How To Select Egc Receiving Channel; How To Select Ncs Channel - Furuno INMARSAT-C FELCOM 18 Operator's Manual

8. OTHER FUNCTIONS
8.3

How to Select EGC Receiving Channel

EGC channel can be selected when the terminal unit is set to operate as an EGC-only
receiver. However, this procedure is shown for reference only; currently there is only
one EGC channel per NCS.
1. Press the F7 and 5 keys to display the [EGC Channel List].
2. Select a desired channel then press the Enter key.
3. Long-press the Esc key to return to the standby display.
8.4

How to Select NCS Channel

You may select NCS common channel as shown below. Currently, each satellite
sends one global beam. In the future, the satellites will transmit multiple spot beams,
namely, the NCS will have multiple channels.
1. Press the F7 and 5 keys to display the [NCS Channel List].
2. Select a desired channel then press the Enter key.
3. Long-press the Esc key to return to the standby display.
8-2
EGC Channel List
ENTER: Set ESC: Quit
11080* 12580*
NCS Channel List
AORW/AMER AORE
No
ID FREQ ID FREQ
01 044 11080* 144 12580*
02 0 1
03 0 1
04 0 1
05 0 1
06 0 1
07 0 1
08 0 1
35:00.00N
135:00.00E
10840* 11088*
ENTER: Set ESC: Quit
POR/APAC IOR/EMEA
ID FREQ ID FREQ
244 12580* 344 10840*
2 3
2 3
2 3
2 3
2 3
2 3
2 3
