Nautica 4000
Installation Guide
Part No. 119500-A Rev. A
January 1998

Advertisement

Table of Contents
loading

Related Manuals for Nortel Nautica 4000

Summary of Contents for Nortel Nautica 4000

  • Page 1 Nautica 4000 Installation Guide Part No. 119500-A Rev. A January 1998...
  • Page 2 4401 Great America Parkway Santa Clara, CA 95054 Copyright © 1998 Bay Networks, Inc. All rights reserved. Printed in the UK. January 1998. The information in this document is subject to change without notice. The statements, configurations, technical data, and recommendations in this document are believed to be accurate and reliable, but are presented without express or implied warranty.
  • Page 3 European Requirements Only EN 55 022 Statement This is to certify that the Bay Networks Nautica 4000 is shielded against the generation of radio interference in accordance with the application of Council Directive 89/336/EEC, Article 4a. Conformity is declared by the application of EN 55 022 Class B (CISPR 22).
  • Page 4 Vert et Jaune Bleu Marron The “in-wall” power cable supplied with the Nautica 4000 must be used to ensure continued compliance with the applicable regulations. Should a replacement power module be required, this must be obtained from Bay Networks Inc.
  • Page 5 Port Specifications The Nautica 4000 has ports, which are classified as follows: Port Type LAN 10BASE-T SELV LAN AUI SELV Manager SELV TNV (within the limits of SELV) ISDN (J2) Host (J1) SELV Interconnection circuits should be such that the equipment continues to comply with the requirement of section 6.2 for Telecommunications Network Voltage (TNV) circuits and...
  • Page 6 Swedish Requirements Only Denna produkt och expansionkort är avsedda för fackmannamässig installation i Sverige. När service utförs på utrustningen, var vänlig koppla ur nätverket (inklusive ISDN-nätet) först, innan kontakten dras ur. Japan/Nippon Requirements Only Voluntary Control Council for Interference (VCCI) Statement Voluntary Control Council for Interference (VCCI) Statement This is a Class B product based on the standard of the Voluntary Control Council for Interference from Information Technology Equipment (VCCI).
  • Page 7 Canada Requirements Only Canadian Department of Communications Radio Interference Regulations This digital apparatus (Nautica 4000) does not exceed the Class B limits for radio-noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.
  • Page 8 exigences techniques relatives au matériel terminal. Le Ministère n'assure toutefois pas que le matériel fonctionnera à la satisfaction de l'utilisateur. Avant d'installer ce matériel, l'utilisateur doit s'assurer qu'il est permis de le raccorder aux installations de l'entreprise locale de télécommunication. Le matériel doit également être installé...
  • Page 9 The required Universal Service Order Code (USOC) jack: RJ48C • When you request ISDN “U” Interface Service, you must provide the telephone company with The Facility Interface Code: 02IS5 The Service Order Code(s) (SOC): 6.0F The required Universal Service Order Code (USOC) jack: RJ49C •...
  • Page 10 Module Installation Warning The power required by the host and the total of adaptor cards installed within the host environment, together with any auxiliary apparatus, shall not exceed the power specifications of the host apparatus. It is essential that when other option cards are introduced which use or generate a hazardous voltage, the minimum creepages and clearances specified in maintained.
  • Page 11 Figure 2. shows a physical representation of the creepage and clearances. Figure 2. Except at the edge connectors, which plug into the host’s expansion slot, clearance distance X (mm) and creepage distance Y (mm) as given in between the communications card and any other assemblies that use or generate a hazardous voltage.
  • Page 12 Grün und Gelb Blau Braun Entsorgung der Batterie Die Entsorgung des Lithium-Batterie-Moduls muß unter Einhaltung der Entsorgungvorschriften des Herstellers erfolgen. Portspezificationen Das Nautica 4000 Gerät hat wie folgt klassifizierte ports: Port LAN 10BASE-T LAN AUI Manager ISDN (J2) Host (J1)
  • Page 13 Die Verbindungsschaltungen sollten so beschaffen sein, daß sie weiterhin den Erfordernissen von Abschnitt 6.2 für Telecommunications Network Voltage (TNV) Schaltungen und Abschnitt 2.3 für Safety Extra Low Voltage (SELV) Schaltungen der bestimmungen EN60950:1992/A4:1997 entsprechen, nachdem die Verbindung zwischen den Schaltungen hergestellt wurde. Warnung für die Installation des Moduls Der Strom, welcher vom Host und allen in der Hostumgebung installierten Adapterkarten benötigt wird, darf nicht die Stromspezificationen für das Hostgeät überschrieten (siehe...
  • Page 14 Abbildung 4. Ausgenommen an den randstiftleisen, die in den erweiterungsschlitz des hosts gesteckt werden, muß spielraumentfernung X (mm) und Kriechstromentfernung Y (mm) gemäß Tabelle 1 zwischen den kommunikationskarten und allen anderen baugruppen, die gefährliche spannung benutzen oder erzeugen, aufrechthalten werden. ISDN-Karten Das ISDN-Kabel darf nicht an das telekommunikationssystem angeschlossen werden, bevor die karte in einem host installiert wurde, der den notwendigen schutz für den...
  • Page 15 Bay Networks, Inc. Software License Agreement NOTICE: Please carefully read this license agreement before copying or using the accompanying software or installing the hardware unit with pre-enabled software (each of which is referred to as “Software” in this Agreement). BY COPYING OR USING THE SOFTWARE, YOU ACCEPT ALL OF THE TERMS AND CONDITIONS OF THIS LICENSE AGREEMENT.
  • Page 16 days from the date Software is first shipped to Licensee. Bay Networks will replace defective media at no charge if it is returned to Bay Networks during the warranty period along with proof of the date of shipment. This warranty does not apply if the media has been damaged as a result of accident, misuse, or abuse.
  • Page 17 6. Use of Software in the European Community. This provision applies to all Software acquired for use within the European Community. If Licensee uses the Software within a country in the European Community, the Software Directive enacted by the Council of European Communities Directive dated 14 May, 1991, will apply to the examination of the Software to facilitate interoperability.

  • Page 19: Table Of Contents

    WAN Ordering Information ... 5 European WAN Information ... 5 North American WAN Information ... 5 Connecting the Cables ... 6 Nautica 4000 Front Panel Display ... 8 Requirements for the PC Applications ... 9 Installing the PC Applications ... 10 119500-A Rev. A...
  • Page 21 Figures Figure 1. Front Panel Display Power-Up Sequence ... 8 119500-A Rev. A...
  • Page 22 Tables Table 1. Operating Requirements ... 3 119500-A Rev. A xxiii...

  • Page 23: Nautica 4000 Installation Guide

    Option slots are available for BRI Leased Line modules, PRI modules and Synchronous Frame Relay modules. For information about the additional modules that can be purchased for the Nautica 4000, refer to the “Nautica Module Installation Guide” that comes with any additional modules you purchase.

  • Page 24: Checklist

    Nautica 4000 Installation Guide Checklist Before you begin the installation, make sure that your Nautica 4000 package includes the following items: • The Nautica 4000 router • One power cable with the correct power connector • Four black ISDN cables labelled 119071, one for each ISDN connection •...

  • Page 25: Site Preparation

    Nautica 4000 Installation Guide Site Preparation You should install the Nautica 4000 on a flat surface, in a clean, dry location with no extreme temperatures. Make sure that all of the required services (power, LAN access and ISDN) are available and working correctly.

  • Page 26: Isdn Ordering Information

    Nautica 4000 Installation Guide ISDN Ordering Information This section describes the ordering information you need if you plan to use ISDN to connect your Nautica 4000 to other devices. European ISDN Information If you require ISDN in Europe, do the following: •...

  • Page 27: Wan Ordering Information

    To configure ISDN, refer to the relevant ISDN chapters in the online documentation on the installation CD. WAN Ordering Information If your Nautica 4000 has a WAN port, connection to a remote unit can be made via a permanent leased circuit. European WAN Information •...

  • Page 28: Connecting The Cables

    Nautica 4000 Installation Guide Connecting the Cables Figure 1 Each numbered item is described on Figure 1 Nautica 4000 with Four or Eight ISDN Ports shows the Nautica 4000 with four or eight ISDN ports. 119500-A Rev. A page...
  • Page 29 ISDN connection. Connect one end of the Ethernet cable (labelled 118138) to the back of the Nautica 4000 and connect the other end to your hub. Or, connect your transceiver or transceiver drop cable (not supplied) to the LAN AUI port on the back of the Nautica 4000 and connect the other end to your Ethernet connector.

  • Page 30: Nautica 4000 Front Panel Display

    Nautica 4000 Installation Guide Nautica 4000 Front Panel Display The front panel of the Nautica 4000 contains a liquid crystal display (LCD). The LCD becomes active after the unit is turned The LCD consists of 80 characters configured in two rows of 40 characters and three control buttons.

  • Page 31: Requirements For The Pc Applications

    Vn.m is the Loader version number, the test is complete. n is the amount of RAM installed. “Enquiring Port n” appears as the Nautica 4000 detects all the ports it needs to use. A number from 1 to 8 appears here as the ports are found.

  • Page 32: Installing The Pc Applications

    Nautica 4000 Installation Guide Installing the PC Applications After you connect the cables and turn on the Nautica 4000, load the Nautica 4000 configuration software onto your PC as follows: Insert the CD that came with the Nautica 4000 package into your CD-ROM drive.
