Contents Connections Playback Setup ≫ ≫ ≫ ≫ What’s in the box Connecting an AV Component in a Separate Room (Multi-zone Connection) Additional Function (Firmware Update) Connecting a TV (ZONE 2) Update Information of the firmware Connecting ZONE B Operation of added new functions Connecting a Pre-main Amplifier (ZONE B) Firmware Update Procedure Connecting Antennas...
Page 3
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Multi-zone Basic Operations Device and Supported Format Playing Back Playing back files on a PC and NAS (Music Server) ZONE B Playback Windows Media Player settings Playing Back ® Playing Back Convenience functions Supported Audio Formats Using PERSONAL PRESET Play Queue...
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Appendix Multi Zone Miscellaneous Reducing the Power Consumption in Standby State 147 MCACC About HDMI Menu operations General Specifications Full Auto MCACC Manual MCACC MCACC Data Check Network/Bluetooth Menu operations Network Bluetooth AV Adjust Menu operations Web Setup...
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Additional Function (Firmware Update) This unit is equipped with a function to update the firmware via network or USB port when the firmware update is announced after purchase. This enables various functions to be added and operations to be improved. Depending on the manufacturing timing of the product, the firmware may be switched to the updated one.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Firmware Update Procedure The update may take approx. 20 minutes to complete via network or via USB Update port. Existing settings are guaranteed in either updating method. 1. Press When this unit is connected to the network, notifications of firmware updates may The Home screen is displayed on the TV screen.
Page 8
Contents Connections Playback Setup ≫ ≫ ≫ ≫ If an Error Message is Displayed • If "HDMI CEC" is set to "On", set it to "Off". If an error occurs, "- Error!" is displayed on the display of the unit. ("" –...
Page 9
Contents Connections Playback Setup ≫ ≫ ≫ ≫ 6. Select "System Setup" - "Miscellaneous" - "Firmware Update" - "Update via the firmware file is for another model. Retry from the download of the firmware USB" with the cursors in order, then press ENTER. file.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Part Names Front Panel ❏ For details, see ( p11) Front Panel≫ Rear Panel≫ Remote≫...
Page 11
Contents Connections Playback Setup ≫ ≫ ≫ ≫ 1. INPUT SELECTOR dial: Switch the input to be played. 17. TUNER button: Switches the input to be played to "TUNER". Also, pressing 2. DIMMER button: You can switch the display off or adjust the brightness of the this button repeatedly switches the input between "AM"...
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Display 9 bk 1. This may light when performing operations with the "NET", "USB" input 5. Displays the audio output destination. selector. A: Outputs audio only to ZONE A. 2. Lights in the following conditions. B: Outputs audio only to ZONE B.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Rear Panel (North American models) 90° 180° ❏ For details, see ( p15) Front Panel≫ Rear Panel≫ Remote≫...
Page 14
Contents Connections Playback Setup ≫ ≫ ≫ ≫ (European, Australian and Asian models) 90° 180° ❏ For details, see ( p15) Front Panel≫ Rear Panel≫ Remote≫...
Page 15
Contents Connections Playback Setup ≫ ≫ ≫ ≫ 1. DIGITAL AUDIO IN OPTICAL/COAXIAL jacks: Input TV or AV component digital audio signals with a digital optical cable or digital coaxial cable. 2. ANTENNA AM LOOP/FM UNBAL 75 Ω terminal: The supplied antennas are connected.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Remote Controller STANDBY/ON button 2. PERSONAL PRESET 1/2/3 buttons: Registers the current setting conditions such as input selector, listening mode, etc. or call the registered settings. p78) 3. Input selector buttons: Switches the input to be played. ...
Page 17
Contents Connections Playback Setup ≫ ≫ ≫ ≫ 20. +Fav button: Used to register AM/FM radio stations. ( p72) 21. MODE button: Switches between automatic tuning and manual tuning for AM/FM stations ( p70). Also, when an HDMI CEC function-enabled AV component is connected to this unit, you can switch "4.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connections Connecting speakers Connecting the TV Connecting Playback Devices Connecting an AV Component in a Separate Room (Multi-zone Connection) Connecting ZONE B Connecting Antennas Network Connection Connecting the Power Cord Front Panel≫ Rear Panel≫ Remote≫...
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connecting speakers You can select the layout of speakers to be installed from various patterns when using this unit. Use the following flow chart to select the speaker layout that suits your speakers and usage environment.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Speaker Installation 5.1 Channel System This is a basic 5.1 Channel System. Front speakers output the front stereo sound, and a center speaker outputs the sound of the center of the screen, such as dialogs and vocals.
Page 21
Contents Connections Playback Setup ≫ ≫ ≫ ≫ 7.1 Channel System This is a 7.1 Channel System that consists of the basic 5.1 Channel System p20) and added surround back speakers. Front speakers output the front stereo sound, and a center speaker outputs the sound of the center of the screen, such as dialogs and vocals.
Page 22
Contents Connections Playback Setup ≫ ≫ ≫ ≫ 5.1.2 Channel System A 5.1.2 Channel System is a speaker layout consisting of the basic 5.1 Channel System ( p20) and added height speakers. Select the height speakers that suit your speakers and usage environment from the following three types. ❏...
Page 23
Contents Connections Playback Setup ≫ ≫ ≫ ≫ ❏ Front High Speakers/Rear High Speakers This is a system with the basic 5.1 channel system ( p20) consisting of front speakers, a center speaker, surround speakers and a powered subwoofer, Installation Example and added front high speakers or rear high speakers combined.
Page 24
Contents Connections Playback Setup ≫ ≫ ≫ ≫ ❏ Ceiling Speakers Installation Example This is a system with the basic 5.1 channel system ( p20) consisting of front speakers, a center speaker, surround speakers and a powered subwoofer, and added top front speakers or top middle speakers or top rear speakers combined. Installing the height speakers will enrich the sound field feeling in the upper space.
Page 25
Contents Connections Playback Setup ≫ ≫ ≫ ≫ ❏ Dolby Enabled Speakers (Dolby Speakers) This is a system with the basic 5.1 channel system ( p20) consisting of front speakers, a center speaker, surround speakers and a powered subwoofer, and Installation Example added Dolby enabled speakers (front) or Dolby enabled speakers (surround) combined.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Speaker Connections and "Speaker Setup" Settings Connections (Note) Speaker Impedance Connect speakers with an impedance of 4 Ω to 16 Ω. If any of the speakers to be connected has an impedance of 4 Ω or more and less than 6 Ω, set "Speaker Impedance"...
Page 27
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connect the Subwoofer a Subwoofer cable Connect a powered subwoofer with this unit using a subwoofer cable. Up to two powered subwoofers can be connected. The same signal is output from each SUBWOOFER PRE OUT jack.
Page 33
Contents Connections Playback Setup ≫ ≫ ≫ ≫ 7.1 Channel System + ZONE SPEAKER (For North American models only) MAIN ROOM "Speaker Setup" settings during Initial Setup ( p133) Speaker Setup Zone 2 Speaker Impedance 6 ohms or above •...
Page 34
Contents Connections Playback Setup ≫ ≫ ≫ ≫ 5.1.2 Channel System "Speaker Setup" settings during Initial Setup ( p133) Speaker Setup 5.1.2 ch Front High Speaker Impedance 6 ohms or above • Speaker Channels: 5.1.2 ch • Subwoofer: •...
Page 35
Contents Connections Playback Setup ≫ ≫ ≫ ≫ 5.1.2 Channel System + ZONE SPEAKER (For North American models only) MAIN ROOM "Speaker Setup" settings during Initial Setup ( p133) Speaker Setup 5.1.2 ch Front High Zone 2 Speaker Impedance 6 ohms or above •...
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Speaker combinations • Up to two powered subwoofers can be connected in either combination. (North American models) SURROUND ZONE 2 Speaker Channels FRONT CENTER SURROUND HEIGHT Bi-AMP BACK (ZONE SPEAKER) 2.1 ch (*1) (*1) 3.1 ch...
Page 37
Contents Connections Playback Setup ≫ ≫ ≫ ≫ (European, Australian and Asian models) SURROUND ZONE 2 Speaker Channels FRONT CENTER SURROUND HEIGHT Bi-AMP BACK (ZONE SPEAKER) 2.1 ch (*1) (*1) 3.1 ch (*1) (*1) 4.1 ch (*1) (*1) 5.1 ch (*1) (*1) 6.1 ch...
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connecting the TV Connect this unit between a TV and AV component. Connecting this unit with the TV can output the video and audio signals of the AV component to the TV, or play the audio of the TV on this unit.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ To ARC TV If the TV supports the ARC (Audio Return Channel) function (*), use only the HDMI cable to connect with the TV. Use the ARC-compatible HDMI IN jack of the TV for connection.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ To Non-ARC TV If the TV does not support the ARC (Audio Return Channel) function (*), connect an HDMI cable and digital optical cable. • If you use a cable set-top box, etc. connected to the input jack of this unit to watch TV (without using a TV’s built-in tuner), connection with a digital optical cable or analog audio cable is not required.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connecting Playback Devices Connecting an AV Component with HDMI Jack Mounted This is a connection example of an AV component equipped with an HDMI jack. When connecting with an AV component that conforms to the CEC (Consumer Electronics Control) standard, you can use the HDMI CEC function (*) that enables linking with input selectors, etc.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connecting an Audio Component This is a connection example of an audio component. Connect a CD player using a digital coaxial cable or analog audio cable. You can also connect a turntable that has an MM-type cartridge to the PHONO jack.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connecting an AV Component in a Separate Room (Multi-zone Connection) Connecting a TV (ZONE 2) While a disc is played on a Blu-ray Disc player in the main room (where this unit is located), you can play the video and audio of the same Blu-ray Disc player or another AV component on the TV equipped with an HDMI IN jack in a separate room (ZONE 2).
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connecting ZONE B Connecting a Pre-main Amplifier (ZONE B) While performing playback through speakers (ZONE A) connected to the unit, you can enjoy the audio of the same source with the pre-main amplifier (ZONE B) connected to the ZONE B LINE OUT jack at the same time.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connecting Antennas Connect the antenna to this unit, and set up the antenna at the best position for listening while receiving radio signals. Attach the indoor FM antenna to the wall using push pins or adhesive tape. (European, (North American Australian and...
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Network Connection This unit can be connected to the network using a wired LAN or Wi-Fi (wireless LAN). You can enjoy network functions such as Internet radio by network connection. If connection is made by the wired LAN, connect the router and the NETWORK jack with the LAN cable as shown in the illustration.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connecting the Power Cord Connect the power cord after all the connections are completed. a Power cord Front Panel≫ Rear Panel≫ Remote≫...
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Playback AV Component Playback BLUETOOTH Playback ® Internet Radio Spotify AirPlay ® DTS Play-Fi ® FlareConnect USB Storage Device Playing back files on a PC and NAS (Music Server) Play Queue Amazon Music Connecting your Unit to a Sonos System Listening To the AM/FM Radio Multi-zone...
Contents Connections Playback Setup ≫ ≫ ≫ ≫ AV Component Playback You can play the audio from AV components, such as Blu-ray disc players through this unit. • When a TV is connected to the HDMI OUT SUB jack, use the HDMI MAIN/SUB button or "AV Adjust" ( p129) to switch between MAIN and SUB.
If a password is requested, enter "0000". • This unit is displayed as "Pioneer VSX-934 XXXXXX". This display can be p126) or the Pioneer Remote changed with the Friendly Name function ( App (can be used with the iOS or Android™).
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Internet Radio By connecting this unit to an Internet-connected network, you can enjoy Internet radio services, such as TuneIn Radio, etc. • To play Internet radio services, the network needs to be connected to the Internet. •...
Page 52
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Internet Radio Service Menu You can bookmark specific stations, or delete stations that have been bookmarked. The displayed menu varies according to the service being selected. The menu icon is displayed while a station is being played. When only this icon is displayed, pressing ENTER will display the menu on the screen.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Spotify Use your phone, tablet or computer as a remote control for Spotify. Go to spotify.com/connect to learn how. Front Panel≫ Rear Panel≫ Remote≫...
Confirm that this unit and the PC are connected to the same network beforehand. Then, press NET on this unit. Next, click the AirPlay icon iTunes, select this unit from the displayed devices, and start play of a music file. iPhone Pioneer VSX-934 XXXXXX e.g., iOS 10 Front Panel≫ Rear Panel≫ Remote≫...
"Group playback" that plays the same music in separate • To use a music streaming distribution service, user registration may be rooms at home. To enjoy this function, download Pioneer Music Control App required. (available on iOS or Android™).
The illustration shows an image. 2. Download Pioneer Remote App from App Store or Google Play™ Store. 3. Connect the mobile device to the network where this unit is connected. 4. Starting up Pioneer Remote App will automatically recognize compatible devices.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ USB Storage Device You can play music files stored on a USB storage device. Basic Operations Perform the following procedure when this unit is on. 1. Switch the input on the TV to the input connected to the unit. TV’s REMOTE 2.
Page 58
Contents Connections Playback Setup ≫ ≫ ≫ ≫ • To return to the previous screen, press • To display an album title, artist name and album art of a file in WAV format, make the folder structure and file names as shown below when saving music files.
Page 59
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Device and Supported Format USB Storage Device Requirements WAV (.wav/.WAV): WAV files contain uncompressed PCM digital audio. • This unit can use USB storage devices that comply with the USB mass • Supported sampling rates: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz storage class standard.
Page 60
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Playing back files on a PC and NAS (Music Server) Streaming play of music files stored on PCs or NAS devices connected to the same network as this unit is supported. • The network servers supported by this unit are PCs that incorporate players equipped with the server functions such as Windows Media Player 11 or 12, or NASes ®...
Page 61
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Playing Back Perform the following procedure when this unit is on. 1. Switch the input on the TV to the input connected to the unit. TV’s REMOTE 2. Start the server (Windows Media Player 11, Windows Media Player 12, or ®...
Page 62
Contents Connections Playback Setup ≫ ≫ ≫ ≫ • Depending on the server sharing settings, contents stored on the server 2. In the "Stream" menu, select "Turn on media streaming" to display a dialog may not be displayed. box. 7. With the cursors, select the music file to play, and then press ENTER to start •...
Page 63
Contents Connections Playback Setup ≫ ≫ ≫ ≫ • Depending on the version of Windows Media Player, the names of items to ® select may differ from the above description. ❏ Supported Audio Formats ( p64) Front Panel≫ Rear Panel≫ Remote≫...
Page 64
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Supported Audio Formats This unit supports the following music file formats. Remote play of FLAC and Apple Lossless (.m4a/.mp4/.M4A/.MP4): DSD is not supported. • Supported sampling rates: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz •...
Page 65
1. Connect this unit to your home network by the network settings on this unit. 2. Download Pioneer Remote App from App Store or Google Play™ Store. 3. Connect the mobile device to the network where this unit is connected.
Page 66
Contents Connections Playback Setup ≫ ≫ ≫ ≫ • If there are no tracks on the Play Queue list, only "Play Now " is 3. To delete a track, slide the track to the left until the trash icon changes to " ".
Page 67
Tap the unit when displayed to select it. selector on the remote controller to display the Network menu and select 5. Tap "NET" or "NETWORK" at the top of the Pioneer Remote App screen, and "Amazon Music" from the menu.
Page 68
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Connecting your Unit to a Sonos System Setting up your Unit to work with the Once your unit is connected to the Sonos Connect you will be able to send any music or source on your Sonos App to the unit. By going through the Sonos Sonos Connect Connect, you can play your unit through other Sonos devices in the network in the same group, or you can just play on your unit.
Page 69
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Now the fun part - listening to Sonos on your Unit 1. Using your Sonos App select the music you want to listen to and send it to the room (or group) where your unit is located. We recommend naming your unit / Sonos Connect combination a friendly name like TV Room or Living Room where the equipment is located.
Page 70
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Listening To the AM/FM Radio You can receive AM and FM radio stations on this unit with the built-in tuner. Tuning into a Radio Station Perform the following procedure when this unit is on. Tuning Automatically 1.
Page 71
Contents Connections Playback Setup ≫ ≫ ≫ ≫ When FM broadcasts reception is poor: Perform the procedure for "Tuning Manually" ( p71). Note that if you tune manually, the reception for FM broadcasts will be monaural rather than stereo, irrespective of the sensitivity of the reception.
Page 72
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Presetting a Radio Station Registration Procedure You can preset up to 40 of your favorite AM/FM radio stations. After tuning in to the AM/FM radio station you want to register, perform the following procedure.
Page 73
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Selecting a Preset Radio Station 1. Press TUNER. 2. Press the cursors to select a preset number. Deleting a Preset Radio Station 1. Press TUNER. 2. Press the cursors to select the preset number to delete. 3.
Page 74
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Using RDS (European, Australian and Asian models) RDS stands for Radio Data System, and is a method of transmitting data in FM • If no stations are found, the message "Not Found" is displayed. radio signals.
Page 75
"BLUETOOTH". You cannot select different stations of AM/FM broadcasts for the main room and separate room. Pioneer Remote App is useful for the multi-zone playback operation. Download Pioneer Remote App (available on iOS or Android™) to a mobile device, such as a smartphone and tablet to use it.
Page 76
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Playing Back In the remote controller operation, while pressing and holding the ZONE 2 SHIFT button on the remote controller, operate with each button. 1. Point the remote controller at the unit, and while pressing and holding the ZONE 2 SHIFT button on the remote controller, press .
Page 77
Contents Connections Playback Setup ≫ ≫ ≫ ≫ ZONE B Playback While performing playback through speakers (ZONE A) connected to the unit, you can enjoy the audio of the same source with the pre-main amplifier (ZONE B) connected to the ZONE B LINE OUT jack at the same time. Playing Back 1.
Page 78
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Convenience functions Using PERSONAL PRESET Registration You can register settings ( p79) such as the current input selector and listening mode with the three PERSONAL PRESET buttons, and call a registered setting in a single operation. e.g.) Pressing the PERSONAL PRESET button will automatically switch the input selector to "TUNER"...
Page 79
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Settings that can be registered The following settings can be registered with PERSONAL PRESET. – Input selector (Network service or AM/FM radio stations can also be registered.) – Listening mode – Volume level (Upper limit "-32 dB") (When ZONE 2 is on, the volume level of ZONE 2 is also registered.) –...
Page 80
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Adjusting the tone Adjusting TREBLE/BASS You can adjust the sound quality of the speakers. 1. Press TONE repeatedly to select Treble or Bass and adjust the content. Treble: Enhances or moderates the high-tone range of the speakers. Bass: Enhances or moderates the low-tone range of the speakers.
Page 81
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Adjusting SUBWOOFER Adjust the speaker level of the subwoofer while listening to the sound. 1. Press SW. 2. Press + or - to adjust the level between "-15.0 dB" and "+12.0 dB". •...
Page 82
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Sleep Timer You can allow the unit to enter standby automatically when the specified time has elapsed. Press SLEEP button on the remote controller to select the time from "30 min", "60 min" and "90 min". "Off": The unit does not automatically enter standby mode.
Page 83
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Listening Mode You can change the listening mode during play by pressing repeatedly "AUTO/DIRECT", "SURR", or "STEREO". Selecting a Listening mode • Each of AUTO/DIRECT, SURR, and STEREO buttons stores the listening mode that was selected last.
Page 84
Contents Connections Playback Setup ≫ ≫ ≫ ≫ AUTO/DIRECT button SURR button Press repeatedly and the listening modes suited to the input signal are switched By pressing repeatedly you can select the audio format of the signals being input between "Auto Surround", "Direct", and "Pure Direct".
Page 85
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Checking the input format and listening mode Pressing repeatedly will switch the display of the main unit in the following order. • The display content for the BLUETOOH input is different. • Not all the information is necessarily displayed. Input source and volume Listening mode Input format...
Page 86
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Speaker Layouts and Selectable Listening Modes See the following table for selectable listening modes for each speaker layout. Speaker layout Listening mode 2.1 ch 3.1 ch 4.1 ch 5.1 ch 6.1 ch 7.1 ch 2.1.2 ch 3.1.2 ch...
Page 89
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Listening Mode Effects Updating of listening modes Atmos Listening modes such as DTS Virtual:X, Atoms 2.0 and DSur 2.0 are (Firmware version supporting Atmos 2.0, etc.) added when the firmware is updated after purchase or the firmware is switched Since this mode calculates the positional data of audio recorded in Dolby Atmos in the product production process.
Page 90
Contents Connections Playback Setup ≫ ≫ ≫ ≫ DD (Dolby Audio - DD) • This mode cannot be selected when DTS signal is input. According to the speaker layout, the following listening modes are displayed. This mode faithfully reproduces the sound design recorded in the Dolby Digital –...
Page 91
Contents Connections Playback Setup ≫ ≫ ≫ ≫ DSD possible to record a maximum of 7.1 channels with additional channels such as the surround back channel. It also supports low bit rates. This mode is suitable for playing sources recorded in DSD. •...
Page 92
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Ent.Show (Entertainment Show) This mode can be selected in any speaker layout such as front speakers-only connection. You can enjoy your favorite movies or TV programs with a more Suitable for rock or pop music. Listening to music in this mode creates a lively immersive audio experience.
Page 93
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Unplugged Suitable for acoustic instruments, vocals and jazz. This mode emphasizes the front sound field image, giving the impression of being in front of the stage. Front Panel≫ Rear Panel≫ Remote≫...
Page 94
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Input Formats and Selectable Listening Modes Selectable listening modes You can select a variety of listening modes Input Format Listening Mode according to the audio format of the signal to be Stereo input.
Page 99
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Input Format Listening Mode DTS:X Stereo DTS:X DTS Virtual:X *1 *2 Classical Unplugged Ent.Show Drama AdvancedGame Action Rock/Pop Sports Ext.Stereo Ext.Mono F.S.Surround Cannot be selected if "Speaker Virtualizer" is set to "Off". Cannot be selected when height speakers are installed.
Page 100
Contents Connections Playback Setup ≫ ≫ ≫ ≫ System Setup Menu list You can configure advanced settings to have a more enjoyable experience with this unit. For operation details, refer to "Menu operations" ( p102). Input/Output TV Out / OSD Make settings for TV output and On-Screen Displays (OSD) that appear on the TV.
Page 101
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Hardware HDMI Change the settings for the HDMI functions. p113 Power Management Change the settings for the power-save function. p115 Works with SONOS Change the settings to connect with the Sonos Connect. p116 Multi Zone Zone 2...
Page 102
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Menu operations Use the on-screen displays (OSD) that appear on the TV to make the settings. Press on the remote controller to display the Home screen, then select System Setup with the cursors on the remote controller and press ENTER. Select the item with the cursor buttons of the remote controller and press ENTER to confirm your selection.
Page 103
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Input/Output Assign Setting Item Default Value Setting Details 1080p -> 4K When using a TV that supports 4K, video signals TV Out / OSD Upscaling input at 1080p can be automatically upscaled to 4K for output.
Page 104
Contents Connections Playback Setup ≫ ≫ ≫ ≫ HDMI Input Digital Audio Input Change input assignment between the input selectors and HDMI IN jacks. Change input assignment between the input selectors and DIGITAL IN COAXIAL/ OPTICAL jacks. If you do not assign a jack, select "---". Setting Item Default Value Setting Details...
Page 105
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Analog Audio Input Setting Item Default Value Setting Details Set whether to skip the AUX input selector. Select Change input assignment between the input selectors and AUDIO IN jacks. If you "Skip"...
Page 106
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Speaker Setting Item Default Value Setting Details Listening Mode Displays the listening mode that has been set. Configuration Volume Displays the volume level that has been set. (Upper limit "-32 dB") Change the settings of connection environment of the speakers.
Page 107
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Crossover Setting Item Default Value Setting Details Bi-Amp Set whether the front speakers are bi-amp Change the settings of crossover frequencies. connected. "No": When front speakers are not bi-amp Setting Item Default Value Setting Details connected...
Page 108
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Distance Setting Item Default Value Setting Details Surround Small Set the low range capabilities for each channel by Set the distance from each speaker to the listening position. setting either small or large. "Small": For small speakers whose low range Setting Item Default Value...
Page 109
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Channel Level Setting Item Default Value Setting Details Surr Back Right 0.0 dB Select a value between "-12.0 dB" and "+12.0 dB" Adjust the volume level of each speaker. (in 0.5 dB increments). A test tone will be output each time you change the value.
Page 110
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Audio Adjust Dolby Enabled Speaker Change the settings of Dolby Enabled Speakers. Dual Mono/Mono Setting Item Default Value Setting Details Change the settings of multiplex audio playback. Dolby Enabled 6.0 ft/1.80 m Set the distance between the Dolby Enabled Speaker to Ceiling Speaker and the ceiling.
Page 111
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Source Volume Change the Volume settings. Input Volume Absorber Setting Item Default Value Setting Details Adjust the volume level when there are differences in volume level among Mute Level -∞ dB Set the volume lowered from the listening volume multiple devices connected to this unit.
Page 112
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Name Edit Audio Select Set an easy name for each input. The set name appears on the main unit’s Select the priority for input selection when multiple audio sources are connected display.
Page 113
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Hardware Setting Item Default Value Setting Details Fixed PCM Select whether to fix input signals to PCM (except HDMI multi-channel PCM) when you select "HDMI", "COAXIAL", or "OPTICAL" in the "Audio Select" Change the settings of the HDMI function.
Page 114
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Setting Item Default Value Setting Details Setting Item Default Value Setting Details HDMI Standby When this is set to anything other than "Off", Audio TV Out You can enjoy audio through the speakers of the Through you can play the video and audio of an HDMI- TV while this unit is on.
Page 115
20 minutes of inactivity without turn on the power of the unit via network using an any video or audio input. (When "USB Power Out application such as Pioneer Remote App that can at Standby" or "Network Standby" is enabled, the control this unit.
Page 116
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Works with SONOS Setting Item Default Value Setting Details Bluetooth Wakeup Off This function wakes up the unit on standby by Change the settings to connect with the Sonos Connect. connecting a BLUETOOTH-enabled device. "On": When this function is used Setting Item Default Value...
Page 117
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Multi Zone Setting Item Default Value Setting Details Preset Volume Main: You can set the volume beforehand for playing Zone 2 Last back the Sonos Connect. You can set volumes Zone 2: for the main room (where this unit is located) and Change the settings for Zone 2.
Page 118
Select an ID for the unit's remote controller from "1", "2", and "3" to prevent interference between the unit and other Pioneer components that are Make the initial setup from the setup menu. installed in the same room. After changing the ID •...
Page 119
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Lock Lock the Setup menu so that the settings cannot be changed. Setting Item Default Value Setting Details Setup Parameter Unlocked Lock the Setup menu so that the settings cannot be changed.
Page 120
Contents Connections Playback Setup ≫ ≫ ≫ ≫ MCACC Menu operations Setup the speakers automatically or make desired changes to the equalizer. You can also check the values set currently for each speaker setting. Use the on-screen displays (OSD) that appear on the TV to make the settings. Press on the remote controller to display the Home screen, then select MCACC with the cursors on the remote controller and press ENTER.
Page 121
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Full Auto MCACC 2. Place the supplied speaker setup microphone in the listening position, and connect to the SETUP MIC jack on the main unit. Place the supplied speaker setup microphone in the listening position, measure the test tones emitted by the speakers, then the unit automatically sets the optimum volume level for each speaker, the crossover frequencies, and the distance from the listening position.
Page 122
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Manual MCACC Setting Item Default Value Setting Details Height Left 0.0 dB After selecting the speaker frequency from between EQ Adjust "63 Hz" and "16 kHz" with the cursors / , adjust the volume of that frequency between "-12.0 dB"...
Page 123
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Setting Item Default Value Setting Details Setting Item Default Value Setting Details Surround Right 0.0 dB After selecting the speaker frequency from between Surr Back Left 0.0 dB After selecting the speaker frequency from between "63 Hz"...
Page 124
Contents Connections Playback Setup ≫ ≫ ≫ ≫ MCACC Data Check You can check the number of speaker channels connected and the content and values you have set for each of the speaker settings. Speaker Setting You can check the number of speaker channels connected and the large and small settings you have set for the low range reproduction capabilities for each of the speakers.
Page 125
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Network/Bluetooth Menu operations Make settings related to network connections and BLUETOOTH. Use the on-screen displays (OSD) that appear on the TV to make the settings. Press on the remote controller to display the Home screen, select Network/ Bluetooth with the cursors on the remote controller, then press ENTER.
Page 126
"DHCP" to "Disable" and assign an address Friendly Name Pioneer VSX- Change the device name for this unit which is to this unit in "IP Address" as well as set information related to your LAN, such...
Page 127
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Bluetooth Setting Item Default Value Setting Details AirPlay Password - You can set a password of up to 31 characters so that only registered users can use AirPlay ® Setting Item Default Value Setting Details 1.
Page 128
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Setting Item Default Value Setting Details Pairing You can initialize the pairing information saved on Information this unit. Pressing ENTER when "Clear" is displayed initializes the pairing information stored in this unit. •...
Page 129
Contents Connections Playback Setup ≫ ≫ ≫ ≫ AV Adjust Menu operations You can quickly adjust the settings you frequently use, such as tone adjustments, etc. You can make the settings on the TV screen while playing something. Press on the remote controller to display the AV Adjust menu. Note that there is no display on the TV screen when the input selector is "AUX", "CD", "TV", "PHONO", "FM", or "AM", so follow the main unit’s display while doing the operations.
Page 130
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Subwoofer: Adjust the speaker level of the subwoofer while listening to the DRC: Make small sounds easily heard. It is useful when you need to reduce the sound. volume while watching a movie late night. You can enjoy the effect only when •...
Page 131
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Web Setup Menu operations You can make the settings for the network function of this unit using an Internet Network Connection: You can select a network connection method. If you select browser on a PC, smartphone, etc. "Wireless", select an access point from "Wi-Fi Setup"...
Page 132
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Initial Setup with Auto Start-up Wizard Operations When you turn the unit on for the first time after purchase, the Initial Setup screen is automatically displayed on the TV to allow you to make settings required for TV’s REMOTE startup using simple operations following on-screen guidance.
Page 133
Contents Connections Playback Setup ≫ ≫ ≫ ≫ • If you have terminated the Initial Setup halfway, turn this unit to standby mode. • If you connect a subwoofer, check the power and volume of the subwoofer. Then turning the power on again can display the Initial Setup again. Set the subwoofer volume to more than half.
Page 134
Contents Connections Playback Setup ≫ ≫ ≫ ≫ 4. Network Connection Make the network connection settings. There are two methods for network connection. "Wired": Use a wired LAN to connect to a network. "Wireless": Wi-Fi connection using an access point such as a wireless LAN router.
Page 135
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Troubleshooting Tuner BLUETOOTH function Before starting the procedure Network function Problems may be solved by simply turning the power on/off or disconnecting/ USB storage device connecting the power cord, which is easier than working on the connection, setting and operating procedure.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ When the unit is operating erratically ❏ Try restarting the unit Restarting this unit may solve the problem. After turning the unit to standby mode, press and hold the STANDBY/ON button of the main unit for at least 5 seconds, and then restart the unit.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ ❏ Resetting the unit (this resets the unit settings to the default) If the restart of the unit does not solve the problem, reset the unit, and restore all the settings to the factory default at the time of purchase. This may solve the problem. If the unit is reset, your settings are restored to the default values.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Troubleshooting Power ❏ When the power is turned on, "AMP Diag Mode" appears on the display of the main unit. • The protection circuit function may have operated. If the unit suddenly enters the standby state and "AMP Diag Mode" appears on the display of the main unit when the power is turned on again, this function is diagnosing whether or not the main unit is malfunctioning or there is an abnormality with the speaker cable connection.
Page 139
Contents Connections Playback Setup ≫ ≫ ≫ ≫ ❏ No sound from the TV • Change the input selector on this unit to the position of the terminal to which the TV is connected. • If the TV does not support the ARC function, along with the connection by an HDMI cable, connect the TV with this unit using a digital optical p40) cable.
Contents Connections Playback Setup ≫ ≫ ≫ ≫ ❏ The beginning of audio received by an HDMI IN cannot be heard • Since it takes longer to identify the format of an HDMI signal than it does for other digital audio signals, audio output may not start immediately. ❏...
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Video • Confirm that the connection between the output jack on the connected device and the input jack on this unit is correct. • Make sure that none of the connecting cables are bent, twisted, or damaged. •...
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Tuner ❏ Poor reception or much noise • Recheck the antenna connection. p45) • Move the antenna away from the speaker cord or power cord. • Move the unit away from your TV or PC. •...
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Network function • If you cannot select a network service, start up the network function to select it. It may take approx. one minute to start it up. • When the NET indicator is blinking, this unit is not properly connected to the home network. •...
Contents Connections Playback Setup ≫ ≫ ≫ ≫ USB storage device ❏ USB storage device is not displayed • Check if the USB storage device or USB cable is securely inserted to the USB port of the unit. p57) •...
Contents Connections Playback Setup ≫ ≫ ≫ ≫ ZONE B function ❏ Cannot output audio to ZONE B • To output audio to ZONE B, set the audio output destination to "ZONE A+B" or "ZONE B". p77) Multi-zone function ❏...
Page 146
Contents Connections Playback Setup ≫ ≫ ≫ ≫ ❏ The message "Noise Error" appears during Full Auto MCACC • This can be caused by a malfunction in your speaker unit. Check the speaker output, etc. ❏ The measurement results of Full Auto MCACC show different distances to the speakers from the actual ones •...
Page 147
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Reducing the Power Consumption in Standby State When the following functions are enabled, the power consumption in standby state increases. To reduce the power consumption in standby state, check each setting and set the functions to "Off". –...
Page 148
Contents Connections Playback Setup ≫ ≫ ≫ ≫ About HDMI Compatible functions transmitted to the TV. Deep Color: HDMI (High Definition Multimedia Interface) is a digital interface standard for By connecting devices supporting Deep Color, video signals input from the connecting TVs, projectors, Blu-ray Disc/DVD players, digital tuners, and other devices can be reproduced on the TV with even more colors.
Page 150
Contents Connections Playback Setup ≫ ≫ ≫ ≫ General Specifications Amplifier Section Signal to Noise Ratio 106 dB (IHF-A, LINE IN, SP OUT) Rated Output Power (FTC) (North American) 80 dB (IHF-A, PHONO IN, SP OUT) With 8 ohm loads, both channels driven, from 20-20,000 Hz; rated 80 watts Speaker Impedance per channel minimum RMS power, with no more than 0.08% total harmonic 4 Ω...
Page 151
Contents Connections Playback Setup ≫ ≫ ≫ ≫ BLUETOOTH Section 2.1 W (Standby mode (ALL ON)) (North American) 2.3 W (Standby mode (ALL ON)) (Others) Communication system 55 W (No-sound) BLUETOOTH Specification version 4.1+LE 6 W (HDMI Standby Through) (North American) Frequency band 6.1 W (HDMI Standby Through) (Others) 2.4 GHz band...
Page 152
Contents Connections Playback Setup ≫ ≫ ≫ ≫ Supported input resolutions HDMI input 4K, 1080p/24, 1080p, 1080i, 720p, 480p/576p • The output from the HDMI OUT jack to the TV is the same resolution as the input. When using a TV that supports 4K, 1080p HDMI video signals can also be output as 4K.
