Grandstream Networks, Inc.
HT801 Analog Telephone Adaptor
Administration Guide

Advertisement

Table of Contents
loading

Related Manuals for Grandstream Networks HT801

Summary of Contents for Grandstream Networks HT801

  • Page 1 Grandstream Networks, Inc. HT801 Analog Telephone Adaptor Administration Guide...
  • Page 2 Grandstream Networks, Inc. is not permitted. The latest electronic version of this user manual is available for download here: http://www.grandstream.com/support Grandstream is a registered trademark and Grandstream logo is trademark of Grandstream Networks, Inc. in the United States, Europe and other countries. CAUTION Changes or modifications to this product not expressly approved by Grandstream, or operation of this product in any way other than as detailed by this User Manual, could void your manufacturer warranty.

  • Page 3: Gnu Gpl Information

    GNU GPL INFORMATION HT801 firmware contains third-party software licensed under the GNU General Public License (GPL). Grandstream uses software under the specific terms of the GPL. Please see the GNU General Public License (GPL) for the exact terms and conditions of the license.

  • Page 4: Table Of Contents

    Connecting HT801 ..........................13 HT801 LEDs Pattern ..........................13 CONFIGURATION GUIDE .................... 15 Obtain HT801 IP Address via Connected Analogue Phone ..............15 Understanding HT801 Interactive Voice Prompt Response Menu ............15 Configuration via Web Browser ......................17 Accessing the Web UI ........................17 Web UI Access Level Management ....................
  • Page 5 Rebooting HT801 from Remote ......................42 UPGRADING AND PROVISIONING ................43 Firmware Upgrade procedure ......................43 Upgrading via Local Directory: ......................44 Upgrading via Local TFTP/HTTP Servers ................... 44 Firmware and Configuration File Prefix and Postfix ................44 Managing Firmware and Configuration File Download ................ 45 Configuration File Download ........................
  • Page 6 Table of Tables Table 1: HT801 Features at a Glance ......................10 Table 2: HT801 Technical Specifications ....................10 Table 3: Definition of the HT801 Connectors ....................12 Table 4: HT801 LEDs Pattern Description ....................14 Table 5: Voice Prompt Menu ........................15 Table 6: Status Page Definitions .........................

  • Page 7: Document Purpose

    DOCUMENT PURPOSE This document describes the basic concept and tasks necessary to use and configure your HT801. And it covers the topic of connecting and configuring the HT801, making basic operations and the call features. Please visit http://www.grandstream.com/support to download the latest “HT801 User Guide”.

  • Page 8: Change Log

    CHANGE LOG This section documents significant changes from previous versions of administration guide for HT801. Only major new features or major document updates are listed here. Minor updates for corrections or editing are not documented here. Firmware Version 1.0.3.2 ...

  • Page 9: Gui Interface Examples

    GUI INTERFACE EXAMPLES http://www.grandstream.com/sites/default/files/Resources/HT801_web_gui.zip 1. Screenshot of Login Page 2. Screenshots of Status Page 3. Screenshots of Basic Settings Page 4. Screenshots of Advanced Settings Page 5. Screenshots of FXS Port Page P a g e HT801 Administration Guide...

  • Page 10: Welcome

    The HT801 Analog Telephone Adapter provides transparent connectivity for analog phones and faxes to the world of Internet voice. Connecting to any analog phone, fax or PBX, the HT801 is an effective and flexible solution for accessing internet-based telephone services and corporate intranet systems across established LAN and Internet connections.

  • Page 11: Product Overview

    PRODUCT OVERVIEW The HT801 is a 1 port analog telephone adapter (ATA) that allows users to create a high-quality and manageable IP telephony solution for residential and office environments. Its ultra-compact size, voice quality, advanced VoIP functionality, security protection and auto provisioning options enable users to take advantage of VoIP on analog phones and enables service providers to offer high quality IP service.
  • Page 12  Dimensions and Weight Dimension: 100mm x 100mm x 29.5mm  Weight: 102g Compliance  Compliance FCC : Part15B  CE : EN55032, EN55024, EN61000-3-2, EN61000-3-3, EN60950-1  RCM: AS/NZS CISPR22, AS/NZS60950.1, S003 P a g e HT801 Administration Guide...

  • Page 13: Getting Started

    Figure 1: HT801 Package Contents Note: Check the package before installation. If you find anything missing, contact your system administrator. HT801 Ports Description The following figure describes the different ports on the back panel of the HT801. Internet Micro USB...

  • Page 14: Connecting Ht801

    2. Insert the Ethernet cable into the internet or LAN port of the HT801 and connect the other end of the Ethernet cable to an uplink port (a router or a modem, etc.) 3.

  • Page 15: Table 4: Ht801 Leds Pattern Description

    Table 4: HT801 LEDs Pattern Description LED Lights Status Power LED The Power LED lights up when the HT801 is powered on and it flashes when it is booting up Internet LED The Ethernet LED lights up when the HT801 is connected to your network through the Ethernet port and it flashes when there is data being sent or received.

  • Page 16: Configuration Guide

    Obtain HT801 IP Address via Connected Analogue Phone HT801 is by default configured to obtain the IP address from DHCP server where the unit is located. In order to know which IP address is assigned to your HT801, you should access to the “Interactive Voice...
  • Page 17 Five success tips when using the voice prompt  “*” shifts down to the next menu option and “#” returns to the main menu. “9” functions as the ENTER key in many cases to confirm or toggle an option.  P a g e HT801 Administration Guide...

  • Page 18: Configuration Via Web Browser

    When changing any settings, always submit them by pressing Update or Apply button on the bottom of the page. After submitting the changes in all the Web GUI pages, reboot HT801 to have the changes take effect if necessary; most of the options under the Advanced Settings and FXS Port page require reboot.

  • Page 19: Changing Admin Level Password

    Changing Admin Level Password 1. Access your HT801 web UI by entering its IP address in your favorite browser. 2. Enter your admin password (default: admin). 3. Press Login to access your settings and navigate to Advanced Settings > Admin Password.

  • Page 20: Web Configuration Pages Definitions

    Web Configuration Pages Definitions This section describes the options in the HT801 Web UI. As mentioned, you can log in as an administrator or an end user.  Status: Displays the system info, network status, account status, and line options.

  • Page 21: Basic Settings Page Definitions

    Enables / Disables access via telnet. Default is Yes (activated). IP Address Specifies IP Address to use on HT801.There are three modes to operate the HT801:  DHCP mode: all the field values for the static IP mode are not used (even though they are still saved in the flash memory.) The HT801 acquires its IP...

  • Page 22: Advanced Settings Page Definitions

    Configures the languages of the voice prompt and web interface, except Spanish that it is only in IVR. Available languages: English, Chinese or Spanish IVR. Reset Type Gives the administrator the option to restore default configuration on the HT801. There are 3 types of factory reset: ...
  • Page 23 Default is fm.grandstream.com/gs. Config Server Path Sets IP address or FQDN of configuration server. The URL of the server that hosts the configuration file to provision HT801. Default is fm.grandstream.com/gs. XML Config File Decrypts XML configuration file when encrypted. The password used for encrypting the Password XML configuration file using OpenSSL.
  • Page 24 (0-6)”. (Day of week is starting from Sunday). Always Check for Configures the HT801 to always search for the new firmware at boot up. During the boot New Firmware at stage, the HT801 will contact the firmware upgrade server to search for a new firmware, Boot up when available it will start the upgrade process, otherwise it will boot normally.
  • Page 25 Conf File unauthorized modifications. Default is No. SIP TLS Certificate Specifies SSL certificate used for SIP over TLS is in X.509 format. The HT801 has built- in private key and SSL certificate. SIP TLS Private Specifies TLS private key used for SIP over TLS is in X.509 format.
  • Page 26 Deactivates Direct IP-to-IP calling function. Default is No. Call NTP Server Defines URL or IP address of the NTP (Network Time Protocol). Used by the HT801 to synchronize the date and time. Public NTP servers can be found at http://www.ntp.org Allow DHCP Option Obtains NTP server address from a DHCP server using DHCP Option 42;...

  • Page 27: Fxs Port Page Definitions

    May 19 02:40:38 192.168.1.14 GS_LOG: [00:0b:82:00:a1:be][000] Ethernet link is up Send SIP Log Configures the HT801 to send a replicate of the SIP packets on the syslog. Default is Download Device Downloads actual device configuration file in .xml format. Configuration Download Device Downloads actual device configuration file in .xml format.
  • Page 28 If symmetric NAT is detected, STUN will not work and only outbound proxy can correct the problem. Allow DHCP Option Configures the HT801 to collect SIP server address from DHCP option 120. Default is 120 (override SIP Server) SIP transport Selects transport protocol for SIP packets;...
  • Page 29 IP 2 to be used for server look up. Default is A Record. TEL URI Indicates E.164 number in “From” header by adding “User=Phone” parameter or using “Tel:” in SIP packets, if the HT801 has an assigned PSTN Number.  Disabled: Use “SIP User ID” information in the Request-Line and “From”...
  • Page 30 Local SIP Port value for FXS is 5060. Defines the local RTP-RTCP port pair the HT801 will listen and transmit. It is the HT801 Local RTP Port RTP port for channel 0. The default value for FXS port is 5004.
  • Page 31 Check SIP User ID Checks SIP User ID in the Request URI of incoming INVITE; if it doesn't match the for Incoming HT801 SIP User ID, the call will be rejected. Direct IP calling will also be disabled. INVITE Default is No.
  • Page 32 Configures a user ID or extension number that is automatically dialed when off-hook. Only the user part of a SIP address needs to be entered. The HT801 will automatically append the “@” and the host portion of the corresponding SIP address.
  • Page 33 Sends only one m line in SDP, regardless of how many m fields are in the incoming Line in SDP SDP. Default is No. Ring Timeout Stops ringing when incoming call if not answered within a specific period of time. Default is 60 seconds. P a g e HT801 Administration Guide...
  • Page 34 Allow 311, 611, 911, and any 10 digit numbers of leading digits 1617 • Example 2: {^1900x+ | <=1617>xxxxxxx} – Block any number with leading digits 1900 and add prefix 1617 for any dialed 7 digit numbers • Example 3: {1xxx[2-9]xxxxxx | <2=011>x+} – P a g e HT801 Administration Guide...
  • Page 35 INVITE message, the session will be terminated. Session Expiration is the time (in seconds) at which the session is considered timed out, if no successful session refresh transaction occurs beforehand. Default is 180 seconds. Min-SE Defines Minimum session expiration (in seconds). Default is 90 seconds. P a g e HT801 Administration Guide...
  • Page 36 6.3kbps or 5.3kbps. Default is 6.3kbps. iLBC Frame Size Specifies iLBC packet frame size (20ms or 30ms). Default is 20ms. Disable OPUS Disables OPUS stereo in SDP. Default is No. Stereo in SDP P a g e HT801 Administration Guide...
  • Page 37 Reverses the polarity upon call establishment and termination. Default is No. Loop Current Allows the traditional PBX used with HT801 to apply this method for signaling call termination. Method initiates short voltage drop on the line when remote (VoIP) side Disconnect disconnects an active call.

  • Page 38: Nat Settings

    Defines the time period when the cradle is pressed (Hook Flash) to simulate FLASH. To prevent unwanted activation of the Flash/Hold and automatic phone ring-back, adjust this time value. HT801 supports a range from 40 to 2000 ms. Default values are 300 minimum and 1100 maximum.

  • Page 39: Dtmf Methods

    Select voice menu option 01 to enable HT801to use DHCP.  STATIC IP MODE Select voice menu option 01 to enable HT801 to use STATIC IP mode, then use option 02, 03, 04, 05 to set up IP address, Subnet Mask, Gateway and DNS server respectively. ...

  • Page 40: Register A Sip Account

    1) Always check, 2) check when pre/suffix changes, and 3) never upgrade. Register a SIP Account The HT801 supports 1 FXS port which can be configured with 1 SIP account. Please refer to the following steps in order to register your accounts via web user interface: 1.

  • Page 41: Figure 8: Sip Accounts Settings

    After applying your configuration, your account will register to your SIP Server, you can verify if it has been correctly registered with your SIP server from your HT801 web interface under Status > Port Status > Registration (If it displays Registered, it means that your account is fully registered, otherwise it will display Not Registered so in this case you must double check the settings or contact your provider).

  • Page 42: Call Features

    Call Features The HT801 supports all the traditional and advanced telephony features. Table 10: HT801 Call Features Call features Forcing a Codec (per call) *027110 (PCMU), *027111 (PCMA), *02723 (G723), *02729 (G729), *0272616 (G726-r16), *0272624 (G726-r24), *0272632 (G726-r32), *0272640 (G726-r40), *027201 (iLBC), *027202 (OPUS).

  • Page 43: Rebooting Ht801 From Remote

    Pressing pound sign will serve as Re-Dial key. Rebooting HT801 from Remote Press the “Reboot” button at the bottom of the configuration menu to reboot the ATA remotely. The web browser will then display a message window to confirm that reboot is underway.

  • Page 44: Upgrading And Provisioning

    UPGRADING AND PROVISIONING The HT801 can be upgraded via TFTP/HTTP/HTTPS by configuring the URL/IP Address for the TFTP/HTTP/HTTPS server and selecting a download method. Configure a valid URL for TFTP or HTTP/HTTPS; the server name can be FQDN or IP address.

  • Page 45: Upgrading Via Local Directory

    1. Download the firmware file from Grandstream web site; 2. Unzip it and copy the file in to a folder in your PC; 3. From the HT801 web interface (Advanced Settings page) you can browse your hard drive and select the folder you previously saved the file (HT801fw.bin);...

  • Page 46: Managing Firmware And Configuration File Download

    Password. For a detailed parameter list, please refer to the corresponding firmware release configuration template. When the HT801 boots up or reboots, it will send a request to download a file named "cfgxxxxxxxxxxxx” followed by a configuration XML file named "cfgxxxxxxxxxxxx.xml", where "xxxxxxxxxxxx" is the MAC address of the phone, i.e., "cfg000b820102ab"...

  • Page 47: Restore Factory Default Settings

    To reset default factory settings using the reset button please follow the steps above: 1. Unplug the Ethernet cable. 2. Locate the reset hole on the back panel of your HT801. 3. Insert a pin in this hole, and press for about 7 seconds.

  • Page 48: Reset From Web Interface (Reset Type)

    Factory Reset will be disabled if the “Lock keypad update” is set to “Yes”. If the HT801 was previously locked by your local service provider, pressing the RESET button will only restart the unit. The device will not return to factory default settings.

  • Page 49: Experiencing Ht801

    Thank you again for purchasing Grandstream analogue telephone adapter, it will be sure to bring convenience to both your business and personal life. P a g e HT801 Administration Guide...
