Marantz VP-10S1 Reference Manual

Partner: Marantz
Model: VP-12S3 + VP-10S1
Device Type: Display
GENERAL INFORMATION
SIMPLWINDOWS NAME:
CATEGORY:
VERSION:
SUMMARY:
GENERAL NOTES:
CRESTRON HARDWARE REQUIRED:
SETUP OF CRESTRON HARDWARE:
VENDOR FIRMWARE:
VENDOR SETUP:
CABLE DIAGRAM:
Marantz VP-12S3 + VP-10S1 Projector.umc
Display
1.0
This module will control the following functions of the VP-12S3 + VP-10S1 DLP
Projectors: Power, Source Select, Picture Mute, Lamp Mode, Aspect Ratio, full menu
control, presets and display Elapsed Lamp Hours.
This module will control the Marantz VP12-S3 + VP-10S1 DLP Projectors. True
feedback is provided for all functions including elapsed lamp hours. When any
command is sent to the projector, it will acknowledge that the command was
processed properly and the corresponding feedback will be reflected at the outputs
of this module.
When the Poll_Enable input is asserted (Default =1), the projector will be polled
every 15 seconds to determine the state of power. If it is desired to poll the
projector for all other setting changes made using the IR remote control, or by the
controls on the projector itself, you can assert the Poll_Settings input (Default =1).
When this input is high, the projector will be polled every 45 seconds to determine
the state of current selected source, aspect ratio, picture mute lamp mode, presets
and elapsed Lamp Hour usage. Typically, you could enable either polling option
when the projector's particular control page is active and displayed on a touch
panel. You would then disable polling at other times.
C2-COM, ST-COM, CNMSX Internal Com Ports
RS232
Baud: 9600
Parity: N
Data Bits: 8
Stop Bits: 1
RTS/CTS Handshaking Enabled
None
None
CNSP-143
