CDMA MOBILE SUBSCRIBER UNIT
KG70c
SERVICE MANUAL
SINGLE BAND
CDMA MOBILE PHONE
0

Advertisement

Table of Contents
loading

Related Manuals for LG KG70c

Summary of Contents for LG KG70c

  • Page 1 CDMA MOBILE SUBSCRIBER UNIT KG70c SERVICE MANUAL SINGLE BAND CDMA MOBILE PHONE...

  • Page 2: Table Of Contents

    KG70c Table of Contents General Introduction ......................... 2 CHAPTER 1. System Introduction 1. System Introduction ......................... 3 2. Features and Advantages of CDMA Mobile Phone ..............4 3. Structure and Functions of CDMA Mobile Phone ..............7 4. Specification ..........................8 5.

  • Page 3: General Introduction

    KG70c General Introduction The KG70c cellular phone functions as digital cellular phone worked in CDMA (Code Division Multiple Access) mode. CDMA mode applies the DSSS (Direct Sequence Spread Spectrum) technique that has been used in military. This technique enables to share one frequency channel with many users in the same specific area.

  • Page 4: Chapter 1. System Introduction

    KG70C CHAPTER 1. System Introduction 1. System Introduction 1.1 CDMA Abstract The cellular system has a channel hand-off function that is used for collecting the information on the locations and movements of radio mobile telephones from the cell site by automatically controlling several cell site through the setup of data transmission routes and thus, enabling one switching system to carry out the automatic remote adjustment.

  • Page 5: Features And Advantages Of Cdma Mobile Phone

    KG70C 2. Features and Advantages of CDMA Mobile Phone 2.1 Various Types of Diversities When employing the narrow band modulation (30kHz band) that is the same as the analog FM modulation system used in the existing cellular system, the multi-paths of radio waves create a serious fading.
  • Page 6 KG70C Moreover, the backward closed loop power control used by the mobile station to control power with the commands issued out by the cell site. The cell site receives the signal of each corresponding mobile station and compares this with the pre-set threshold value and then, issues out power increase/decrease commands to the corresponding mobile station every 1.25 msec (800 times per...
  • Page 7 KG70C 2.6 Frequency Re-Use and Sector Segmentation Unlike the existing analog cellular system, the CDMA system can reuse the same frequency at the adjacent cell and accordingly, there is no need to prepare a separate frequency plan. Total interference generated on mobile station signals received from the cell site is the sum of interference generated from other mobile stations in the same cell site and interference generated from the mobile station of adjacent cell site.

  • Page 8: Structure And Functions Of Cdma Mobile Phone

    KG70C 3. Structure and Functions of CDMA Mobile Phone The mobile station of CDMA system is made up of a radio frequency part and logic/control (digital) part. The mobile station antenna is connected with the transmitter/receiver via a SAW duplexer filter so that it can carry out the transmit/receive function at the same time.

  • Page 9: Specification

    KG70C 4. Specification 4.1 General Specification 4.1.1 Transmit/Receive Frequency Interval : 45MHz 4.1.2 Number of Channels (Channel Bandwidth) : 20CH (BW : 1.23MHz) 4.1.3 Operating Voltage : DC 3.2~4.2V 4.1.4 Battery Power Consumption : DC 3.7V SLEEP IDLE MAX POWER 1.5mA↓...
  • Page 10 KG70C 4.2 Receive Specification 4.2.1 Frequency Range : 869.04 MHz ~ 893.97 MHz 4.2.2 Local Oscillating Frequency Range : 1738.05MHz ~ 1787.61MHz 4.2.3 Intermediate Frequency : Zero IF (MSM6100) 4.2.4 Sensitivity : -104dBm ( C/N 12dB or more) 3dB C/N Degration (With Fch ± 1.25KHz : -30dBm) 4.2.5 Selectivity :...
  • Page 11 KG70C MS (Mobile Station) Transmitter Frequency FA NO. CH.NO. CENTER FREQUENCY FA NO. CH.NO. CENTER FREQUENCY 1011 824.640 MHz 837.120 MHz 825.870 MHz 838.350 MHz 827.100 MHz 839.580 MHz 828.330 MHz 840.810 MHz 829.560 MHz 842.040 MHz 830.790 MHz 843.270 MHz 832.020 MHz...

  • Page 12: Installation

    KG70C 5. Installation 5.1 Installing a Battery Pack (Soft Pack type) 1) The soft battery pack is keyed so it can only fit one way. Align the groove in the battery pack with the rail on the back of the phone until the battery pack rests flush with the back of the phone.
  • Page 13 JTAG Interface JTAG Interface MODE Select MODE Select MODE Select Digital Test Bus Digital Test Bus Digital Test Bus External Mode Selection External Mode Selection External Mode Selection B7838 B7838 B7838 Interface Interface Interface [Figure 1-1] Block Diagram Of KG70c...
  • Page 14 The RFR6122 has cellular LNA. The characteristics of Low Noise Amplifier (LNA) are low noise figure, high gain, high intercept point and high reverse isolation. The frequency selectivity characteristic of mobile phone is mostly determined by LNA. The specifications of KG70c LNA are described below Parameter Gain Mode 0(G0) Gain Mode 1(G1)
  • Page 15 KG70C 6.1.3.1 Description on the Internal Circuit of MSM6100 (U200) and RFT6122 (U106) For the transmit data path(Tx), the MSM6100 modulates, interpolates, and converts the digital signal into an analog baseband before sending it to the RFT6122. The RFT6122 upconverts the Tx analog baseband into RF.

  • Page 16: Digital/Voice Processing Part

    KG70C 6.1.4 Description of Frequency Synthesizer Circuit 6.1.4.1 Voltage Controlled Temperature Compensation Crystal Oscillator (U101) The temperature range that can be compensated by VC-TCXO which is the reference frequency generator of a mobile station is -30~+80 ° C. VC-TCXO receives frequency tuning signals called TRK_LO_ADJ from MSM6025 as 0.5V~2.5V DC via R and C filters in order to generate the reference frequency of 19.20MHz and input it into the...
  • Page 17 KG70C 6.2.2 Circuit Description 6.2.2.1 Keypad / LCD and Receptacle Part This is used to transmit keypad signals to MSM6100. It is made up of a keypad backlight part that illuminates the keypad, LCD part that displays the operation status on to the screen, and a receptacle that receives and sends out voice and data with external sources.
  • Page 18 KG70C 6.2.2.4 Memory Part (MCP) Memory part consists of 1 Gbits flash memory and 512 Mbits Static RAM. the Flash Memory part are programs used for terminal operation. The programs can be changed through down loading after the assembling of terminals. On the SRAM data generated during the terminal operation are stored temporarily..

  • Page 19: Chapter 2. Nam Input Method

    KG70C CHAPTER 2. NAM Input Method 1. How to Power up ① Press power key. ② You have to input correct PIN code[Default Code: 0000], then press [OK] key. ③ Handset start data loading process, and then searching signal. 2. NAM Input Method (Inputting of Telephone Numbers Included) 2-1.

  • Page 20: Chapter 3. Trouble Shooting

    KG70C CHAPTER 3. Trouble Shooting CHAPTER 3. Trouble Shooting CHAPTER 3. Trouble Shooting CHAPTER 3. Trouble Shooting 3.1 Rx Part Trouble 3.1 Rx Part Trouble 3.1.1 When Rx Power isn’t enough 3.1.1 When Rx Power isn’t enough Test Point Test Point...
  • Page 21 KG70C 3.1.2 Checking Regulator Circuit 3.1.2 Checking Regulator Circuit Test Point Test Point U400 U400 Pin#1 High Pin#1 High Pin#10 Pin#10 (PS_HOLD) (PS_HOLD) (+2.6V_ Rx) (+2.6V_ Rx) Figure 3-1-2 Figure 3-1-2 Circuit Diagram Circuit Diagram Checking Flow Checking Flow Check Pin 1...
  • Page 22 KG70C 3.1.3 Checking VCTCXO Circuit 3.1.3 Checking VCTCXO Circuit Test Point Test Point Checking Flow Checking Flow Pin#3 Pin#3 Check U101 Pin#3 Check U101 Pin#3 ◆ Refer to Graph 3-1-1(a) ◆ Refer to Graph 3-1-1(a) U101 U101 VCTCXO Circuit is Ok VCTCXO Circuit is Ok 19.2MHz OK?
  • Page 23 KG70C 3.1.4 Checking Control Signal 3.1.4 Checking Control Signal Test Point Test Point Pin#3 : SBDT Pin#3 : SBDT Pin#4 : SBCK Pin#4 : SBCK Pin#5 : SBST Pin#5 : SBST Figure 3-1-4 Figure 3-1-4 Pin#3 Pin#3 Pin#4 Pin#4 Checking Flow...
  • Page 24 KG70C 3.1.5 Checking Mobile SW & Duplexer (DCN) 3.1.5 Checking Mobile SW & Duplexer (DCN) Test Point Test Point U100.Pin#2 U100.Pin#2 DP100.Pin#6 DP100.Pin#6 DP100.Pin#3 DP100.Pin#3 Figure 3-1-5 Figure 3-1-5 Circuit Diagram Circuit Diagram...
  • Page 25 KG70C Checking Flow Checking Flow Rx TEST SETUP(HHP) Rx TEST SETUP(HHP) - Test Channel : 384(DCN), - Test Channel : 384(DCN), E5515C Setup E5515C Setup - CH : 384(DCN) - CH : 384(DCN) - Sector Power : -30 dBm - Sector Power : -30 dBm...
  • Page 26 KG70C DP100 Pin #6 DP100 Pin #6 Graph 3-1-3(b) Graph 3-1-3(b) DP100 Pin #3 DP100 Pin #3 Graph 3-1-3(c) Graph 3-1-3(c)
  • Page 27 KG70C 3.1.6 Checking Rx I/Q data 3.1.6 Checking Rx I/Q data Test Point Test Point R138 R138 R137 R137 R136 R136 R135 R135 U107 U107 Figure 3-1-6 Figure 3-1-6 Waveform Waveform R135 (Rx_ I_P) R135 (Rx_ I_P) R135 (Rx_ I_P)

  • Page 28: Tx Part Trouble

    KG70C 3.2 Tx Part Trouble 3.2 Tx Part Trouble Test Point Test Point Mobile S/W Mobile S/W RFT6122 RFT6122 Duplexer Duplexer VCTXO VCTXO Figure 3-2 Figure 3-2 Checking Flow Checking Flow START START √ Press “ SPC Code ” in Phone idle state √...
  • Page 29 KG70C 3.2.1 Check Regulator Circuit 3.2.1 Check Regulator Circuit U106 Pin9 U106 Pin9 Test Point Test Point TX_ON(TP208) TX_ON(TP208) Pin#15 Pin#15 2.6V Tx 2.6V Tx U106 U106 U400 U400 Figure 3-2-1(b) Figure 3-2-1(b) Figure 3-2-1(a) Figure 3-2-1(a) Circuit Diagram Circuit Diagram...
  • Page 30 KG70C 3.2.2 Check VCTCXO Circuit 3.2.2 Check VCTCXO Circuit Test Point Test Point Checking Flow Checking Flow Pin#3 Pin#3 Check U101 Pin#3 Check U101 Pin#3 U101 U101 ◆ Refer to Graph 3-2-1(a) ◆ Refer to Graph 3-2-1(a) VCTCXO Circuit is Ok...
  • Page 31 KG70C 3.2.3 Check SBI Control Signal 3.2.3 Check SBI Control Signal Test Point Test Point U107 U107 Pin#3 : SBDT Pin#3 : SBDT Pin#4 : SBCK Pin#4 : SBCK Pin#5 : SBST Pin#5 : SBST Figure 3-2-3 Figure 3-2-3 Pin#3...
  • Page 32 KG70C 3.2.4 Check RFT6122 Circuit 3.2.4 Check RFT6122 Circuit Test Point Test Point C174,C175 C174,C175 U106 Pin#12 U106 Pin#12 RFT6122 RFT6122 I/Q DATA I/Q DATA TX_ CP TX_ CP U106 U106 U106 Pin#23 U106 Pin#23 CELL_OUT CELL_OUT Figure 3-2-4 Figure 3-2-4...
  • Page 33 KG70C Circuit Diagram Circuit Diagram U106 Pin#23 U106 Pin#23 CELL_OUT CELL_OUT U106 Pin#12 U106 Pin#12 TX_ CP TX_ CP Waveform Waveform C174,C175 TX_ I,Q DATA C174,C175 TX_ I,Q DATA U106 Pin23 CELL_OUT U106 Pin23 CELL_OUT Graph 3-2-3(a) Graph 3-2-3(a) Graph 3-2-3(b)
  • Page 34 KG70C 3.2.5 Check PAM Circuit 3.2.5 Check PAM Circuit Test Point Test Point Pin#8 Pin#8 Pin#7 Pin#7 Pin#2 Pin#2 Vcc2 Vcc2 RF_OUT RF_OUT U102 U102 U104 U104 Q100 Q100 Q100 Figure 3-2-5 Figure 3-2-5 Pin#4 Pin#4 Pin#1 Pin#1 Pin#2 Pin#2 VREF 2 .85V...
  • Page 35 KG70C Circuit Flow Circuit Flow Input Level is Appear? Input Level is Appear? Check F100 Check F100 Check U104 Pin#2 Check U104 Pin#2 Vreg 2.6~2.8V Vreg 2.6~2.8V Check U104 Pin#4 Check U104 Pin#4 Check Q100,U400 Check Q100,U400 Check U102 Pin#2...
  • Page 36 KG70C 3.2.6 Check Duplexer & Mobile SW 3.2.6 Check Duplexer & Mobile SW Test Point Test Point Pin#1 Pin#1 (ANT_OUT) (ANT_OUT) U100 U100 Pin#6 Pin#6 DP100 DP100 (DP→ANT TX signal) (DP→ANT TX signal) Figure 3-2-6 Figure 3-2-6 Circuit Flow Circuit Flow...

  • Page 37: Logic Part Trouble

    KG70C 3.3 Logic Part Trouble 3.3 Logic Part Trouble 3.3.1 When power isn't "Turn On". 3.3.1 When power isn't "Turn On". Circuit Diagram Circuit Diagram Test Point Test Point Pin#28 Pin#28 Pin#1 Pin#1 Pin#28 Pin#28 Pin#22 Pin#22 Pin#1 Pin#1 U400...
  • Page 38 KG70C 3.3.2. When LCD isn't displayed. 3.3.2. When LCD isn't displayed. • LCD Control signal : LCDD[0:15], LCD_CS/, LCD_RESET/, LCD_ADS, LCD_WR/, LCD_RD/, LCD_IFM ODE • LCD Control signal : LCDD[0:15], LCD_CS/, LCD_RESET/, LCD_ADS, LCD_WR/, LCD_RD/, LCD_IFM ODE Circuit Diagram Circuit Diagram...
  • Page 39 KG70C Checking Flow Checking Flow START START Refer Refer Is the power supplied Is the power supplied to [1] to [1] to main board normal? to main board normal? Check the connection between CON 1101 and CON 2101 Check the connection between CON 1101 and CON 2101...
  • Page 40 KG70C 3.3.3. When Tx Audio (MIC) isn't transmitted. 3.3.3. When Tx Audio (MIC) isn't transmitted. Circuit Diagram Circuit Diagram Test Point Test Point R203 R203 Check MIC +/ㅡ point’s Check MIC +/ㅡ point’s U200 U200 Soldering state Soldering state Figure 3-3-3 (a)
  • Page 41 KG70C 3.3.4. When Rx Audio (Receiver, Speaker) isn't heard. 3.3.4. When Rx Audio (Receiver, Speaker) isn't heard. Circuit Diagram Circuit Diagram Test Point Test Point Pin #9 Pin #9 Pin #6 Pin #6 U502 U502 U502 C530(DNI) C530(DNI) U502 U502...
  • Page 42 KG70C 3.3.5. When Keytone and ring sound isn't heard. 3.3.5. When Keytone and ring sound isn't heard. Please refer to the receiver part for circuit diagram and test point. Please refer to the receiver part for circuit diagram and test point.
  • Page 43 KG70C 3.3.6. When Vibrator, T-Flash , and USB interface doesn’t operate. 3.3.6. When Vibrator, T-Flash , and USB interface doesn’t operate. 3.3.6.1 Vibrator 3.3.6.1 Vibrator Circuit Diagram Circuit Diagram Pin #2 Pin #2 Pin #1 Pin #1 Test Point Test Point...
  • Page 44 KG70C Checking Flow Checking Flow START START Vibrator Vibrator Vibrator Solder again the vib rator Solder again the vib rator Solder again the vib rator soldering soldering soldering Set up manner mode Set up manner mode Set up manner mode...
  • Page 45 KG70C 3.3.6.2 T-Flash 3.3.6.2 T-Flash Circuit Diagram Circuit Diagram Pin #4 Pin #4 Pin #3 Pin #3 T flash data T flash data Pin #1, 2, 7, 8 Pin #1, 2, 7, 8 Pin #5 Pin #5 Pin #9 Pin #9...
  • Page 46 KG70C Checking Flow Checking Flow Setting : Insert T-Flash card into the phone Setting : Insert T-Flash card into the phone START START The voltage at Pin#9 The voltage at Pin#9 Change CON301 Change CON301 is Lo w? is Lo w?
  • Page 47 KG70C 3.3.6.3 USB interface 3.3.6.3 USB interface Circuit Diagram Circuit Diagram Q400 Q400 R409, 410 R409, 410 Test Point Test Point R200 R200 R410 R410 R409 R409 X200 X200 U400 U400 U400 Figure 3-3-6-3 (c) Figure 3-3-6-3 (c) Figure 3-3-6-3 (b)
  • Page 48 KG70C Checking Flow Checking Flow START START The voltage at Pin#2 The voltage at Pin#2 Check the connection of USB cable Check the connection of USB cable Of Q400 is 5.0V? Of Q400 is 5.0V? Logic level at Logic level at...
  • Page 49 KG70C 3.3.7. When Camera isn’t displayed. 3.3.7. When Camera isn’t displayed. Circuit Diagram Circuit Diagram C505 C505 C500 C500 Pin #21 C_MSCK Pin #21 C_MSCK C534, 535 C534, 535 (From DSP chip U702) (From DSP chip U702) U2100 U2100 Test Point...
  • Page 50 KG70C Checking Flow Checking Flow START START Is Camera module Is Camera module Reconnect to CON500 Reconnect to CON500 Connecting to CON500 Connecting to CON500 Set up camera mode Set up camera mode Check the camera module’s power voltage Check the camera module’s power voltage The voltage at C534 is about = 2.8V?
  • Page 51 KG70C 3.3.8. Charging Trouble 3.3.8. Charging Trouble Circuit Diagram Circuit Diagram Pin #36 Pin #36 Pin #37 Pin #37 U400 U400 U603 U603 Test Point Test Point CON600 CON600 Pin #36 Pin #36 Pin #18 Pin #18 Pin #12, 13...
  • Page 52 KG70C Checking Flow Checking Flow SETTING : Connect the only charging adaptor (TA) to the phone SETTING : Connect the only charging adaptor (TA) to the phone START START The Battery is The Battery is Change the Battery Change the Battery...

  • Page 53: Chapter 4. Safety

    KG70C CHAPTER 4. Safety ▣ IMPORTANT Read This Information Before Using Your Hand-Held Portable Cellular Telephone First introduction in 1984, the hand-held portable cellular telephone is one of the most exciting and innovative electronic products ever developed. With it you can stay in contact with your office, your home, emergency service, and others. For the safe and efficient operation of your phone, observe these guidelines.
  • Page 54 KG70C ▣ Antenna Care and Replacement Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with skin, a minor bum may result. Replace a damaged antenna immediately. Consult your manual to see if you may change your antenna yourself.
  • Page 55 KG70C ▣ Children Do not allow children to play with your phone. It is not a toy. Children could hurt themselves or others (by poking themselves or others in the eye with the antenna, for example). Children also could damage the phone, or make calls that increase your telephone bills.

  • Page 56: Chapter 5. Glossary

    KG70C CHAPTER 5. Glossary General Terms Abbreviated Alert. An abbreviated alert is used to remind the mobile station user that previously selected alternative routing features are still active. AC. See Authentication Center. Access Attempt. A sequence of one or more access probe sequences on the Access Channel containing the same message.
  • Page 57 KG70C have been recently sent to it from the base station and the pilots whose handoff drop timers have recently expired. A-key. A secret, 64-bit pattern stored in the mobile station. It is used to generate update the mobile station’s Shared Secret Data. The A-key is used in the mobile station authentication process.
  • Page 58 KG70C analog control channel. Call Disconnect. The process that releases the resources handling a particular call. The disconnect process beings either when the mobile station user indicates the end of the call by generating an on-hook condition or other call release mechanism, or when the base station initiates a release.
  • Page 59 KG70C power control groups in the frame while guaranteeing that every modulation symbol is transmitted exactly once. DBc. The ratio(in dB) of the sideband power of a signal, measured in a given bandwidth at a given frequency offset from the center frequency of the same signal, to the total inband power of the signal.
  • Page 60 KG70C ERP. See Effective Radiated Power. ESN. See Electronic Serial Number. Extended Protocol. An optional expansion of the signaling message between the base station and mobile station to allow for the addition of new system features and operational capabilities. Fade Timer. A timer kept by the mobile station as a measure of Forward Traffic Channel continuity. If the Fade timer expires, the mobile station drops the call.
  • Page 61 KG70C Half Frame. A 10 ms interval on the paging Channel. Two half frames comprise a frame, the first half frame begins at the same time as the frame. Handoff. The transferring communication of with a station mobile station from one base station to another.
  • Page 62 KG70C Long Code Mask. A 42-bit binary number that creates the unique identity of the long code. See also Public Long Code, Private Long Code, Public Long Code Mask, and Private Long Code Mask. LSB. Least significant bit. Maximal Length Sequence (m-Sequence). A binary sequence of period 2n-1, n a positive integer, with no internal periodicities.
  • Page 63 KG70C Modulation Symbol. The output of the data modulator before spreading. On the Reverse Traffic Channel, 64-ary orthogonal modulation is used and six code symbol (when the data rate is 9600bps) or each repeated code symbol (when the data rate is less than 9600bps) is one modulation symbol.
  • Page 64 KG70C OLC. See Overload Class (CDMA) or Overload Control (analog). Optional Field. A field defined within a message structure that is optionally to the message recipient. Order. A type of message that contains control codes for either the mobile station or the base station.
  • Page 65 KG70C Forward CDMA Channel, provides a phase reference for coherent demodulation, and provides a means for signal strength comparisons between base station for determining when to handoff. Pilot PN Sequence. A pair of modified maximal length PN sequences with period 2 used to spread the Foward CDMA Channel and the Reserve CDMA Channel.
  • Page 66 KG70C receivers relating electrical excitation from a reference generator to sound pressure at the earphone. The receive objective loudness tasting is normally specified in dB relative to one Pascal per millivolt. See IEEE Standard 269-1992, IEEE Standard 661-1979, CCITT Recommendation P.76, and CCITT Recommendation P.79.
  • Page 67 KG70C Seizure Precursor. The initial digital sequence transmitted by a mobile station to a base station on a reverse analog control channel. Seizure Option. A service capability of the system. Service options may be applications such as voice, data, or facsimile.
  • Page 68 KG70C Local Control Status. Indicates whether a mobile station must respond to local control messages. Roam Status. Indicates whether a mobile station is in its home system. Termination Status. Indicates whether a mobile station must terminate the call when it is on an analog voice channel.
  • Page 69 KG70C Unique Challenge-Response Procedure. An exchange of information between a mobile station and a base station for the purpose of confirming the mobile station’s identity. The procedure is initiated by the base station and is characterized by the use of a challenge-specific random number(i.e., RANDU) instead of the random variable broadcast globally(RAND).

  • Page 70: Chapter 6. Appendix

    KG70C CHAPTER 6. Appendix 1. Assembly and Diassembly Diagram 2. RF Block Diagram 3. Circuit Diagram 4. Component Layout 5. Component List...
  • Page 71 1.Assembly and Diassembly Diagram 1.1 Slide ass'y and front parts...
  • Page 72 1.2 Key, Main PCB and Rear parts...
  • Page 73 1.3 Rear parts...
  • Page 74 1.4 Front parts...
  • Page 75 1.5 Slide upper parts...
  • Page 76 1.6 Slide lower parts...
  • Page 77 KG70c Functional Block Diagram KG70c Functional Block Diagram □ □ U601 U106 MSM6100 Bluetooth RF Module Bluetooth (90n) U104 F100 Bluetooth RF U108 RF Transmitter LBRQ-2B43A Baseband Tx RF SAW High Pwr Det UART1 Processor RFT6122 Connectivity B9003 MAX2205 SKY77162...
  • Page 78 LG-KG70c MAIN B’D SAFY0172803-CD Doc. Name Doc. Number SHEET : 1 of 7 DRAW : D.K.KIM DATE 2007-02-05 <RF Tx PATH> CHKD S.H.KIM * Tx Path L110 APRD DAC_REF * Rx Path +2.6V_TX B.C.SEO C144 C138 C141 100n TX_I_N 100n...
  • Page 79 LG-KG70c MAIN B’D SAFY0172803-CD Doc. Name Doc. Number SHEET : 2 of 7 DRAW : D.K.KIM +2.6V_MSMA DATE 2007-02-05 R204 +2.6V_MSMP C222 C223 C224 C225 CHKD C215 C217 C216 S.H.KIM R205 +1.85V_MSMC APRD B.C.SEO C210 C213 C227 TP205 TP206 ISSUE : Rev 1.0...
  • Page 80 LG-KG70c MAIN B’D SAFY0172803-CD Doc. Name Doc. Number SHEET : 3 of 7 DRAW : D.K.KIM <MEMORY NAND 1G & SDRAM 512M> DATE 2007-02-05 CHKD S.H.KIM <microSD & RUIM HYBRID SOCKET> APRD A[0] B.C.SEO AD[0] A[1] AD[1] A[2] AD[2] A[3]...
  • Page 81 LG-KG70c MAIN B’D SAFY0172803-CD Doc. Name Doc. Number SHEET : 4 of 7 DRAW : D.K.KIM DATE 2007-02-05 CHKD S.H.KIM <PMIC PART> APRD B.C.SEO R407 +VBATT USB_OE/ R408 <TCXO LDO> +2.6V_MSMP ISSUE : Rev 1.0 USB_SENSE/ +V_CHAR CONTENT : Q400...
  • Page 82 LG-KG70c MAIN B’D SAFY0172803-CD Doc. Name Doc. Number SHEET : 5 of 7 DRAW : D.K.KIM DATE 2007-02-05 C511 100n CHKD S.H.KIM R505 C518 6.8k 2.2n APRD B.C.SEO C514 100p <AUDIO PART> <HP_AMP> C519 MIDI_TCXO ISSUE : Rev 1.0 CONTENT :...
  • Page 83 LG-KG70c MAIN B’D SAFY0172803-CD Doc. Name Doc. Number SHEET : 6 of 7 DRAW : D.K.KIM DATE 2007-02-05 CHKD S.H.KIM <BLUETOOTH PART> APRD B.C.SEO <18 PIN MMI CONNECTOR> ANT600 ANT601 ISSUE : Rev 1.0 ANT_1.8_2.1 ANT_1.8_2.1 CONTENT : R618 OUT_Y...
  • Page 84 LG-KG70c MAIN B’D SAFY0172803-CD Doc. Name Doc. Number SHEET : 7 of 7 DRAW : D.K.KIM DATE 2007-02-05 CHKD S.H.KIM APRD B.C.SEO <MULTIMEDIA APPLICATION PROCESSOR> ISSUE : Rev 1.0 CONTENT : +2.85V_L +2.8V_CAM_IO +1.5V_DSP C705 10u-6.3V TCSCM0J106MJAR +2.8V_DSP +3.0V_SD A2[19]...
  • Page 85 KG70c LCD FPCB Doc. Name Doc. Number SHEET : 1 of 1 DRAW : S.K.HONG DATE 2007.01.03 CHKD S.M.KIM CONN For SUB PCB SCROLL KEY & APRD I.YOO KEY LED (WHITE) CON1101 AXK7L54227G +VPWR LCD_RD/ +VPWR High:active / low:PDN ISSUE : REV 1.1...
  • Page 86 KG70c KEY PCB Doc. Name Doc. Number SHEET : DRAW : D.I.KIM DATE 2007.02.06 CHKD S.H.KIM APRD B.C.SEO CONN For MAIN PCB CONN For SLIDE PCB ISSUE : CONTENT : Rev1.0 CON2100 AXK760145G CON2101 +VBATT AXK8L54125BG LCDD[15] LCDD[11] +VBATT LCD_RD/ LCDD[7] +2.85V_L...
  • Page 87 KG70c KEY PCB Doc. Name Doc. Number SHEET : DRAW : D.I.KIM DATE 2007.02.06 CHKD S.H.KIM APRD B.C.SEO KEY MATRIX ISSUE : CONTENT : Rev1.0 KYDP[19] ESD PROTECTOR SIDE KEY LEFT RIGHT KYDP[17] SW2200 SW2204 SW2208 SW2216 SW2213 U2200 MSMF05C-P...
  • Page 89 KG70C R100, R107, R112, R117, R120 R121, R130, R500, R514, R515 ERHZ0000401 RES,CHIP,MAKER R517, R518 R201 ERHZ0000402 RES,CHIP,MAKER R135, R136, R137, R138, R140 ERHZ0000404 RES,CHIP,MAKER R414, R516 R109, R202 ERHZ0000405 RES,CHIP,MAKER R103 ERHZ0000406 RES,CHIP,MAKER R126 ERHZ0000434 RES,CHIP,MAKER R501 ERHZ0000443 RES,CHIP,MAKER...
  • Page 90 KG70C C200, C201, C208, C209, C210 C211, C212, C213, C215, C216 C217, C222, C223, C224, C225 ECCH0000155 CAP,CERAMIC,CHIP C413, C415, C419, C520, C537 C538 C433, C434 ECCH0000157 CAP,CERAMIC,CHIP C202 ECCH0000161 CAP,CERAMIC,CHIP C218, C219, C220, C221 ECCH0000179 CAP,CERAMIC,CHIP C226, C302, C310, C315, C409...
  • Page 91 KG70C R209, R210, R301, R315, R401 R613, R614, R618, R623, R702 ERHZ0000405 RES,CHIP,MAKER R706, R707, R709, R711, R712 R713 R714 R302, R406 ERHZ0000406 RES,CHIP,MAKER R701 ERHZ0000407 RES,CHIP,MAKER R502, R510, R511 ERHZ0000422 RES,CHIP,MAKER R207 ERHZ0000437 RES,CHIP,MAKER R203 ERHZ0000443 RES,CHIP,MAKER R508 ERHZ0000460...
  • Page 92 KG70C C2106 ECCH0000155 CAP,CERAMIC,CHIP C2102, C2107, C2108 ECCH0005604 CAP,CERAMIC,CHIP C2103, C2110, C2111 ECZH0000813 CAP,CHIP,MAKER C2104, C2105, C2109, C2112 ECZH0001215 CAP,CHIP,MAKER C2113 ECZH0001511 CAP,CHIP,MAKER LED2101, LED2102 EDLH0013701 DIODE,LED,CHIP LED2100 EDLM0008601 DIODE,LED,MODULE U2200, U2201 EDTY0008604 DIODE,TVS D2100, D2101, D2102, D2103, EDTY0008606 DIODE,TVS...
  • Page 93 KG70C MICZ01 MICZ0028501 INSERT MMAA00 MMAA0006901 MAGNET,SWITCH MPBJ00 MPBJ0039301 PAD,MOTOR MPBZ00 MPBZ0164801 MTAZ00 MTAZ0181601 TAPE 5.6-1. Slide FPCB Design No. Part Number Description Remark SPCY00 SPCY0105101 PCB,FLEXIBLE 5.6-2. Slide FPCB Top Ref No Description Part Name Remark PCB ASSY,FLEXIBLE,SMT SACD00...
