STEP 4
It is recommended to connect the cameras to your PC
Software Installation on Local Computer (Server)
prior to installing the VistaPro4 software application
1. Browse to your CD drive and open the 2. Open to view the contents from within the
VistaPro4 software. Install folder.
4. Click "Next" and proceed with your 5. Enter the necessary information and press
installation the "Next" button. The serial number can
be found within the sleeve of the VistaPro4
CD. E.g.
Tip: Please keep a copy of your
serial number in a safe location.
7. Wait for the software installation to complete 8. Open the VistaPro4 Server software icon from
and click "Yes" to register your product. This your computer desktop. If the cameras are
ensures that the server application launches connected, you will see the live images.
at the start up of your computer. Note: Click "Unblock" when you see the Windows XP™
Security Alert.

Congratulations!
You have completed Step 4 successfully. Your computer is now ready to view, record and play back video using the VistaPro4 software.
QLR0440 SERIES QUICK START GUIDE - EN - R2
STEP 5
Software Installation on Remote Computer (Client)
Port Forward Your Router First
3. Double click to execute the Setup.exe file.
forward your router, please refer to your router's user manual. A router configuration guide featuring the most commonly used routers in the market is available on
www.lorexcctv.com/support in the Consumer's Guide Section
1. Follow the installation screens as per
Step 4 (section 1 - 5) to install the Client
software. Once you see the "Select
Component" screen, choose " General
Client (Client & Search) option and
press the "NEXT" button. After the
installation is complete, you will see
VistaPro4 Client and Search icons on
your desktop. Click on the VistaPro4
6. Choose "All Components" option and
Client software icon to open the Client
press the "Next" button.
software .
TIPS
How to Connect BNC Cameras (not included) to VistaPro4 PCI Card
9. If your Serial Number registers successfully,
you will see the confirmation within the
VistaPro4 sofware window.
Camera with BNC Connector
BNC Cameras require BNC Male to Female connector & RCA Male to Male cable to connect to the VistaPro4 PCI Card.
1. Connect BNC female end of 2. Connect the RCA Cable.
the camera to the BNC Male
end of the connector.
As our product is subject to continuous improvement, Lorex Technology & subsidiaries reserve the right to modify product design, specifications & prices without notice and without incurring any obligation. E&OE
before proceeding with the set-up. You must forward Ports: 2000, 2001, 2002, 2003 (TCP/IP). All routers are different. To port
www.lorexcctv.com/support
3. On the VistaPro4 Client screen, press the
2. • Click on the Setup button
"Connect" button and enter the password
• On the "Select System Setup" screen,
(master by default) to view the cameras remotely.
choose "Local" and click "OK".
• On the "Setup" screen, click on the "Server
Registration" tab and click on the "Registration"
button to configure the Server Name (e.g. office) with
IP/Product No. that can be found within the sleeve of
the VistaPro4 CD.
• Add Video Port No: 2000
• Add the User ID (admin by default) and click the
"Ok" button.
Office User ID by default is "admin"
Password is "master"

Congratulations!
You have completed Step 5 successfully. Your
computer is now ready to view, record and play
back video remotely.
BNC Male to RCA Female Connector RCA Male to Male cable
BNC Male to RCA Female Connector
Kit (Model BNC-4PK)
You can order the connector kit from our
3. Connect the other end of the 4. Connect your Camera Power
RCA Male cable to the video adaptor to the Power end of website at www.lorexcctv.com
port of the PCI Card (already the Camera Cable.
inserted to your computer).
©2008 Lorex Technology Inc.
QuICk START GuIDE
QLR0440 SERIES
4 PORT PCI CARD
DIGITAL VIDEO RECORDER
 PACKAGE CONTENTS:
1 x 4 Port PCI Capture Card
1 x User's Manuals
1 x Quick Start Guide
1 x Software CD
NOTE:
QLR0444 includes:
4 x Cameras
4 x 60ft extension cables
4 x Power adaptors
FOR MORE INFORMATION & PRODUCT SUPPORT,
VISIT WWW.LOREXCCTV.COM
