Roberts Gorden Blackheat BH20UT Installation, Operation & Service Manual
Vacuum assisted linear, double linear, u-tube, and multi-burner gas fired heating systems
Hide thumbs
Also See for Blackheat BH20UT:
- Installation, operation & service manual (84 pages) ,
- Installation & servicing instructions manual (37 pages) ,
- Installation, operation & service manual (70 pages)
Table of Contents
Advertisement
Quick Links
FOR YOUR SAFETY
If you smell gas:
1. Open windows.
2. DO NOT try to light any appliance.
3. DO NOT use electrical switches.
4. DO NOT use any telephone in
your building.
5. Extinguish any open flame.
6. Leave the building.
7. Immediately call your local gas
supplier after leaving the building.
Follow the gas supplier's
instructions.
8. If you cannot reach your gas
supplier, call the Fire Department.
WARNING
Fire Hazard
Keep all flammable objects, liquids and
vapors the minimum required clear-
ances to combustibles away from
heater.
Some objects will catch fire or explode
when placed close to heater.
Failure to follow these instructions can
result in death, injury or property
damage.
WARNING
Improper installation, adjustment, alteration, service
or maintenance can result in death, injury or
property damage. Read the installation, operation
and service manual thoroughly before installing or
servicing this equipment.
Installation must be done by a registered installer/
contractor qualified in the installation and service
of gas-fired heating equipment or your gas supplier.
© 2010 Roberts-Gordon LLC
Blackheat
Linear, Double Linear,
U-Tube, and Multi-Burner
Gas Fired Heating Systems
Installation, Operation &
BH15UT
BH20UT
BH25UT/EF
BH30UT/EF
BH35UT/EF
BH40UT/EF
BH45UT/EF
BH50UT/EF
Please take the time to read and understand
these instructions prior to any installation.
Installer must give a copy of this manual to the owner.
Keep this manual in a safe place in order to provide
your serviceman with necessary information.
Roberts-Gordon Europe Limited
Unit A, Kings Hill Business Park
Darlaston Road, Wednesbury
West Midlands WS10 7SH UK
Telephone: +44(0)121 506 7700
Fax: +44(0)121 506 7701
Service Telephone: +44(0)121 506 7709
Service Fax: +44(0)121 506 7702
E-mail: uksales@rg-inc.com
E-mail: export@rg-inc.com
www.rg-inc.com
Vacuum Assisted
Service Manual
BH15ST
BH30DL
BH20ST
BH40DL
BH25ST/EF
BH50DL/EF
BH30ST/EF
BH60DL/EF
BH35ST/EF
BH70DL/EF
BH40ST/EF
BH45ST/EF
BH50ST/EF
BH55ST
Installer
Owner
170101UK Rev. P 08/10
®
Advertisement
Table of Contents
Related Manuals for Roberts Gorden Blackheat BH20UT
Summary of Contents for Roberts Gorden Blackheat BH20UT
- Page 1 FOR YOUR SAFETY If you smell gas: 1. Open windows. Blackheat ® 2. DO NOT try to light any appliance. 3. DO NOT use electrical switches. 4. DO NOT use any telephone in your building. 5. Extinguish any open flame. 6.
-
