- Page 1 Portable Printer B-FP3D-GH30/40-QM-R B-FP3D-GS32/42-QM-R B-FP3D-GH52-QM-R Owner's Manual...
-
Page 2: Part Names
Part Names Print head Media sensor Platen Top cover Peel-off unit GH30/GH40/GH52 only) Tear bar Top cover open button Battery cover DCIN connector Operation panel Battery lever Strap slot USB port Battery pack Belt clip Print head cleaner BD address label (GS32/GH30/GH52 models only) M-3x8 screws... -
Page 3: Operation Panel Functions
Operation Panel Functions (11) (12) (10) POWER FEED PAUSE STATUS CHARGE NOTE: Do not touch the operation panel with a sharp object, as its surface is easily damaged. Name/Icon Function/Usage Icons indicating the printer statuses, such as the radio intensity, Liquid Crystal Display battery level, etc. - Page 4 Displayed when an error has occurred in the printer. Error Battery level Indicates the battery level in 5 levels. Lights or blinks in green, red or orange to indicate the printer status. • Lights up in green: Normal state • Lights up in orange: Low-battery warning state (Operable) STATUS lamp •...
- Page 5 Loading a Battery Pack WARNING! 1. If the battery pack leaks liquid or gives out smoke or a bad smell, immediately stop using it and keep it away from fire. Failure to do this may cause combustion or even an explosion. 2.
-
Page 6: Removing A Battery Pack
Removing a Battery Pack Push the battery lever down in the direction of the arrow, and remove the battery pack from the printer by pulling on the tab. Battery lever Open Battery pack Charging the Battery Pack with an Optional Adapter When charging the battery pack in the printer using an optional AC adapter, cigarette lighter adapter, or DC adapter, insert the plug of the adapter into DCIN... -
Page 7: Loading The Media
Paper guide Paper lever guide NOTE: • Use Toshiba Tec approved media only. We are not responsible for any print result due to the use of other media. • When you order media, contact the nearest Toshiba Tec representative. NOTE: Be careful when working with the tear bar. - Page 8 Before using a Peel-off Unit (GH30, GH40, GH52 models only) How to put away the peel-off roller When issuing labels in the peel-off mode, pull out the peel-off roller before loading a label roll. 1. Gently press the peel-off roller unit down and 1.
- Page 9 How to Attach the Accessories CAUTION! 1. Care should be taken not to drop the printer when securing it to your waist or slinging it over your shoulder. The use of the other belts may cause 2. For fixing the printer to your belt, the belt width should be 40 mm or less. the printer to fall.
-
Page 10: Data Transmission
The radio connectivity is affected by the operating Access point environment. Especially, metal obstacles, metal powder or locations enclosed by metal walls may prevent proper communication. For the installation location of access points, consult Handy terminal the nearest Toshiba Tec representative. [Wireless LAN]... -
Page 11: Daily Maintenance
Daily Maintenance To maintain the high quality and performance of the printer, regular cleaning is required. CAUTION! DO NOT USE a sharp object to clean the print head or various rollers, as this may cause a print failure or even •... - Page 12 Media sensor window and media path Media sensor window Remove dust or dirt from the media sensor window with a commercially available soft, dry brush. Clean the media path with a soft dry cloth. When linerless labels are used, wipe off the dirt of residual glues from the media guides each time one or two media rolls are used up.
-
Page 13: Troubleshooting
If you cannot solve a problem by means of the following, do not attempt to repair it by yourself. Turn off the printer, remove the battery pack, then contact a Toshiba Tec service representative for assistance. When an error message is displayed When an error message is displayed, follow the respective instruction then press the [PAUSE] button. - Page 14 The flash memory has insufficient area FLASH MEMORY FULL again. If the problem reoccurs, turn off for storing data. the power and contact your Toshiba Tec service representative. Turn off the printer and replace the LOW BATTERY The remaining battery capacity is low.
- Page 15 Load the media properly. The printout is light. Damaged media is used. Load a new media roll. The media is not a Toshiba Tec Use a Toshiba Tec approved media. approved one The [STATUS] lamp is lit or blinking. Clear the error The printer received print data but does not print.
-
Page 16: Printer Specification
Printer Specification Model B-FP3D-GS32-QM-R B-FP3D-GS42-QM-R B-FP3D-GH30-QM-R B-FP3D-GH40-QM-R Media types Label / Tag / Receipt Print method Direct Thermal Resolution 203dpi (8dots/mm) Max. 6 inch/s (152 mm/s) Print speed (Depending on the operating environment, print conditions, battery condition, etc.) Effective print width 72mm (2.9") - Page 17 Model B-FP3D-GH52-QM-R Media types Label / Tag / Receipt Print method Direct Thermal Resolution 203dpi (8dots/mm) Max. 6 inch/s (152 mm/s) Print speed (Depending on the operating environment, print conditions, battery condition, etc.) Effective print width 72mm (2.9") Issue mode Batch / Peel-off UPC-A/E, EAN8/13,UPC-A/E add on 2&5, EAN-8/13 add on 2&5, Code39, Code93, Barcode...
-
Page 18: Media Specification
Media Specification <Labels> Print surface Feed direction Roll method: Labels facing outside <Tag> Black mark (back side） Print surface Roll method: Receipts facing outside Feed direction... - Page 19 (Unit: mm) Media type Label Receipt With black Without Mode Batch Peel-off Item marks black marks Min. 10.0 13.0 10.0 – A Label pitch Max. 999.9 67.0 999.9 – Min. 10.0 – B Label length Max. 997.0 60.0 997.0 – Min.
- Page 20 Do not use labels pre-printed with ink which contains hard substances such as carbonic calcium (CaCO and kaolin (Al , 2SiO , 2H For further information, contact your local distributor or your media manufacturer. PRINTED IN INDONESIA © 2023 Toshiba Tec Corporation All Rights Reserved R221121Z7800-TTEC 1-11-1, Osaki, Shinagawa-ku, Tokyo 141-8562, JAPAN BU22006400-EN Ver0000...
