Philips 55PFL6900/F7 Service Manual page 214

PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
C.....±0.25% D.....±0.5%
G.....±2% J......±5%
M.....±20% N.....±30%
Different parts from the original model
TYPE D 55PFL6900/F7 A (Serial No. : DS2)
Ref. No. Description
DIGITAL MAIN CBA UNIT
MSW ASSEMBLY
Consists of the following
FUNCTION CBA UNIT
IR SENSOR CBA UNIT
POWER SUPPLY CBA
2016/12/06
Electrical Parts
F.....±1%
K.....±10%
Z.....+80/-20%
Part No.
A51RHMMA-001
A51RHMSW-001
A51RHMSW-001-FN
A51RHMSW-001-IR
A51RHMPW-001
13-29 A51RH_EL.fm
