2-6 User's Reference Guide

Netopia R3100 ISDN Router Status Lights

The figure below represents the Netopia R3100 status light (LED) panel.
Netopia R3100 LED front panel
WAN 1
The following table summarizes the meaning of the various LED states and colors:
When this happens...
Power is on
Data is transmitted or received over the ISDN D channel
The WAN interface is operational
The WAN interface is inactive
The WAN interface detects a failure after line activation
Calls are setting up (voice or data)
Data calls connect
Voice calls connect
The line is carrying data traffic
The respective Ethernet port is connected to the LAN
There is activity on the respective Ethernet ports
Note: 8 through 11 are unused. Also, Console carrier (6) is ignored if the console is not configured for a
remote modem.
WAN 2 Ethernet
1 is green.
2 flashes orange.
3 is green.
3 is off.
3 flashes red.
4 and 5 flash green.
4 and 5 are green.
4 and 5 flash green.
4 and 5 pulse orange.
14 through 21 are green.
14 through 21 flash green.
Link/Receive
the LEDs...
