Carrier Infinity SYSTXCCSAM01 Installation Instructions Manual

SYSTXCCSAM01
Infinity System Access Module
NOTE: Read the entire instruction manual before starting the
installation.
pointSETt U.S. Pat No. 7,415,102
Fig. 1 - - Infinity System Access Module
SYSTXCCSAM01

TABLE OF CONTENTS

SAFETY CONSIDERATIONS
INSTALLATION CONSIDERATIONS
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compatible Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Check Equipment and Job Site
Component Location and Wiring Considerations
Connect Power Source and Antenna
Radio Installation and/or Test
Install Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connect Infinity Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connect Auxiliary Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Start- -Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PIN Number and Serial Number
RS- -232 CONNECTOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
UPDATING SYSTEM PROFILE
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation Instructions
PAGE
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
SAFETY CONSIDERATIONS
Improper installation, adjustment, alteration, service, maintenance,
or use can cause explosion, fire, electrical shock, or other
conditions which may cause death, personal injury or property
damage. Consult a qualified installer, service agency or your
distributor or branch for information or assistance. The qualified
installer or agency must use factory- -authorized kits or accessories
when modifying this product. Refer to the individual instructions
packaged with the kits or accessories when installing.
Follow all safety codes. Wear safety glasses, protective clothing,
and work gloves. Have a fire extinguisher available. Read these
instructions thoroughly and follow all warnings and cautions
included in literature and attached to the unit. Consult local
building codes and the current edition of the National Electrical
Code (NEC) NFPA 70.
In Canada, refer to the current editions of the Canadian Electrical
Code CSA C22.1.
Recognize safety information. When you see this symbol
the unit and in instructions or manuals, be alert to the potential for
A97040
personal injury. Understand the signal words DANGER,
WARNING, and CAUTION. These words are used with the
safety- -alert symbol. DANGER identifies the most serious hazards,
which will result in severe personal injury or death. WARNING
signifies hazards, which could result in personal injury or death.
CAUTION is used to identify unsafe practices, which may result
in minor personal injury or product and property damage. NOTE
1
is used to highlight suggestions which will result in enhanced
installation, reliability, or operation.
1

INSTALLATION CONSIDERATIONS

2
Before the actual installation of a System Access Module (SAM01)
2
can begin, determine the mounting location. For previous
2 - - 4
generation UID/UIZ systems, only, a radio test must be performed
2
with the System Access Module in the intended mounting location.
See Step 4 to perform a radio test.
2
The System Access Module is powered with an independent 24
3
VAC, 40 VA transformer. An accessory plug- -in transformer is
3
available to order through Replacement Components (Part No.
SYSTXNNXFM01).
3
transformer, a 120VAC supply must be near the mounting location
3
of the System Access Module. Provisions must be made to secure
3
the transformer to the outlet, due to its weight. The D- -wire (24
VAC) from the Infinity system MUST NOT be used to power the
4
System Access Module.
4
Use this instruction to guide the actual installation process after the
4
Infinity system(s) have been installed. One SAM01 System Access
Module is capable of handling two Infinity systems.
4
4
When using an accessory,
on
plug- -in
