Maintenance - Craftsman CMCE521 Instruction Manual

English
Digital Gauge Display (Fig. A, E, F)
The digital gauge display
amount of pressure being applied to the item being inflated
and also serves as a pressure gauge.
Refer to the Using the inflator as a Pressure gauge section.
To turn the digital gauge display on, install the battery
pack 11 into the inflator and squeeze the trigger switch
Refer to the switching On section.
Switching On (Fig. A, F)

WARNING: Risk of bursting. Do not leave unit
running unattended. Overinflation of tires and
other items could result in serious injury and
property damage.
nOTE: When powered on, the digital gauge display 4 on
the inflator will remain on for approximately 0.5 minutes
before the display shuts off/goes into sleep mode. This
occurs when the unit is not operating. To wake up the
system, press the trigger switch 1 . At this time the digital
gauge display will turn on and the inflator is ready for use.
To Inflate Using High Pressure (Fig. A, F)

WARNING: Risk of bursting. Excessive air pressure
may cause a hazardous risk of bursting or personal
injury. Check the manufacturer's maximum pressure
rating for items being inflated.

Improperly attached accessories or hoses can become
detached under pressure and can cause serious injury.
Possible air leaks can cause false pressure readings.
Make sure that all connections are secured tightly.
nOTE: If the pressure rating for the item being inflated is
above 30 PSI, note that the maximum run time is 5 minutes.
The high-pressure air hose
that need more air pressure, such as tires and basketballs.
The air chuck on the high-pressure air hose can be used
without an adaptor to inflate any application that has a valve
stem that fits the air chuck opening.
1. Remove the high-pressure air hose
storage area .
6
2. Attach a nozzle as described in the Fitting the
Accessories section. Attach the air chuck
stem to inflate a tire, or attach an accessory to inflate a
ball or other inflatable.
3. Attach or insert the nozzle into the object being inflated.
4. Squeeze the trigger switch
readout will appear on the digital gauge display
5. To stop the inflator at any time, release the trigger switch.
nOTE: The pressure readout on the digital gauge display
while inflating is a measurement of the changing pressure
between the item and the air hose. To get an accurate
reading, release the trigger switch and wait for the readout
to adjust. The gauge will indicate the pressure in PSI. When
the desired pressure is reached, release the trigger switch
and disconnect the inflator.
10
on the inflator monitors the
4
is meant to be used for objects
2
from the hose
2
3 to the tire
1 to begin inflation. A
nOTE: Maximum PSI for this unit is 150 PSI.
nOTE: You may notice the actual pressure reading drop after
a couple of seconds. This is normal.
Using the Inflator as a Pressure Gauge
(Fig. A)

WARNING: Operating a vehicle with improperly
1 .
inflated tires could result in serious injury.
Your inflator does not have a calibrated pressure gauge;
therefore exact values are not binding. When using the
inflator as a pressure gauge, please verify pressure with a
separate gauge in advance.
1. Connect the high-pressure air hose
be checked.
2. Squeeze the trigger switch
3. The digital gauge will display the item's pressure.
4. After checking, detach the high-pressure air hose
from the application and return the air hose to the
storage area.

MAINTENANCE


WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can cause injury.
Your CRAFTSMAN power tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regular cleaning.
Cleaning

WARNING: Blow dirt and dust out of all air vents with
clean, dry air at least once a week. To minimize the risk
of eye injury, always wear ANSI Z87.1 approved eye
protection when performing this procedure.

WARNING: Never use solvents or other harsh
chemicals for cleaning the non‑metallic parts of the
tool. These chemicals may weaken the plastic materials
used in these parts. Use a cloth dampened only with
water and mild soap. Never let any liquid get inside the
tool; never immerse any part of the tool into a liquid.
Accessories

WARNING: Since accessories, other than those
4 .
offered by CRAFTSMAN, have not been tested with
this product, use of such accessories with this product
could be hazardous. To reduce the risk of injury, only
CRAFTSMAN recommended accessories should be used
with this product.
Recommended accessories for use with your product are
available at extra cost from your local dealer or authorized
service center. If you need assistance in locating any
accessory, please contact CRAFTSMAN. Call 1‑888‑331‑4569.
2 to the item to
for 3 seconds.
1
