Operator's Manual
HomeFill
™
Oxygen Conserving
Cylinder
HF2PCM2KIT
Dealer: This manual MUST be given to the end
user.
User: Before using this cylinder, read this
manual and save for future reference.
For more information regarding
Invacare products, parts, and services,
please visit www.invacare.com
Advertisement
Table of Contents
Related Manuals for Invacare HomeFill HF2PCM2KIT
Summary of Contents for Invacare HomeFill HF2PCM2KIT
- Page 1 ™ Oxygen Conserving Cylinder HF2PCM2KIT Dealer: This manual MUST be given to the end user. User: Before using this cylinder, read this manual and save for future reference. For more information regarding Invacare products, parts, and services, please visit www.invacare.com...
- Page 2 Invacare products are specifically designed and manufactured for use in conjunction with Invacare accessories. Accessories designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products. DANGER Users MUST NOT SMOKE while using this device. Keep all matches, lighted cigarettes or other sources of ignition out of the room in which this product is located.
-
Page 3: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS SPECIAL NOTES ..........4 RECEIVING INSPECTION ........4 INTENDED USE ..........4 SECTION 1—GENERAL GUIDELINES ....5 SECTION 2—FEATURES ........8 SECTION 3—TYPICAL PRODUCT PARAMETERS ..........9 SECTION 4—INSPECTION AND COMPRESSOR INTERFACE ........... 10 Cylinder Prefill Inspection ............... -
Page 4: Special Notes
SPECIAL NOTES SPECIAL NOTES Signal words are used in this manual and apply to hazards or unsafe practices which could result in personal injury or property damage. Refer to the following table for definitions of the signal words. SIGNAL WORD MEANING DANGER Danger indicates an imminently hazardous... -
Page 5: Section 1-General Guidelines
SECTION 1—GENERAL GUIDELINES SECTION 1—GENERAL GUIDELINES WARNING SECTION 1 - IMPORTANT SAFEGUARDS contains important information for the safe operation and use of this product. DO NOT use this product or any available optional equipment without first completely reading and understanding these instructions and any additional instructional material such as Owner’s Manuals, Service Manuals or Instruction Sheets supplied with this product or optional equipment. - Page 6 DO NOT attempt to repair product. DO NOT immerse product in any kind of liquid. Store product in a clean area when not in use. Only use Invacare Corporation HF2PCM2 carrying bag. NEVER smoke in an area where oxygen is being administered.
- Page 7 SECTION 1—GENERAL GUIDELINES WARNING DO NOT allow cylinders to tip or fall. Secure gas cylinders so they cannot fall. For storage, ensure cylinder is ALWAYS in upright position. DO NOT store cylinders near sources of heat or flame. This product is equipped with a relief valve. If you hear a loud hissing or popping sound coming from the product, discontinue use of product, turn the flow selector to the “Off”...
-
Page 8: Section 2-Features
SECTION 2—FEATURES SECTION 2—FEATURES DANGER This product is not intended as a life-sustaining or life-supporting device. Outlet Connection Cannula Indicator Flow Dial Pointer Cylinder Gauge Cylinder Fill Port FIGURE 2.1 Product Diagram Oxygen Conserving Cylinder Part No 1143247... -
Page 9: Section 3-Typical Product Parameters
SECTION 3—TYPICAL PRODUCT PARAMETERS SECTION 3—TYPICAL PRODUCT PARAMETERS CONSERVER S/N RANGE: 75,000+ INLET PRESSURE RANGE: 300 - 2100 psig INTERNAL REGULATED PRESSURE: 50 psig DIMENSIONS: HF2PCM2KIT: Weight 2.0 lbs (.90 kg) HF2PCM2KIT: Overall Length 8.9 in (22.2 cm) HF2PCM2KIT: Diameter 3.2 in (8.13 cm) PULSE SETTINGS: 1,2,3,4, &... -
Page 10: Section 4-Inspection And Compressor Interface
SECTION 4—INSPECTION AND COMPRESSOR INTERFACE SECTION 4—INSPECTION AND COMPRESSOR INTERFACE NOTE: Refer to the HomeFill Compressor Owner’s Manual for compressor operating instructions. Cylinder Prefill Inspection WARNING All cylinders MUST be inspected before attempting to fill; otherwise, injury or damage may occur. NEVER smoke in an area where oxygen is being administered. - Page 11 SECTION 4—INSPECTION AND COMPRESSOR INTERFACE External Examination 1. Examine the outside of the cylinder for the following conditions, and replace the cylinder if they exist: • Dents or dings • Arc Burns • Oil or Grease • Any other signs of damage that might cause a cylinder to be unacceptable or unsafe for use.
- Page 12 "Not to be filled for resale or use by professional users". This cylinder is to be used with the Invacare Venture HomeFill system. This cylinder contains 93 + 3% oxygen produced by an oxygen concentrator using the pressure swing adsorption process.
-
Page 13: Connecting/Disconnecting The Cylinder To/From The Compressor
SECTION 4—INSPECTION AND COMPRESSOR INTERFACE Connecting/Disconnecting the Cylinder to/from the Compressor Connecting the Cylinder to the Compressor WARNING NEVER use tools of any kind to connect/disconnect the cylinder and the compressor. Otherwise, severe injury and/or damage may occur. DO NOT drop oxygen cylinders. Use two hands when handling/transporting oxygen cylinders. - Page 14 SECTION 4—INSPECTION AND COMPRESSOR INTERFACE 4. Momentarily push DOWN on the outer ring (sleeve) of the connector fillport to reset the connector as shown in FIGURE 4.2. NOTE: If the outer ring (sleeve) is in the UP position (GREEN dots not visible), the connector fillport will not be able to accept the cylinder fillport.
- Page 15 SECTION 4—INSPECTION AND COMPRESSOR INTERFACE Compressor Cylinder/Regulator Assembly Cylinder Fillport Connector Fillport Outer Ring (Sleeve) Cylinder Gauge PULL UP Regulator Regulator Cylinder Flow Dial Cylinder Outlet (Cannula) Gauge Connection Cylinder Fillport Power Switch Compressor Cradle Connector Outer Ring Fillport (Sleeve) NOTE: Cylinder bag, cylinder fillport cover and connector fillport cover are not shown for clarity.
- Page 16 SECTION 4—INSPECTION AND COMPRESSOR INTERFACE Disconnecting the Cylinder from the Compressor WARNING NEVER use tools of any kind to connect/disconnect the cylinder and the compressor. Otherwise, severe injury and/or damage may occur. NOTE: For this procedure, refer to FIGURE 4.4 on page 16. 1.
- Page 17 SECTION 4—INSPECTION AND COMPRESSOR INTERFACE 5. When the cylinder fillport is disconnected from the connector fillport, release the outer ring (sleeve) of the connector fillport and use two hands to remove the cylinder from the compressor cradle. WARNING The fillport cover on the connector fillport and the cylinder fillport MUST be replaced after filling and whenever not in use.
-
Page 18: Changing The Carrying Position Of The Cylinder
SECTION 4—INSPECTION AND COMPRESSOR INTERFACE Changing the Carrying Position of the Cylinder NOTE: For this procedure, refer to FIGURE 4.6 on page 19. The cylinder MUST be kept in the cylinder bag at all times except when cleaning. The cylinder MUST be in the bag to ensure the cylinder couples with the HomeFill properly. -
Page 19: Cleaning The Cylinder Bag
SECTION 4—INSPECTION AND COMPRESSOR INTERFACE ii. Thread the end of the belt that has no buckle and retaining loop through the two loops on the cylinder bag. See Detail “B”. NOTE: The web material on the belt should be facing away from the cylinder bag. - Page 20 SECTION 4—INSPECTION AND COMPRESSOR INTERFACE Cleaning the Cylinder Bag NOTE: Skip STEP one if the belt is to be cleaned with the cylinder bag. 1. Unhook and remove the cylinder bag and belt from body. 2. Re-attach the buckle. NOTE: Either end of the belt can be used in this procedure. 3.
-
Page 21: Section 5-Operating Instructions
SECTION 5—OPERATING INSTRUCTIONS SECTION 5—OPERATING INSTRUCTIONS WARNING NEVER smoke in an area where oxygen is being administered. NEVER use near any type of flame or flammable/explosive substances, vapors or atmosphere. NOTE: For this procedure, refer to FIGURE 5.1 on page 22. 1. - Page 22 WARNING When pointer on contents gauge enters red zone, it is recommended to refill the cylinder on the Invacare HomeFill Compressor. NO OXYGEN is delivered in between settings. To obtain desired flow, the indicating pointer must align with a specific number on the dial.
-
Page 23: Section 6-Maintenance
2. Store product in a clean area free from grease, oil, and other sources of contamination. CAUTION DO NOT use cleaning solutions. DO NOT immerse product in any kind of liquid. All repairs MUST be done by Invacare Corporation. Part No 1143247 Oxygen Conserving Cylinder... -
Page 24: Section 7-Cylinder Fill Times
SECTION 7—CYLINDER FILL TIMES SECTION 7—CYLINDER FILL TIMES NOTE: All filling times are approximate and may vary on environmental conditions. Cylinder Concentrator Flow Rate to Patient: Filling (Platinum 5 up to 3 L/min. and Platinum 10 up to 5 Times L/min) HF2PCM2KIT NORMAL... - Page 25 SECTION 7—CYLINDER FILL TIMES NOTES Part No 1143247 Oxygen Conserving Cylinder...
-
Page 26: Limited Warranty
Upon receiving notice of an alleged defect in a product, Invacare will issue a serialized return authorization. It shall be the responsibility of the purchaser to pack the product(s) or part(s) in an appropriate manner to avoid shipping damage and return the product(s) or part(s), at the purchaser’s expense, to either... - Page 27 COMPONENT WITHOUT THE SPECIFIC CONSENT OF INVACARE; PRODUCTS DAMAGED BY CIRCUMSTANCES BEYOND INVACARE’S CONTROL; OR PRODUCTS REPAIRED BY ANYONE OTHER THAN INVACARE OR AN INVACARE SERVICE CENTER. SUCH EVALUATION SHALL BE SOLELY DETERMINED BY INVACARE. THE FOREGOING EXPRESS WARRANTY IS EXCLUSIVE...
- Page 28 Invacare Corporation Invacare, Yes, you can., and the One Invacare Way Medallion Design are registered Elyria, Ohio USA trademarks of Invacare Corporation. 44036-2125 Platinum and HomeFill are trademarks 800-333-6900 of Invacare Corporation Technical Services © 2006 Invacare Corporation 800-832-4707...
