- Page 1 AIR-COOLED SCREW LIQUID CHILLERS WIRING DIAGRAM New Release Form 201.19-W1 (304) YCAS AIR-COOLED LIQUID CHILLERS YCAS0130 THROUGH YCAS0230 STYLE G (60 Hz) 200-3-60 230-3-60 380-3-60 460-3-60 575-3-60 MODELS ONLY...
-
Page 2: Table Of Contents
FIG. 10 – CONNECTION DIAGRAM (SYSTEM WIRING)............27 FIG. 11 – COMPRESSOR TERMINAL BOX ................28 FIG. 12 – ELEMENTARY DIAGRAM STARTER CONTROL CIRCUIT ........29 FIG. 13 – ELEMENTARY DIAGRAM FAN CONTROL CIRCUIT ..........30 YORK INTERNATIONAL YORK INTERNATIONAL... -
Page 3: Nomenclature
FORM 201.19-W1 (304) NOMENCLATURE The Model Number denotes the following characteristics of the unit: 0140 YORK Chiller Design Series YC = YORK Chiller Type Start Y = Star (WYE)-Delta Air-Cooled X = Across-the-Line Compressor Type S = Screw Voltage Code... -
Page 4: Electrical Notes
11. Consult factory for Electrical Data on units equipped with “High Static Fan” option. High Static Fans are 3.8 kW each. 12. FLA for “Low Noise Fan” motors: 200V = 8.0A, 230V = 7.8A, 380V = 4.4A, 460V = 3.6A, 575V = 2.9A. 13. Group Rated breaker must be HACR type for cU.L. Machines. YORK INTERNATIONAL... - Page 5 FORM 201.19-W1 (304) This page intentionally left blank. YORK INTERNATIONAL...
-
Page 6: Electrical Data
2/0 - 500 (2) 3/0-250 (2) 3/0-250 1093 23.0 2/0 - 500 # 6 - 350 (2) 3/0-250 19.0 1/0 - 300 # 6 - 350 # 6 - 350 15.2 See page 4 for Electrical Data footnotes. YORK INTERNATIONAL... - Page 7 (2) 2/0 - 500 (3) 2/0-400 (3) 2/0-400 33.0 0230EC 2/0 - 500 (2) 3/0-250 (2) 3/0-250 1093 23.0 2/0 - 500 # 6 - 350 (2) 3/0-250 19.0 1/0 - 300 # 6 - 350 # 6 - 350 15.2 YORK INTERNATIONAL...
- Page 8 (2) 3/0-250 923.5 1000 1200 1200 809.3 1000 1000 1000 0230EC 491.3 (2) 2/0 - 500 (2) 250-500 406.8 (2) 2/0 - 500 (2) 250-500 323.5 (2) 1/0 - 300 (2) 3/0-250 See page 4 for Electrical Data footnotes. YORK INTERNATIONAL...
- Page 9 0210EC 197.0 1093 23.0 181.0 1093 23.0 163.0 19.0 149.0 19.0 130.0 15.2 119.0 15.2 374.0 38.0 374.0 38.0 325.0 33.0 325.0 33.0 0230EC 197.0 1093 23.0 197.0 1093 23.0 163.0 19.0 163.0 19.0 130.0 15.2 130.0 15.2 YORK INTERNATIONAL...
- Page 10 (2) 3/0-250 (2) # 1 - 500 (2) 250-500 0210EC (2) # 2 - 300 (2) 3/0-250 (2) # 1 - 500 (2) 250-500 0230EC (2) # 2 - 300 (2) 3/0-250 See page 4 for Electrical Data footnotes. YORK INTERNATIONAL...
- Page 11 0140EC 15.2 15.2 19.0 19.0 0150EC 15.2 15.2 19.0 19.0 0160EC 15.2 15.2 19.0 19.0 0170EC 15.2 15.2 19.0 19.0 0180EC 15.2 15.2 19.0 19.0 0200EC 15.2 15.2 19.0 19.0 0210EC 15.2 15.2 19.0 19.0 0230EC 15.2 15.2 YORK INTERNATIONAL...
- Page 12 1. – – – – – – – Dashed Line indicates Field Provided Wiring. 2. The above recommendations are based on the National Electric Code and using copper connectors only. Field wiring must also comply with local codes. YORK INTERNATIONAL...
- Page 13 DXS45LA – MOTOR CODE A DXS36LA – MOTOR CODE A DXS24LA – MOTOR CODE (TBD) (B5N, B5E, B6N, B6E) (A5N, A5E, A6N, A6E) (C5N, C5E, C6N, C6E) VOLTAGE CODE- -46 -50 -56 MAX kW 80 105 MAX AMPS 135 118 YORK INTERNATIONAL...
-
Page 14: Wiring Diagram
6. Alarm contacts are for annunciating alarm/unit mal func - (Class 2) Connections. See Note 2 tion. Con tacts are rated at 115V, 100VA, re sis tive load only, Terminal Block for YORK Connections Only and must be suppressed at load by user. Wiring and Components by YORK 7. -
Page 15: Fig. 2 - Wiring Diagram - Across-The-Line Start
FORM 201.19-W1 (304) WIRING DIAGRAM (CONT'D) ACROSS-THE-LINE START LD09233 FIG. 2 – WIRING DIAGRAM – ACROSS-THE-LINE START YORK INTERNATIONAL... -
Page 16: Elementary Diagram
FORM 201.19-W1 (304) ELEMENTARY DIAGRAM LD09480 FIG. 3 – ELEMENTARY DIAGRAM – ACROSS-THE-LINE START YORK INTERNATIONAL... - Page 17 BAS in puts on ter mi nals 13 - 19 or TB3, or any oth er ter mi nals, must be sup- pressed with a YORK P/N 031- 00808-000 sup pres sor across the re lay/con tac tor coil.
-
Page 18: Wiring Diagram
6. Alarm contacts are for annunciating alarm/unit mal func - (Class 2) Connections. See Note 2 tion. Con tacts are rated at 115V, 100VA, re sis tive load only, Terminal Block for YORK Connections Only and must be suppressed at load by user. Wiring and Components by YORK 7. -
Page 19: Fig. 5 - Elementary Diagram - Wye-Delta Start
FORM 201.19-W1 (304) WIRING DIAGRAM (CONT'D) WYE-DELTA START LD09236 FIG. 5 – ELEMENTARY DIAGRAM – WYE-DELTA START YORK INTERNATIONAL... -
Page 20: Elementary Diagram
FORM 201.19-W1 (304) ELEMENTARY DIAGRAM LD09480 FIG. 6 – ELEMENTARY DIAGRAM – WYE-DELTA START YORK INTERNATIONAL... - Page 21 BAS inputs on ter mi nals 13 - 19 or TB3, or any oth er ter mi nals, must be sup- pressed with a YORK P/N 031- 00808-000 sup pres sor across the re lay/con tac tor coil.
-
Page 22: Power Panel
FORM 201.19-W1 (304) POWER PANEL (SYSTEM #1) LD09238 FIG. 7 – POWER PANEL (SYSTEM #1) COMPONENT LO CA TIONS YORK INTERNATIONAL... -
Page 23: Control Panel
FORM 201.19-W1 (304) CONTROL PANEL LD09239 FIG. 8 – CONTROL PANEL COMPONENT LOCATION YORK INTERNATIONAL... -
Page 24: Power Panel
FORM 201.19-W1 (304) POWER PANEL (SYSTEM #2) LD09240 FIG. 9 – POWER PANEL (SYSTEM #2) COMPONENT LO CA TIONS YORK INTERNATIONAL... - Page 25 FORM 201.19-W1 (304) LEGEND LD09241 YORK INTERNATIONAL...
- Page 26 FORM 201.19-W1 (304) LD03282 LD03283 2 ACE MOTOR PROTECTOR MODULE LD03284 YORK INTERNATIONAL...
-
Page 27: Connection Diagram (System Wiring)
FORM 201.19-W1 (304) CONNECTION DIAGRAM (SYSTEM WIRING) FIG. 10 – CONNECTION DIAGRAM (SYSTEM WIRING) LD09242 YORK INTERNATIONAL... -
Page 28: Compressor Terminal Box
FORM 201.19-W1 (304) COMPRESSOR TERMINAL BOX FIG. 11 – COMPRESSOR TERMINAL BOX LD09243 YORK INTERNATIONAL... -
Page 29: Elementary Diagram Starter Control Circuit
FORM 201.19-W1 (304) ELEMENTARY DIAGRAM STARTER CONTROL CIRCUIT LD09373 FIG. 12 – ELEMENTARY DIAGRAM STARTER CONTROL CIRCUIT YORK INTERNATIONAL... -
Page 30: Elementary Diagram Fan Control
ELEMENTARY DIAGRAM FAN CONTROL #3/#4 #3/#4 #5/#6 #5/#6 #7/#8 #3/#4 #5/#6 #7/#8 #9/#10 LD06840 FIG. 13 – ELEMENTARY DIAGRAM FAN CONTROL CIRCUIT... - Page 31 FORM 201.19-W1 (304) NOTES YORK INTERNATIONAL...
- Page 32 P.O. Box 1592, York, Pennsylvania USA 17405-1592 Subject to change without notice. Printed in USA Tele. 800-861-1001 Copyright © by York International Corporation 2004 www.york.com ALL RIGHTS RESERVED Form 201.19-W1 (304) New Release...
