Summary of Contents for FujiFilm Apeos C7070
- Page 1 Reference Guide Optional Units Apeos C7070 Apeos C6570 Apeos C5570 Apeos C4570 Apeos C3570 Apeos C3070 Apeos C2570 March 2023 GM1048E2-5 Edition 1 FUJIFILM Business Innovation Corp.
- Page 2 Preface A guide describing the operations for optional units, such as the Finisher. Refer Descriptions for the following optional products are provided in different guides. Envelope Tray, Extra Center Tray, Left-Side tray, : “Reference Guide Main Unit” Wireless Network Kit, print / scan / FAX function-related products: “Reference Guide - Operations” ...
-
Page 3: Device Components
High Capacity Feeder B1 Device Components Component Function Remaining Volume Display You can check the remaining paper volume. High Capacity Tray (Paper Load paper here. Tray 6) Top Cover Open this cover to clear paper jams. Main specifications Item Specification Paper size A4 , Letter , JIS B5 55 to 216... -
Page 4: Paper And Other Media
Paper and Other Media After loading paper, configure the Paper Tray settings on the Home screen. Refer For details, refer to “Setup” in “Reference Guide - Operations”. The top face of loaded paper is the surface printed on. Pull out the Paper Tray until it stops. When paper is already loaded in the tray, take out the paper. - Page 5 Remove the screw for the guide in front and remove the guide from the Paper Tray . Insert the protrusions under the guide into the Paper Size holes. Insert the Paper Tray protrusions into the Paper Size holes on top of the guide and tighten the screw. Pull the handle for the end guide up ( ), align with the Paper Size while moving the handle along the groove (...
- Page 6 Close the end guide completely. Push in the Paper Tray . Setting special paper and other media Hole punched paper Paper orientation: Load paper with holes facing the right side when viewed from the front of the machine 2 High Capacity Feeder B1...
-
Page 7: Paper Jams
Paper Jams If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper. Gently remove the paper being careful not to tear it. If paper is torn while it is being removed from the machine, remove all the torn pieces making sure that none remain inside the machine. -
Page 8: Paper Tray
Pull the handle ( ) and open the cover ( Remove the jammed paper. Close the cover. Move the unit to the right and connect it with the main unit. Paper Tray Pull out the Paper Tray until it stops. Remove the jammed paper. - Page 9 High Capacity Feeder B2 Device Components Component Function High Capacity Tray (Paper Load paper here. Tray 6) Top Cover Open this cover to clear paper jams. Remaining Volume Display You can check the remaining paper volume. Main specifications Item Specification Paper size A4 , Letter , JIS B5 55 to 216...
- Page 10 Paper and Other Media After loading paper, configure the Paper Tray settings on the Home screen. Refer For details, refer to “Setup” in “Reference Guide - Operations”. The top face of loaded paper is the surface printed on. Pull out the Paper Tray until it stops. When paper is already loaded in the tray, take out the paper.
- Page 11 Remove the screw for the guide in front and remove the guide from the Paper Tray. Insert the protrusions under the guide into the Paper Size holes. Insert the Paper Tray protrusions into the Paper Size holes on top of the guide and tighten the screw. Pull the handle for the end guide up ( ), align with the Paper Size while moving the handle along the groove (...
- Page 12 Setting special paper and other media Hole punched paper Paper orientation: Load paper with holes facing the right side when viewed from the front of the machine 3 High Capacity Feeder B2...
- Page 13 Paper Jams If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper. Gently remove the paper being careful not to tear it. If paper is torn while it is being removed from the machine, remove all the torn pieces making sure that none remain inside the machine.
- Page 14 Pull the handle ( ) and open the cover ( Remove the jammed paper. Close the cover. Move the unit to the right and connect it with the main body. Paper Tray Pull out the Paper Tray until it stops. Remove the jammed paper.
- Page 15 Finisher A2 Device Components Component Function Center Tray Outputs are delivered here. Extension Tray, Guide Wire This prevents the ejected paper from falling out. Top Cover Open this cover to clear paper jams. Front Cover Open this cover to replace staples or remove jammed staples. Staple Cartridge This unit is used to replace staples.
- Page 16 Main specifications Item Specification Type Sort (Offset available) / Stack (Offset available) Paper size Standard size A3, 11 x 17" A5, Postcard (by Japan Post) Paper weight 52 to 256 (g/m Tray capacity No staple (sheets) With staples 30 copies or 500 sheets JIS B4 (sheets) A3 or greater (sheets)
- Page 17 Number of sheets that can be stapled (Approximation: For A4) Uncoated Coated Paper weight (g/m 52 to 90 91 to 105 106 to 128 129 to 150 151 to 176 177 to 220 221 to 256 -: Ejection is not available. 4.1 Device Components...
-
Page 18: Outputting Paper
Outputting Paper Extension Tray To eject SEF paper, pull out the Extension Tray and guide wire. Note Roller-shaped trace may be left on coated paper. Staple Cartridge For the replacement method, refer to the steps on the label that is affixed on the machine. Note Use up the staples before replacing. - Page 19 Note Depending on the usage condition, such as the paper type, staples may be bent or bent staples may be caught inside of the unit, causing paper jamming. If you open the Staple Cartridge cover, be sure to remove all bent staples. Not removing bent staples ...
-
Page 20: Top Cover
Paper Jams If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper. Gently remove the paper being careful not to tear it. If paper is torn while it is being removed from the machine, remove all the torn pieces making sure that none remain inside the machine. - Page 21 Open the Upper Cover ( ) and remove paper ( Close the Upper Cover. Close the Front Cover. 4.4 Paper Jams...
- Page 22 Finisher B In this guide, “Finisher B4,” and “Finisher B5,” are generally referred to as “Finisher B”. Device Components Component Function Top Cover Open this cover to clear paper jams. Side Cover Open this cover when replacing staples for saddle stitch. Finisher Tray Finished paper is ejected.
- Page 23 Main specifications Item Specification Type Sort (Offset available) / Stack (Offset available) Paper size Standard size A3, 11 x 17” Paper weight 52 to 300 (g/m Tray capacity No staple (sheets) 2,000 JIS B4 or 1,000 greater Mixed Size Stacking With staples 100 copies or 1,000 sheets JIS B4 or...
- Page 24 Item Specification Staple-Free Staple Maximum number 10 (Same weight, same size) of sheets of paper (sheets) Note This value applies if paper of 80 g/m or less is used. Paper size Standard size A3, 11 x 17" Paper weight 60 to 105 (Uncoated) (g/m Stapled location 1 location, 2 locations...
- Page 25 Number of sheets that can be stapled (approximation) Staple Staple-Free Staple Paper weight (g/m Uncoated Coated Uncoated Coated 52 to 59 60 to 80 81 to 90 91 to 105 106 to 128 129 to 150 151 to 176 177 to 220 221 to 256 -: Ejection is not available.
- Page 26 Staple Cartridge Replacing Cartridge Consumables recommended by our company are manufactured under the standards suitable for this machine. Using consumables not recommended by our company may affect print quality or performance provided by the product. Use consumables that our company recommends for this machine.
- Page 27 Staple cartridge for side stitch Note In case of jammed staples when using the Staple cartridges for saddle stitch, contact our customer support center or sales agency. When you are removing the jammed staples from the staple cartridge when [Staple-Free] is set in >...
- Page 28 Push the metal part of the cartridge up. Remove the jammed staple ( ) and return the pushed up metal part back to the original position ( Insert the cartridge into the original position. Hold the handle and lightly press it up until you hear a click. Close the cover.
- Page 29 Center Tray Cover Open the Center Tray Cover ( ) and remove the jammed paper ( Close the Center Tray Cover. 5.3 Paper Jams...
-
Page 30: Folder Unit
Folder Unit Device Components Component Function Tri-Fold Output Tray Button Press the button to remove paper from the Tri-Fold Output Tray. The Tri-Fold Output Tray is opened when the lamp stops blinking and comes on and the lock is released. Cover Open this cover to clear paper jams. - Page 31 Main specifications Item Specification Z-Fold Half Sheet Paper size A3, 11 x 17”, JIS B4 60 to 90 (Uncoated) Paper weight (g/m Tri-fold Paper size A4, Letter 60 to 90 (Uncoated) Paper weight (g/m Tray capacity 40 sheets Note This value applies if 70 g/m paper is used.
- Page 32 Paper Jams If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper. Gently remove the paper being careful not to tear it. If paper is torn while it is being removed from the machine, remove all the torn pieces making sure that none remain inside the machine.
- Page 33 Right side Open the handle [2g] to the right ( ), turn the knob [2c] to the left ( ), and remove the jammed paper ( Return the handle [2g]. Tri-Fold Output Tray Pull out the Tri-Fold Output Tray [2d]. Open the handle [2e] to the right ( ), turn the knob [2c] to the left (...
- Page 34 If it is difficult to remove the paper, open the handle [2f] to the right ( ), turn the knob [2c] to the left ( ), and remove the jammed paper ( Return the handle [2f]. Return the Tri-Fold Output Tray [2d] to the original position.
- Page 35 Finisher C In this guide, “Finisher C4,” “Finisher C4 with Booklet Maker,” “Finisher C5,” and “Finisher C5 with Booklet Maker” are generally referred to as “Finisher C”. Device Components Component Function Hole Punch Waste Container Punched pieces go in here. Top Output Tray Outputs are delivered here.
- Page 36 Main specifications Item Specification Type Top Output Tray Sort (Offset available) / Stack (Offset available) Finisher Tray Sort (Offset available) / Stack (Offset available) Booklet Tray Sort / Stack Paper size Top Output Tray Standard size 12 x 19", A3 A6, Postcard Finisher Tray Standard size...
- Page 37 Item Specification Staple-Free Maximum number 10 (Same weight, same size) Staple of sheets of paper (sheets) Note This value applies if paper of 80 g/m or less is used. Paper size Standard size A3, 11 x 17" Paper weight 60 to 105 (Uncoated) (g/m Stapled location 1 location, 2 locations...
- Page 38 Number of sheets that can be stapled (approximation) Side Stitch Saddle stitch Staple Staple-Free Staple Paper weight (g/m Uncoated Coated Uncoated Coated Uncoated Coated 52 to 59 50/65 60 to 80 50/65 81 to 90 50/65 91 to 105 106 to 128 129 to 150 151 to 176 177 to 220...
- Page 39 Staple Cartridge Replacing Cartridge Consumables recommended by our company are manufactured under the standards suitable for this machine. Using consumables not recommended by our company may affect print quality or performance provided by the product. Use consumables that our company recommends for this machine.
- Page 40 Staple Jams If paper is not being stapled or if staples are bent, follow the procedures mentioned in the following pages. If the issue isn’t resolved even after the procedure, contact your local representative. Paper is not stapled Staple is bent If the staple looks like any of the following images, contact your local representative.
- Page 41 Staple cartridge for side stitch On the message screen or by navigating from > [Device Status] > [Supplies] > [Staple Cartridge (R1)], first press [Confirm/Supply], and then remove the jammed staples according to the instructions on the screen. Confirm that the machine is not operating, and open the Cover.
- Page 42 Remove the jammed staple ( ) and return the pushed up metal part back to the original position ( Insert the cartridge into the original position. Hold the handle and lightly press it up until you hear a click. Close the cover. Staple cartridges for saddle stitch Confirm that the machine is not operating, and open the Cover.
- Page 43 Insert the cartridge into the original position. Hold the handle and lightly press it up until you hear a click. Note Align the “” marks. Slowly insert Booklet Maker [4] all the way. Close the cover. 7.2 Staple Cartridge...
-
Page 44: Center Tray
Paper Jams If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper. Gently remove the paper being careful not to tear it. If paper is torn while it is being removed from the machine, remove all the torn pieces making sure that none remain inside the machine. - Page 45 Exit Finisher Tray Remove the paper that is jammed in the Exit. Booklet Tray Open the Cover. Turn the knob [4a] to the right ( ) and remove the paper that is jammed in the Exit of the Booklet Tray ( Close the cover.
- Page 46 Handle [3a] Open handle [3a] upward ( ) and remove the jammed paper ( Return the handle [3a]. Handle [3d] Open the handle [3d] to the right ( ) and remove the jammed paper ( Return the handle [3d]. Booklet Maker Hold the handle and pull out Booklet Maker [4].
