Page 1: Table Of Contents
6 DEALER MANUAL FOR H500 (RM G062.750/1000.D) CONTENT 6.1 Introduction 6.3 Drive Unit Installation 6.2 Specifications 6.3.1 List of Tools to be used 6.2.1 Outline and geometric size 6.3.2 Motor Installation 6.4 Maintenance 6.2.2 Surface 6.2.3 Storage Information BF-DM-C-RM G062-D-EN November 2019... -
Page 2: Introduction
6.1 INTRODUCTION • Scope Applies only to electrically powered pedelecs developed or licensed by Bafang. It is suitable for fat bikes or all terrain bikes, which have been developed for off road on gravel or sand use. The engine is not suitable for sport competi- tions. -
Page 3: Outline And Geometric Size
6.2.1 Outline and geometric size Model A(mm) B(mm) C(mm) D(mm) E(mm) 42.2 RM G062.750.D 32.5 42.2 42.2 RM G062.1000.D 32.5 42.2 Motor cable length: L=250mm 6.2.2 Surface Shockproof black coating 6.2.3 Storage Information The pedelec should be stored in a ventilated dry room. Avoid storing the pedelec near strong magnetic objects. -
Page 4: Drive Unit Installation
6.3 DRIVE UNIT INSTALLATION 6.3.1 List of Tools to be used Use of the Tools Tools To tighten/loosen the M5*8 screws onto the disc brake. Internal hex wrench To tighten/loosen the M12 flange nuts. Open spanner 6.3.2 Motor Installation Mount the cassette on the motor. Mount the stop pin into on the shaft. -
Page 5: Maintenance
Mount the 2mm washer on both sides of Tighten the flange nuts with open spanner the frame. at both sides of the motor. (torque require- ment: 47-60 N.m.) 6.4 MAINTENANCE • Maintenance must be carried out by autho- rized personnel with the correct equipment. •... - Page 6 BF-DM-C-RM G062-D-EN November 2019...
