Grandstream Networks, Inc.
HT801/HT802
Administration Guide
HT801
HT802

Advertisement

Table of Contents
loading

Related Manuals for Grandstream Networks HT801

Summary of Contents for Grandstream Networks HT801

  • Page 1 Grandstream Networks, Inc. HT801/HT802 Administration Guide HT801 HT802...

  • Page 2: Product Overview

    The Grandstream handy tones HT801/HT802 are new additions to the popular handy tone ATA product family. This manual will help you learn how to operate and manage your HT801/HT802 analog telephone adaptor and make the best use of its many upgraded features including simple and quick installation, 3-way conferencing, and direct IP-IP Calling, and new provisioning support among other features.
  • Page 3 Telephone One (1) RJ11 FXS port Two (2) RJ11 FXS ports Interfaces Network One (1) 10/100Mbps auto-sensing Ethernet port (RJ45) Interface POWER, INTERNET, PHONE1, POWER, INTERNET, PHONE Indicators PHONE2 Factory Reset Button Voice, Fax, Modem Telephony Caller ID display or block, call waiting, flash, blind or attended transfer, forward, hold, do not disturb, 3-way Features conference.

  • Page 4: Equipment Packaging

    Table 2: HT801/HT802 Technical Specifications GETTING STARTED This chapter provides basic installation instructions including the list of the packaging contents and information for obtaining the best performance with the HT801/HT802. Equipment Packaging The HT801 ATA package contains: Figure 1: HT801 Package Contents...

  • Page 5: Internet Port

    1. Insert a standard RJ11 telephone cable into the phone port and connect the other end of the telephone cable to a standard touch-tone analog telephone. 2. Insert the Ethernet cable into the internet or LAN port of the HT801/ht802 and connect the other end of the Ethernet cable to an uplink port (a router or a modem, etc.) 3.

  • Page 6: Configuration Guide

    Figure 5: Connecting the HT801/HT802 HT801/HT802 LEDs Pattern There are 3 LED buttons on HT801 and 4 LED buttons on HT802 that help you manage the status of your Handy Tone. Figure 6 : HT801/HT802 LEDs Pattern LED Lights Status...
  • Page 7 HT801/HT802 is by default configured to obtain the IP address from the DHCP server where the unit is located. To know which IP address is assigned to your HT801/HT802, you should access the “Interactive Voice Response Menu” of your adapter via the connected phone and check its IP address mode.

  • Page 8: Configuration Via Web Browser

    Dial *98 to announce the extension number of the port. Configuration via Web Browser The HT801/HT802 embedded Web server responds to HTTP GET/POST requests. Embedded HTML pages allow a user to configure the HT801/HT802 through a web browser such as Google Chrome, Mozilla Firefox, and Microsoft’s IE.

  • Page 9: Web Ui Access Level Management

    Update or Apply button at the bottom of the page. After submitting the changes in all the Web GUI pages, reboot HT801/HT802 to have the changes take effect if necessary; most of the options under the Advanced Settings and FXS Port (x) pages require a reboot.

  • Page 10: Changing User Level Password

    Figure 7: Admin Level Password Changing User Level Password 1. Access your HT801/HT802 web UI by entering its IP address in your favorite browser. 2. Enter your admin password (default: admin). 3. Press Login to access your settings and navigate to Basic Settings��End User Password.

  • Page 11: Web Configuration Pages Definitions

    Figure 10: Web HTTP Port Web Configuration Pages Definitions This section describes the options in the HT801/HT802 Web UI. As mentioned, you can log in as an administrator or an end user. Status: Displays the system info, network status, account status, and line options.
  • Page 12 Bootloader: Specifies Boot version. Softwar Core: Specifies Core version. version Base: Specifies Base version. CPE: Specifies CPE version. CPE version is displayed only when HT801/HT802 is connected to an ACS using TR-069 protocol. Softwar Indicates actual software status. e Status System Indicates actual system time and uptime since the last reboot.
  • Page 13 “Disabled”. If “Disabled” is selected, web UI access will be disabled. By default, “HTTP” is selected. HTTP Web Port Customizes HTTP port used to access the HT801/HT802 web UI. Default is 80. HTTPS Web Port Customizes HTTPS port used to access the HT801/HT802 web UI. Default is 443.
  • Page 14 All the field values for the static IP mode are not used (even though they are still saved in the flash memory.) The HT801/802 acquires its IP address from the first DHCP server it discovers from the LAN it is connected.
  • Page 15 ● DHCP mode: all the field values for the static IP mode are not used (even though they are still saved in the flash memory.) The HT801/HT802 acquires its IP address from the first DHCP server it discovers from the LAN it is connected.
  • Page 16 ● ISP Data Reset: All VoIP related configuration (mainly everything located on FXS page). ● VOIP Data Reset: All ISP (Internet Service Provider) configuration which may affect the IP address. ● Full Reset: Both VoIP and ISP related configuration at the same time. Note:  After you choose the reset type, you must click the reset button to take effect.
  • Page 17 certificate It is set to no upgrade by Default. Sets IP address or FQDN of firmware server. The URL of the server that hosts the Firmware Server Path firmware release. Default is fm.grandstream.com/gs. Sets IP address or FQDN of configuration server. The URL of the server that hosts Config Server Path the configuration file to provision HT8xx.
  • Page 18 Default is No. Randomized Automatic Upgrade within the range of hours of the day or postpone Randomized Automatic Upgrade the upgrade every X minute(s) by random 1 to X minute(s). Configures the HT8xx to always search for the new firmware at boot up. During the Always Check for New Firmware at boot stage, the HT8xx will contact the firmware upgrade server to search for a new Boot up...
  • Page 19 Gen-2 EC private key Configures the Gen-2 Elliptic Curve Private Key. based on RFC 5915. The Max value length is 8192 characters. Sets the phone adapter system to enable the “CPE WAN Management Protocol” (TR- Enable TR-069 069). Default setting is Yes. TR-069 firewall rules Configures the TR-069 firewall rules , Value port range is 1-65535 Specifies URL of TR-069 Auto Configuration Servers (e.g.,...
  • Page 20 Set RADIUS shared secret. Configure RADIUS VSA Vendor ID to match RADIUS server’s configuration. Default is RADIUS VSA Vendor ID 42397 for Grandstream Networks Inc. Configure RADIUS VSA Access Level Attribute to match RADIUS server’s RADIUS VSA Access Level Attribute configuration.
  • Page 21 Enable OpenVPN® Allow user to enable OpenVPN®. Default is No. OpenVPN® Server Address Specify the IP address or FQDN for the OpenVPN® Server. OpenVPN® Port Specify the listening port of the OpenVPN® server. Default is 1194 OpenVPN® Interface type Specify the Interface type of OpenVPN® whether TAP or TUN. Default is TUN. OpenVPN®...
  • Page 22 Play Busy Tone When Account is When this feature is set to Yes, device will play busy tone when the FXS port account unregistered is not registered, and the attached analog phone is offhook. Allow users to block incoming calls from specific list of numbers. Maximum allow 10 SIP numbers and each number should be separated by a comma Blacklist for Incoming Calls (‘,’) in web UI.
  • Page 23 Syslog Protocol If set to SSL/TLS, the syslog messages will be sent through secured TLS Protocol to syslog server. Default setting is UDP. Note: The CA certificate is required to connect with the TLS server A reboot is required to take effect. URL or IP address of syslog server.
  • Page 24 The output is “cfg<mac>_enc.xml” (where <mac> is the MAC address of the device). The file is encrypted and can be used on same device only. Press Upload button to restore device configuration from previously exported Restore From Backup Configuration backup configuration. E911/HELD Protocol: Enable E911 Enable Enhanced 911 call.
  • Page 25 IP address, if any: IPv4: 192.168.5.170/ IPv6: Outbound Proxy 2001:1260:1:277::3). Used by HT801/HT802 for firewall or NAT penetration in different network environments. If symmetric NAT is detected, STUN will not work, and only outbound proxy can correct the problem.
  • Page 26 SIP request (INVITE) to the new successfully registered server or not. Indicates E.164 number in “From” header by adding “User=Phone” parameter or using “Tel:” in SIP packets, if the HT801/HT802 has an assigned PSTN Number. Disabled: Use “SIP User ID” information in the Request-Line and “From” header. TEL URI User=Phone: “User=Phone”...
  • Page 27 Local SIP Port packets. Default value for FXS 1 is 5060 and 5062 for FXS 2. Defines the local RTP-RTCP port pair the HT801/HT802 will listen and transmit. It is Local RTP Port the HT801/HT802 RTP port for channel 0. The default value for FXS port is 5004.
  • Page 28 Checks SIP User ID in the Request URI of incoming INVITE; if it does not match the Check SIP User ID for Incoming HT801/HT802 SIP User ID, the call will be rejected. Direct IP calling will also be INVITE disabled. Default is No.
  • Page 29 Selects the Caller ID display order which need to be respected by the HT801/HT802. The available options are: Auto: When set to “Auto”, the HT801/HT802 will look for the caller ID in the order of P-Asserted Identity Header, Remote-Party-ID Header and From Header in the incoming SIP INVITE.
  • Page 30 When ‘Off Hook Auto-Dial’ is configured, this feature allows user to configure DTMF Off Hook Auto-Dial DTMF digits to send after ‘OffHook auto-dial’ call gets connected. Determines a SIP Extension to notify the SIP server that the HT801/HT802 is behind Proxy-Require a NAT/Firewall.
  • Page 31 Default is No. Disables playing call waiting tone during active call when receiving a second Disable Call Waiting Tone incoming call. The CWCID will still be displayed. Default is No. Disable Connected Line ID Disables displaying the number of the person answering the phone. Default is No. Enables / disables the warning to alert that the phone has been left off-hook for an Disable Receiver Off Hook Tone extended period of time.
  • Page 32 Disable # as Redial Key With this feature and feature ‘Use # as Dial Key’ set to Yes, the # key will act as dial key but not as redial key. Default No. Dial Plan Rules: 1. Accept Digits: 1,2,3,4,5,6,7,8,9,0, *, #, A,a,B,b,C,c,D,d 2.
  • Page 33 Enable Session Timer Disable the session timer when this option is set to “No”. By default, this option is enabled. Enables SIP sessions to be periodically “refreshed” via a SIP request (UPDATE, or re-INVITE). When the session interval expires, if there is no refresh via an UPDATE or re-INVITE message, the session will be terminated.
  • Page 34 6.3kbps or 5.3kbps. Default is 6.3kbps. Specifies iLBC packet frame size (20ms or 30ms). iLBC Frame Size Default is 20ms. Disables OPUS stereo in SDP. If set to Yes, HT8XX will remove /2 from offer. Disable OPUS Stereo in SDP Default is No. Determines payload type for iLBC.
  • Page 35 To prevent unwanted activation of the Flash/Hold and automatic phone ring-back, Hook Flash Timing adjust this time value. HT801/HT802 supports a range from 40 to 2000 ms. Default values are 300 minimum and 1100 maximum. Specifies the on-hook time for an on-hook event to be validated. HT801/HT802 On Hook Timing supports a range from 40 to 2000 ms.
  • Page 36 This feature allows users to customize the count of RFC2833 events. RFC2833 Events Count Valid range is 2 – 10. Default is 8. This feature allows users to customize the count of RFC2833 end events. Valid RFC2833 End Events Count range is 2 – 10. Default is 3. Customizes the Ring Tone 1 to 10 with associate caller ID: when selected, if caller ID is configured, then the device will ONLY use this ring tone when the incoming call is from the Caller ID.
  • Page 37 SRTP per call Feature – Enable SRTP per call: Default is 18 – Disable SRTP per call: Default is 19 Allow users to customize the CID feature codes. Default is Yes CID Feature – Enable CID: Default is 31 – Disable CID: Default is 30 –...

  • Page 38: Nat Settings

    Set priority of DTMF methods according to your preference. This setting should be based on your server’s DTMF setting. Preferred Vocoder (Codec) The HT801/HT802 support the following voice codecs. On FXS ports pages, choose the order of your favorite codecs: PCMU/A (or G711µ/a) G729 A/B G723.1...
  • Page 39 Select voice menu option 01 to enable HT801/HT802to use DHCP. STATIC IP MODE Select voice menu option 01 to enable HT801/HT802 to use STATIC IP mode, then use options 02, 03, 04, and 05 to set up IP address, Subnet Mask, Gateway, and DNS server respectively.
  • Page 40 After applying your configuration, your account will register to your SIP Server, you can verify if it has been correctly registered with your SIP server or from your HT801/HT802 web interface under Status��Port Status��Registration (If it displays Registered, it means that your account is fully registered, otherwise it will display Not Registered so in this case you must double check the settings or contact your provider).

  • Page 41: Call Features

    When all the FXS ports are registered (for HT802), the simultaneous ring will have one second delay between each ring on each phone. Call Features The HT801/HT802 support all the traditional and advanced telephony features. Call Features Forcing a Codec (per call) *027110 (PCMU), *027111 (PCMA), *02723 (G723), *02729 (G729), *027201 (iLBC). *02722 (G722).

  • Page 42: Upgrading And Provisioning

    Wait 30 seconds to log in again. UPGRADING AND PROVISIONING The HT801/HT802 can be upgraded via TFTP/HTTP/HTTPS/FTP/FTPS by configuring the URL/IP Address for the TFTP/HTTP/HTTPS/FTP/FTPS server and selecting a download method. Configure a valid URL for TFTP or FTP/FTPS or HTTP/HTTPS (default is HTTPS);...

  • Page 43: Upgrading Via Local Directory

    1. Download the firmware file from the Grandstream website; 2. Unzip it and copy the file into a folder on your PC; 3. From the HT801/HT802 web interface (Advanced Settings page) you can browse your hard drive and select the folder you previously saved the file (HT802fw.bin);...

  • Page 44: Firmware And Configuration File Prefix And Postfix

    When the HT801/HT802 boots up or reboots, it will send a request to download a file named “cfgxxxxxxxxxxxx” followed by a configuration XML file named “cfgxxxxxxxxxxxx.xml”, where “xxxxxxxxxxxx” is the MAC address of the phone, i.e., “cfg000b820102ab”...

  • Page 45: Restore Factory Default Settings

    To reset default factory settings using the reset button please follow the steps above: 1. Unplug the Ethernet cable. 2. Locate the reset hole on the back panel of your HT801/HT802. 3. Insert a pin in this hole and press for about 7 seconds.

  • Page 46: Reset From Web Interface (Reset Type)

    Factory Reset will be disabled if the “Lock keypad update” is set to “Yes”. If the HT801/HT802 was previously locked by your local service provider, pressing the RESET button will only restart the unit. The device will not return to factory default settings.
  • Page 47 This section documents significant changes from previous versions of the administration guide for HT801/HT802. Only major new features or major document updates are listed here. Minor updates for corrections or editing are not documented here. Firmware version 1.0.43.11 Added Charter CA to the approved certificate list.
  • Page 48 Added Local IVR option that announces extension number of the port. [Understanding HT801/HT802 Interactive Voice Prompt Response Menu] Firmware version 1.0.37.1 Added feature Configuration File Types Allowed. [Advanced Settings Page Definitions]. Added feature MAC in User-Agent [FXS Port Settings] Added feature Use MAC Header...
  • Page 49 Added “Disable” option for Web access mode. [Web Access Mode] • Moved “Trusted CA certificates” from Profile1/Profie2 to Advanced Settings and renamed as Trusted CA Certificates A and Trusted CA Certificates B. [Trusted CA certificates A] [Trusted CA certificates B] Added Feature “Disable User Level Web Access”...
  • Page 50 Added feature “Allow SIP Factory Reset”. [Allow SIP Factory Reset] [Reset using SIP NOTIFY] Added support for G722 Codec. [HT801/HT802 Technical Specifications] Added support for allow user to choose preference codec from PCMU and PCMA for FAX pass-through codec. [Fax Mode] Firmware Version 1.0.9.3...
  • Page 51 Added feature “SSH Port” to self-configure SSH port. [SSH Port] Added SNMP related features. Firmware Version 1.0.3.2 This is the initial version for HT801. Added option “DNS SRV use Registered IP” [DNS SRV use Registered IP]. Changed default NTP server from us.pool.ntp.org to pool.ntp.org.
  • Page 52 Grandstream Networks, Inc. is not permitted. The latest electronic version of this user manual is available for download here: http://www.grandstream.com/support Grandstream is a registered trademark and Grandstream logo is trademark of Grandstream Networks, Inc. in the United States, Europe and other countries. CAUTION Changes or modifications to this product not expressly approved by Grandstream, or operation of this product in any way other than as detailed by this User Manual, could void your manufacturer warranty.

  • Page 53: Gnu Gpl Information

    GNU GPL INFORMATION HT801/HT802 firmware contains third-party software licensed under the GNU General Public License (GPL). Grandstream uses software under the specific terms of the GPL. Please see the GNU General Public License (GPL) for the exact terms and conditions of the license.
