- Page 1 Wireless Thermo Clock Model : RMR602A User Manual RMR602A lab test cover R1 1/8/04, 6:51 PM...
-
Page 2: Table Of Contents
CONTENTS Contents ... 1 Introduction ... 2 About Oregon Scientific ... 2 Product Overview ... 3 Front View ... 3 Back View ... 4 Remote Sensor ... 5 Getting Started ... 6 Batteries ... 6 Change Settings ... 6 Table Stand or Wall Mount ... 6 Remote Sensor ... -
Page 3: Introduction
INTRODUCTION Thank you for selecting the Oregon Scientific Thermo Clock (RMR602A). This device bundles precise time keeping, alarm, and temperature monitoring features into a single tool you can use from the convenience of your home. In this box, you will find: •... -
Page 4: Product Overview
PRODUCT OVERVIEW FRONT VIEW RMR602A lab test R2 Outdoor Temperature Area: Readings, sensor battery and reception status Indoor Temperature Area: Readings and main unit battery status. Clock / Alarm Area: Time, day of week, month, date, alarm : Press to increase setting or enable Atomic Clock... -
Page 5: Back View
"AAA" UM4 1.5V "AAA" UM4 1.5V "AAA" UM4 1.5V C/ F C/ F SEARCH SEARCH RESET RESET RMR602A lab test R2 Wall mount Battery compartment °C / °F switch RESET hole SEARCH button Table stand REMOTE SENSOR (THGR122N) GETTING STARTED... -
Page 6: Remote Sensor
REMOTE SENSOR LED Status indicator RMR602A lab test R2 Wall mount hole Battery compartment Battery compartment cover 1/17/04, 4:49 PM 2, 3... -
Page 7: Getting Started
UNIT LOCATION Main Indoor Temperature Area Remote Outdoor Temperature Area. RMR602A lab test R2 CHANGE SETTINGS Press and hold MODE for 2 seconds to enter setting mode. Press UP or DOWN to change settings. Press MODE to confirm. TABLE STAND OR WALL MOUNT Use the stand on the back of the product, or mount it on a wall with a nail. -
Page 8: Setup Sensor
Close the remote sensor battery compartment. Secure the sensor in the desired location using the wall mount or table stand. RMR602A lab test R2 For best results: • Insert the batteries before you mount the sensor. • Place the sensor out of direct sunlight and moisture. -
Page 9: Data Transmission
This is normal and does not affect general product performance. The reception will resume once the interference ends. RMR602A lab test R2 CLOCK This product has two displays: Clock with day of week in German, English, French, Italian, or Spanish, and Calendar display with month and date. -
Page 10: Turn Atomic Clock On/Off
SWITCH CLOCK DISPLAY Press MODE to toggle between Calendar and Clock display with Hour Offset, Seconds, or Weekday. RMR602A lab test R2 ALARM This product has 2 alarms: a Single Alarm and a Weekday Alarm. The Single Alarm can be set to go off at a specific time for a one-time event (for example, if you are napping on Saturday). -
Page 11: Temperature
The current temperature readings will be shown as the minimum and maximum records. RMR602A lab test R2 RESET SYSTEM T h e R E S E T b u t t o n i s l o c a t e d i n t h e b a t t e r y compartments for the main unit. -
Page 12: Warnings
Unauthorized changes may void your right to use the product. The technical specification of this product and contents of this user guide are subject to change without notice. Images not drawn to scale. RMR602A lab test R2 TROUBLESHOOTING Check here before contacting our customer service department. -
Page 13: Specifications
-20 °C to 60 °C Outdoor Range (-4 °F to 140 °F) 0.1 °C (0.2° F) Resolution Memory Min / Max RMR602A lab test R2 REMOTE SENSOR RF frequency 433 MHz Range 30 meters (98 feet) with no obstructions Transmission... -
Page 14: Fcc Statement
RMR602A lab test R2 • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. - Page 15 Phase 1, 41 Man Yue St., Hung Hom, Kowloon, Hong Kong RMR602A lab test R2 is in conformity with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference.
- Page 16 © 2004 Oregon Scientific. All rights reserved. P/N.: 086-003350-010 RMR602A lab test back cover 12/29/03, 10:23 PM Black...
