  • Page 53: Passenger (1+1) Seat

    CONTROLS, INSTRUMENTS AND EQUIPMENT Passenger Seat Installation 1. Place the passenger seat facing for- ward on the storage compartment lid. 2. Slightly incline the passenger seat towards front and engage both seat hooks in the storage compartment lid slots. mmo2008-003-020_a FUEL LEVEL 1.

  • Page 54: Passengers Handholds

    CONTROLS, INSTRUMENTS AND EQUIPMENT 14) Passengers Handholds 17) Storage Compartment Fixed handholds on each side of the The storage compartment is located passenger seat. behind the driver's seat. WARNING The storage compartment must be properly latched and must not con- tain any sharp, heavy or breakable objects.

  • Page 55: Rear Rack

    CONTROLS, INSTRUMENTS AND EQUIPMENT J-Type Hitch (European Models) CAUTION When closing lid with the passenger seat installed, Attaching an Equipment secure with the retaining strap. 18) Rear Rack WARNING All objects in rear rack must be properly latched. Do not carry any breakable objects.

  • Page 56: Upper Side Panels

    CONTROLS, INSTRUMENTS AND EQUIPMENT mmo2009-004-038_a 1. Rubber tie mmo2009-004-040_a 3. Slide hood towards front to free the TYPICAL 1. Rubber tie tabs from their slots. 2. Lift the rear portion of panel to free Hood Installation the plastic tab from the console. 1.

  • Page 57: Lower Side Panels

    CONTROLS, INSTRUMENTS AND EQUIPMENT mmo2011-006-100_a TYPICAL mmo2009-004-045_a 1. Console hook 1. Clip 2. Console slot 3. Panel center tabs 3. Push and hold lock tab in, then pull 3. Insert the rear tab into the console panel up and rearward. slot.

  • Page 58: Drive Belt Guard

    CONTROLS, INSTRUMENTS AND EQUIPMENT Lift rear portion of drive belt guard, then release from front tabs by pivot- ing the guard outwards. Drive Belt Guard Installation When reinstalling drive belt guard, position its cutaway toward front of snowmobile. Place the front LH slot of the drive belt guard over the longest tab.

  • Page 59: Eco/Standard/Sport Mode Switch (600 Ace And 900 Ace Only)

    CONTROLS, INSTRUMENTS AND EQUIPMENT NOTE: Drive belt guard is purposely made slightly oversize to maintain ten- sion on its pins and retainers prevent- ing undue noise and vibration. It is im- portant that this tension be maintained when reinstalling. mmo2008-003-063_a 1.

  • Page 60: Fuel And Oil

    FUEL AND OIL Fuel Requirements MINIMUM FUEL ENGINE OCTANE TYPE NOTICE Always use fresh gaso- RATING line. Gasoline will oxidize; the re- 550F 87 AKI sult is loss of octane, volatile com- 600 ACE (RON+MON)/2 pounds, and the production of gum Fuel 900 ACE 92 RON...

  • Page 61: Fueling Procedure

    – Never use an open flame to oil injected 2-stroke engine may not check fuel level. be covered by the BRP limited war- – Never smoke or allow flame or ranty. spark in vicinity.

  • Page 62: Injection Oil Level Verification

    NOTICE The engine of this snow- mobile has been developed and val- NOTICE mismatch idated using the BRP XPS™ Synthe- reservoir cap with fuel tank cap. tic 4-stroke oil. BRP recommends the use of its XPS Synthetic 4-stroke WARNING oil or equivalent. Damages caused by oil which is not suitable for this Wipe off any oil spills.

  • Page 63: Break-In Period

    BREAK-IN PERIOD Operation During Break-In – Avoid pulling a load. – Avoid high speed cruising. A break-in period of 10 operating hours or 500 km (300 mi) is required for the vehicle. After the break-in period, the vehicle should be inspected by an authorized Ski-Doo dealer, repair shop, or person MAIN- of your own choosing.

  • Page 64: Operating Modes (600 Ace And 900 Ace Only)

    OPERATING MODES (600 ACE AND 900 ACE ONLY) To increase power, press the switch WARNING upwards. To decrease power, press Whenever changing operating the switch downwards. mode, make sure to maintain situ- ational awareness while riding. ECO Mode (Fuel Economy Mode) When ECO mode is selected (fuel economy mode), vehicle torque and speed are limited whereby an optimal...

  • Page 65: Learning Key Modes

    OPERATING MODES (600 ACE AND 900 ACE ONLY) To activate Sport mode when in Stan- dard mode, press top end of switch once. To activate Sport mode when in ECO mode, press top end of switch twice. To activate Standard mode when in ECO mode, press top end of switch once.

  • Page 66: Operating Instructions

    OPERATING INSTRUCTIONS Engine Starting Procedure 6 6 6 6 0 0 0 0 0 0 0 0 H H H H O O O O E E E E - - - - T T T T E E E E C C C C M M M M o o o o d d d d e e e e l l l l s s s s If the starter does not operate and you Procedure ENGINE...

  • Page 67: Vehicle Warm-Up

    OPERATING INSTRUCTIONS mmo2008-005-007 3. Attach the other end of emergency mmo2008-005-014_a rope to the starter clip supplied in 6. Pull the rope using a sharp, crisp pull the tool kit. so the rope comes free of the drive pulley. WARNING When starting the snowmobile in an emergency situation, using drive pulley, do not reinstall the...

  • Page 68: Gearbox Operation

    OPERATING INSTRUCTIONS NOTICE If vehicle does not move Neutral when throttle is applied, stop en- When set in neutral (N), the gearbox gine, remove tether cord cap from disengages the pulleys from the track. the engine cut-off switch, then do the following.

  • Page 69: Towing An Accessory

    OPERATING INSTRUCTIONS Shut off the engine using either the Remove the drive belt, attach the rope emergency engine stop switch or by to the ski legs (spindles), have some- pulling off the tether cord cap from the one sit on the towed snowmobile to ac- engine cut-off switch.

  • Page 70: Tune Your Ride

    TUNE YOUR RIDE Rear Suspension WARNING Adjustments Suspension adjustment could af- fect vehicle handling. Always take time to familiarize yourself with the vehicle's behavior after any suspension adjustment have been made. Snowmobile handling and comfort de- pend upon suspension adjustments. mmo2011-006-005_a Choice of suspension adjustments SC5-U REAR SUSPENSION...
  • Page 71 TUNE YOUR RIDE ACTION RESULT Lighter ski pressure under acceleration Increasing stopper More center spring straps travel length More bump absorption capability Heavier ski pressure under acceleration Decreasing stopper Less center spring travel straps length Less bump absorption capability NOTE: Stopper strap could be set to position 1, 2, 3, 4 and 5.
  • Page 72 TUNE YOUR RIDE mmo2015-007-103_b STOPPER STRAP POSITION 3 (3RD HOLE) 1. Free holes 2. 3rd hole from end 3. Towards rear 4. Tip of strap touching strap axis 5. Two holes left open between screw head and nut 6. Towards front NOTE: Decreasing the stopper strap mmo2015-007-101_b length may reduce comfort.
  • Page 73 TUNE YOUR RIDE Rear Spring Preload Rear spring preload has an effect on comfort, ride height and load compen- sation. Also, adjusting rear spring preload shifts more or less weight to the snow- mobile front end. As a result, more or less weight is applied to the skis.
  • Page 74 TUNE YOUR RIDE mmo2007-009-006_a TYPICAL — LH SIDE 1. Adjust spring preload mmo2010-003-014_a CAM TYPE - MOTION CONTROL SHOCK ABSORBER 1. Spring preload adjustment cam 2. Increase preload 3. Decrease preload NOTE: For cam type preload adjuster, use the suspension adjustment tool provided in the tool kit.
  • Page 75 TUNE YOUR RIDE Rear Suspension Extension Stabilizer Cam Stabilizer cam is used to control the suspension extension stroke. Stabilizer cam setting has an effect on manoeuvrability, traction and reverse capability. mmo2010-007-024_a PARTIALLY LIFTED 1. Adjustment cam 2. Lower stop block mbl2012-004-001_a 1.

  • Page 76: Vehicle Behavior Related To Suspension Adjustment

    TUNE YOUR RIDE Vehicle Behavior Related to Suspension Adjustment PROBLEM CORRECTIVE MEASURES Check ski alignment and camber angle adjustment. See an authorized Ski-Doo dealer. Front suspension wandering Reduce ski ground pressure. – Increase center spring preload. – Reduce rear spring preload. Reduce rear suspension front arm pressure.

  • Page 77: Vehicle Transportation

    VEHICLE TRANSPORTATION Make sure that oil reservoir and fuel tank caps are properly installed. Tilt bed trailers can easily be equipped with a winch mechanism to afford maximum safety in loading. Simple as it may seem, never drive your snow- mobile onto a tilt bed trailer or any other kind of trailer or vehicle.
  • Page 78 VEHICLE TRANSPORTATION This page is intentionally blank ______________...

  • Page 79: Maintenance

    MAINTENANCE _______________...

  • Page 80: First Inspection

    FIRST INSPECTION This vehicle should be serviced by an authorized Ski-Doo dealer, repair shop, or per- son of your own choosing. The first inspection is very important and must not be neglected. NOTE: The first inspection is at the expense of the vehicle owner. Signature of the Authorized Ski-Doo Date of inspection dealer, repair shop, or person...
  • Page 81 FIRST INSPECTION FIRST INSPECTION (550F) AFTER THE FIRST 1 500 KM (1,000 MI) Models with gearbox: Check oil level FIRST INSPECTION (600 HO E-TEC, 600 ACE AND 900 ACE) AFTER THE FIRST 1 500 KM (1,000 MI) Models with gearbox: Check oil level Adjust and align track Adjust drive chain FIRST INSPECTION (600 ACE AND 900 ACE)

  • Page 82: Maintenance Schedule

    Ski-Doo dealer has an in-depth technical knowledge and tools to service the Ski-Doo snowmobile, the emission-related warranty is not conditioned on the use of an authorized Ski-Doo dealer or any other establishment with which BRP has a commercial relationship. For emission-related warranty claims, BRP is limiting...
  • Page 83 MAINTENANCE SCHEDULE EVERY 3 000 KM (2,000 MI) OR 1 YEAR AT PRESEASON (WHICHEVER COMES FIRST) Lubricate rear suspension (lubricate whenever the vehicle is used in wet conditions (rain, puddles) Inspect front suspension Inspect tie-rod ends and alignment Inspect fuel lines and connections Inspect and adjust oil injection pump Clean, inspect and adjust carburetors Inspect engine fan belt...
  • Page 84 MAINTENANCE SCHEDULE 6 6 6 6 0 0 0 0 0 0 0 0 H H H H O O O O E E E E - - - - T T T T E E E E C C C C M M M M o o o o d d d d e e e e l l l l s s s s EVERY 3 000 KM (2,000 MI) OR 1 YEAR AT PRESEASON (WHICHEVER COMES FIRST) Perform pre-ride inspection...
  • Page 85 MAINTENANCE SCHEDULE EVERY 10 000 KM (6,000 MI) OR 3 YEARS (WHICHEVER COMES FIRST) Replace spark plugs Inspect oil pump strainer and clean if needed EVERY 5 YEARS Replace engine coolant Replace in-line fuel filter _______________...
  • Page 86 MAINTENANCE SCHEDULE 6 6 6 6 0 0 0 0 0 0 0 0 A A A A C C C C E E E E a a a a n n n n d d d d 9 9 9 9 0 0 0 0 0 0 0 0 A A A A C C C C E E E E M M M M o o o o d d d d e e e e l l l l s s s s EVERY 3 000 KM (2,000 MI) OR 1 YEAR (WHICHEVER COMES FIRST) Perform pre-ride inspection...
  • Page 87 MAINTENANCE SCHEDULE EVERY 6 000 KM (4,000 MI) OR 2 YEARS (WHICHEVER COMES FIRST) Inspect drive pulley slider shoes and ramps and replace if needed Replace drive pulley O-ring Lubricate splines of the countershaft EVERY 10 000 KM (6,000 MI) OR 3 YEARS (WHICHEVER COMES FIRST) Replace spark plugs EVERY 5 YEARS...

  • Page 88: Maintenance Procedures

    MAINTENANCE PROCEDURES Engine Coolant This subsection includes instructions for basic maintenance procedures. (Except 550F) WARNING WARNING Turn off the engine, remove tether Never open coolant tank cap when cord cap and follow these mainte- engine is hot. nance procedures when perform- ing maintenance.

  • Page 89: Engine Oil (600 Ace / 900 Ace)

    MAINTENANCE PROCEDURES Engine Oil (600 ACE / Recommended Engine Coolant 900 ACE) COOLANT Engine Oil Level Verification LONG LIFE Finland, ANTIFREEZE(F) Norway NOTICE Check level every 10 (P/N 619 590 hours of use and refill if necessary. 204) Sweden Do not overfill. Operating the en- recommended gine with an improper level may LONG LIFE...

  • Page 90: Exhaust System

    MAINTENANCE PROCEDURES Engine Stopper CAUTION Engine oil can be (600 HO E-TEC) very hot. Engine Stopper Adjustment WARNING The engine stopper is located on the Wipe off any oil spills. Oil is highly LH front engine support, in front of the flammable when heated.

  • Page 91: Brake Fluid

    MAINTENANCE PROCEDURES mmo2010-009-007_b mmo2010-009-001_a TIGHTENING SEQUENCE 1. Opening 2. Feeler gauge STOPPER SCREW TIGHTENING 6. Place feeler gauge between engine TORQUE stopper and rubber stop block (on 10 N•m ± 2 N•m (89 lbf•in ± 18 lbf•in) engine). NOTE: Do not insert the feeler gauge NOTICE Serious pulley damage too deep, as it will pass over the bump...

  • Page 92: Gearbox Oil

    XPS Synthetic gear oil at all times. Damages caused by oil which is not suitable for the gearbox will not be covered by the BRP lim- ited warranty. Access to Gearbox Remove upper and lower side panels,...

  • Page 93: Drive Belt

    MAINTENANCE PROCEDURES 2. Insert the DRIVEN PULLEY OPEN- ING TOOL (P/N 529 017 200) (or the pulley expander provided in the tool box) in the threaded hole on the ad- juster hub. mmo2009-004-034_a TYPICAL 529017200 1. Filler cap DRIVEN PULLEY OPENING TOOL 3.
  • Page 94 MAINTENANCE PROCEDURES NOTE: The maximum drive belt life span is obtained when drive belt is in- stalled with arrows in the direction of rotation. mmo2011-003-010_a 1. Adjuster hub mmo2011-002-006_a 2. Clamping bolt 1. To be pointed in the direction of rotation 4.

  • Page 95: Drive Pulley

    MAINTENANCE PROCEDURES 6. Install drive belt guard. This adjustable drive pulley allows set- ting maximum engine RPM to maintain 7. Install side panel. maximum power. NOTE: This setting is correct as a pre- Calibration screws should be adjusted liminary adjustment for most models. so that actual maximum engine RPM In some cases, when starting the en- matches the maximum horsepower...

  • Page 96: Track

    MAINTENANCE PROCEDURES Calibration screws initially set at posi- WARNING tion 4 and changed to position 6 will NEVER disassemble or modify the increase maximum engine RPM by drive pulley. 400 RPM. Improper assembly or modifica- tions could cause the pulley to ex- Procedure plode violently under the stress Loosen the lock nut just enough to get...
  • Page 97 T T T T r r r r a a a a c c c c t t t t i i i i o o o o n n n n E E E E n n n n h h h h a a a a n n n n c c c c i i i i n n n n g g g g P P P P r r r r o o o o d d d d u u u u c c c c t t t t s s s s To prevent serious injury to indi- If your snowmobile is equipped with viduals near the snowmobile: a BRP approved studded track, PRO- – NEVER stand behind or near a CEED WITH A VISUAL INSPECTION moving track.
  • Page 98 MAINTENANCE PROCEDURES mmr2009-133-003_b mmr2009-133-003_a DEFLECTION SETTING LOAD READING 1. Bottom O-ring set to specification 1. Upper O-ring 6. Place upper O-ring to 0 kgf (0 lbf). 10. Load reading must be as per the following table. 7. Position the tensiometer on track, halfway between front and rear idler TRACK ADJUSTMENT wheels.
  • Page 99 MAINTENANCE PROCEDURES Track Alignment WARNING Before checking track alignment, ensure that the track is free of all particles which could be thrown out while track is rotating. Keep hands, tools, feet and clothing clear of track. Always lift the snow- mobile on a wide-base stand with mmr2008-048-008_a a rear deflector panel.

  • Page 100: Suspension

    MAINTENANCE PROCEDURES WARNING Remove the tether cord cap from engine cut-off switch before per- forming any maintenance or ad- justment, unless otherwise spec- ified. Vehicle must be parked in a safe place, away from the trail. 1. Remove the tether cord cap from A05F0EB engine cut-off switch.

  • Page 101: Skis

    MAINTENANCE PROCEDURES mmo2011-006-003_a mmo2010-007-014_a 1. Grease fittings LH SIDE SHOWN 1. Grease fitting 2. Steering arm Skis Wear and Condition of Skis and Runners Check the condition of the skis and ski runner carbides. If worn, contact an mmo2011-006-004_a authorized Ski-Doo dealer. 1.

  • Page 102: Lights

    MAINTENANCE PROCEDURES WARNING Do not use a higher rated fuse. WARNING If fuse has burnt out, source of mal- function should be determined and corrected before restarting. See an authorized Ski-Doo dealer for servicing. mmo2009-004-036_b TYPICAL - PULL STRIP Fuse Location 5 5 5 5 5 5 5 5 0 0 0 0 F F F F The 20A charging system fuse is lo- cated on on left side of vehicle, be-...
  • Page 103 MAINTENANCE PROCEDURES mmo2007-009-063_a mmo2007-009-061_a Step 1: Push both sides 1. Locking tab Step 2: Pull to release 2. Gently pull on multifunction gauge 1. Retaining clip and set aside. 5. Pull bulb and replace. Properly rein- stall parts. mmo2007-009-062_a mmo2007-009-064_a 3.
  • Page 104 MAINTENANCE PROCEDURES Taillight Bulb Replacement 1. Remove taillight housing by care- fully pulling on lens at both ends using an equal force. NOTICE If taillight housing is not removed perpendicularly to the tail- light holder, mounting pins may break and taillight housing will have to be replaced.

  • Page 105: Vehicle Care

    To remove grease, oil and grime, use BRP HEAVY DUTY CLEANER (P/N 293 110 001). NOTICE Do not use Heavy duty cleaner on decals or vinyl. To remove stubborn dirt from all plastic and vinyl surfaces, use XPS ALL PUR- POSE CLEANER (P/N 219 701 709).

  • Page 106: Storage

    STORAGE Engine Lubrication During summer, or when a snowmo- bile is not in use for more than three months, proper storage is necessary. Engine Lubrication Procedure (550F) STORAGE NOTICE Fuel stabilizer should Clean the vehicle be added prior to engine lubrica- tion to ensure carburetor protection Protect fuel system by adding fuel against varnish deposits.
  • Page 107 STORAGE 9. Reinstall spark plugs and primary air intake silencer. Engine Storage Mode (E-TEC) Like other engines, the E-TEC has to be properly lubricated at storage for internal parts protection. The E-TEC system offers a built-in engine lubri- cation function can be initiated by the operator.
  • Page 108 STORAGE mmr2009-004-003 5. When the gauge displays "PUSH S", release all buttons. 6. Again, press and hold the SET but- ton for 2 - 3 seconds. The gauge will display "OIL" when the engine enters storage procedure (sum- merization feature). mmr2009-004-004 Do not touch anything during engine lu- brication cycle.

  • Page 109: Technical Information

    TECHNICAL INFORMATION ______________...

  • Page 110: Vehicle Identification

    VEHICLE IDENTIFICATION Vehicle Description Decal Vehicle Identification Number (VIN) Vehicle description decal is located on VIN is scribed on the vehicle descrip- right hand side of the tunnel. tion decal. See above. It is also en- graved on the tunnel, near the vehicle description decal.
  • Page 111 VEHICLE IDENTIFICATION mmo2011-003-003_a 600 ACE ENGINE 1. Engine identification number mmo2014-004-007_a 900 ACE ENGINE 1. Engine identification number ______________...

  • Page 112: Noise Emission And Vibration Values (All Countries Except Canada/United States)

    NOISE EMISSION AND VIBRATION VALUES (ALL COUNTRIES EXCEPT CANADA/UNITED STATES) MODEL 550F 600 HO E-TEC 600 ACE 900 ACE NOISE EMISSION AND VIBRATION VALUES 101,1 dB @ 96,7 dB @ 90,4 dB @ 92,7 dB @ Sound power 3400 RPM 4050 RPM 3625 RPM 3625 RPM...

  • Page 113: Ec-Declaration Of Conformity

    The EC-Declaration of Conformity does not appear in this version of the Operator's Guide. Please refer to the printed version that was delivered with your vehicle. ddd2009-001...

  • Page 114: Epa Certified Engines

    Engine Emissions EPA Emission Regulations Information Ski-Doosnowmobiles manufac- tured by BRP are certified to the EPA Manufacturer's Responsibility as conforming to the requirements of the regulations for the control of air Beginning with 2007 model year en- pollution from new snowmobile en- gines, snowmobile manufacturers of gines.

  • Page 115: Radio Frequency Digitally Encoded Security System

    RADIO FREQUENCY DIGITALLY ENCODED SECURITY SYSTEM (RF D.E.S.S. KEY) This device complies with FCC Part 15 and Industry Canada license exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

  • Page 116: Specifications

    SPECIFICATIONS SYSTEM MODELS ENGINE 550F Rotax ® 552, fan-cooled (axial fan), Engine type cylinder reed porting Cylinders Displacement 553.4 cm³ (33.8 in³) Bore 76 mm (3 in) Stroke 61 mm (2.4 in) Maximum horsepower RPM 6800 RPM Carburetion 2 x VM-30 Exhaust system Single tuned pipe, baffle muffler XPS INJECTION OIL...
  • Page 117 SPECIFICATIONS SYSTEM MODELS ENGINE 600 HO E-TEC Rotax ® 593, liquid cooled w/Reed Engine type valve, 3D-RAVE Cylinders Displacement 594.4 cm³ (36.27 in³) Bore 72 mm (2.83 in) Stroke 73 mm (2.87 in) Maximum horsepower RPM 8100 RPM Fuel injection system E-TEC direct injection Exhaust system Single tuned pipe, baffle muffler...
  • Page 118 SPECIFICATIONS SYSTEM MODELS ENGINE 600 ACE Rotax 602, liquid cooled, 4-stroke, Engine type D.O.H.C., dry sump. Cylinders Displacement 600 cm³ (36.6 in³) Bore 74 mm (2.91 in) Stroke 69.7 mm (2.74 in) Maximum horspower RPM 7250 RPM Fuel injection system Multi point EFI, 46 mm throttle body Exhaust system Double front pipe, baffle muffler...
  • Page 119 SPECIFICATIONS SYSTEM MODELS ENGINE 900 ACE Rotax 903, liquid cooled, 4-stroke, Engine type D.O.H.C., dry sump Cylinders Displacement 899 cm³ (54.9 in³) Bore 74 mm (2.9 in) Stroke 69.7 mm (2.74 in) Maximum horsepower RPM 7250 RPM Exhaust system Single front pipe, baffle muffler XPS 4-STROKE SYNTHETIC OIL Engine oil (P/N 293 600 112)
  • Page 120 SPECIFICATIONS SYSTEM MODELS DRIVE SYSTEM ALL MODELS 550F eDrive II LC 600 HO TRA III™ E-TEC Type 600 ACE eDrive II LC eDrive II 900 ACE Drive pulley 550F 2600 ± 100 RPM 600 HO 3000 RPM ± 100 Engagement E-TEC 600 ACE / 2200 RPM ±...
  • Page 121 SPECIFICATIONS SYSTEM MODELS DRIVE SYSTEM (cont'd) ALL MODELS Equal distance between edges of Track alignment track guides and slider shoes BRAKE SYSTEM ALL MODELS Brake system Hydraulic, REV-XP brake type Brake fluid DOT 4 SUSPENSION ALL MODELS Front suspension XU-LTS Front shock Motion control Front suspension max.
  • Page 122 SPECIFICATIONS SYSTEM MODELS ELECTRICAL SYSTEM 600 HO E-TEC Lightning system output 12V/1200 W Headlights bulb HI/LOW beam 2 x 60/55 Watts (H-4) Taillight bulb P 21/5 W Type NGK PZFR6F or equivalent Spark plug 0.75 mm ± 0.05 mm (.03 in ± .002 in) (not adjustable) F 1: Battery 30 A F 2: Start...
  • Page 123 SPECIFICATIONS SYSTEM MODELS ELECTRICAL SYSTEM 600 ACE Lightning system output 12V/650 W Headlights bulb HI/LOW beam 2 x 60/55 Watts (H-4) Taillight bulb 2 x P 21/5 W Type NGK-MR7Bi-8 or equivalent Spark plug .8 mm (.031 in) F 1: Battery 30 A F 2: Relay/start button F 3: Starter solenoid...
  • Page 124 SPECIFICATIONS SYSTEM MODELS ELECTRICAL SYSTEM 900 ACE Lightning system output 650 Watts @ 6000 RPM Headlights bulb HI/LOW beam 2 x 60/55 Watts (H-4) Taillight bulb 2.6 W / 139m W LED Type NGK-MR7Bi-8 or equivalent Spark Plug 0.8 mm (.031 in) F1: Battery 30 A F2: Relay / Start button...
  • Page 125 SPECIFICATIONS SYSTEM MODELS WEIGHT AND DIMENSIONS ALL MODELS 550F 270 kg (596 lb) 600 ACE 285 kg (629 lb) 600 HO 286 kg (630 lb) E-TEC 298 kg (657 lb) Dry weight 900 ACE 550F 314 kg (692 lb) 600 HO 303 kg (669 lb) E-TEC 316 kg (696 lb)
  • Page 126 SPECIFICATIONS This page is intentionally blank ______________...

  • Page 127: Troubleshooting

    TROUBLESHOOTING ______________...

  • Page 128: Troubleshooting Guidelines

    TROUBLESHOOTING GUIDELINES ELECTRIC STARTER DOES NOT WORK 1. Emergency engine stop switch in OFF position or tether cord cap not installed on engine cut-off switch. – Place the emergency engine stop switch in the ON position and install tether cord cap (on engine cut-off switch. 2.
  • Page 129 TROUBLESHOOTING GUIDELINES ENGINE LACKS ACCELERATION OR POWER (cont’d) 7. Drive belt worn too thin. – If the drive belt has lost more than 3 mm (1/8 in) of its original width, it will af- fect vehicle performance. – Replace drive belt. 8.

  • Page 130: Monitoring System

    MONITORING SYSTEM Pilot Lamps, Messages and Beeper Codes Gauge pilot lamp(s) will inform you if an anomaly occurs or to inform you of a particular condition. mmo2008-003-024_a TYPICAL — PILOT LAMPS Pilot lamp can flash alone or in combi- nation with another lamp. Beeper codes will be emitted to catch your attention.
  • Page 131 MONITORING SYSTEM NOTE: Some of the listed pilot lamps do not apply to all models. PILOT LAMP(S) BEEPER DESCRIPTION Engine is overheating, reduce snowmobile speed and run in loose snow or stop engine immediately and let engine MAINTENANCE cool down. Check coolant level, refer to .
  • Page 132 MONITORING SYSTEM PILOT LAMP(S) BEEPER DESCRIPTION Short Shutdown procedure in force due to engine overheating or beeps fuel pump problem, remove tether cord cap from engine — repeating cut-off switch and contact an authorized Ski-Doo dealer, repair rapidly shop, or person of your own choosing. 2 short Good key, vehicle ready to operate.

  • Page 133: Warranty

    WARRANTY ______________...

  • Page 134: Brp Limited Warranty Usa And Canada: 2018 Ski-Doo ® Snowmobiles

    BRP. BRP reserves the right to modify this limited warranty at any time, be- ing understood that such modification will not alter the warranty conditions appli- cable to the products sold while this warranty is in effect.
  • Page 135 BRP will not honor this limited warranty to any private use owner or commercial use owner if one of the preceding conditions has not been met. Such limitations are necessary in order to allow BRP to preserve both the safety of its products, and also that of its consumers and the general public.
  • Page 136 The customer must cease using the snowmobile upon the appearance of an anom- aly. The customer must notify a servicing BRP dealer within three (3) days of the appearance of a defect, and provide it with reasonable access to the product and reasonable opportunity to repair it.
  • Page 137 In the event of a controversy or a dispute in connection with this limited warranty, BRP suggests that you try to resolve the issue at the dealership level. We recom- mend discussing the issue with the authorized dealer's service manager or owner.

  • Page 138: Epa Emission-Related Warranty

    2. It is free from defects in materials and workmanship that may keep it from meeting the requirements of 40 CFR 1051 and 40 CFR 1060. Where a warrantable condition exists, BRP will repair or replace, as it elects, any part or component with a defect in materials or workmanship that would increase the engine’s emissions of any regulated pollutant within the stated warranty...
  • Page 139 Components Covered The emission-related warranty covers all components whose failure would in- crease an engine’s emissions of any regulated pollutant, including the following listed components: 1. For exhaust emissions, emission-related components include any engine parts related to the following systems: –...
  • Page 140 * In the USA, products are distributed and serviced by BRP US Inc. ______________...

  • Page 141: Brp International Limited Warranty: 2018 Ski-Doo ® Snowmobiles

    BRP. BRP reserves the right to modify this warranty at any time, being understood that such modification will not alter the warranty conditions applicable to the products sold while this warranty is in effect.
  • Page 142 – Damage resulting from removal of parts, improper repairs, service, main- tenance, modifications or use of parts or accessories not manufactured or approved by BRP which in its reasonable judgement are either incompatible with the product or adversely affect its operation, performance and durability, or resulting from repairs done by a person that is not an authorized servicing Ski-Doo Distributor/Dealer;...
  • Page 143 BRP will not honour this limited warranty to any private use owner or commercial use owner if one of the preceding conditions has not been met. Such limitations are necessary in order to allow BRP to preserve both the safety of its products, and also that of its consumers and the general public.
  • Page 144 BRP reserves the right to improve or modify products from time to time without as- suming any obligation to modify products previously manufactured. 8) TRANSFER If the ownership of a product is transferred during the warranty coverage period, this limited warranty, subject to its terms and conditions, shall also be transferred...

  • Page 145: Brp Limited Warranty For The European And The

    BRP. BRP reserves the right to modify this warranty at any time, being understood that such modification will not alter the warranty conditions applicable to the products sold while this warranty is in effect.
  • Page 146 – Damage resulting from removal of parts, improper repairs, service, main- tenance, modifications or use of parts or accessories not manufactured or approved by BRP which in its reasonable judgement are either incompatible with the product or adversely affect its operation, performance and durability, or resulting from repairs done by a person that is not an authorized servicing Ski-Doo Distributor/Dealer;...
  • Page 147 BRP will not honour this limited warranty to any private use owner or commercial use owner if one of the preceding conditions has not been met. Such limitations are necessary in order to allow BRP to preserve both the safety of its products, and also that of its consumers and the general public.
  • Page 148 We recommend discussing the issue with the authorized Ski-Doo Distribu- tor/Dealer's service manager or owner. If the matter still remains unresolved, contact BRP by filling out the customer con- tact form at www.brp.com or contact BRP by mail at one of the addresses listed CONTACT US under the section of this guide.
  • Page 149 ADDITIONAL TERMS AND CONDITIONS FOR FRANCE ONLY The following terms and conditions are applicable to products sold in France only: The seller shall deliver goods that are complying with the contract and shall be responsible for defects existing upon delivery. The seller shall also be responsible for defects resulting from packaging, assembling instructions or the installation when it is its responsibility per the contract or if accomplished under its responsibility.
  • Page 150 This page is intentionally blank ______________...

  • Page 151: Customer Information

    CUSTOMER INFORMATION ______________...

  • Page 152: Privacy Information

    PRIVACY INFORMATION BRP wishes to inform you that your coordinates will be used for safety and war- ranty related purposes. Furthermore, BRP and its affiliates may use its customer list to distribute marketing and promotional information about BRP and related products.

  • Page 153: Contact Us

    CONTACT US South America www.brp.com Rua James Clerck Maxwell, 230 North America TechnoPark Campinas SP 13069-380 Brazil 565 de la Montagne Street Valcourt (Québec) J0E 2L0 Asia Canada Sturtevant, Wisconsin, U.S.A. 15/F Parale Mitsui Building,8 10101 Science Drive Higashida-Cho, Kawasaki-ku...

  • Page 154: Change Of Address/Ownership

    Notifying BRP, even after the expiration of the limited warranty, is very important as it enables BRP to reach the snowmobile owner if necessary, like when safety re- calls are initiated. It is the owner’s responsibility to notify BRP.
  • Page 155 CHANGE OF ADDRESS/OWNERSHIP ______________...
  • Page 156 CHANGE OF ADDRESS/OWNERSHIP This page is intentionally blank ______________...
  • Page 157 CHANGE OF ADDRESS/OWNERSHIP ______________...
  • Page 158 CHANGE OF ADDRESS/OWNERSHIP This page is intentionally blank ______________...
  • Page 159 CHANGE OF ADDRESS/OWNERSHIP NOTES ______________...
  • Page 160 CHANGE OF ADDRESS/OWNERSHIP NOTES ______________...
  • Page 161 CHANGE OF ADDRESS/OWNERSHIP NOTES ______________...
  • Page 162 CHANGE OF ADDRESS/OWNERSHIP NOTES ______________...
  • Page 163 GUIDE DU CONDUCTEUR, SÉRIE SKANDIC / ANGLAIS FAIT AU / MADE IN CANADA U/M:P.C. ®™ AND THE BRP LOGO ARE TRADEMARKS OF BOMBARDIER RECREATIONAL PRODUCTS INC. OR ITS AFFILIATES. ©2017 BOMBARDIER RECREATIONAL PRODUCTS INC. ALL RIGHTS RESERVED. PRINTED IN CANADA.

This manual is also suitable for:

Ski-doo skandic 600 ace 2018

Table of Contents
