Models:
ST-550TM-IPI
• Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
See Table of Contents for location of additional Commonwealth
of Massachusetts requirements.
Pour demander un exemplaire en français de ce Manuel
du propriétaire, visitez www.heatnglo.com/translations.
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15
Owner's Manual
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
DANGER
HOT GLASS WILL
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certifi ed kit is used.
CAUSE BURNS.
UNTIL COOLED.
1

Advertisement

Table of Contents
loading

Related Manuals for Heat & Glo ST-550TM-IPI

Summary of Contents for Heat & Glo ST-550TM-IPI

  • Page 1 Pour demander un exemplaire en français de ce Manuel du propriétaire, visitez www.heatnglo.com/translations. Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...

  • Page 2: Congratulations

    BTUH: 00,000 00,000 00,000 00,000 MIN. MIN. INPUT INPUT BTUH: BTUH: 00,000 00,000 00,000 00,000 Serial Serial XXXXXXXX XXXXXXXX ORIFICE ORIFICE SIZE: SIZE: #XXXXX #XXXXX #XXXXX #XXXXX (Serie): (Serie): Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...

  • Page 3: Table Of Contents

    E. Junction Box Installation......43 Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...
  • Page 4 D. Contact Information ......62  = Contains updated information. Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...

  • Page 5: Limited Lifetime Warranty

    3 years Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645H 10/15 Page 1 of 2 Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...
  • Page 6 THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645H 10/15 Page 2 of 2 Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...

  • Page 7: Listing And Code Approvals

    • A 110-120 VAC circuit for this product must be protected with ground-fault circuit-interrupter protection, in compliance with the applicable electrical codes, when it is installed in locations such as in bathrooms or near sinks. Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...

  • Page 8: Requirements For The Commonwealth Of Massachusetts

    VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OB- of the installation. STRUCTIONS”. See Gas Connection section for additional Common- wealth of Massachusetts requirements. Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...

  • Page 9: User Guide

    • Install a switch lock or a wall/remote control with child protection lockout feature. Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...

  • Page 10: Clear Space

    Contact your dealer or Hearth & Home Technologies if the barrier is not present or help is needed to properly install one. For more information refer to the instructions supplied with your decorative door or front. Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...

  • Page 11: Lighting Instructions (Ipi)

    Keep burner and control compartment clean. See installation and operating instruc- Propane Installation code, CSA B149.1. tions accompanying appliance. For additional information on operating your 593-913i Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...

  • Page 12: After Fireplace Is Lit

    Noise is caused by metal expanding and contracting as it heats up and cools down, similar to Metallic noise the sound produced by a furnace or heating duct. This noise does not affect the operation or longevity of the fi replace. Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...

  • Page 13: Maintenance And Service

    • Carefully set fi xed glass assembly in place on fi replace. Hold glass in place with one hand and secure glass latches with the other hand. • Reinstall door or decorative front. Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...

  • Page 14: Maintenance Tasks-Qualifi Ed Service Technician

    • Remove all foreign objects. • Verify weather stripping, sealing and fl ashing remains intact. • Verify unobstructed air circulation. • Inspect draft shield to verify it is not damaged or missing. Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...
  • Page 15 • Verify that there is not a short in fl ame sense circuit by checking continuity between pilot hood and fl ame sense rod. Replace pilot as necessary. Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...

  • Page 16: Installer Guide

    VENT PIPE (SECTION 8 and 10) FRAMING HEADED OFF IN CEILING JOISTS (SECTION 8.C) CEILING FIRESTOP ON FLOOR OF ATTIC (SECTION 8.C) GAS LINE (SECTION 11.C) OPTIONAL WALL SWITCH Figure 4.1 Typical System Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...

  • Page 17: Design And Installation Considerations

    Electric drill and bits (1/4 in.) Plumb line Safety glasses Level Reciprocating saw Manometer Flat blade screwdriver 1/2 - 3/4 in. length, #6 or #8 Self-drilling screws Caulking material (300ºF minimum continuous exposure rating) Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...

  • Page 18: Framing And Clearances

    36 in. 914 mm 36 in. 914 mm Figure 5.1 Appliance Locations Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...

  • Page 19: Constructing The Appliance Chase

    * Adjust framing dimensions for interior sheathing (such as sheetrock) ** NOTICE: Appliance must be raised a minimum of 1/2 inch when using the Modern Front. Figure 5.2 Clearances to Combustibles ST-550TM-IPI Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...

  • Page 20: Mantel And Wall Projections And Non Combustible Zone

    MIN. MEASUREMENT FROM FIREPLACE OPENING TO BOTTOM OF APPLIANCE = 30-1/4 IN. AIR SPACE REQUIRED Figure 5.4 Minimum Vertical and Maximum Horizontal Dimensions of Non-Combustibles Figure 5.6 Non-Combustible Zone Heat & Glo • ST-550TM-IPI • 2142-900 Rev. P • 12/15...
