Marantz VP-10S1 User Manual

Marantz vp-10s1: user manual
Hide thumbs Also See for VP-10S1:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Reference Manual
Model VP-10S1 User Guide
DLP
TM
Projector

Advertisement

Table of Contents
loading

Related Manuals for Marantz VP-10S1

Summary of Contents for Marantz VP-10S1

  • Page 1 Model VP-10S1 User Guide Projector...
  • Page 2 - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. CAUTION RISK OF ELECTRIC SHOCK...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY This product was designed and manufactured to meet strict quality and safety standards. There are, however, some installation and operation precautions which you should be particularly aware of. Read these instructions - All the safety and operating instructions should be read before the product is operated. Keep these instructions - The safety and operating instructions should be kept for future reference.
  • Page 4 Before use, carefully read the User Guide of the projector and the Lamp Replacement Instructions. Remember to handle the lamp with care. In the event of serious trouble, call for Marantz authorized dealer. • Never look directly into the lamp with unprotected eyes while lit.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS PRECAUTIONS IN USE ...2 Precautions in Relocation...2 Precautions in Installation ...2 Precautions in Operation ...2 Lamp Replacement Precautions ...3 Lens Changes ...3 FEATURES ...4 ACCESSORIES ...5 NAMES AND FUNCTIONS OF PARTS...6 Front and Top ...6 Rear and Terminals ...7 Bottom ...7 Remote Controller ...8 Remote Controller Operating Range ...9...

  • Page 6: Precautions In Use

    11 13/16 inch (30 cm) or more from objects on all sides. • To hang the projector from a ceiling, contact the Marantz Authorized Dealer or Service Center. To ensure safe installation, the ceiling must be reinforced to support the projector’s weight.

  • Page 7: Lamp Replacement Precautions

    It is almost impossible to have zero pixel defects, even using the most advanced technology. This is not a problem only for Marantz, but all projector manufactures. Therefore we have to note that the warranty does not cover the DMD defects.

  • Page 8: Features

    16:9 wide panel) to distinctly reproduce R/G/B colors. Using an optimized system for movie viewing with the below image circuit and optical parts, the VP-10S1 brings high color reproduction and rich tones that balance pitch black with bright white to images.

  • Page 9: Accessories

    ACCESSORIES After opening the package, check the below accessories have been included. • Lens cap x 1 • Remote controller x 1 STANDBY POWER ON PATTERN PATT. MENU V-MUTE ENTER INPUT ASPECT INPUT1 MODE ASPECT COMP.1 THEATER FULL COMP.2 NORMAL S-VIDEO DYNA.

  • Page 10: Names And Functions Of Parts

    NAMES AND FUNCTIONS OF PARTS Front and Top Projection Lens IR sensor q POWER button ( pg. 20) Switches power ON/OFF (standby). w MENU button ( pg. 25) Displays the on-screen menu (*OSD). * OSD: Acronym for On Screen Display. With this projector, OSD entails menus for making adjustments and settings.

  • Page 11: Rear And Terminals

    Use to control this projector when combined with Marantz products into a system. Connect the REMOTE CONTROL OUT of the other Marantz product to the REMOTE CONTROL IN of this projector and the REMOTE CONTROL IN of this other Marantz product to the REMOTE CONTROL OUT of this projector.

  • Page 12: Remote Controller

    Remote Controller STANDBY POWER ON PATTERN PATT. MENU V-MUTE ENTER INPUT ASPECT INPUT MODE ASPECT COMP.1 THEATER FULL COMP.2 NORMAL S-VIDEO DYNA. ZOOM VIDEO USER THROUGH CINEMA INFO ¡0 LIGHT ¡1 REMOTE CONTROLLER RC-12VPS3 a STANDBY button ( pg. 20) Sets the projector on standby provided power to the projector is on.

  • Page 13: Remote Controller Operating Range

    IR sensor. Remote Controller Remote Controller 16.4ft (5m) VP-10S1 Remote Controller 16.4ft (5m) VP-10S1 Remote Controller 16.4ft...

  • Page 14: Installation

    • Specialized skill is required to hang this projector from a ceiling. For safety reasons, do not install the projector yourself. Contact your nearest Marantz Authorized Dealer or Service Center. Hanging the projector from the ceiling requires a separately solder hanger and pole.

  • Page 15: Screen Size And Projection Distance (16:9 Screen) - (Inch)

    Screen Size and Projection Distance (16:9 Screen) - (inch) The projection distance for projecting a 16:9 image on a 16:9 screen is shown below. Diagonal 16:9 Screen Screen size Image width (inch) (inch) 52.29 61.01 62.75 69.73 71.47 73.21 78.44 80.18 87.16 92.39...

  • Page 16: Screen Size And Projection Distance (16:9 Screen) - (M)

    Screen Size and Projection Distance (16:9 Screen) - (m) The projection distance for projecting a 16:9 image on a 16:9 screen is shown below. Diagonal 16:9 Screen Screen size Image width (inch) 1.52 1.33 1.78 1.55 1.83 1.59 2.03 1.77 2.08 1.82 2.13...

  • Page 17: Screen Size And Projection Distance (4:3 Screen) - (Inch)

    Screen Size and Projection Distance (4:3 Screen) - (inch) The projection distance for projecting a 16:9 image on a 4:3 screen is shown below. Diagonal 16:9 Screen Screen size Image width (inch) (inch) 48.00 56.00 57.60 64.00 65.60 67.20 72.00 73.60 80.00 84.80...

  • Page 18: Screen Size And Projection Distance (4:3 Screen) - (M)

    Screen Size and Projection Distance (4:3 Screen) - (m) The projection distance for projecting a 16:9 image on a 4:3 screen is shown below. Diagonal 4:3 Screen Screen size Image width (inch) 1.22 1.52 1.42 1.78 1.83 1.46 2.03 1.63 2.08 1.67 2.13...

  • Page 19: Connections

    CONNECTIONS ❖ When making connections be sure to: • Turn off the projector and any connected equipment before making any connections. • Use the proper cables for each connection. See the instruction manual of each connected device. • Securely insert the plug into the jack to connect cables. Loose connections can lead to trouble. ❖...

  • Page 20: Connecting To An Hd-Video, Satellite, Cable Tuner Or Pc

    DVI-D cable (commercially available) Connecting to a Home Theater System You can control an entire home theater system using a PC and Marantz receiver equipment. To install the below system, contact your nearest Marantz Authorized Dealer or Service Center. VIDEO IN S-VIDEO IN COMPONENT VIDEO IN 1...

  • Page 21: Initial Setting

    INITIAL SETTING Activating the Power Connect the included AC power cable. ( Set the ON/OFF switch on the projector rear in the on position. The STANDBY indicator on the projector will light up. Press the POWER ON button on the remote controller or the POWER button on the projector. The POWER ON indicator on the projector will light up.

  • Page 22: Positioning The Projected Image

    Positioning the Projected Image You can position the projected image on the screen using the “Lens shift” feature in the menu (OSD). (For an explanation of this feature, see “Configuration” First, project an image on the screen. (If you haven’t an Input signal, display the focus pattern.) Press the MENU button on the remote controller or projector to display the menu.

  • Page 23: Keystone Correction

    Keystone Correction If the projected image appears trapezoidal in shape, you can correct it using the “Keystone V” and “Keystone H” features in the menu (OSD). (For an explanation of this feature, see “Display” Press the MENU button on the remote controller or projector to display the menu. 3 / 4 Select “Display”...

  • Page 24: Basic Operations

    BASIC OPERATIONS Activating the Power Connect the included AC power cable. ( Set the ON/OFF switch in the on position. The STANDBY indicator will light up. Press the POWER ON button on the remote controller or the POWER button on the projector. The POWER ON indicator on the projector will light up.

  • Page 25: Selecting An Input Signal

    Selecting an Input signal You can select the Input signal from amongst the devices connected to the projector. Every time the INPUT button on the projector or the remote controller is pressed, the Input signal rotates in the order of COMPONENT 1 ➔...

  • Page 26: When Using A 16:9 Screen

    When Using a 16:9 Screen • To project a video source of a 4:3 aspect ratio, use either the Full, Normal or Zoom mode. • To project a video source of a 16:9 aspect ratio such as 1080i, 1035i or 720p, use the Full mode. •...

  • Page 27: When Using A 4:3 Screen

    When Using a 4:3 Screen • To project a video source of a 4:3 aspect ratio, use either the Full, Normal or Zoom mode. • To project a video source of a 16:9 aspect ratio such as 1080i, 1035i or 720p, use the Full mode. •...

  • Page 28: Menu Operations

    MENU OPERATIONS Menu Structure Main Menu Picture Adjust Contrast pg. 26 Brightness Color Sharpness Tint Noise Reduction Color Temp. (Temperature) Fine Menu Setting Lamp mode pg. 29 High Bright Aspect OSD Position VCR Mode Cinema Black Setup During DVI input, “NORMAL” or “EXPAND” is shown. Component 1 System pg.

  • Page 29: How To Operate Menus

    How to Operate Menus This projector uses menus to make setting and adjustment easy. Press the MENU button. The MENU screen will appear on the screen. Use the buttons to select a main menu (Picture Adjust, Setting, System, Display, Config, Trigger 2, Preset) and press the button.

  • Page 30: Picture Adjust

    Picture Adjust You can adjust picture quality to your liking in each of the picture modes and save those adjustments in memory. This projector makes 3 memory indexes (1, 2 and 3) available for each picture mode. ❖ For a video signal input, the following adjustments can be made. Menu Picture Adjust Contrast...

  • Page 31: Fine Menu

    Fine Menu Picture quality can be fine-adjusted from the Fine Menu. Note : Some menu items cannot be adjusted depending on the input signal. ❖ Luminance FineMenu Luminance H Detail Gain Chrominance H Detail Threshold Sub Control H Edge Gain Miscellaneous H Edge Threshold V Detail Gain...
  • Page 32 ❖ Sub Control FineMenu Luminance Contrast Red Chrominance Contrast Green Sub Control Contrast Blue Miscellaneous Brightness Red Brightness Green Brightness Blue Clamp Position Clamp Width Contrast Red : Sets how much red contrast comes out in images. Contrast Green : Sets how much green contrast comes out in images. Contrast Blue : Sets how much blue contrast comes out in images.

  • Page 33: Setting

    OSD position for 16:9 – VCR Mode On : Stabilizes the picture. Use to play back video or input TV signals of weak electromagnetic waves if the image is unstable when the mode is off. Off : Normally use this mode.

  • Page 34: System

    RGB, YP , YC Sets the color space conversion for DVI input. RGB: Does not convert color space. : Suitable for high definition TV signals such as 720p and 1080i. : Suitable for signals such as 480p and 576p. ❖...

  • Page 35: Display

    Display You can make the following settings. Menu Picture Adjust Keystone V Setting Keystone H System Auto Adjust Display Picture Shift V Config Picture Shift H Trigger 2 Size V Size H Preset Phase – Keystone V / H Corrects the trapezoidal shape of the projected image. (For details, “Keystone Correction” –...

  • Page 36: Configuration

    Configuration You can configure the projector from the following settings. Menu Picture Adjust Auto Power Off Disable Setting Installation Front System Language English Display Focus/Zoom Config Lens Shift Trigger 2 Color Temp. Calibration Reset Lamp Life Preset Reset All – Auto Power Off When the auto power off feature is turned on, the below message appears on the screen if no signals are received and no operations are performed for 9 consecutive minutes.

  • Page 37: Trigger 2

    – Reset All Resets all settings to their factory defaults except the user-selected gamma curve and the lamp life counter. When you select “Yes”, the following message appears on the screen. Reset All ? Select “Yes” and press the ENTER button. ❖...

  • Page 38: Preset

    Preset You can select a picture mode from the MENU screen. This projector offers 4 pictures modes: Theater, Standard, Dynamic and User. Moreover, each of these picture modes has 3 indexes for saving picture quality adjustments. • Theater : Reproduces the kind of black suited for movie software. •...

  • Page 39: Maintenance

    MAINTENANCE Lamp Life and Replacement ❖ Lamp Life Pressing the INFO. button on the remote controller displays the below message on the screen. The remaining lamp life appears on the second from last line. Information Video Input Component-1080i Preset User A1 Cinema Mode Auto Aspect...

  • Page 40: Lamp Unit Replacement

    • Do not loosen any screws except those specifically mentioned in the below procedure. • The lamp may break under excessive force or mechanical shock. • Use only the Marantz original lamp unit LU10VPS1 (sold separately). ❖ How to Replace the Lamp Preparation: Turn off power to the projector before replacing the lamp.
  • Page 41 Loosen the 2 screws that lock down the lamp cover. (Slotted head screwdriver required.) Detach the lamp cover in the direction of the arrow. Lamp cover Remove the 2 screws that lock down the lamp shield. (Phillips screwdriver required.) Pull the lamp shield downward as indicated in the below figure and detach.

  • Page 42: Color Temperature Adjustment

    Color Temperature Adjustment After replacing the lamp or otherwise when the lighting changes, you can adjust the color temperature using the included color temperature sensor. In the adjustment procedure, you must first initialize the sensor itself before adjusting color temperature. It takes about 10 minutes from when power to the projector is activated for the lamp’s brightness to stabilize.

  • Page 43: Lens Cleaning

    Replacement Parts If replacement parts are needed, contact your nearest Marantz dealer or authorized service center. Use only replacement parts specified by Marantz. Unauthorized substitutes may result in fire, electric shock or other hazards, and will forfeit warranted servicing.

  • Page 44: Specifications

    SPECIFICATIONS ❖ Optical characteristics Technology 3-chip DLP Panel 0.8 inch 16:9 1280 x 720 pixels Digital Micromirror Device Lamp P-VIP 250W AC Lens 1.44 – 1.80:1 (LN10VP32) 1.80 – 2.40:1 (LN10VP40) 2.40 – 3.60:1 (LN10VP53) Projection size 60 to 300 inch (when using 16:9 screen) Light output 1200 ANSI LUMEN typical...

  • Page 45: Glossary

    GLOSSARY Aspect ratio Width and height ratio of an image. The aspect ratio of ordinary computer monitors and TV screens is 4:3. The aspect ratio for wide screens ranges from 16:9 to 21:9. Black level The level of brightness in black areas or the absence of light, which incidentally is black.

  • Page 46: Troubleshooting

    (center) position? Note: • If the lamp still does not function after the replacement and initialization of the lamp life, contact a Marantz authorized dealer, or service center. Note: This projector uses a microcomputer. External noise can cause malfunctions. In such case, shut power OFF and unplug the power cable from AC power outlet.

  • Page 47: Error Mode

    ERROR MODE WARNING indicator, POWER ON indicator, and STANDBY indicator diagnose error mode of the projector as follows. Error mode WARNING Lamp cover Lamp Temperature Flashing Flashing Color temperature adjustment Other Flashing ON SCREEN MESSAGE Use the list below to check the message displayed on the screen. Message NO SIGNAL No input signal.

  • Page 48: Dimensions

    DIMENSIONS ❖ POWER MENU INPUT PATTERN STANDBY φ7 5/16 (185.0) 20 1/16 (510.0) ❖ Front φ2 3/16 13 7/8 (352.0) (55.5) ❖ Bottom ENTER ❖ Rear 4 15/16 7 15/16 7 1/16 (202.0) (180.0) 21 7/8 (555.0) 13/16 (21.3) 3 1/8 3 1/8 2 1/8 (79.8)
  • Page 49 You can find your nearest authorized distributor or dealer on our website. JAPAN Marantz Japan, Inc. U.S.A. Marantz America, Inc. EUROPE Marantz Europe B.V. Printed in Japan 35-1 Sagami Ohno 7-Chome, Sagamihara-shi, Kanagawa 228-8505, Japan 1100 Maplewood Drive, Itasca, IL 60143, U.S.A.
