6 DEALER MANUAL FOR M620 (MM G510.750/1000/1300.C) CONTENT 6.1 Introduction 6.3.2 Motor Installation 6.2 Specifications 6.3.3 Cabling 6.2.1 Outline and geometric size 6.3.4 Motor Cover Installation 6.3.5 Chain Wheel Installation 6.2.2 Surface 6.3.6 Crank Installation 6.2.3 Storage Information 6.3 Drive Unit Installation 6.3.7 External Speed Sensor Installation 6.4 Maintenance 6.3.1 List of Tools to be used... -
Page 2: Introduction
• Scope the information from the motor. Applies only to electrically powered pedelecs developed or licensed by Bafang. It is suitable for speed and cargo bikes, which have been developed for road use. The engine is not suitable for sport competitions. -
Page 3: Specifications
6.2 SPECIFICATIONS Motor model: MM G510 .750 / 1000 / 1300.C Rated power (W) 750 / 1000 / 1300 Rated voltage (V) 48 / 52 Waterproof IP65 Certification CE / ROHS / EN14766 Outdoor Temperatures -20℃~45℃ 6.2.1 Outline and geometric size BF-DM-C-MM G510-EN November 2019... -
Page 4: Surface
Chain line(CL): 48 / 70mm Shaft standard: ISIS 6.2.2 Surface Shockproof black coating 6.2.3 Storage Information The pedelec should be stored in a ventilated dry room. Avoid storing the pedelec near strong magnetic objects. BF-DM-C-MM G510-EN November 2019... -
Page 5: Drive Unit Installation
6.3 DRIVE UNIT INSTALLATION 6.3.1 List of Tools to be used Use of the Tools Tools To fasten bolts onto the frame adapter and the drive unit Internal hex wrench To fasten nuts onto the frame adapter and the drive unit Socket spanner To fasten screws on the motor cover and cable cover Cross screwdriver... - Page 6 2) Align the three mounting holes of the drive unit with the mounting holes in the bike frame. From the right of the bike frame insert three special M8 bolts (A) into the mounting holes in the bike frame and the drive unit.
-
Page 7: Cabling
6.3.3 Cabling Note: Please attention and make sure that the cable cannot be squeezed by the motor and frame. 6.3.3.1 Connection of the battery cables to the motor The male connector (red/ positive) from the battery The male connector (red/ positive) from the motor The female connector (black/ negative) from the battery... - Page 8 6.3.3.3 Connection of the EB-BUS to the motor The male connector from the motor The female connector from the EB-BUS cable Please connect the connectors from the motor and EB-BUS cable together. 6.3.3.4 Connection of the headlight cable to the motor The male connector from the motor The female connector from...
-
Page 9: Motor Cover Installation
6.3.3.6 Connection of the communication to the motor The female connector from the battery BMS The male connector from the motor Please connect the connectors from the motor and the battery BMS together. 6.3.4 Motor Cover Installation Motor cover M3*8 star socket screws Fasten the motor-cover with three screws M3*8 into in the frame adapter. -
Page 10: Chain Wheel Installation
6.3.5 Chain Wheel Installation Chain wheel Lock nut Special tool Put the chain wheel onto the spline shaft of the drive unit. Use a special tool to fasten the lock nut onto the spline shaft. Torque: 35 Nm. An impact wrench cannot be used. 6.3.6 Crank Installation M15 inner hexagon screws Right crank... -
Page 11: External Speed Sensor Installation
6.3.7 External Speed Sensor Installation Speed sensor Magnet for the speed sensor Fasten the mounting screws through the speed sensor and with a cross screwdriver. Tightening the speed sensor onto the frame. Then place the rubber seal on the speed sensor hiding the screw. Torque requirement: 1.5-2 N.m. -
Page 12: Maintenance
6.4 MAINTENANCE • Maintenance must be carried out by autho- rized personnel with the correct equipment. • Do not disassemble the motor. • Do not use thinners or other solvents to clean the components. Such substances can damage the surfaces. •...
