SP20TNS SP30TNS SP50TS
SP20TNS SP30TNS SP50TS
SP20TNS SP30TNS SP50TS
20 TON MANUAL SHOP PRESS
30 TON MANUAL SHOP PRESS
50 TON MANUAL SHOP PRESS
SP20TNS
SP20TNS
Capacity ................................. 20 Tons
Ram Travel .................................5-3/4"
Ram Extension Screw Travel ........... 3"
Throat Height Min.. .......................... 1"
Throat Height Max. ..................33-1/4"
Throat Width ............................21-1/4"
Bed Height Adjustments .... 6 x 6-1/2"
Between Uprights ......................5-1/4"
Between Bolster Rails ...............5-7/8"
Base Width .................................... 20"
Base Length ................................. 28"
Overall Height ................................ 71"
Net Weight ..........................267.6 Lbs.
Shipping Weight .................327.4 Lbs.
SP20TNS, SP30TNS, SP50TS
SP30TNS
SPECIFICATIONS
SP30TNS
Capacity ................................. 30 Tons
Ram Travel .................................5-3/4"
Ram Extension Screw Travel ........... 3"
Throat Height Min.. ....................... 3/4"
Throat Height Max. ..................33-1/4"
Throat Width ............................21-1/4"
Bed Height Adjustments .... 6 x 6-1/2"
Between Uprights ......................5-3/4"
Between Bolster Rails ...............6-1/2"
Base Width .................................... 20"
Base Length ................................. 28"
Overall Height ................................ 71"
Net Weight ..........................345.7 Lbs.
Shipping Weight .................407.9 Lbs.
1
ASME PASE-2019
SP50TS
SP50TS
Capacity ................................. 50 Tons
Ram Travel .................................5-3/4"
Ram Extension Screw Travel ........... 3"
Throat Height Min.. .......................... 3"
Throat Height Max. ..................30-1/2"
Throat Width ............................29-1/2"
Bed Height Adjustments .... 6 x 5-1/2"
Between Uprights ......................7-7/8"
Between Bolster Rails ...............8-3/4"
Base Width .................................... 21"
Base Length ................................. 37"
Overall Height ................................ 75"
Net Weight ..........................537.5 Lbs.
Shipping Weight .................612.2 Lbs.
Rev. 05/10/21
Advertisement
Table of Contents
Related Manuals for Napa CARLYNE TOOLS SP20TNS
Summary of Contents for Napa CARLYNE TOOLS SP20TNS
- Page 1 SP20TNS SP30TNS SP50TS SP20TNS SP30TNS SP50TS SP20TNS SP30TNS SP50TS 20 TON MANUAL SHOP PRESS ASME PASE-2019 30 TON MANUAL SHOP PRESS 50 TON MANUAL SHOP PRESS SP20TNS SP30TNS SP50TS SPECIFICATIONS SP20TNS SP30TNS SP50TS Capacity ......... 20 Tons Capacity ......... 30 Tons Capacity .........
-
Page 2: Warning Information
It is the responsibility of the owner to make sure all personnel read this manual prior to using the device. It is also the responsiblity of the device owner to keep this manual intact and in a convenient location for all to see and read. If the manual or product labels are lost or not legible, contact NAPA for replacements. -
Page 3: Setup Instructions
OPERATING MANUAL FOR SP20TNS SP30TNS SP50TS CONSEQUENCES OF NOT AVOIDING HAZARDOUS SITUATIONS WARNING Failure to read this manual completely and thoroughly, failure to understand its OPERATING INSTRUCTIONS, SAFETY WARNINGS, MAINTENANCE INSTRUCTIONS and comply with them, and failure to comply with the METHODS TO AVOID HAZARDOUS SITUATIONS could cause accidents resulting in serious or fatal personal injury and/or property damage. - Page 4 OPERATING MANUAL FOR SP20TNS SP30TNS SP50TS 7. Install the pump handle (25) in the handle receiver (48) by 2. Turn the release valve knob ½ turn counterclockwise from depressing the spring loaded button (26) in the handle, slide the its closed position. Activate the pump handle (25) ten full handle in the receiver until the button pops into the hole in the incremental pump strokes.
-
Page 5: Maintenance
6. Inspect the press before each use. Do not use if any component is cracked, broken, bent, shoes signs of damage or excessive wear, or leaks hydraulic fluid. Take corrective action before using the press again. WARRANTY Please contact your local NAPA Auto Parts Store for details on warranty. SP20TNS, SP30TNS, SP50TS Rev. 05/10/21... - Page 6 SP20TNS, SP30TNS and SP50TS PARTS DRAWING SP20TNS, SP30TNS, SP50TS Rev. 05/10/21...
-
Page 7: Parts List
PARTS LIST Model # SP20TNS SP30TNS SP50TS Ref # Part# Description Qty. RS00201 RS00201 RS00501 Pump Assy. Spring Washer Inner Hexagonal Screw Press Frame Assy. Pulley Protection Cover Assy Pulley Protection Cover Assy RS00202 RS00202 RS00502 Retaining Ring RS00203 RS00301 RS00503 Cylinder Assy Spare Parts Tray... - Page 8 PARTS LIST Model # SP20TNS SP30TNS SP50TS Ref # Part# Description Qty. Workbench Wear Plate(Right) Workbench Wear Plate(Left) Wire Cable RS00217 8 Pc. Plunger Set (2T-15T) RS00209 Plunger (2T) RS00210 Plunger (3T) RS00211 Plunger (6T) RS00212 Plunger (8T) RS00213 Plunger (10T) RS00214 Plunger (12T) RS00215...
- Page 9 SP20TNS SP30TNS SP50TS SP20TNS SP30TNS SP50TS SP20TNS SP30TNS SP50TS PRENSA DE TALLER MANUAL 20 TONELADAS ASME PASE-2019 PRENSA DE TALLER MANUAL 30 TONELADAS PRENSA DE TALLER MANUAL 50 TONELADAS SP20TNS SP30TNS SP50TS SPECIFICATIONS SP20TNS SP30TNS SP50TS Capacidad ......20 toneladas Capacidad ......
-
Page 10: Información De Advertencia
Si las etiquetas del manual o producto son ilegibles o no están en su lugar, deberá ponerse en contacto con NAPA para obtenerlas gratis. El comprador/ propietario o una persona designada deberá... -
Page 11: Instrucciones De Ajuste
MANUAL DEL FUNCIONAMIENTO PARA SP20TNS SP30TNS SP50TS • Libere la presión hidráulica antes de aflojar cualquier acople. • Se podrían ocasionar lesiones personales serias o fatales y/o daños a la propiedad al hacer caso omiso o por la falta de comprender estas instrucciones y marcas ADVERTENCIA: Este producto le podrá exponer a ciertos químicos, para incluir el níquel, conocidos en el Estado de California por ocasionar cáncer y defectos congénitos u otros daños a la reproducción. Para mayores informes, visite www.P65Warnings.ca.gov. CONSECUENCIAS DE NO PREVENIR LAS SITUACIONES DE RIESGO ADVERTENCIA No leer, comprender u observar todo el contenido de este manual en relación con sus INSTRUCCIONES DE USO, ADVERTENCIAS DE SEGURIDAD y FORMA DE MANTENIMIENTO, así... -
Page 12: Instrucciones De Operación
MANUAL DEL FUNCIONAMIENTO PARA SP20TNS SP30TNS SP50TS 7. Instale la palanca de la bomba (25) en el receptor de la palanca (48) al oprimir el botón con resorte (26) en la palanca, deslice la Figura 3 palanca en el receptor hasta que el botón se encaje en al agujero en el receptor. -
Page 13: Mantenimiento
Tome las acciones correctivas antes de usar la prensa de nuevo. GARANTÍA: Para mayores informes sobre la garantía, comuníquese por favor con su tienda local de partes automotrices NAPA. SP20TNS, SP30TNS, SP50TS... - Page 14 SP20TNS SP30TNS SP50TS SP20TNS SP30TNS SP50TS SP20TNS SP30TNS SP50TS PRESSE D’ATELIER – 20 TONNES ASME PASE-2019 PRESSE D’ATELIER – 30 TONNES PRESSE D’ATELIER – 50 TONNES SP20TNS SP50TS SPÉCIFICATIONS SP20TNS SP30TNS SP50TS Capacité ........20 tonnes Capacité ........30 tonnes Capacité ........50 tonnes Course du piston ..
- Page 15 état et le ranger dans un endroit facilement accessible à tous ceux qui doivent le lire. Si le manuel ou les étiquettes de l'outil sont perdus ou illisibles, communiquer avec NAPA pour obtenir un remplacement. Si l’utilisateur ne parle pas couramment le français, les consignes de sécurité...
-
Page 16: Directives De Montage
MANUEL DE FONCTIONNEMENT POUR SP20TNS SP30TNS SP50TS CONSÉQUENCES EN CAS DE SITUATIONS DANGEREUSES AVERTISSEMENT L'inobservance des CONSIGNES D'UTILISATION, des MISES EN GARDE, des CONSIGNES D'ENTRETIEN ainsi que des MÉTHODES POUR ÉVITER LES SITUATIONS DANGEREUSES peut causer des accidents ayant pour conséquences des dommages matériels ou des blessures corporelles graves ou mortelles. -
Page 17: Directives D'utilisation
MANUEL DE FONCTIONNEMENT POUR SP20TNS SP30TNS SP50TS 7. Insérer le levier de la pompe (25) dans le porte-levier (48) en FIGURE 3 Bouchon d’évent appuyant sur le bouton à ressort (26) du levier jusqu’à ce que le bouton ressorte dans le trou du porte-levier. 8. -
Page 18: Garantie
Fermer la soupape de relâchement (sens horaire) et actionner le levier de la pompe. GARANTIE Pour plus de renseignements au sujet de la garantie, veuillez communiquer avec votre magasin de pièces automobiles NAPA local. ENTRETIEN 1. Éviter d’exposer la presse à des vapeurs corrosives ou à des poussières abrasives.
