Summary of Contents for Fisher & Paykel OR120DDWGFX2
Page 1
• Immediately wipe off any caustic cleaners if they are spilled onto the oven door handle. Wipe the outside surfaces often, using warm water and a mild household detergent. The stainless steel may also be cleaned with a suitable cleaner and polish. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGFX2/User_Guide_OR120DDW… Updated: Thu, 06 Apr 2023 11:51:13 GMT Powered by...
• It is very important to check that the burner flame spreader and the cap have been correctly positioned. Failure to do so can cause serious problems. To avoid damage to the electronic ignition, do not try to light a burner without all burner parts in place. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGFX2/User_Guide_OR120DDW… Updated: Thu, 06 Apr 2023 11:51:13 GMT Powered by...
To replace the wok burner, fit the burner ring to the housing as shown by the arrow in Figs. 29-30. Make sure the burner is not able to rotate Fig. 29. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGFX2/User_Guide_OR120DDW… Updated: Thu, 06 Apr 2023 11:51:13 GMT Powered by...
Page 4
• Position the central small cap in its housing as shown by the arrows (Fig. 31b). • Position the big cap in its housing as shown by the arrows (Fig. 31c). https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGFX2/User_Guide_OR120DDW… Updated: Thu, 06 Apr 2023 11:51:13 GMT Powered by...
If you have problems with the gas valves, call your Authorised Service Centre. Cleaning the Inside of Your Ovens • Do not use abrasive cleaners, cloths or pads to clean the enamel. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGFX2/User_Guide_OR120DDW… Updated: Thu, 06 Apr 2023 11:51:13 GMT Powered by...
Page 6
Make sure that the fixing screw is tightened and the element is held securely in place. • The grill element itself is self-cleaning. Fig. 33 Drop-down grill element https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGFX2/User_Guide_OR120DDW… Updated: Thu, 06 Apr 2023 11:51:13 GMT Powered by...
The oven door has three panes of glass. To clean these, you need to remove the inner and middle panes. Removing the Inner and Middle Panes of Glass https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGFX2/User_Guide_OR120DDW… Updated: Thu, 06 Apr 2023 11:51:13 GMT Powered by...
Page 8
• Clean the glass with an appropriate cleaner. Dry thoroughly, and place on a soft surface. Fig. 35e Fig. 35d 3. Remove the middle pane: • Gently unlock the middle pane of glass from the bottom clamps by moving it as in Fig. 36b. https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGFX2/User_Guide_OR120DDW… Updated: Thu, 06 Apr 2023 11:51:13 GMT Powered by...
Page 9
• Gently insert the top edge of the pane into the top clamps (arrow 1 in Fig. 37b), then lower the pane and insert the bottom edge into the bottom clamps (arrow 2 in Fig. 37b); and then slide the pane into position (Fig. 37c). https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGFX2/User_Guide_OR120DDW… Updated: Thu, 06 Apr 2023 11:51:13 GMT Powered by...
Page 10
“H” (Fig. 38c). • Replace the seal “G” by hooking in the three fixing hooks. Make sure that you put it in the correct way. (Fig. 38e). Fig. 38a Fig. 38b https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGFX2/User_Guide_OR120DDW… Updated: Thu, 06 Apr 2023 11:51:13 GMT Powered by...
The oven door(s) can easily be removed as follows: • Open the door to the full extent (Fig. 39a). Open the lever “A” completely on the left and right hinges (Fig. 39b). https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGFX2/User_Guide_OR120DDW… Updated: Thu, 06 Apr 2023 11:51:13 GMT...
Page 12
• Withdraw the hinge hooks from their location following arrow “C” (Fig. 39e). Rest the door on a soft surface. To replace the door, repeat the above steps in reverse order. Fig. 39a Fig. 39b Fig. 39e Fig. 39d https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGFX2/User_Guide_OR120DDW… Updated: Thu, 06 Apr 2023 11:51:13 GMT Powered by...
2. Gently close the drawer completely; the safety catches will automatically hook. Make sure you put the drawers back on the correct side. The left (warmer) drawer is uncoated stainless steel. Fig. 40b Replacing the drawers https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGFX2/User_Guide_OR120DDW… Updated: Thu, 06 Apr 2023 11:51:13 GMT Powered by...
• Unscrew and replace the bulb “A” with a new one suitable for high temperatures (300°C) with the specifications: 230-240V 50 Hz, 25W, E14 • Refit the protective cover, “B”. Oven bulb replacement is not covered by your warranty. Fig. 41 Removing the oven lamp https://producthelp.fisherpaykel.com/eu/Cook/Freestanding_Cookers/Dual_Fuel/OR120DDWGFX2/User_Guide_OR120DDW… Updated: Thu, 06 Apr 2023 11:51:13 GMT Powered by...
