Network Receiver OWNER’S MANUAL MANUAL DE INSTRUCCIONES...
Page 2
12 Only voltage specified on this unit must be used. Using this unit with a higher voltage than specified is dangerous and may cause fire, damage to this unit, and/or personal injury. Yamaha will not be held responsible for any damage resulting from use of this unit with a voltage other than specified.
• Selecting songs and starting/stopping playback • Playing back music from the iPhone or Android device • To download the application or see the latest information, access the App Store or Google Play and search for “NP Controller.” For details, please visit Yamaha website.
Supplied accessories Supplied accessories Check that the following accessories are supplied with the product. Remote control AM antenna FM antenna Batteries (x2) (AAA, R03, UM-4) CODE SET SOURCE RECEIVER SLEEP SPEAKERS DIMMER COAX1 COAX2 OPT1 OPT2 LINE1 LINE2 LINE3 PHONO TUNER PRESET TUNING...
Selects the tuning frequency when TUNER is selected as Switch the remote control ID between ID1 and ID2 when using the input source (p.18). multiple Yamaha receivers or amplifiers (p.35). B PURE DIRECT and indicator 4 DIMMER Allows you to listen to a source in the purest possible Changes the brightness level of the front display.
Page 7
Controls and functions F INPUT selector Selects the input source you want to listen to. G BASS control Increases or decreases the low frequency response. The center position produces a flat response (p.16). H TREBLE control Increases or decreases the high frequency response. The center position produces a flat response (p.16).
Controls and functions Front display VOL. SLEEP SP A STEREO TUNED SP B MUTE 1 Information display Displays the current status (such as input name sound mode name). You can switch the information that is displayed when you press DISPLAY (p.30). 2 STEREO Lights up when the unit is receiving a stereo FM radio signal.
REMOTE IN/OUT jacks of this unit, using cables with 3 ANTENNA terminals monaural miniplugs. For connecting to FM and AM antennas (p.12). Up to six Yamaha components (including this unit) can be 4 COAXIAL 1-2 jacks connected. For connecting to audio components equipped with a Rear panel of R-N500 coaxial digital output (p.10).
This section describes the function of each key on the Input selection keys remote control used to control this unit or other Select an input source for playback. components made by Yamaha or other manufacturers. COAX 1-2 COAXIAL 1-2 jacks OPT 1-2...
Controls and functions Using the remote controls ■ Installing batteries AAA, R03, UM-4 batteries ■ Operation range The remote controls transmit a directional infrared beam. Be sure to aim the remote controls directly at the remote control sensor on the front panel of this unit. Approximately 6 m (20 ft) 30°...
PREPARATION Connections Connections Connecting speakers and source components CAUTION • Do not connect this unit or other components to the main power until all connections between components are complete. • All connections must be correct: L (left) to L, R (right) to R, “+” to “+” and “–” to “–”. If the connections are faulty, no sound will be heard from the speakers, and if the polarity of the speaker connections is incorrect, the sound will be unnatural and lack bass.
Connections ■ Connecting via banana plug Connecting the speakers (Asia model only) Tighten the knob and then insert the banana plug into the ■ Setting the speaker impedance end of the corresponding terminal. Under its default settings, the unit is configured for 8-ohm speakers.
The antennas for receiving FM and AM broadcasts are included with this unit. In general, these antennas should provide sufficient signal strength. Connect each antenna correctly to the designated terminals. Note If you experience poor reception quality, install an outdoor antenna. Consult the nearest authorized Yamaha dealer or service center about outdoor antennas. AM antenna (included) •...
Connections Connecting to a network You can enjoy Internet radio or music files stored on media servers, such as PCs and Network Attached Storage (NAS), on the unit. Connect the unit to your router with a commercially-available STP network cable (CAT-5 or higher straight cable). Network Attached Storage Internet (NAS)
Connections Connecting power cable Before connecting the power cable (General model only) Set the switch position of VOLTAGE SELECTOR according to your local voltage. Voltages are AC 110–120/220–240 V, 50/60 Hz. Note Make sure you set VOLTAGE SELECTOR of the unit BEFORE plugging the power cable into an AC wall outlet.
BASIC OPERATION Playback Playback CAUTION Extreme caution should be exercised when you play back CDs encoded in DTS. If you play back a CD encoded in DTS on a CD player that does not support DTS, only noise will be heard, and this noise may damage your speakers.
Page 18
Playback ■ Adjusting the BASS and TREBLE ■ Adjusting the LOUDNESS control controls LOUDNESS VOLUME TREBLE BASS HOME PLAYING SETUP OPTION The BASS and TREBLE controls adjust high and low frequency response. VOLUME +/– ENTER VOLUME The center position produces a flat response. DISPLAY RETURN POP-UP...
Playback Using the sleep timer Use this feature to automatically set this unit to standby mode after a certain amount of time. The sleep timer is useful when you are going to sleep while this unit is playing or recording a source. CODE SET SOURCE RECEIVER...
Listening to FM/AM radio Listening to FM/AM radio Setting the frequency steps Press TUNER to select TUNER as the input source. At the factory, the frequency step setting is set to 50 kHz for FM and 9 kHz for AM. Depending on your country or region, set the frequency steps to 100 kHz for FM and 10 Press FM or AM to select the reception band kHz for AM.
