Installation instructions

6.1.2 Setting the clock

The programmer is required in order to check and set the clock in the actuator.
Always check the time following a change of batteries or at least once a year. A
detailed description can be found in the Programmer user manual. It is essential
that the clock is set precisely for the system to work correctly in CardLink
authorisation mode.

6.1.3 Reading Traceback

The Traceback (event list) of the most recent 2000 events can be read using the
Programmer, provided that the function has not been previously deactivated in
the KEM software.
See Programmer user manual.
The events and data that are registered in the Traceback are listed in the kaba
evolo system description.

6.1.4 Emergency opening for discharged batteries

As the batteries are accessible from the outside, no emergency opening using
the Programmer or emergency opening device is necessary. Change discharged
batteries immediately, as described in section 5.4.
Emergency opening using locking cylinder
If all the alarms were ignored until the batteries were completely dead, the door
can only be opened from the outside using an authorised mechanical key and
the key-operated latch. To be able to open the door mechanically in an
emergency, a lock with a key operated latch must be used or fitted!
Unlocking from the inside
1. With a panic lock, the c-lever can always be unlocked by operating the lever
handle. The relevant locking function is otherwise ensured by moving the
inner lever handle.
Unlocking from the outside
1. Insert the mechanically authorised key into the locking cylinder..
2. Turn the key in the opening direction as far as the limit stop.
3. Open the door using the key-operated latch.
Kaba c-lever compact
Maintenance and troubleshooting
k2evo703en-2014-01 19
