- Page 1 Apeos™ C7070 Apeos C6570 Apeos C5570 Apeos C4570 Apeos C3570 Apeos C3070 Apeos C2570 Reference Guide Optional Units April 2021 GM1048E1-1Ver. 1 FUJIFILM Business Innovation Corp.
- Page 2 Preface A guide describing the operations for optional units, such as the Finisher. Refer Descriptions for the following optional products are provided in different guides. Envelope Tray, Extra Center Tray, Left-Side tray, : Reference Guide Main Unit Wireless kit, print / scan / FAX function-related products: Reference Guide - Operations ...
-
Page 3: Device Components
High Capacity Feeder B1 Device Components Component Function Remaining Volume Display You can check the remaining paper volume. High Capacity Tray (Paper Load paper here. Tray 6) Top Cover Open this cover to clear paper jams. Main specifications Item Specification Paper size A4 , Letter , JIS B5 55 to 216... -
Page 4: Paper And Other Media
Paper and Other Media After loading paper, configure the Paper Tray settings on the Home screen. Refer For details, refer to “Setup” in Reference Guide - Operations. The top face of loaded paper is the surface printed on. Pull out the Paper Tray until it stops. When paper is already loaded in the tray, take out the paper. - Page 5 Remove the screw for the guide in front and remove the guide from the Paper Tray . Insert the protrusions under the guide into the Paper Size holes. Insert the Paper Tray protrusions into the Paper Size holes on top of the guide and tighten the screw. Pull the handle for the end guide up ( ), align with the Paper Size while moving the handle along the groove (...
- Page 6 Close the end guide completely. Push in the Paper Tray . Setting special paper and other media Hole punched paper Paper orientation: Load paper with holes facing the right side when viewed from the front of the machine Reference Guide Optional Units...
-
Page 7: Paper Jams
Paper Jams If paper is jammed, the machine stops and an alarm sounds. A message also appears on the control panel. Follow the message displayed to remove the jammed paper. Gently remove the paper being careful not to tear it. If paper is torn while it is being removed from the machine, remove all the torn pieces making sure that none remain inside the machine. -
Page 8: Paper Tray
Pull the handle ( ) and open the cover ( Remove the jammed paper. Close the cover. Move the unit to the right and connect it with the main unit. Paper Tray Pull out the Paper Tray until it stops. Remove the jammed paper. - Page 9 High Capacity Feeder B2 Device Components Component Function High Capacity Tray (Paper Load paper here. Tray 6) Top Cover Open this cover to clear paper jams. Remaining Volume Display You can check the remaining paper volume. Main specifications Item Specification Paper size A4 , Letter , JIS B5 55 to 216...
- Page 10 Paper and Other Media After loading paper, configure the Paper Tray settings on the Home screen. Refer For details, refer to “Setup” in Reference Guide - Operations. The top face of loaded paper is the surface printed on. Pull out the Paper Tray until it stops. When paper is already loaded in the tray, take out the paper.
- Page 11 Remove the screw for the guide in front and remove the guide from the Paper Tray. Insert the protrusions under the guide into the Paper Size holes. Insert the Paper Tray protrusions into the Paper Size holes on top of the guide and tighten the screw. Pull the handle for the end guide up ( ), align with the Paper Size while moving the handle along the groove (...
- Page 12 Setting special paper and other media Hole punched paper Paper orientation: Load paper with holes facing the right side when viewed from the front of the machine Reference Guide Optional Units...
- Page 13 Paper Jams If paper is jammed, the machine stops and an alarm sounds. A message also appears on the control panel. Follow the instructions displayed to remove the jammed paper. Gently remove the paper being careful not to tear it. If paper is torn while it is being removed from the machine, remove all the torn pieces making sure that none remain inside the machine.
- Page 14 Pull the handle ( ) and open the cover ( Remove the jammed paper. Close the cover. Move the unit to the right and connect it with the main body. Paper Tray Pull out the Paper Tray until it stops. Remove the jammed paper.
- Page 15 Finisher A2 Device Components Component Function Center Tray Outputs are delivered here. Extension Tray, Guide Wire This prevents the ejected paper from falling out. Top Cover Open this cover to clear paper jams. Front Cover Open this cover to replace staples or remove jammed staples. Staple Cartridge This unit is used to replace staples.
- Page 16 Main specifications Item Specification Type Sort (Offset available) / Stack (Offset available) Paper size Standard size A3, 11 x 17" Postcard (by Japan Post) Paper weight 52 to 256 (g/m Tray capacity No staple (sheets) With staples 30 copies or 500 sheets JIS B4 (sheets) A3 or greater (sheets)
- Page 17 Number of sheets that can be stapled (Approximation: For A4 ) Uncoated Coated Paper weight (g/m 52 to 90 91 to 105 106 to 128 129 to 150 151 to 176 177 to 220 221 to 256 -: Ejection is not available. 4 Finisher A2...
-
Page 18: Outputting Paper
Outputting Paper Extension Tray To eject SEF paper, pull out the Extension Tray and guide wire. Note Roller-shaped trace may be left on coated paper. Staple Cartridge For the replacement method, refer to the box of the consumable. Staple Jams If paper is not being stapled or if staples are bent, follow the procedures mentioned in the following pages. - Page 19 Note Depending on the usage condition, such as the paper type, staples may be bent or bent staples may be caught inside of the unit, causing paper jamming. If you open the Staple Cartridge cover, be sure to remove all bent staples. Not removing bent staples may cause staple jamming.
-
Page 20: Top Cover
Paper Jams If paper is jammed, the machine stops and an alarm sounds. A message also appears on the control panel. Follow the message displayed to remove the jammed paper. Gently remove the paper being careful not to tear it. If paper is torn while it is being removed from the machine, remove all the torn pieces making sure that none remain inside the machine. - Page 21 Open the Upper Cover ( ) and remove paper ( Close the Upper Cover. Close the Front Cover. 4 Finisher A2...
- Page 22 Finisher B4 Device Components Component Function Top Cover Open this cover to clear paper jams. Side Cover Open this cover when replacing staples for saddle stitch. Finisher Tray Finished paper is ejected. Staple cartridges for saddle This unit is used to replace staples for saddle stitch. There are stitch two.
- Page 23 Main specifications Item Specification Type Sort (Offset available) / Stack (Offset available) Paper size Standard size A3, 11 x 17” Paper weight 52 to 300 (g/m Tray capacity No staple (sheets) 2,000 JIS B4 or 1,000 greater Mixed Size Stacking With staples 100 copies or 1,000 sheets JIS B4 or...
- Page 24 Item Specification Hole Punch Paper size Standard size A3, 11 x 17" (With Punch Unit) Paper weight 52 to 220 (g/m Number of 2 holes / 4 holes or 2 holes / 3 holes (US standard) punched holes Note The number of punched holes that can be processed differs for each Paper Size.
- Page 25 Staple Cartridge Replacing Cartridge Consumables recommended by our company are manufactured under the standards suitable for this machine. Using consumables not recommended by our company may affect print quality or performance provided by the product. Use consumables that our company recommends for this machine.
- Page 26 Staple cartridge for side stitch Note In case of jammed staples when using the Staple cartridges for saddle stitch, contact our customer support center or sales agency. Confirm that the machine is not operating, and open the Front Cover. Hold [R1] and move the stapler unit to the front. Hold the handle and remove the cartridge.
- Page 27 Remove the jammed staple ( ) and return the pushed up metal part back to the original position ( Insert the cartridge into the original position. Hold the handle and lightly press it up until you hear a click. Close the cover. Paper Jams If paper is jammed, the machine stops and an alarm sounds.
-
Page 28: Folder Unit
Folder Unit Device Components Component Function Tri-Fold Output Tray Button Press the button to remove paper from the Tri-Fold Output Tray. The Tri-Fold Output Tray is opened when the lamp stops blinking and comes on and the lock is released. Cover Open this cover to clear paper jams. - Page 29 Item Specification Tray capacity 40 sheets Note This value applies if our C paper is used. Power supply AC 100 V ± 10%, 1 A, 50/60 Hz common Maximum power 100 W consumption Dimensions (mm) Width 232 x Depth 588 x Height 991 Weight (kg) 6 Folder Unit...
- Page 30 Paper Jams If paper is jammed, the machine stops and an alarm sounds. A message also appears on the control panel. Follow the instructions displayed to remove the jammed paper. Gently remove the paper being careful not to tear it. If paper is torn while it is being removed from the machine, remove all the torn pieces making sure that none remain inside the machine.
- Page 31 Right side Open the handle [2g] to the right ( ), turn the knob [2c] to the left ( ), and remove the jammed paper ( Return the handle [2g]. Tri-Fold Output Tray Pull out the Tri-Fold Output Tray [2d]. Open the handle [2e] to the right ( ), turn the knob [2c] to the left (...
- Page 32 If it is difficult to remove the paper, open the handle [2f] to the right ( ), turn the knob [2c] to the left ( ), and remove the jammed paper ( Return the handle [2f]. Return the Tri-Fold Output Tray [2d] to the original position.
- Page 33 Finisher C In this guide, “Finisher C4” and “Finisher C4 with Booklet Maker” are generally referred to as “Finisher C”. Device Components Component Function Hole Punch Waste Container Punched pieces go in here. Top Output Tray Outputs are delivered here. Finisher Tray Side stitch paper is ejected.
- Page 34 Main specifications Item Specification Type Top Output Tray Sort (Offset available) / Stack (Offset available) Finisher Tray Sort (Offset available) / Stack (Offset available) Booklet Tray Sort / Stack Paper size Top Output Tray Standard size 12 x 19" Postcard (by Japan Post) Finisher Tray Standard size 12 x 19"...
- Page 35 Item Specification Staple Maximum number of sheets of paper (sheets) Note This value applies if paper of 90 g/m or less is used. Up to 65 sheets are possible if 65 sheet cartridge is installed. Paper size Standard size A3, 11 x 17"...
- Page 36 Number of sheets that can be stapled (approximation) Side Stitch Saddle stitch Paper weight (g/m Uncoated Coated Uncoated Coated 52 to 90 50/65 91 to 105 106 to 128 129 to 150 151 to 176 177 to 220 221 to 350 -: Ejection is not available.
- Page 37 Staple Cartridge Replacing Cartridge Consumables recommended by our company are manufactured under the standards suitable for this machine. Using consumables not recommended by our company may affect print quality or performance provided by the product. Use consumables that our company recommends for this machine.
- Page 38 Staple cartridge for side stitch Tap [Device Status] > [Supplies] > [Staple Cartridge (R1)] > [Confirm/Supply] on the Touch Panel Display. Confirm that the machine is not operating, and open the Cover. Hold the handle and remove the cartridge. When using the 65 sheet cartridge, flip the handle down and remove the cartridge.
- Page 39 Remove the jammed staple ( ) and return the pushed up metal part back to the original position ( Insert the cartridge into the original position. Hold the handle and lightly press it up until you hear a click. Close the cover. Staple cartridges for saddle stitch Confirm that the machine is not operating, and open the Cover.
-
Page 40: Center Tray
Insert the cartridge into the original position. Hold the handle and lightly press it up until you hear a click. Note Align the “” marks. Slowly insert Booklet Maker [4] all the way. Close the cover. Paper Jams If paper is jammed, the machine stops and an alarm sounds. A message also appears on the control panel. - Page 41 Hold the handle and open the Center Tray Cover [F]. Remove the jammed paper. Close the cover. 7 Finisher C...
- Page 42 Exit Finisher Tray Remove the paper that is jammed in the Exit. Booklet Tray Open the Cover. Turn the knob [4a] to the right ( ) and remove the paper that is jammed in the Exit of the Booklet Tray ( Close the cover.
- Page 43 Handle [3a] Open handle [3a] upward ( ) and remove the jammed paper ( Return the handle [3a]. Handle [3d] Open the handle [3d] to the right ( ) and remove the jammed paper ( Return the handle [3d]. Booklet Maker Hold the handle and pull out Booklet Maker [4].
