Pioneer VSX-935 Instruction Manual

Hide thumbs Also See for VSX-935:

Advertisement

Quick Links

Instruction Manual
AV RECEIVER
VSX-935
En

Advertisement

loading

Related Manuals for Pioneer VSX-935

Summary of Contents for Pioneer VSX-935

  • Page 1 Instruction Manual AV RECEIVER VSX-935...

  • Page 2: Table Of Contents

    Table of contents Firmware Update Speaker Layout Speaker Layout Troubleshooting Main Room Main Room Room Supplementary Information Zone 2 Zone 2 Zone 2 Zone 2 Speaker Connections Speaker Connections Reducing the Power Consumption in Standby State When the following functions are enabled, the power consumption in standby state increases.

  • Page 3: Speaker Layout

    Before starting the procedure Connections Firmware Update Notes regarding connections with HDMI cables Update Information of the firmware Connections Firmware Update Procedure Connecting the TV Part Names To ARC/eARC TV Front Panel To Non-ARC TV Display Connecting the SUB Monitor Rear Panel (North American models) SUB Monitor Rear Panel (European, A Australian and Asian...
  • Page 4 Playing audio from BLUETOOTH wireless technology Playing Amazon Music using the Pioneer Remote enabled devices with this unit Playing Amazon Music using the remote controller Transmitting audio from this unit to BLUETOOTH wireless technology enabled devices TIDAL Registering this unit with TIDAL...
  • Page 5 Operations 1. Speaker Setup System Setup 2. Multi Zone Sound Check Menu list 3. ARC Setup Input/Output Assign 4. Full Auto MCACC Speaker Pioneer Remote App Audio Adjust Main features Source Initial Setup Hardware Troubleshooting Multi Zone Miscellaneous Before starting the procedure...
  • Page 6 Appendix Speaker Layouts and Selectable Listening Modes Input Formats and Selectable Listening Modes Listening Mode Effects Speaker combinations General Specifications...
  • Page 7 Before starting the procedure „ What's in the box „ Note • Connect speakers with an impedance of 4 Ω to 16 Ω. • The power cord must be connected only after all other connections are completed. • We will not accept any responsibility for damage arising from the connection with equipment manufactured by other companies.
  • Page 8 Firmware Update This unit is equipped with a function to update the firmware via network or USB Updating the Firmware via Network port when the firmware update is announced after purchase. This enables • While updating the firmware, do not do the following: various functions to be added and operations to be improved.
  • Page 9 If an Error Message is Displayed Updating via USB If an error occurs, "- Error!" is displayed on the display of the unit. ("" • While updating the firmware, do not do the following: represents an alphanumeric character.) Refer to the following descriptions and –...
  • Page 10 4. Connect the USB storage device to the USB port of this unit. • Others: • If an AC adapter is supplied with the USB storage device, connect the AC After removing the power plug once, insert it to the outlet, and then start the adapter, and use it with a household outlet.
  • Page 11 Part Names Front Panel is selected with the input selector and the unit is connected to the network. Lights up when any of the following functions is working or enabled in standby state of this unit. When this indicator is lighting, the power consumption in standby state increases, however, the increase in power consumption is minimized by entering the HYBRID STANDBY mode where only the...
  • Page 12 Front Panel player, etc. using a stereo mini plug cable (ø1/8″/3.5 mm). 18. PERSONAL PRESET 1/2/3 buttons: Registers STANDBY/ON button 15. PHONES jack: Headphones with a standard the current setting conditions such as input plug (ø1/4"/6.3 mm) are connected. selector, listening mode, etc. or call the registered settings.
  • Page 13 Display Display input is selected. 3. Lights according to the type of input digital audio signal and the listening mode. 4. Lights in the following conditions. RDS: Receiving RDS broadcasting. TUNED: Receiving DAB (European models)/AM (North American,Australian and Asian models)/ FM radio STEREO: Receiving FM stereo.
  • Page 14 Rear Panel (North American models) Rear Panel (North American models) 5. HDMI IN jacks: Transmit video signals and audio signals with an HDMI cable connected to an AV component. 6. NETWORK port: Connect to the network with an Ethernet cable. 7.
  • Page 15 Rear Panel (North American models) 13. SPEAKERS terminals: Connect speakers with speaker cables. (North American models support banana plugs. Use a plug 4 mm in diameter. Y plug connection is not supported.) (Bi-AMP) 9. SIGNAL GND terminal: Connect the ground (ZONE A) connected to this unit by connecting wire of the turntable.
  • Page 16 Rear Panel (European, A Australian and Asian models) Rear Panel (European, A Australian and Asian models) 3. HDMI OUT jacks: Transmit video signals and audio signals with an HDMI cable connected to a monitor such as a TV or projector. 4.
  • Page 17 Rear Panel (European, A Australian and Asian models) 13. SPEAKERS terminals: Connect speakers with speaker cables. (Y plug connection is not supported.) 9. SIGNAL GND terminal: Connect the ground (ZONE A) connected to this unit by connecting wire of the turntable. this unit to wireless headphones, wireless 10.
  • Page 18 Remote Controller Remote Controller 10. INPUT SELECT button: Switches the input to be STANDBY/ON button 2. PERSONAL PRESET 1/2/3 buttons: Registers played. the current setting conditions such as input (STATUS) button: Switches the information selector, listening mode, etc. or call the on the display and is used to operate RDS.
  • Page 19 Remote Controller 14. TONE/DIALOG/SW buttons: Adjusts the sound 17. ZONE 2 SHIFT button: Used to control the multi-zone function ( →p92). (The ZONE 3 quality of the speakers and volume level of the subwoofer. SHIFT button cannot be used with this unit.) 18.

  • Page 20: Zone 2

    Inputting Characters You can input characters or symbols on the keyboard displayed on the TV • Select "A/a" to switch between upper and lower cases. (Can also be switched screen such as when inputting a password for Wi-Fi Setup ( →p135) or naming with the MODE button on the remote controller.) a preset radio station ( →p121).
  • Page 21 Speaker Layout This unit can be used in different ways, depending on the layout of the speakers you are installing. Select the speaker layout that suits the installation environment, then confirm the methods for installation and connection. Speaker Layout 3.1ch 5.1ch 7.1ch ‰...
  • Page 22 Speaker Layout The listening room and the speaker layout 1. ZONE A Speakers The speaker system set up in the main room (where this unit is located). 2. ZONE 2 Speakers The 2 ch speaker system set up in a separate room (ZONE 2). This enables you to play the same source in the main room and the separate at the same time, or to play separate sources.
  • Page 23 Speaker Layout 3.1 Channel System A 3.1 Channel System that combines front speakers with a center speaker and a subwoofer. Basic system ( →p29) 3.1 ch + ZONE 2 ( →p29) 3.1 ch (Bi-Amping (Front)) ( →p29) Main Room Zone 2 Zone 2 3.1ch 5.1ch...
  • Page 24 Speaker Layout 5.1 Channel System This is a basic 5.1 Channel System. Basic system ( →p29) 5.1 ch + ZONE 2 ( →p29) 5.1 ch (Bi-Amping (Front)) ( →p29) Main Room Zone 2 Zone 2 3.1ch 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 25 Speaker Layout 7.1 Channel System This is a 7.1 Channel System that consists of the basic 5.1 Channel System and added surround back speakers. Basic system ( →p30) 7.1 ch + ZONE 2 (North American models) ( →p30) Main Room Zone 2 Zone 2 3.1ch...
  • Page 26 Speaker Layout 3.1.2 Channel System A Speaker System that is a 3.1 Channel System with one set of height speakers added. 3.1.2 ch (Front High or Rear High) ( →p31) 3.1.2 ch (Top Front or Top Middle or Top Rear) 3.1.2 ch (Dolby Enabled Speakers (Front)) ( →p31) ( →p31)
  • Page 27 Speaker Layout 5.1.2 Channel System A Speaker System that is a 5.1 Channel System with one set of height speakers added. 5.1.2 ch (Front High or Rear High) ( →p32) 5.1.2 ch (Top Front or Top Middle or Top Rear) 5.1.2 ch (Dolby Enabled Speakers (Front or ( →p32) Surround)) ( →p32)
  • Page 28 Speaker Installation How the speakers are set up depends on the size and shape of the room, so here we introduce just a basic layout example. The alphabetic symbols used in this chapter represent the following speakers: Front speaker Left Front speaker Right Center speaker powered SubWoofer...
  • Page 29 Speaker Installation „ 3.1 Channel System „ 5.1 Channel System a: 22° to 30° a: 22° to 30°, b: 120° FL, FR Place the Left and Right Front Speakers to match ear height. FL, FR Place the Left and Right Front Speakers to match ear height. The center speaker should be set up facing the listening position at The center speaker should be set up facing the listening position an angle.
  • Page 30 Speaker Installation „ 7.1 Channel System a: 22° to 30°, b: 90° to 110°, c: 135° to 150° FL, FR Place the Left and Right Front Speakers to match ear height. The center speaker should be set up facing the listening position at an angle.
  • Page 31 Speaker Installation „ 3.1.2 Channel System Top Speakers High Speakers a: 22° to 30° a: 30° to 55° 3´ (0.9 m) b: 65° to 100° or more c: 125° to 150° 3´ (0.9 m) or more TFL, TFR Fit top front speakers on the ceiling in front of the listening position. TML, TMR Fit top middle speakers on the ceiling directly above the listening position.
  • Page 32 Speaker Installation „ 5.1.2 Channel System Top Speakers High Speakers a: 22° to 30° b: 120° a: 30° to 55° 3´ (0.9 m) b: 65° to 100° or more c: 125° to 150° 3´ (0.9 m) or more TFL, TFR Fit top front speakers on the ceiling in front of the listening position. TML, TMR Fit top middle speakers on the ceiling directly above the listening position.
  • Page 33 Speaker Connections (Before starting the procedure) Speakers you can use with this unit and cable connections 4-16Ω Speaker Connections 3.1 Channel System 36, 37, 38, 39 5.1 Channel System 40, 41, 42, 43 7.1 Channel System 44, 45 3.1.2 Channel System 46, 47, 48, 49 5.1.2 Channel System 50, 51...
  • Page 34 Speaker Connections Speakers you can use with this unit and cable connections „ Speakers you can use with this unit This unit supports speakers with 4 Ω to 16 Ω impedance. For speaker impedance, check the speaker instruction manual. „ (Note) Speaker Impedance If any of the speakers to be connected has an impedance of 4 Ω...
  • Page 35 Speaker Connections „ Connect the Subwoofer a Subwoofer cable Connect a powered subwoofer with this unit using a subwoofer cable. Up to two powered subwoofers can be connected. The same signal is output from each SUBWOOFER PRE OUT jack. 3.1ch 5.1ch 7.1ch 3.1.2ch...
  • Page 36 Speaker Connections „ 3.1 Channel System 3.1ch 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 37 Speaker Connections „ 3.1 Channel System + ZONE SPEAKER (North American models) MAIN ROOM ZONE 2 FL(Z2) FR(Z2) 3.1ch FR(Z2) FL(Z2) 5.1ch 7.1ch ‰ 3.1 Channel System ＋ ZONE SPEAKER 3.1.2ch (European, Australian and Asian models) 5.1.2ch p38)
  • Page 38 Speaker Connections „ 3.1 Channel System + ZONE SPEAKER (European, Australian and Asian models) MAIN ROOM ZONE 2 FL(Z2) FR(Z2) FR(Z2) FL(Z2)
  • Page 39 Speaker Connections „ 3.1 Channel System (Bi-Amping the Speakers) For high- frequency 3.1ch For low- frequency 5.1ch Be sure to remove the jumper bar connecting between the woofer jacks and tweeter jacks of the Bi-Amping supported speakers. Refer to the instruction manual of your speakers as well.
  • Page 40 Speaker Connections „ 5.1 Channel System 3.1ch 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 41 Speaker Connections „ 5.1 Channel System + ZONE SPEAKER (North American models) MAIN ROOM ZONE 2 FL(Z2) FR(Z2) FR(Z2) FL(Z2) ‰ 5.1 Channel System ＋ ZONE SPEAKER (European, Australian and Asian models) p42)
  • Page 42 Speaker Connections „ 5.1 Channel System + ZONE SPEAKER (European, Australian and Asian models) MAIN ROOM ZONE 2 FL(Z2) FR(Z2) 3.1ch FR(Z2) FL(Z2) 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 43 Speaker Connections „ 5.1 Channel System (Bi-Amping the Speakers) For high- frequency 3.1ch For low- frequency 5.1ch Be sure to remove the jumper bar connecting between the woofer jacks and tweeter jacks of the Bi-Amping supported speakers. Refer to the instruction manual of your speakers as well.
  • Page 44 Speaker Connections „ 7.1 Channel System 3.1ch 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 45 Speaker Connections „ 7.1 Channel System + ZONE SPEAKER (For North American models only) FR(Z2) FL(Z2) While ZONE 2 playback is being performed, surround back speakers installed in the main room cannot play audio.
  • Page 46 Speaker Connections „ 3.1.2 Channel System *1 Connect the Height Speakers you have actually installed (HL/HR: Height Speakers, Top Speakers, Dolby Enabled Speakers).
  • Page 47 Speaker Connections „ 3.1.2 Channel System + ZONE SPEAKER (North American models) MAIN ROOM ZONE 2 FL(Z2) FR(Z2) 3.1ch FR(Z2) FL(Z2) 5.1ch 7.1ch ‰ 3.1.2 Channel System ＋ ZONE SPEAKER 3.1.2ch *1 Connect the Height Speakers you have actually installed (European, Australian and Asian models) (HL/HR: Height Speakers, Top Speakers, Dolby Enabled Speakers).
  • Page 48 Speaker Connections „ 3.1.2 Channel System + ZONE SPEAKER (European, Australian and Asian models) MAIN ROOM ZONE 2 FL(Z2) FR(Z2) 3.1ch FR(Z2) FL(Z2) 5.1ch 7.1ch 3.1.2ch *1 Connect the Height Speakers you have actually installed (HL/HR: Height Speakers, Top Speakers, Dolby Enabled Speakers). 5.1.2ch...
  • Page 49 Speaker Connections „ 3.1.2 Channel System (Bi-Amping the Speakers) For high- frequency 3.1ch For low- frequency 5.1ch 7.1ch Be sure to remove the jumper bar connecting between the woofer jacks and tweeter jacks of the Bi-Amping supported speakers. Refer to the instruction manual of 3.1.2ch your speakers as well.
  • Page 50 Speaker Connections „ 5.1.2 Channel System 3.1ch 5.1ch 7.1ch 3.1.2ch *1 Connect the Height Speakers you have actually installed (HL/HR: Height Speakers, Top Speakers, Dolby Enabled Speakers). 5.1.2ch...
  • Page 51 Speaker Connections „ 5.1.2 Channel System + ZONE SPEAKER (For North American models only) FR(Z2) FL(Z2) While ZONE 2 playback is being performed, height speakers installed in the main room cannot play audio. *1 Connect the Height Speakers you have actually installed (HL/HR: Height Speakers, Top Speakers, Dolby Enabled Speakers).
  • Page 52 Connections Notes regarding connections with HDMI cables Connecting the TV Connecting the SUB Monitor Connecting Playback Devices Connecting a TV or Integrated Amplifier in a separate room (Multi-zone) Connecting Antennas Network Connection Connections Connecting the Power Cord...
  • Page 53 Connections Notes regarding connections with HDMI cables HDMI (High-Definition Multimedia Interface) is a digital interface standard for „ (Note) Placement of cables connecting TVs, projectors, Blu-ray Disc players, game consoles, and other Putting a load on HDMI cables can lead to poor operational performance. Place video components.
  • Page 54 Connections Connecting the TV By connecting a TV to this unit, you can show the video from AV devices connected to this unit on the TV and also play the sound from the TV through this unit. To ARC/eARC TV IN(ARC) If the TV supports the ARC (Audio Return Channel) function(*), use only the HDMI cable to connect with the TV.
  • Page 55 Connections Connecting the SUB Monitor SUB Monitor This unit has multiple HDMI OUT jacks, and another TV or projector can be connected to the HDMI OUT SUB jack. • Switch between MAIN and SUB using the HDMI MAIN/SUB button on the remote controller ( →p18) or "AV Adjust"...
  • Page 56 Connections Connecting Playback Devices Connections to BD/DVD and GAME with HDMI jacks This is a connection example of an AV component equipped with an HDMI jack. When connecting with an AV component that conforms to the CEC (Consumer Electronics Control) standard, you can use the HDMI CEC function (*) that enables linking with input selectors, etc.
  • Page 57 Connections Connecting an Audio Component This is a connection example of an audio component. Connect a CD player using a digital coaxial cable or analog audio cable. You can also connect a turntable that has an MM-type cartridge to the PHONO jack. •...
  • Page 58 Connections Connecting a TV or Integrated Amplifier in a separate room (Multi-zone) Connecting a TV (ZONE 2) While a disc is played on a Blu-ray Disc player in the main room (where this unit is located), you can play the video and audio of the same Blu-ray Disc player or another AV component on the TV equipped with an HDMI IN jack in a separate room (ZONE 2).
  • Page 59 Connections Connecting an Integrated Amplifier (ZONE 2) You can enjoy 2 ch audio in the separate room (ZONE 2) while performing playback in the main room (where this unit is located). Use an analog audio cable to connect the ZONE 2 LINE OUT terminal on this unit to the input jack on an integrated amplifier in the separate room.
  • Page 60 Connections Connecting Antennas North American, Australian and Asian models Connect the antenna to this unit, and set up the antenna at the best position for listening while receiving radio signals. Attach the indoor FM antenna to the wall (North American, using push pins or adhesive tape.
  • Page 61 Connections Network Connection This unit can be connected to the network using a wired LAN or Wi-Fi (wireless LAN). You can enjoy network functions such as Internet radio by network connection. If connection is made by the wired LAN, connect the router and the NETWORK jack with the Ethernet cable as shown in the illustration.
  • Page 62 Connections Connecting the Power Cord Connect the power cord after all the connections are completed. a Power cord...
  • Page 63 Playback Basic Operations Playing audio from an externally connected device BLUETOOTH ® Playback Listening To the Radio Listening Mode AV Adjust Network Services Playback Spotify AirPlay ® ® DTS Play-Fi Amazon Alexa Amazon Music TIDAL Connecting the Sonos System for Playback Internet Radio Convenience functions Multi-zone...
  • Page 64 Playback Playing audio from an externally connected device You can play the audio from AV components, such as Blu-ray disc players through this unit. • When a TV is connected to the HDMI OUT SUB jack, use the HDMI MAIN/SUB button or "AV Adjust" ( →p77) to switch between MAIN and SUB. Basic Operations Perform the following procedure when this unit is on.
  • Page 65 If a password is requested, enter "0000". • This unit is displayed as "Pioneer VSX-935 XXXXXX". This display can be changed with the Friendly Name function ( →p136) or the Pioneer The illustration shows an image.
  • Page 66 • Due to the characteristics of BLUETOOTH wireless technology, the sound produced on this unit may slightly be behind the sound played on the BLUETOOTH enabled device.
  • Page 67 Playback Transmitting audio from this unit to BLUETOOTH wireless technology enabled devices Pairing 1. Press the input selector you want to play. • Select a source other than "BLUETOOTH". This function does not work if you select "BLUETOOTH". 2. Press on the remote controller, and in the Home menu displayed, select "Network/Bluetooth"...
  • Page 68 Playback Playing Back 1. Do the play operations on the AV component connected to this unit. Do the play operations on this unit when the input is TUNER or NET. • If "Variable" has been selected for the "Output Level", the volume can be adjusted on this unit.
  • Page 69 Playback Listening To the Radio You can receive AM (North American, Australian and Asian models), FM and DAB (European models) radio stations on this unit with the built-in tuner. Listening To the AM/FM Radio Tuning into a Radio Station Perform the following procedure when this unit is on. „...
  • Page 70 Playback „ Tuning Manually Using RDS (European, Australian and Asian Note that if you tune manually, the reception for FM broadcasts will be monaural models) rather than stereo, irrespective of the sensitivity of the reception. 1. Press TUNER repeatedly to select either "AM" or "FM". RDS stands for Radio Data System, and is a method of transmitting data in FM 2.
  • Page 71 Playback 3. When a station is found, the station blinks on the display. Pressing the ENTER button in this state will receive that station. If you don't press the ENTER button, the unit starts to search for another station. • If no stations are found, the message "Not Found" is displayed. •...
  • Page 72 Playback Listening To DAB Digital Radio (European models only) Tuning into a Radio Station Perform the following procedure when this unit is on. 1. Press TUNER repeatedly to select "DAB". • The very first time you select DAB, the Auto Tuning function automatically scans the DAB Band 3 for the multiplexes (i.e., stations) available in your area.
  • Page 73 Playback „ Changing the order stations are displayed You can sort the available stations alphabetically or by multiplex. 1. Press MODE repeatedly to set the method for sorting the display order from the following. Alphabet (default setting): Sort stations alphabetically. Multiplex: Sort stations by multiplex.
  • Page 74 Playback Presetting a Radio Station „ Registration Procedure „ Selecting a Preset Radio Station You can preset up to 40(*) of your favorite radio stations. 1. Press TUNER. (*)North American,Australian and Asian models: AM and FM stations 2. Press the cursors to select a preset number.
  • Page 75 Playback Listening Mode You can change the listening mode during play by pressing repeatedly "AUTO/DIRECT", "SURR", or "STEREO". • For details of the effects of each listening mode, refer to "Listening Mode Effects" ( →p167). • For listening modes selectable for each audio format of input signals, refer to "Input Formats and Selectable Listening Modes" ( →p163). „...
  • Page 76 Playback „ SURR button Checking the input format and listening mode By pressing repeatedly you can select the audio format of the signals being input Repeatedly pressing the button on the remote controller switches the display and switch between a variety of listening modes. Select the mode that suits your of the main unit in the following order.
  • Page 77 Playback AV Adjust Menu operations You can quickly adjust the settings you frequently use, such as tone adjustments, etc. You can make the settings on the TV screen while playing something. Press on the remote controller to display the AV Adjust menu. Note that there is no display on the TV screen when the input selector is "CD", "TV", "PHONO", "FM", "AM", or "DAB"...
  • Page 78 Playback „ HDMI „ Room EQ HDMI Out: Select the HDMI OUT jack to output video signals from "MAIN", MCACC EQ: Enable or disable the equalizer function that corrects for distortion "SUB", and "MAIN+SUB". caused by the acoustic environment of the room. •...
  • Page 79 Playback Spotify Use your phone, tablet or computer as a remote control for Spotify. Go to spotify.com/connect to learn how.
  • Page 80 Confirm that this unit and the PC are connected to the same network beforehand. Then, press NET on the remote controller. Next, click the AirPlay icon in iTunes, select this unit from the displayed devices, and start play of a music file. iPhone Pioneer VSX-935 XXXXXX e.g., iOS 10...
  • Page 81 AirPlay-enabled iPhone device. XXXXXX Pioneer VSX-935 You can also play the music files on a PC with iTunes (Ver. 12.8 or later) XXXXXXXX Pioneer equipped. Confirm that this unit and the PC are connected to the same network...
  • Page 82 "Group playback" that plays the same music in https://intl.pioneer-audiovisual.com/playfi/info_p.html separate rooms at home. To enjoy this function, download Pioneer Music Control • To use a music streaming distribution service, user registration may be App (available on iOS or Android™).
  • Page 83 Amazon website. 2. Start Pioneer Remote App and tap the unit when displayed. 3. Tap "NET" or "NETWORK" at the top of the Pioneer Remote App screen, and after switching to the network menu, tap the "amazon alexa" icon.
  • Page 84 Playback 7. When registration is finished, the screen returns to the one for Pioneer Operating this unit Remote App. Follow the on screen instructions and talk to the terminal with Amazon Alexa (an Amazon Echo, etc.), and confirm that you can use voice You can use voice commands to adjust the volume on this unit, start and stop commands.
  • Page 85 Refer to "Pioneer Remote App" ( →p145) for information about the app. 2. Start Pioneer Remote App and tap the unit when displayed. 3. Tap "NET" or "NETWORK" at the top of the Pioneer Remote App screen, and You can use the music distribution service provided by Amazon by registering after switching to the network screen, tap the "Amazon Music"...
  • Page 86 Playing Amazon Music using the Pioneer Remote App 1. Start the Pioneer Remote App. This unit is displayed automatically when the app is started, so tap the unit when displayed to select it. 2. Tap "NET" or "NETWORK" at the top of the screen, and after switching to the network screen, tap the "Amazon Music"...
  • Page 87 Registering this unit with TIDAL allows you to enjoy the music distribution service provided by TIDAL. You can register this unit on the screen of Pioneer Remote App by downloading Pioneer Remote App (available on iOS or Android™) to mobile devices such as a smartphone and tablet.
  • Page 88 Playback Connecting the Sonos System for Playback How to Connect This Unit and Sonos Connect 1. Connect the Sonos Connect to the AUDIO IN jack of this unit with the RCA audio cable supplied with the Sonos Connect. Any input can be used other than the PHONO jack.
  • Page 89 Playback Sonos Connect. • Up to 32 devices can be displayed on the Sonos product list screen. If you cannot find the Sonos Connect to be interlocked, return to the previous screen, turn off the product you do not want to interlock, and try again. Output Zone: With the cursors / , select the ZONE where you want to listen to the music.
  • Page 90 Playback Internet Radio By connecting this unit to an Internet-connected network, you can enjoy Internet radio services such as TuneIn Radio. • To play Internet radio services, the network needs to be connected to the Internet. • Depending on the Internet radio service, a user registration may be required on your PC beforehand. For details of each service, visit the website of each service.
  • Page 91 Playback Internet Radio Service Menu You can bookmark specific stations, or delete stations that have been bookmarked. The displayed menu varies according to the service being selected. The menu icon is displayed while a station is being played. When only this icon is displayed, pressing ENTER will display the menu on the screen.
  • Page 92 FM broadcasts for the main room and separate room. Pioneer Remote App ( →p145) is useful for the multi-zone playback operation. Download Pioneer Remote App (available on iOS or Android™) to a mobile device, such as a smartphone and tablet to use it.
  • Page 93 Playback Playing Back In the remote controller operation, while pressing and holding the ZONE 2 SHIFT button on the remote controller, operate with each button. 1. Point the remote controller at the unit, and while pressing and holding the ZONE 2 SHIFT button on the remote controller, press . •...
  • Page 94 Playback To set the function to off: While pressing and holding ZONE 2 SHIFT button, press . Alternatively, press the ZONE 2-ON/OFF button on the main unit.
  • Page 95 Playback Using PERSONAL PRESET Registration You can register settings ( →p96) such as the current input selector and listening mode with the three PERSONAL PRESET buttons, and call a registered setting in a single operation. e.g.) Pressing the PERSONAL PRESET button will automatically switch the input selector to "TUNER"...
  • Page 96 Playback Settings that can be registered The following settings can be registered with PERSONAL PRESET. – Input selector (Network service or AM (North American,Australian and Asian models)/FM/DAB (European models) radio stations can also be registered.) – Output destination (HDMI) – Listening mode –...
  • Page 97 Playback USB Storage Device You can play music files stored on a USB storage device. Supported Audio Formats USB Storage Device Requirements MP3 (.mp3) • This unit can use USB storage devices that comply with the USB mass • MPEG-1/MPEG-2 Audio Layer 3/44.1 kHz, 48 kHz/Between 8 kbps and 320 kbps, storage class standard.
  • Page 98 Playback Playing music files saved on a USB storage device Perform the following procedure when this unit is on. 1. Switch the input on the TV to the input connected to the unit. 2. Plug your USB storage device with the music files into the USB port either on the front panel or rear panel of this unit.
  • Page 99 Playback may not be displayed correctly. • This unit supports the gapless playback of the USB storage device in the following conditions. When continuously playing WAV, FLAC and Apple Lossless files with the same format, sampling frequency, the number of channels and quantization bit rate.
  • Page 100 Playback Music Server Streaming play of music files stored on PCs or NAS devices connected to the same network as this unit is supported. • The network servers this unit is compatible with are those PCs with players installed that have the server functionality of Windows Media ®...
  • Page 101 Playback Playing Back Perform the following procedure when this unit is on. 1. Switch the input on the TV to the input connected to the unit. TV’s REMOTE 2. Start the server (Windows Media ® Player 12, or NAS device) containing the Inputs music files to play.
  • Page 102 Playback 6. Select the target server with the cursors, and press ENTER to display the Controlling Remote Playback from a PC items list screen. You can use this unit to play music files stored on your PC by operating the PC •...
  • Page 103 The Play Queue information is effective until the power cord of this unit is removed from the outlet. Refer to "Pioneer Remote App" ( →p145) for information about the app.
  • Page 104 Playback 2. Tap the " " icon of the track to sort, and drag the icon to the destination. 3. To delete a track, slide the track to the left until the trash icon changes to " ". " icon to the left. Releasing your finger will If the device is on iOS, slide the "...
  • Page 105 Playback Connecting a transmitter for playback When you connect wireless headphones or a wireless speaker transmitter to the ZONE B LINE OUT terminal of this unit, you can play back the same source through the wireless headphones or wireless speakers as in the main room. Connections Setting Up 1.
  • Page 106 Playback When using a speaker layout of 3.1 ch or more, you can select only the "Ext. Stereo" listening mode.
  • Page 107 Setup System Setup MCACC Network/Bluetooth Web Setup Initial Setup with Auto Start-up Wizard Pioneer Remote App Setup...
  • Page 108 Setup System Setup Use the on-screen displays (OSD) that appear on the TV to make the settings. Press on the remote controller to display the Home screen, then select System Setup with the cursors on the remote controller and press ENTER. buttons of the remote controller and press ENTER to confirm your selection.

  • Page 109: Firmware Update

    Setup Adjust the volume level when there are differences in volume level among multiple devices Source Input Volume Absorber p121 connected to this unit. Name Edit Set an easy name for each input. p121 Audio Select Select the priority for input selection when multiple audio sources are connected to one input p122 selector.
  • Page 110 Setup Input/Output Assign Input/Output Assign ‰ Upscaling (Default Value: Off) „ TV Out / OSD When using a TV that supports 4K/8K, video signals input at 1080p can be Make settings for TV output and On-Screen Displays (OSD) that appear on the automatically upscaled to 4K/8K for output.
  • Page 111 Setup Input/Output Assign ‰ HDMI 4K/8K Signal Format ‰ Zone 2 HDMI (Default Value: Not Use) Set the 4K/8K signal format input and output by this unit. Set to suit the TV or Make the setting when you output to the Zone 2 TV connected to the HDMI OUT player connected.
  • Page 112 Setup Input/Output Assign „ HDMI Input „ Digital Audio Input Change input assignment between the input selectors and HDMI IN jacks. Change input assignment between the input selectors and DIGITAL AUDIO IN ‰ BD/DVD COAXIAL/OPTICAL jacks. If you do not assign a jack, select "---". (Default Value: HDMI 1 (HDCP 2.3)) ‰...
  • Page 113 Setup Input/Output Assign „ Analog Audio Input „ Input Skip Change input assignment between the input selectors and AUDIO IN jacks. If You can skip inputs to which nothing is connected when selecting them with the you do not assign a jack, select "---". INPUT SELECTOR dial on the main unit or with the INPUT SELECT button on ‰...
  • Page 114 Setup Input/Output Assign „ PERSONAL PRESET Information (Zone 2) Confirm the registered contents of 1 to 3 buttons of PERSONAL PRESET. Setting Item Default Value Setting Details The registered settings are displayed in the list. Input Selector Displays the input selector that has been set. ‰...
  • Page 115 Setup Speaker Speaker „ Configuration ‰ Zone 2 Lineout (Default Value: Zone 2) Set an output destination of the audio output from ZONE 2 LINE OUT/ZONE B Change the settings of connection environment of the speakers. LINE OUT jack. ‰ Speaker Channels (Default Value: 7.1 ch) •...
  • Page 116 Setup Speaker „ Crossover Surround Back: Set according to the speakers to be used. Change the settings of crossover frequencies. "Small": When speaker where the speaker diameter is 16 cm or less are to be ‰ Front (Default Value: Small) used.
  • Page 117 Setup Speaker „ Distance „ Channel Level Set the distance from each speaker to the listening position. Adjust the volume level of each speaker. ‰ Front Left ‰ Front Left (Default Value: 10.0 ft/3.00 m) (Default Value: 0.0 dB) Center (Default Value: 10.0 ft/3.00 m) Center (Default Value: 0.0 dB)
  • Page 118 Setup Speaker „ Dolby Enabled Speaker Change the settings of Dolby Enabled Speakers. • This setting can be selected when "Configuration" - "Height Speaker" is set to "Dolby Speaker". ‰ Distance from the ceiling (Default Value: 6.0 ft/1.80 m) Set the distance between the Dolby Enabled Speaker and the ceiling. Select between "0.1 ft"/"0.03 m"...
  • Page 119 Setup Audio Adjust Audio Adjust „ Dual Mono/Mono „ Dolby Change the settings of multiplex audio playback. Change the setting of when Dolby signals are input. ‰ Dual Mono (Default Value: Main) ‰ Loudness Management (Default Value: On) Set the audio channel or language to be output when playing multiplex audio or When playing Dolby TrueHD, enable the dialog normalization function which keeps the volume of dialog at a certain level.
  • Page 120 Setup Audio Adjust „ Volume Change the Volume settings. ‰ Mute Level (Default Value: -∞ dB) Set the volume lowered from the listening volume when muting is on. Select a value from "-∞ dB", "-40 dB" and "-20 dB". ‰ Volume Limit (Default Value: Off) Set the maximum value to prevent the volume from becoming too loud.
  • Page 121 Setup Source Source „ Input Volume Absorber „ Name Edit Adjust the volume level when there are differences in volume level among Set an easy name for each input. The set name appears on the main unit’s multiple devices connected to this unit. Select the input selector to make the display.
  • Page 122 Setup Source „ Audio Select Analog When giving priority to the input signal from AUDIO IN jacks • This item can be selected only when the input to be set is Select the priority for input selection when multiple audio sources are connected assigned to the AUDIO IN jack in the "Input/Output Assign"...
  • Page 123 Setup Hardware Hardware „ HDMI ‰ HDMI Standby Through (Default Value: Auto (Eco)) When this is set to anything other than "Off", you can play the video and audio of Change the settings of the HDMI function. an HDMI-connected player on the TV even if the unit is in standby mode. Also, ‰...
  • Page 124 Setup Hardware ‰ Audio TV Out (Default Value: Auto) ‰ Auto Delay (Default Value: On) You can enjoy audio through the speakers of the TV while this unit is on. Automatically corrects desynchronization between the video and audio signals • The setting is fixed to "Auto" if "HDMI CEC" is set to "On". If you change this based on the information from the HDMI Lip-Sync-compatible TV.
  • Page 125 Pioneer Remote App that can control this unit. • When this function is set to "On", the power consumption in standby state...
  • Page 126 Setup Hardware „ Works with SONOS ‰ Output Zone (Default Value: Main) Select the zone where you want to listen to the music. Change the settings to connect with the Sonos Connect. • To use this function, set "Input Selector" beforehand. (SONOS-1/SONOS-2) ‰...
  • Page 127 Setup Multi Zone Multi Zone „ Zone 2 „ Remote Play Zone Change the settings for Zone 2. Change the settings for remote play. ‰ Volume Limit (Default Value: Off) ‰ Remote Play Zone (Default Value: Auto) When playing with AirPlay or Spotify Connect, or when using the Music Server Set the maximum value for Zone 2 to avoid too high volume.
  • Page 128 Value:10 kHz / 0.2 MHz) Select an ID for the unit's remote controller from "1", "2", and "3" to prevent interference between the unit and other Pioneer components that are installed Select a frequency step to suit your residential area.
  • Page 129 Setup Miscellaneous „ Firmware Update „ Initial Setup Change the settings for Firmware Update. Make the initial setup from the setup menu. ‰ Update Notice (Default Value: Enable) • Wait for a while if "Initial Setup" cannot be selected. It can be selected when the network function is activated.
  • Page 130 Setup MCACC Menu operations Setup the speakers automatically or make desired changes to the equalizer. You can also check the values set currently for each speaker setting. Use the on-screen displays (OSD) that appear on the TV to make the settings. Press on the remote controller to display the Home screen, then select MCACC with the cursors on the remote controller and press ENTER.
  • Page 131 Setup Full Auto MCACC 2. Place the supplied speaker setup microphone at the listening position, and connect it to the SETUP MIC jack on the main unit. Place the supplied speaker setup microphone in the listening position, measure the test tones emitted by the speakers, then the unit automatically sets the optimum volume level for each speaker, the crossover frequencies, and the distance from the listening position.
  • Page 132 Setup Manual MCACC „ EQ Adjust Center, Surround Right, Surround Left: After selecting the speaker frequency from between "63 Hz" and "16 kHz" with If you perform Full Auto MCACC then settings are automatic, but you can also / , adjust the volume of that frequency between "-12.0 dB" and the cursors adjust the output volume of the range of each connected speaker to suit your "+12.0 dB"...
  • Page 133 Setup MCACC Data Check You can check the number of speaker channels connected and the content and values you have set for each of the speaker settings. „ Speaker Setting You can check the number of speaker channels connected and the large and small settings you have set for the low range reproduction capabilities for each of the speakers.
  • Page 134 Setup Network/Bluetooth Menu operations Make settings related to network connections and BLUETOOTH. Use the on-screen displays (OSD) that appear on the TV to make the settings. Press on the remote controller to display the Home screen, select "Network/ Bluetooth" with the cursors on the remote controller, then press ENTER. Select the item with the cursor buttons of the remote controller and press ENTER to confirm your selection.
  • Page 135 Setup Network • When LAN is configured with a DHCP, set "DHCP" to "Enable" to configure ‰ MAC Address (Default Value: -) the setting automatically. ("Enable" is set by default) To assign fixed IP addresses to each components, you must set "DHCP" to "Disable" and Check the MAC address of this unit.
  • Page 136 When this function is not used Displays/Sets the proxy server port number when you input "Proxy URL". ‰ AirPlay Device Name (Default Value: Pioneer VSX-935 XXXXXX) ‰ Friendly Name (Default Value: Pioneer VSX-935 XXXXXX) Change the model name of this unit which is displayed on the AirPlay- connected device to an easily recognized name.
  • Page 137 Setup Network ‰ AirPlay Password (Default Value: -) ‰ Network Check (Default Value: -) You can set a password of up to 31 characters so that only registered users You can check the network connection. can use AirPlay. Press ENTER when "Start" is displayed. 1.
  • Page 138 Setup Bluetooth Bluetooth ‰ Pairing Information (Default Value: -) Change the settings for the BLUETOOTH function. • Wait for a while if "Bluetooth" cannot be selected. It will appear when the You can initialize the pairing information stored on this unit. If you are no longer BLUETOOTH function is started up.
  • Page 139 Setup Bluetooth ‰ Low Latency Mode (Default Value: Off) „ Bluetooth Transmitter If the audio from a device connected via BLUETOOTH is delayed compared to ‰ Bluetooth Transmitter (Default Value: Off) the video on the TV when watching a gaming screen, etc., you can reduce the Select whether or not to use the function that transmits audio from this unit to audio delay.
  • Page 140 Setup Bluetooth ‰ Status (Default Value: -) Displays the status of the BLUETOOTH wireless technology enabled device connected to the unit. Ready Not paired Pairing Paired Connected Successfully connected Connected Successfully connected with aptX compatible device (aptX) Connected Successfully connected with aptX HD compatible device (aptX HD)
  • Page 141 Setup Web Setup Menu operations You can make the settings for the network function of this unit using an Internet Device Information browser on a PC, smartphone, etc. You can change the Friendly Name or AirPlay Device Name, set an AirPlay Password, etc.
  • Page 142 Setup Initial Setup with Auto Start-up Wizard Operations When you turn the unit on for the first time after purchase, the Initial Setup screen is automatically displayed on the TV to allow you to make settings TV’s REMOTE required for startup using simple operations following on-screen guidance. Inputs 1.
  • Page 143 Setup Network Connection Keyboard Input 1. A confirmation screen asking you whether to agree to the privacy statement To switch between upper and lower cases, select "A/a" on the screen, and press is displayed during network setting. If you agree, select "Accept" and press ENTER on the remote controller.
  • Page 144 Setup press ENTER. 1. Place the supplied speaker setup microphone at the listening position, and connect it to the SETUP MIC jack on the main unit. 2. Multi Zone Sound Check Output test tones to ZONE 2 to enjoy audio in a separate room (ZONE 2) in addition to the main room.
  • Page 145 (internet radio or play of a music file) without looking at the TV. • To use Pioneer Remote App, this unit needs to be connected to the same network as the mobile device.
  • Page 146 Troubleshooting Before starting the procedure When the unit is operating erratically Try restarting the unit Resetting the unit (this resets the unit settings to the default) Troubleshooting „ Power „ Audio Troubleshooting „ Listening Modes „ Video „ Linked operation „...
  • Page 147 Troubleshooting Before starting the procedure Problems may be solved by simply turning the power on/off or disconnecting/ connecting the power cord, which is easier than working on the connection, setting and operating procedure. Try the simple measures on both the unit and the connected device.
  • Page 148 Troubleshooting When the unit is operating erratically ‰ Try restarting the unit ‰ Resetting the unit (this resets the unit settings to the default) Restarting this unit may solve the problem. Set the main unit to standby, then after waiting for 5 seconds or more, press and hold the STANDBY/ON button If the restart of the unit does not solve the problem, reset the unit, and restore of the main unit for at least 5 seconds, and then restart the unit.

  • Page 149: Troubleshooting

    Troubleshooting Troubleshooting „ Power ‰ When the power is turned on, "AMP Diag Mode" appears on the display of the main unit • The protection circuit function may have operated. If the unit suddenly enters the standby state and "AMP Diag Mode" appears on the display of the main unit when the power is turned on again, this function is diagnosing whether or not the main unit is malfunctioning or there is an abnormality with the speaker cable connection.
  • Page 150 Troubleshooting ‰ No sound from the TV • Change the input selector on this unit to the position of the terminal to which the TV is connected. • If the TV doesn't support the ARC function, along with connection by HDMI, connect the TV and this unit using a digital optical cable. ( →p54) ‰...
  • Page 151 Troubleshooting ‰ Noise can be heard • Using cable ties to bundle audio pin cables, power cords, speaker cables, etc. may degrade the audio performance. Do not bundle the cords. • An audio cable may be picking up interference. Change the position of the cables. ‰...
  • Page 152 Troubleshooting ‰ About DTS signals • With media that switches suddenly from DTS to PCM, PCM playback may not start immediately. In such a case, stop playback on the player side for approx. 3 seconds or more. Then, resume playback. The playback will be performed normally. •...
  • Page 153 Troubleshooting ‰ Images flicker • The output resolution of the player may not be compatible with the resolution of the TV. If the player is connected to this unit with an HDMI cable, change the output resolution on the player. Also this may be solved by changing the screen mode on the TV. ‰...
  • Page 154 Troubleshooting ‰ Cannot transmit from a BLUETOOTH wireless technology enabled device (PC, smartphone, etc.) to this unit • Check if the BLUETOOTH function of the BLUETOOTH enabled device is enabled. ‰ Cannot connect a BLUETOOTH wireless technology enabled device (PC, smartphone, etc.) to this unit ( →p138) •...
  • Page 155 Troubleshooting ‰ Sound is interrupted • There maybe a problem with the BLUETOOTH enabled device. Check the information on a web page. ‰ The audio quality is poor after connection with a BLUETOOTH enabled device • The BLUETOOTH reception is poor. Move the BLUETOOTH enabled device closer to the unit, or remove any obstacle between the BLUETOOTH enabled device and this unit.
  • Page 156 Troubleshooting „ USB storage device ‰ USB storage device is not displayed ( →p97) • Check if the USB storage device or USB cable is securely inserted to the USB port of the unit. • Disconnect the USB storage device once from the unit, and then reconnect it. •...
  • Page 157 Troubleshooting „ ZONE B function ‰ Cannot output audio to ZONE B ( →p105) • To output audio to ZONE B, set the audio output destination for "Audio" - "Zone B" on AV Adjust to "On (A+B)" or "On (B)" and also set "Speaker" - "Configuration"...
  • Page 158 • The volume level correction of the subwoofer may not have been completed. Lower the volume of the subwoofer before Full Auto MCACC measurement. ‰ Cannot operate the Full Auto MCACC screen with the Pioneer Remote App (available on iOS and Android™)
  • Page 159 Appendix Speaker Layouts and Selectable Listening Modes Input Formats and Selectable Listening Modes Listening Mode Effects Speaker combinations General Specifications Appendix...
  • Page 160 Appendix Speaker Layouts and Selectable Listening Modes See the following table for selectable listening modes for each speaker layout. Speaker layout (ch) Listening mode 2.1.2 3.1.2 4.1.2 5.1.2 DD (Dolby Audio - DD) (*1) (*1) (*1) (*2) (*2) (*2) (*2) (*2) DD+ (Dolby Audio - DD+) (*1)
  • Page 161 Appendix Speaker layout (ch) Listening mode 2.1.2 3.1.2 4.1.2 5.1.2 (*3) (*3) (*3) ES Discrete (DTS-ES Discrete) ES Matrix (DTS-ES Matrix) DTS 96/24 (*3) (*3) (*3) DTS-HD HR (DTS-HD High Resolution) DTS-HD Master (DTS-HD Master Audio) DTS Express DTS:X DTS Neural:X DTS Virtual:X...
  • Page 162 Appendix Speaker layout (ch) Listening mode 2.1.2 3.1.2 4.1.2 5.1.2 (*1) (*1) (*1) (*1) (*1) (*3) (*3) (*3) (*3) (*1) (*1) (*1) (*2) (*2) (*2) (*2) (*2) Stereo (*4) (*4) (*4) (*4) (*4) (*4) (*4) (*4) (*4) Mono (*4) (*4) (*4) (*4) (*4)
  • Page 163 Appendix Input Formats and Selectable Listening Modes You can select a variety of listening modes Listening mode DTHD according to the audio format of the signal to be Pure Direct DSur (Dolby Audio (Dolby Atmos input. Direct (Dolby Audio (Dolby Audio - DD+) Audio - (*13)
  • Page 164 Appendix Listening mode DTS-HD HR DTS-HD ES Discrete ES Matrix DTS 96/24 (DTS-HD High Master (DTS- (DTS-ES DTS (*2) Express (DTS-ES DTS:X Neural:X Virtual:X (*2) Resolution) HD Master Discrete) (*9) (*10) (*2) Matrix) (*5) (*6) Input format (*2) Audio) (*2) (*5) 2-channel signal input Analog / PCM...
  • Page 165 Appendix Listening mode Classical / Unplugged / F.S.Surround Ent.Show (Entertainment Ext.Stereo / (Front Stage (Multich Mono Show) / Drama / Mono Music (*2)(*12) Surround) (*8) PCM) (*2) AdvancedGame / Action Input format (*9) / Rock/Pop / Sports (*7) 2-channel signal input Analog / PCM Music files / DSD (*1) DD / DD+ / DTHD...
  • Page 166 Appendix (*1) You cannot select any mode other than Pure Direct, Stereo, Ext.Stereo and Mono Music if the sampling rate is 5.6/11.2 MHz. (*2) A center speaker or surround speakers need to be installed. (*3) If the input source is Blu-ray Disc and the speaker layout is 5.1 ch or less, DD+ cannot be selected. Instead, the listening mode for DD can be selected. (*4) This can only be selected when no surround back speaker is connected.
  • Page 167 Appendix Listening Mode Effects Atmos 3.0/3.1: When front speakers and center speaker are installed In alphabetical order – Atmos 4.0/4.1: When front speakers and surround speakers are – „ Action installed Atmos 5.0/5.1: When front speakers, center speaker and surround –...
  • Page 168 Appendix „ „ DD+ (Dolby Audio - DD+) DTHD (Dolby Audio - TrueHD) This mode faithfully reproduces the sound design recorded in the Dolby Digital This mode faithfully reproduces the sound design recorded in the Dolby TrueHD Plus audio format. audio format.
  • Page 169 Appendix channels such as the surround back channel at a sampling rate of 96 kHz and at „ DTS a resolution of 24 bits. This mode faithfully reproduces the sound design recorded in the DTS audio • To enable transfer of this audio format, connect via an HDMI cable and set format.
  • Page 170 Appendix „ DTS:X „ F.S.Surround (Front Stage Surround) This mode faithfully reproduces the sound design recorded in the DTS:X audio In this mode, you can enjoy a virtual playback of multichannel surround sound format. even with only two or three speakers. This works by controlling how sounds reach the listener's left and right ears.
  • Page 171 Appendix Speaker combinations • Up to two powered subwoofers can be connected in either combination. (North American models) SURROUND ZONE 2 Speaker Channels FRONT CENTER SURROUND HEIGHT Bi-AMP BACK (ZONE SPEAKER) 2.1 ch (*1) (*1) 3.1 ch (*1) (*1) 4.1 ch (*1) (*1) 5.1 ch...
  • Page 172 Appendix (European, Australian and Asian models) SURROUND ZONE 2 Speaker Channels FRONT CENTER SURROUND HEIGHT Bi-AMP BACK (ZONE SPEAKER) 2.1 ch (*1) (*1) 3.1 ch (*1) (*1) 4.1 ch (*1) (*1) 5.1 ch (*1) (*1) 6.1 ch 7.1 ch 2.1.2 ch (*2) (*1) (*2) (*1)
  • Page 173 Appendix General Specifications Amplifier Section North American models European models Australian and Asian models With 8 ohm loads, both channels driven, from 20-20,000 Hz; rated 80 watts per channel minimum RMS 7 ch × 135 W at 6 ohms, 1 kHz, 1 ch driven of 1% THD (IEC) Rated Output Power power, with no more than 0.08% total harmonic distortion from 250...
  • Page 174 Appendix Tuner Section North American models European models Australian and Asian models 87.5 MHz - 107.9 MHz 87.5 MHz - 108.0 MHz, RDS FM Tuning Frequency Range 50 dB quieting sensitivity (FM MONO) 1.0 μV, 11.2 dBf (IHF, 1 kHz, 100% MOD) 530 kHz - 1710 kHz 522/530 kHz - 1611/1710 kHz AM Tuning Frequency Range...
  • Page 175 Appendix HDMI North American models European models Australian and Asian models Input Output 2 (MAIN, SUB/ZONE2) Input *1 Output SUB/Zone2 HDMI 1 HDMI 2 HDMI 3 HDMI 4 HDMI 5 HDMI 6 MAIN Zone2 HDMI Ver 40Gbps 40Gbps 40Gbps 18Gbps 18Gbps 18Gbps 40Gbps...
  • Page 176 Appendix Corresponding Frame rate Color space Color depth HDMI IN 1 - 3 HDMI IN 4 - 6 input resolutions 24/25/30 Hz YCbCr4:2:2 12 bit (3840x2160p) 8 bit YCbCr4:4:4/RGB 10/12 bit 4K SMPTE 48/50/60 Hz YCbCr4:2:0 8 bit (4096x2160p) 10/12 bit YCbCr4:2:2 12 bit 8 bit...
  • Page 177 Appendix • Signals are output from the HDMI OUT jack of this unit to the TV with the same resolution as the input resolution. When a TV supporting 4K is used, HDMI video signals with 1080p can be output with 4K. For linked functions to work properly, do not connect CEC-compliant devices exceeding the connectable number to the HDMI jack as shown below.
  • Page 178 Appendix USB Section North American models European models Australian and Asian models 2 (Front : Ver.2.0, 5 V/0.5 A, Rear : Ver.2.0, 5V/1 A) MP3 (.mp3) • MPEG-1/MPEG-2 Audio Layer-3/44.1 kHz, 48 kHz/Between 8 kbps and 320 kbps, and VBR WMA (.wma) •...

  • Page 179: Hdmi Cec ( →P123)

    Appendix General North American models European models Australian and Asian models AC 120 V, 60 Hz AC 220 - 240 V, 50/60 Hz Power Supply 460 W 450 W Power Consumption 0.10 W 0.15 W Full Standby mode 1.8 W Network Standby (wired) 1.6 W 1.8 W...
  • Page 180 Appendix Video Inputs North American models European models Australian and Asian models Composite Not equipped Component Not equipped Audio Inputs North American models European models Australian and Asian models Analog 6 (Including 1 × PHONO, 1 × AUX (Front)) 2 (COAXIAL×1, OPTICAL×1) •...
  • Page 181 Appendix Others North American models European models Australian and Asian models Setup Mic 1 (Front) RS-232 Not equipped 12V TRIGGER OUT Not equipped Not equipped Specifications and features are subject to change without notice. ‰ License and Trademark...
  • Page 182 SN 29403933A_EN © 2021 Onkyo Home Entertainment Corporation. All rights reserved. ©2021 Onkyo Home Entertainment Corporation, Tous droits de reproduction et de traduction réservés. https://pioneer-audiovisual.com/privacy/ "Pioneer" and "MCACC logo" are trademarks of Pioneer Corporation, and are used under license. O2110-1...
