Description
The RUGGEDCOM RS400F features various ports, controls and indicator LEDs on the
front panel for connecting, configuring and troubleshooting the device.
1
3
1
2
3
4
5
6
7
8
9
10
Figure 1.1
POWER LED
ALARM LED
RUGGEDCOM RS400F
Installation Manual, 11/2022, C79000-G8976-1341-06
CSA/UL 60950 safety approved to 85 °C (185 °F)
2
POWER LED
ALARM LED
RESET Button
Ethernet Port Status LEDs
Serial Port Status LEDs
Failsafe Alarm Relay
Modem Port (Optional)
RS232 Serial Console Port (DB9)
Surge Ground Terminal
Power Supply Terminal Block
RUGGEDCOM RS400F Modules
4
5
Illuminates when power is being supplied to the device.
Illuminates when an alarm condition exists.
