Summary of Contents for Yamaha R-N602

  • Page 1 R-N602 Network Receiver OWNER’S MANUAL...
  • Page 2 12 Only voltage specified on this unit must be used. Using this unit with a higher voltage than specified is dangerous and may cause fire, damage to this unit, and/or personal injury. Yamaha will not be held responsible for any damage resulting from use of this unit with a voltage other than specified.
  • Page 3 Caution: Read this before operating your unit. ■ Notes on remote controls and batteries ■ For U.K. customers • Do not spill water or other liquids on the remote control. If the socket outlets in the home are not suitable for the plug supplied with this appliance, it should be cut off and an •...
  • Page 4 In this case it complies with the requirement set by the Directive for the chemical involved. We, Yamaha Music Europe GmbH hereby declare that this unit is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

  • Page 5: Table Of Contents

    Contents Listening to Internet radio ........33 INTRODUCTION Registering favorite Internet radio stations What you can do with this unit ......... 2 (bookmarks)............. 34 Sources that can be played back on this unit ....2 Playing back iPod/iTunes music via a network Mastering useful apps (MusicCast CONTROLLER)..

  • Page 6: Introduction

    INTRODUCTION What you can do with this unit This unit is a network receiver compatible with a network source such as a media server and mobile device. It supports playback from not only analog sources such as a CD player but also Bluetooth devices and network streaming services.

  • Page 7: Mastering Useful Apps (Musiccast Controller)

    • Play songs stored on computers (servers) • Select an Internet radio station • Play music stored on mobile devices • Play music on streaming service • Distribute and receive audio between the unit and other Yamaha MusicCast supported devices See MusicCast Setup Guide for details.

  • Page 8: Supplied Accessories

    Supplied accessories Check that the following accessories are supplied with the product. Remote control Batteries (x2) AM antenna FM antenna (AA, R6, UM-3) SPEAKERS PHONO SLEEP COAX 1 COAX 2 BLUETOOTH OPT 1 OPT 2 LINE 1 LINE 2 LINE 3 TUNER BAND TUNING...

  • Page 9: Controls And Functions

    Controls and functions Controls and functions Front panel 4 5 6 7 8 9 : PURE DIRECT DIMMER DISPLAY MODE MEMORY CLEAR BAND PRESET TUNING VOLUME INPUT BASS TREBLE BALANCE LOUDNESS SELECT PUSH - ENTER FLAT PHONES SPEAKERS -30dB RETURN CONNECT 1 A (power) 7 MEMORY...
  • Page 10 Controls and functions PURE DIRECT DIMMER DISPLAY MODE MEMORY CLEAR BAND PRESET TUNING VOLUME INPUT BASS BALANCE LOUDNESS TREBLE SELECT PUSH - ENTER FLAT PHONES SPEAKERS -30dB RETURN CONNECT D PHONES jack K LOUDNESS control Outputs audio to your headphones for private listening. Retains a full tonal range at any volume level to compensate for the human ears’...

  • Page 11: Front Display

    Controls and functions Front display SLEEP STEREO TUNED MUTE VOL. If the network connection is not set, turn the power ON to display “WAC” (Wireless Accessory Configuration) on the front panel and trigger an automatic iOS device search. See “Sharing the iOS device setting” (p. 16) for details on the iOS device and network connection.

  • Page 12: Rear Panel

    Controls and functions Rear panel NETWORK PHONO SIGNAL ANTENNA OPTICAL SPEAKERS 75Ω COAXIAL SUBWOOFER PRE OUT LINE 1 PHONO jacks 8 Power cable For connecting to a turntable (p. 11). For connecting to an AC wall outlet (p. 14). 2 OPTICAL 1/2 jacks 9 LINE 1-3 jacks For connecting to audio components equipped with For connecting to analog audio components (p.

  • Page 13: Remote Control

    Controls and functions Remote control 1 Infrared signal transmitter Sends infrared signals. 2 SPEAKERS A/B SPEAKERS Turns on and off the set of speakers connected to the SPEAKERS A and/or SPEAKERS B terminals on the rear panel of this unit PHONO SLEEP when the corresponding key is pressed.

  • Page 14: Installing Batteries

    Controls and functions B A (power) Turns on/off (standby) the unit. C SLEEP SPEAKERS Sets the sleep timer (p. 23). D OPTION PHONO SLEEP Displays the “Option” menu (p. 43). COAX 1 COAX 2 BLUETOOTH E MUTE Mutes the audio output. OPT 1 OPT 2 LINE 1...

  • Page 15: Preparation

    PREPARATION Connections CAUTION • Do not connect this unit or other components to the main power until all connections between components are complete. • All connections must be correct: L (left) to L, R (right) to R, “+” to “+” and “–” to “–”. If the connections are faulty, no sound will be heard from the speakers, and if the polarity of the speaker connections is incorrect, the sound will be unnatural and lack bass.

  • Page 16: Connecting The Speakers

    Connections ■ Bi-wire connection Connecting the speakers Bi-wire connection separates the woofer from the combined midrange and tweeter section. A bi-wire ■ Connecting speaker cables compatible speaker has four binding post terminals. These Speaker cables have two wires. One is for connecting the two sets of terminals allow the speaker to be split into two negative (–) terminal of the unit and the speaker, and the independent sections.

  • Page 17: Connecting The Fm And Am Antennas

    The antennas for receiving FM and AM broadcasts are included with this unit. In general, these antennas should provide sufficient signal strength. Connect each antenna correctly to the designated terminals. Note If you experience poor reception quality, install an outdoor antenna. Consult the nearest authorized Yamaha dealer or service center about outdoor antennas. FM antenna...

  • Page 18: Connecting The Network Cable

    Connections Connecting the network cable Connect the unit to your router with a commercially-available STP network cable (CAT-5 or higher straight cable). Network Attached Storage Internet (NAS) Modem Router Network cable Mobile device (such as iPhone) NETWORK PHONO SIGNAL ANTENNA OPTICAL SPEAKERS 75Ω...

  • Page 19: Connecting To Network

    Connecting to network Connecting to network There are several methods to connect the unit to a network. Select a connection method according to your environment. Notes • Some security software installed on your PC or the firewall settings of network devices (such as a router) may block the access of the unit to the network devices or the Internet.

  • Page 20: Sharing The Ios Device Setting

    The following connection methods are available. You can apply the connection settings on the iOS device to the unit using a wireless connection. For R-N602 XXXXXX Wireless details, see “Sharing the iOS device setting (WAC) wirelessly”. (You need iOS device with iOS 7 or If the unit is already wire connected and also later.)

  • Page 21: Using The Wps Push Button Configuration

    Connecting to network When the sharing process finishes, the unit is automatically connected to the selected network Press A to turn on this unit. (access point). When the setting finishes, verify whether the unit is Press SETUP. connected to a wireless network (p. 20). ■...

  • Page 22: Set The Wireless Network Connection Manually

    Connecting to network Set the wireless network Use the cursor keys (B / C) to select connection manually “Security” and press ENTER. Before performing the following procedure, check the SECURITY security method and security key on the wireless router WPA2-PSK(AES) (access point).

  • Page 23: Connecting A Mobile Device To The Unit Directly (Wireless Direct)

    Connecting to network Connecting a mobile device to the Use the cursor keys (D / E) to select desired unit directly (Wireless Direct) security method and press RETURN. Settings Using Wireless Direct, this unit can operate as a wireless None, WPA2-PSK (AES) network access point that mobile devices can directly connect to.

  • Page 24: Verify The Network Connection Status

    Connecting to network Verify the network connection status Perform the following procedure to verify the unit’s connection to a network. MEMORY PRESET Cursor keys B / C ENTER ENTER HOME RETURN RETURN SETUP OPTION SETUP VOLUME NOW PLAYING MUTE Press SETUP. Use the cursor keys (B / C) to select “Network”...

  • Page 25: Basic Operation

    BASIC OPERATION Playback Playing a source Play the source. A (power) Rotate the VOLUME control on the front panel (or press VOLUME +/– on the remote control) to adjust the sound output level. PURE DIRECT DIMMER DISPLAY MODE MEMORY CLEAR BAND PRESET TUNING...

  • Page 26: Adjusting The Bass And Treble

    Playback ■ Adjusting the BASS and TREBLE ■ Adjusting the LOUDNESS control controls PURE DIRECT DIMMER DISPLAY MODE MEMORY CLEAR BAND PRESET TUNING PURE DIRECT VOLUME INPUT BASS TREBLE BALANCE LOUDNESS SELECT PUSH - ENTER FLAT PHONES SPEAKERS DIMMER DISPLAY MODE MEMORY CLEAR...

  • Page 27: Using The Sleep Timer

    Playback Using the sleep timer Use this feature to automatically set this unit to standby mode after a certain amount of time. The sleep timer is useful when you are going to sleep while this unit is playing or recording a source. SPEAKERS (power) PHONO...

  • Page 28: Listening To Fm/Am Radio

    Listening to FM/AM radio ■ Improving FM reception (FM mode) FM/AM tuning If the signal from the station is weak and the sound quality is not good, set the FM band reception mode to monaural mode to improve reception. SPEAKERS PHONO SLEEP PURE DIRECT...

  • Page 29: Manual Tuning Preset

    Listening to FM/AM radio Manual tuning preset LINE 1 LINE 2 LINE 3 TUNER Select a radio station manually and register it to a preset TUNER BAND number. You can then easily recall any preset station by TUNING BAND selecting its preset number. MEMORY PRESET j / i PRESET...

  • Page 30: Recalling A Preset Station

    Listening to FM/AM radio Recalling a preset station Use the cursor keys to select “Clear Preset” and press ENTER. You can recall preset stations that were registered using automatic station preset or manual station preset. OPTION VOL. Clear Preset SPEAKERS PHONO SLEEP Use the cursor keys (B / C) to select a preset...

  • Page 31: Radio Data System Tuning

    Listening to FM/AM radio ■ Receiving traffic information Radio Data System tuning automatically When “TUNER” is selected as the input source, the unit (U.K. model only) automatically receives traffic information. To enable this Radio Data System is a data transmission system used by function, follow the procedure below to set the traffic FM stations in many countries.

  • Page 32: Playing Back Music Via Bluetooth

    Playing back music via Bluetooth You can play back music files stored on a Bluetooth device (such as mobile device) on the unit. On the Bluetooth device, select the unit’s Please also refer to the owner’s manual of your Bluetooth model name from the available device list.

  • Page 33: Disconnecting A Bluetooth Connection

    Playing back music via Bluetooth Operate the Bluetooth device to establish a Bluetooth connection. Select the unit’s model name from the Bluetooth device list on your device. When a connection is established, Bluetooth indicator on the front display will be light up. If you cannot connect the Bluetooth device, please perform pairing again.

  • Page 34: Playing Back Music Stored On Media Servers (Pcs/Nas)

    Playing back music stored on media servers (PCs/NAS) You can play back music files stored on your PC or DLNA-compatible NAS on the unit. This unit Notes • To use this function, the unit and your PC/NAS must be connected to the same router (p. 14). You can check whether the network parameters (such as the IP address) are properly assigned to the unit in “Information”...

  • Page 35: Playback Of Pc Music Contents

    Playing back music stored on media servers (PCs/NAS) Playback of PC music contents Select “Allowed” from the drop-down list next to the unit’s model name. Follow the procedure below to operate the PC music contents and start playback. Note “_” (underscore) will be displayed for characters not supported by the unit.
  • Page 36 Playing back music stored on media servers (PCs/NAS) Use the following remote control keys to control playback. Keys Function Select a music file or folder. Cursor keys Starts playback if pressed while content is selected. Moves down ENTER one level if pressed while a folder is selected.

  • Page 37: Listening To Internet Radio

    Listening to Internet radio You can listen to Internet radio stations from all over the world. Notes Use the cursor keys to select an item and • To use this function, the unit must be connected to the Internet press ENTER. (p.

  • Page 38: Registering Favorite Internet Radio Stations (Bookmarks)

    Listening to Internet radio Registering favorite Internet radio stations (bookmarks) By registering your favorite Internet radio stations to “Bookmarks”, you can quickly access to them from the “Bookmarks” folder in the front display. Select any of Internet radio stations on the unit.

  • Page 39: Playing Back Ipod/Itunes Music Via A Network (Airplay)

    Playing back iPod/iTunes music via a network (AirPlay) The AirPlay function allows you to play back iPod/iTunes music on the unit via network. On the iPod/iTunes, click (tap) the AirPlay icon and select the unit (network name of the unit) as the audio output device. iTunes iTunes (example) iPod (example)
  • Page 40 Playing back iPod/iTunes music via a network (AirPlay) Use the following remote control keys to control playback. Keys Functions Stops/resumes playback. p/ e Stops playback. b / w Playback Skips forward/backward. keys f / a Changes the Repeat settings. REPEAT Changes the Shuffle settings.

  • Page 41: Playing Back Music Stored On A Usb Storage Device

    Playing back music stored on a USB storage device You can play back music files stored on a USB storage device on the unit. Refer to the instruction manuals for the USB storage device for more information. Notes • The unit supports USB mass storage class devices (e.g., flash memories or portable audio players) using FAT16 or FAT32 format. •...
  • Page 42 Playing back music stored on a USB storage device ■ Repeat/shuffle settings You can configure the repeat/shuffle settings for playback Use the cursor keys to select an item and of USB storage device contents. press ENTER. If a song is selected, playback starts and the playback information is displayed.

  • Page 43: Playing Back Ipod Music

    Playing back iPod music You can play back iPod music on the unit using a USB cable supplied with the iPod. Note Playback of iPod content An iPod may not be detected by the unit or some features may not be compatible, depending on the model or software version of the Follow the procedure below to operate the iPod contents iPod.
  • Page 44 Playing back iPod music ■ Repeat/shuffle settings Use the following remote control keys to control playback. You can configure the repeat/shuffle settings of your iPod. Keys Function Select a music file, album or genre. Cursor keys If the input source is “USB,” press REPEAT Starts playback if pressed while a or SHUFFLE on the playback keys repeatedly music file is selected.

  • Page 45: Switching Information On The Front Display

    Switching information on the front display When you select a network source or USB as the input source, you can switch playback information on the front display. PURE DIRECT DIMMER DISPLAY MODE MEMORY CLEAR BAND PRESET TUNING VOLUME INPUT BASS TREBLE BALANCE LOUDNESS...

  • Page 46: Registering The Current Playback Song/Station (Preset Function)

    Registering the current playback song/station (Preset function) When you select network sources and USB as the input source, you can register the current playback song or streaming station as a preset up to 40. You can then easily recall any preset song/station by selecting its preset number. The following input sources can be set as presets.

  • Page 47: Advanced Operation

    ADVANCED OPERATION Configuring playback settings for different playback sources (Option menu) You can configure separate playback settings for different playback sources. This menu allows you to easily configure settings during playback. ■ Volume Trim MEMORY PRESET Corrects volume differences between input sources. If you are bothered by volume differences when switching between input sources, use this function to correct it.

  • Page 48: Configuring Various Functions (Setup Menu)

    Configuring various functions (Setup menu) You can configure the unit’s various functions. Setup menu items MEMORY PRESET Menu item Function Page Cursor keys ENTER B / C / D / E Selects the network Connection connection method. ENTER HOME RETURN RETURN Displays the network Information...

  • Page 49: Network

    Configuring various functions (Setup menu) Manual network settings Network Set “DHCP” to “Off”. Configures the network settings. ■ Connection Use the cursor keys (B / C) to select a Selects the network connection method. parameter type. Select this option when you want to connect Specifies an IP address.

  • Page 50: Bluetooth

    NAME on the unit from Bluetooth devices (Bluetooth standby). If this function is set to “On”, the unit automatically turns on R-N602 XXXXXX when a connect operation is performed on the Bluetooth device. Use the cursor keys (D / E) to move the edit Disables the Bluetooth standby function.

  • Page 51: Max Volume

    Configuring various functions (Setup menu) Max Volume ECO Mode Sets the maximum volume to prevent excessive loudness. Enables/disables the eco (power saving) mode. When the eco mode is enabled, you can reduce the unit’s power Setting range consumption. -30 dB to +15.0 dB / +16.5 dB (5 dB step) The new setting will take effect after the unit is restarted.

  • Page 52: Configuring The System Settings (Advanced Setup Menu)

    Configuring the system settings (ADVANCED SETUP menu) Configure the system settings of the unit while viewing the front display. Changing the speaker impedance Turn off the unit. setting (SP IMP.) While holding down RETURN on the front panel, press A (power). SP IMP.••8¬MIN A (power) RETURN...

  • Page 53: Updating The Firmware (Update)

    Configuring the system settings (ADVANCED SETUP menu) Updating the firmware (UPDATE) Checking the firmware version (VERSION) UPDATE•NETWORK VERSION••xx.xx New firmware that provides additional features or product improvements will be released as needed. If the unit is Check the version of firmware currently installed on the connected to the Internet, you can download the firmware unit.

  • Page 54: Updating The Unit's Firmware Via The Network

    Updating the unit’s firmware via the network New firmware that provides additional features or product improvements will be released as needed. If the unit is connected to the Internet, you can download the firmware via the network and update it. Notes •...

  • Page 55: Additional Information

    As a safety precaution, capability to turn on the power The power does not three times consecutively. If the unit is in is disabled. Contact your nearest Yamaha dealer or turn on. this condition, the standby indicator on the service center to request repair.
  • Page 56 Troubleshooting Problem Cause Remedy page Incorrect cable connections. Connect the cables properly. If the problem persists, Only the speaker on the cables may be defective. one side can be heard. Incorrect setting for the speaker balance. Set the BALANCE control to the appropriate position.
  • Page 57 Troubleshooting ■ Tuner Problem Cause Remedy page The particular characteristics of the FM Check the antenna connections. FM stereo stereo broadcasts being received may Try using a high-quality directional FM antenna. reception is cause this problem when the transmitter is noisy.
  • Page 58 Troubleshooting ■ Bluetooth Problem Cause Remedy page The Bluetooth function of the unit is Enable the Bluetooth function in the “Setup” menu. A Bluetooth disabled. connection cannot be established. Another Bluetooth device is already Terminate the current Bluetooth connection and then connected to the unit.

  • Page 59: Usb And Network

    Troubleshooting ■ USB and network Problem Cause Remedy page The USB device is not connected to the Turn off the unit, reconnect your USB device, and The unit does not — USB jack securely. turn the unit on again. detect the USB device.
  • Page 60 Troubleshooting ■ Remote control Problem Cause Remedy page Wrong distance or angle. The remote control will function within a maximum The remote control range of 6 m (20 ft) and no more than 30 degrees off- does not work nor axis from the front panel.

  • Page 61: Error Indications On The Front Display

    Error indications on the front display Message Cause Remedy Access to the PC is denied. Configure the sharing settings and select the unit as a device to Access denied which music contents are shared (p. 30). The unit cannot access the USB device. Turn off the unit and reconnect your USB device.

  • Page 62: Trademarks

    Windows is a registered trademark of Microsoft information on GPL/LGPL open source software, how to Corporation in the United States and other countries. obtain it, and the GPL/LGPL license, refer to the Yamaha Internet Explorer, Windows Media Audio and Windows Corporation website Media Player are either registered trademarks or (http://download.yamaha.com/sourcecodes/musiccast/).

  • Page 63: Specifications

    Specifications • RIAA equalization deviation Network PHONO (MM) ..............± 0.5 dB • Input jack: NETWORK x 1 (100Base-TX/10Base-T) • Total harmonic distortion • PC client function PHONO (MM) to OUT • Compatible with DLNA ver. 1.5 (20 Hz to 20 kHz, 3 V) .........0.025% or less •...

  • Page 64: Index

    Index Index FM antenna connection..........13 FM mode................ 24 ADVANCED SETUP menu.......... 48 FM radio listening............24 AirPlay................35 Front display (Controls and functions) ......7 AM antenna connection..........13 Front panel (Controls and functions) ....... 5 AM radio listening............24 ANTENNA jacks............
  • Page 65 Index Signal Info (Option menu) ..........43 Signal strength indicator ..........7 OPTICAL jacks ............8, 11 SLEEP indicator............. 23 OPTION................. 43 Sleep timer ..............23 Option menu ..............43 SP IMP. (ADVANCED SETUP menu) ......48 Speaker balance.............. 22 Pairing (Bluetooth) ............
  • Page 66 © 2015 Yamaha Corporation Printed in Malaysia ZS22660...
