Panasonic Lumix DMC-FX700P Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Digital Camera
  5. Lumix DMC-FX700P
  6. Service manual

Panasonic Lumix DMC-FX700P Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DMC-FX700P
Model No.
DMC-FX700PC
DMC-FX700PU
DMC-FX700EB
DMC-FX700EE
DMC-FX700EF
DMC-FX700EG
DMC-FX700EP
DMC-FX700GC
DMC-FX700GD
DMC-FX700GH
DMC-FX700GK
DMC-FX700GN
DMC-FX700GT
DMC-FX700SG
Vol. 1
Colour
(S)...........Silver Type (only P/PC/GC/GH/GK/SG)
(K)...........Black Type
(N)...........Gold Type (only GC/GD/GK/GT/SG)
(W)..........White Type (only GC/GD/GH/GT/SG)
© Panasonic Corporation 2010 Unauthorized copy-
ing and distribution is a violation of law.
ORDER NO. DSC1008051CE
B26
Digital Camera

Advertisement

Table of Contents
loading

Related Manuals for Panasonic Lumix DMC-FX700P

Summary of Contents for Panasonic Lumix DMC-FX700P

  • Page 1 DMC-FX700EG DMC-FX700EP DMC-FX700GC DMC-FX700GD DMC-FX700GH DMC-FX700GK DMC-FX700GN DMC-FX700GT DMC-FX700SG Vol. 1 Colour (S)...Silver Type (only P/PC/GC/GH/GK/SG) (K)...Black Type (N)...Gold Type (only GC/GD/GK/GT/SG) (W)..White Type (only GC/GD/GH/GT/SG) © Panasonic Corporation 2010 Unauthorized copy- ing and distribution is a violation of law.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE PAGE 1 Safety Precautions -----------------------------------------------3 1.1. General Guidelines ----------------------------------------3 1.2. Leakage Current Cold Check ---------------------------3 1.3. Leakage Current Hot Check (See Figure 1.)--------3 1.4. How to Discharge the E.Capacitor on Flash Top P.C.B. ----------------------------------------------------4 2 Warning --------------------------------------------------------------5 2.1.

  • Page 3: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1.3. Leakage Current Hot Check 1. IMPORTANT SAFETY NOTICE (See Figure 1.) There are special components used in this equipment 1. Plug the AC cord directly into the AC outlet. Do not use which are important for safety. These parts are marked by an isolation transformer for this check.

  • Page 4: How To Discharge The E.capacitor On Flash Top P.c

    1.4. How to Discharge the E.Capacitor on Flash Top P.C.B. CAUTION: 1. Be sure to discharge the E.capacitor on FLASH TOP P.C.B.. 2. Be careful of the high voltage circuit on FLASH TOP P.C.B. when servicing. [Discharging Procedure] 1. Refer to the disassemble procedure and remove the necessary parts/unit. 2.

  • Page 5: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD).

  • Page 6: Caution For Ac Cord(For Eb/Gc

    A replacement fuse cover can be purchased from your local 2.3.2.3. How to Replace the Fuse Panasonic Dealer. 1. Remove the Fuse Cover with a screwdriver. If the fitted moulded plug is unsuitable for the socket outlet in your home then the fuse should be removed and the plug cut off and disposed of safety.

  • Page 7: How To Replace The Lithium Battery

    NOTE: This Lithium battery is a critical component. (Type No.: ML421 Manufactured by Energy Company, Panasonic Corporation.) It must never be subjected to excessive heat or discharge. It must therefore only be fitted in requirement designed specifically for its use.

  • Page 8: Service Navigation

    3 Service Navigation 3.1. Introduction This service manual contains technical information, which allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, the information will be followed by service manual to be controlled with original service manual. 3.2.

  • Page 9: How To Define The Model Suffix (Ntsc Or Pal Model)

    3.5. How to Define the Model Suffix (NTSC or PAL model) There are nine kinds of DMC-FX700, regardless of the colours. • a) DMC-FX700 (Japan domestic model), DMC-FX700SG • b) DMC-FX700P/PC • c) DMC-FX700EB/EF/EG/EP • d) DMC-FX700EE • e) DMC-FX700GT •...
  • Page 10 3.5.2. INITIAL SETTINGS: After replacing the MAIN P.C.B., be sure to perform the initial settings after achieving the adjustment by ordering the following pro- cedure in accordance with model suffix of the unit. 1. IMPORTANT NOTICE: Before proceeding Initial settings, be sure to read the following CAUTIONS. 2.
  • Page 11 [CASE 1. After replacing MAIN P.C.B.] [Except “EG, EF, EB and EP” models: (VEP56109A is used as a Main P.C.B.] When MAIN P.C.B. has just been replaced, all of the model suffix is displayed as follows. (Four pages in total) [Only “EG, EF, EB and EP”...
  • Page 12 • Step 7. CONFIRMATION: Confirm the display of “PLEASE SET THE CLOCK” in concernd language when the unit is turned on again. When the unit is connected to PC with USB cable, it is detected as removable media. (When the “GT” or “GK” model suffix is selected, the display shows “PLEASE SET THE CLOCK” in Chinese.) 1) As for your reference, major default setting condition is as shown in the following table.

  • Page 13: Specifications

    4 Specifications...

  • Page 14: Location Of Controls And Components

    19 Card/Battery door 20 Release lever 21 DC coupler cover When using an AC adaptor, ensure that the Panasonic DC coupler and AC adaptor are used. Always use a genuine Panasonic AC adaptor (optional). We recommend you use a battery with sufficient battery power or the AC adaptor when recording motion pictures.
  • Page 15 How to Use the Touch Panel This touch panel is a type that detects pressure. Operation or settings are performed by directly touching the icons displayed on the LCD monitor (touch panel) or by moving while touching the touch panel (dragging) using your fingers or the supplied stylus pen.
  • Page 16 The only batteries suitable for use with this unit are genuine Panasonic products and batteries manufactured by other companies and certified by Panasonic. (Batteries which do not support this function cannot be used). Panasonic cannot in any way guarantee the quality, performance or safety of batteries which have been manufactured by other companies and are not genuine Panasonic products.

  • Page 17: Service Mode

    6 Service Mode 6.1. Error Code Memory Function 1. General description This unit is equipped with history of error code memory function, and can be memorized 16 error codes in sequence from the latest. When the error is occurred more than 16, the oldest error is overwritten in sequence. The error code is not memorized when the power supply is shut down forcibly (i.e.,when the unit is powered on by the battery, the battery is pulled out) The error code is memorized to FLASH-ROM when the unit has just before powered off.
  • Page 18 • 3. Error Code List The error code consists of 8 bits data and it shows the following information.

  • Page 19: Ics (Indication Of Additional Camera Settings When Picture Was Taken) Function

    Important notice about "Error Code List" 1) About "*" indication: The third digit from the left is different as follows. - In case of 0 (example: 18001000) When the third digit from the left shows "0", this error occurred under the condition of INITIAL SETTINGS has been completed.
  • Page 20 3. How to read 4. How to exit: Simply, turn the power off. (Since ICS function is executed under the condition of temporary cancellation of "INITIAL SETTINGS", it wake up with normal condition when turn off the power.)

  • Page 21: Service Fixture & Tools

    7 Service Fixture & Tools 7.1. Service Fixture and Tools The following Service Fixture and tools are used for checking and servicing this unit.

  • Page 22: When Replacing The Main P.c.b

    7.2. When Replacing the Main P.C.B. After replacing the MAIN P.C.B., be sure to achieve adjustment. The service software is available at “TSN Website”. To download, click on “Support Information from NWBG/VDBG-AVC”. 7.3. Service Position This Service Position is used for checking and replacing parts. Use the following Extension cables for servicing. Table S1 Extension Cable List Parts No.

  • Page 23: Disassembly And Assembly Instructions

    8 Disassembly and Assembly Instructions 8.1. Disassembly Flow Chart This is a disassembling chart. When assembling, perform this chart conversely. 8.2. P.C.B. Location...

  • Page 24: Disassembly Procedure

    8.3. Disassembly Procedure 8.3.1. Removal of the Rear Case Unit and Front Case Unit Item Removal Rear Case Unit (Fig. D1) Card Front Case Unit Battery 6 Screws (A) Side Ornament R (Fig. D2) 2 Locking tabs 2 Hanging parts Rear Case Unit 1 Locking tab Front Case Unit...
  • Page 25 8.3.2. Removal of the Sub Operation FPC Unit/PCB Frame (Fig. D2) (Fig. D3)
  • Page 26 8.3.3. Removal of the LCD Unit 8.3.4. Removal of the Top Operation Unit (Fig. D4) (Fig. D5)
  • Page 27 8.3.5. Removal of the Flash Top P.C.B. and Speaker (Fig. D7) (Fig. D6)
  • Page 28 8.3.6. Removal of the Lens Unit 8.3.8. Removal of the Sub Operation FPC Unit (Fig. D8) 8.3.7. Removal of the Main P.C.B. (Fig. D10) (Fig. D9)
  • Page 29 8.3.9. Removal of the Battery Case 8.3.10. Removal of the Battery Door Unit (Fig. D12) NOTE: (When Installing) Make sure to confirm the following points when installing: • The Screw is tightened enough. • Installing conditions are fine. (No distortion, no abnormal- space.) •...

  • Page 30: Lens Disassembly Procedure

    8.4. Lens Disassembly Procedure 8.4.1. Removal of the Zoom Motor and Lens FPC P.C.B. Unit Precaution: 1. Do not remove the MOS sensor unit when disassembling 1. Remove the Connector. or re-assembling the lens in order to maintain it clean. 2.
  • Page 31 8.4.2. Removal of the Master Flange Unit 8.4.3. Removal of the Cam Frame Unit/ 1. Unscrew the 4 screws (C). Direct Frame/1st Lens Frame Unit/ 2. Remove the master flange unit. 2nd Lens Frame Move Unit 1. Push the cam frame unit from the lens front side in the direction of arrow, and then remove the unit of cam frame unit/direct frame/1st lens frame unit/2nd lens frame move unit from the fixed frame unit/drive frame unit/penetration...
  • Page 32 8.4.4. Removal of the Direct Frame/1st 8.4.5. Removal of the 1st Lens Frame Lens Frame Unit/2nd Lens Frame Unit/2nd Lens Frame Move Unit Move Unit 1. Detach the shutter flex from 2 convexes of direct frame and pull it up. 1.

  • Page 33: Assembly Procedure For The Lens

    8.4.6. Removal of the 2nd Lens Frame 8.5. Assembly Procedure for the Move Unit Lens 1. Remove the 2nd Lens frame move unit in the direction of 8.5.1. Phase alignment of the Drive Frame the arrow. Unit and Penetration Cam Frame Unit...
  • Page 34 8.5.2. Phase alignment of the Drive Frame 8.5.4. Install of the 1st Lens Frame Unit/ Unit/Penetration Cam Frame Unit 2nd Lens Frame Move Unit and Fixed Frame Unit 8.5.3. Install of the 2nd Lens Frame Move Unit...
  • Page 35 8.5.5. Phase alignment of the Direct 8.5.6. Phase alignment of the Cam Frame Frame/1st Lens Frame Unit/2nd Unit/Direct Frame/1st Lens Frame Lens Frame Move Unit and Cam Unit/2nd Lens Frame Move Unit and Frame Unit Fixed Frame Unit/Drive Frame Unit/ Penetration Cam Frame Unit...
  • Page 36 8.5.7. Install of the Master Flange Unit 8.5.8. Install of the Lens FPC P.C.B. Unit and Zoom Motor...

  • Page 37: Removal Of The Mos Sensor Unit

    8.6. Removal of the MOS Sensor Unit When remove the MOS sensor unit once (the screw(D) is loos- ened even a little), the optical tilt adjustment is required. When loosen the screw(D), necessary the optical tilt adjust- ment at the end of assembling. (Refer to item "9.3.2.") To prevent the MOS sensor unit from catching the dust and dirt, do not remove the MOS sensor unit except for replacing.

  • Page 38: Removal Of The Focus Motor

    8.7. Removal of the Focus Motor 8.8. Application Grease Method The grease application parts of lens unit are as follows. Apply grease additionally in the specified position if necessary. When the grease is applied, use a toothpick and apply thinly. •...

  • Page 39: Measurements And Adjustments

    9 Measurements and Adjustments 9.1. Introduction When servicing this unit, make sure to perform the adjustments necessary based on the part(s) replaced. Before disassembling the unit, it is recommended to back up the camera data stored in flash-rom as a data file. IMPORTANT NOTICE (After replacing the MAIN P.C.B.) After replacing the MAIN P.C.B., it is necessary to use the “DIAS”...
  • Page 40 9.2.2. Flash-Rom Data Backup When trouble occurs, it is recommended to backup the Flash-rom data before disassembling the unit. There are two kinds of Flash-rom data backup methods: [ ROM_BACKUP (Method of Non-PC backup) ] 1. Insert the SD-card into the camera. 2.

  • Page 41: Details Of Electrical Adjustment

    9.3. Details of Electrical Adjustment 9.3.1. How to execute the Electrical Adjustment It is not necessary to connect the camera to a PC to perform adjustments. “Flag reset operation” and “Initial setting operation” are required when carrying out the alignment, follow the procedure below. 9.3.1.1.
  • Page 42 9.3.1.3. Execute Adjustment (In case of “OIS Adjustment”) 1. Perform step “9.3.1.1.” to “9.3.1.2.”, to reset the OIS flag status “F” (Set) to “0” (Reset) 2. Press [ MODE ] button after Flag reset. OIS Adjustment screen is displayed on the LCD panel. (Refer to Fig.3-3) 3.
  • Page 43 9.3.2. Adjustment Specifications The following matrix table shows the relation between the replaced part and the Necessary Adjustment. When a part is replaced, make sure to perform the necessary adjustment(s) in the order indicated. The table below shows all the information necessary to perform each adjustment.

  • Page 45: After Adjustment

    9.4. After Adjustment 9.4.1. Initial Setting Since the initial setting has been released to execute the built-in adjustment software, it should be set up again before shipping the camera to the customer. Refer to the procedure described in “3.5.2. INITIAL SETTINGS” for details. [ IMPORTANT ] 1.

  • Page 46: Maintenance

    10 Maintenance 10.1. Cleaning Lens and LCD Panel Do not touch the surface of lens and LCD Panel with your hand. When cleaning the lens, use air-Blower to blow off the dust. When cleaning the LCD Panel, dampen the lens cleaning paper with lens cleaner, and the gently wipe the its surface. Note: The Lens Cleaning KIT ;...
  • Page 47 DSC1008051CE S1. About Indication of The Schematic Diagram Service Manual S1.1. Important Safety Notice COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CHARACTERISTICS Diagrams and Replacement FOR SAFETY. WHEN REPLACING ANY OF THESE COMPONENTS USE ONLY THE SAME TYPE. 1.Although reference number of the parts is indicated on the P.C.B. drawing and/or Parts List schematic diagrams, it is NOT mounted on the P.C.B.

  • Page 48: S2. Voltage Chart

    S2. Voltage Chart Note) Indicated voltage values are the standard values for the unit measured by the DC electronic circuit tester (high-impedance) with the chassis taken as standard. Therefore, there may exist some errors in the voltage values, depending on the internal impedance of the DC circuit tester. S2.1.

  • Page 49: S3. Block Diagram

    S3. Block Diagram S3.1. Overall Block Diagram (24mm ~ 120mm) MOS SENSOR CARD STEREO MICROPHONE ZOOM OIS UNIT IRIS SHUTTER FOCUS X6001 (24MHz) IC9101 SYSTEM IC SPEAKER MICROPHONE AMP SPEAKER CONTROL IC9101 VIDEO OUT SYSTEM IC MOTOR DRIVE, OIS DRIVE& AV OUT / DIGITAL PRE PROCESS TERMINAL...

  • Page 50: S4. Schematic Diagram

    S4. Schematic Diagram S4.1. Interconnection Diagram ET8001 PS8001 FLASH TOP P.C.B. FP8001 (COMPONENT SIDE) P8002 : (FOIL SIDE) ET8002 TOUCH PANEL LCD UNIT SPEAKER STEREO BATTERY MICROPHONE FP9002 MOS THERMO VDD33 AVDD AVDD AVDD VDD36 VDD12 VDD12 VDD12 VDD12 VDD12 VDD18 VDD18 FP9502...

  • Page 51: S4.2. Sub Operation Schematic Diagram

    S4.2. Sub Operation Schematic Diagram PLAY K0D112B00145 S9501 FRAME_GND REC_PLAY_SW R9501 K1MN04BA0162 FP9502 TO TOUCH PANEL TO MAIN BOARD BL_MINUS FT9501 BL_PLUS PW_BL_MINUS PW_BL_MINUS K1MN04BA0162 PW_BL_PLUS PW_BL_PLUS FP9501 TO BACKLIGHT FRAME-GND FRAME_GND FRAME-GND MENU MENU MODE MODE REC_PLAY_SW REC_PLAY_SW MODE MENU VREF_Y ALPS...

  • Page 52: S4.3. Flash Top Schematic Diagram

    S4.3. Flash Top Schematic Diagram CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE 2.0A 32V FUSE. ATTENTION: POUR UNE PROTECTION CONTINUE LES RISQUES 2.0A 32V D' INCENDIE N' UTILISERQUE DES FUSIBLE DE MÉME TYPE 2.0A 32V. GYRO_X(YAW) C7302 N.C.

  • Page 53: S4.4. Lens Flex Schematic Diagram

    S4.4. Lens Flex Schematic Diagram POSITIVE VOLTAGE LINE IRB+ IRB+ IRB- IRB- DC SOLENOID (IRIS) IRA+ IRA+ SHUTTER UNIT IRA- IRA- DC SOLENOID (SHUTTER) YDR- DRIVE COIL (Y) XDR+ YDR+ DRIVE COIL (X) XDR- YHI- OIS UNIT YHO+ HALL SENSOR (Y) YHI+ YHO- TO MAIN...

  • Page 54: S5. Print Circuit Board

    S5. Print Circuit Board S5.1. Sub Operation Flex P.C.B. C7201 C7202 IC7201 (Foil Side) DMC-FX700 Sub Operation Flex P.C.B.

  • Page 56: S5.2. Flash Top P.c.b

    S5.2. Flash Top P.C.B. DMC-FX700 Flash Top P.C.B. (Component Side) LB8002 CL8011 LB8001 CL8001 ET8005 C8010 C8003 CL8005 CL8008 CL8202 R8013 T8001 IC8100 CL8201 FP8001 D8001 CL8004 CL8003 CL8006 (Component Side) S-10...
  • Page 57 DMC-FX700 Flash Top P.C.B. (Component Side) 34 30 TL8007 PS8001 F8021 CL8202 RL8003 L8001 CL8201 P8002 RL8001 S-11...
  • Page 58 (Component Side) S8002 TL8004 CL7304 CL7303 C7302 CL7302 CL7301 R8036 VA8005 IC7301 VA8003 (Foil Side) DMC-FX700 Flash Top P.C.B. (Foil Side) S-12...
  • Page 59 ET8001 ET8003 ET8004 R8005 CL8002 RL8002 ET8002 DMC-FX700 Flash Top P.C.B. (Foil Side) S-13...

  • Page 60: S5.3. Lens Flex P.c.b

    S5.3. Lens Flex P.C.B. ZOOM MOTOR UNIT SHUTTER UNIT ZOOM ENCODER 1 C3/D1 ZOOM ENCODER 2 CO. BARREL ENCODER (FULL RETRACT) Pin 1 OIS UNIT Pin 45 FOCUS MOTOR UNIT DMC-FX700 LENS FLEX P.C.B. S-14...

  • Page 61: S6. Replacement Parts List

    ELECTROSTATIC DISCHARGE (ESD) TO ELECTROSTATICALLY SENSITIVE (ES) DEVICES section. Definition of Parts supplier: 1. Parts marked with [ENERGY] in the remarks column are supplied from Panasonic Corporation Energy Company. 2. Parts marked with [PAVCSG] in the remarks column are supplied from PAVCSG.
  • Page 62 DMC-FX700EGK vol.1 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VEP56109B MAIN P.C.B. 1 (RTL) E.S.D. EG,EP,EF,EB VEP56109A MAIN P.C.B. 1 (RTL) E.S.D. EE,P,PC,PU, GC,GH,SG,GT,GK,GN,GD VEP59086A SUB OPERATION FPC UNIT 1 (RTL) E.S.D. VEP58124A FLASH TOP P.C.B.
  • Page 63 DMC-FX700EGK vol.1 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VHD2240 SCREW VGK3649 SIDE ORNAMENT (R) 1 [PAVCSG] VHD2240 SCREW VYK4F74 FRONT CASE UNIT 1 PCS,GCS,GHS,SGS,GKS VHD2240 SCREW [PAVCSG] VHD2240 SCREW VYK4F75 FRONT CASE UNIT 1 P-S [PAVCSG] VHD2240...
  • Page 64 DMC-FX700EGK vol.1 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VPF1317 CAMERA BAG 1 P,PC,PU DE-A59BB BATTERY CHARGER 1 P,PC,PU ----- BATTERY 1 P,PC,PU K1HA08AD0002 USB CABLE W/PLUG 1 P,PC,PU K1HA08CD0028 AV CABLE W/PLUG 1 P,PC,PU VFC4297 HAND STRAP...
  • Page 65 DMC-FX700EGK vol.1 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VQT2Y01 INSTRUCTION BOOK 1 GD VPF1317 CAMERA BAG 1 EXCEPT P,PC,PU (KOREAN) DE-A60AA BATTERY CHARGER 1 EG,EP,EF,EB,GN VPK4564 PACKING CASE 1 EGK,EPK,EFK,EBK,EEK,GCK, DE-A60BB BATTERY CHARGER 1 EE,GC,GH,GK,GD...

  • Page 66: S7. Exploded View

    S7. Exploded View S7.1. Frame and Casing Section 55-1 B101 B102 B103 109 110 B109 B107 B108 108-3 104-1 B110 B105 B111 B112 B106 108-2 108-1 S-20...

  • Page 67: S7.2. Packing Parts And Accessories Section (1

    S7.2. Packing Parts and Accessories Section (1) In the case of DMC-FX700PU, stick the Ref. No.217 (NTSC LABEL) to printed “PAL” of the packing case. S-21...

  • Page 68: S7.3. Packing Parts And Accessories Section (2

    S7.3. Packing Parts and Accessories Section (2) (DMC-FX700EE/EF/ EG/EP/GC/GD) (DMC-FX700EB/GC/GH) (DMC-FX700 GK/GT/SG) (DMC-FX700GN) In the case of DMC-FX700GT/GD, stick the Ref. No.317 (NTSC LABEL) to printed “PAL” of the packing case. S-22...
