Siemens SIMATIC NET RUGGEDCOM RS400F Installation Manual page 46

IEC 61000-4-16
IEC 61000-4-17
IEC 60255-5
IEEE 1613 (C37.90.x) EMC Immunity Type Tests
Note
RUGGEDCOM products meet Class 1 requirements for copper Ethernet
configurations and Class 2 for fiber Ethernet configurations. Class 1 allows for
temporary communication loss, while Class 2 requires error-free and interrupted
communications.
Dielectric Strength
Environmental Type Tests
RUGGEDCOM RS400F
Installation Manual, 11/2022, C79000-G8976-1341-06
Test
Mains Frequency
Voltage
Ripple on DC
Power Supply
Dielectric
Strength
H.V. Impulse
Description
ESD Enclosure Contact
Radiated RFI
Fast Transient
Earth Ground Ports
Oscillatory
HV Impulse
Test
IEC 60068-2-1 Cold Temperature
6.2 EMC and Environmental Type Tests
Description
Signal Ports
DC Power Ports
DC Power Ports
Signal Ports
DC Power Ports
AC Power Ports
Signal Ports
DC Power Ports
AC Power Ports
Enclosure Air
Enclosure Ports
Signal Ports
DC Power Ports
AC Power Ports
Signal Ports
DC Power Ports 1 kV Common and Differential Mode at 1 MHz
AC Power Ports 1 kV Common and Differential Mode at 1 MHz
Signal Ports
DC Power Ports
AC Power Ports
Signal Ports
DC Power Ports
AC Power Ports
Description
Test Levels
30 V Continuous, 300 V for 1 s
30 V Continuous, 300 V for 1 s
10%
2 kVac (Fail-Safe Relay Output)
1.5 kVDC
2 kVAC
5 kV (Fail-Safe Relay output)
5 kV
5 kV
Test Levels
±8 kV
±15 kV
35 V/m
±4 kV at 2.5 kHz
±4 kV
±4 kV
±4 kV
2.5 kV Common Mode at 1 MHz
2 kVAC
1.5 kVDC
2 kVAC
5 kV (Failsafe Relay)
5 kV
5 kV
Test Levels
Test Ad -40 °C (-40 °F), 16 Hours
Certification
Severity
Levels
4
4
3
37
