Web Management Software Opens

This is the Home screen from which you can access all setup functions.
Note: Only the top portion of the Home screen is shown here.

Navigating Through the Software Screen

Before using the software, you may find the following information about navigating through
the screens and the structuring of the menus helpful.
Menu
Bar
Sub
Menu

Menu Bar

See menu categories and their submenus listed on the next page.
Multi-Tech Systems, Inc. RF820/RF820-AP & RF830/RF830-AP Quick Start Guide
Chapter 2 – Installation
Other
Options
Screen
Name
Input
Area
