Page 1: Instruction Manual
Video Surveillance System with 4 Indoor/Outdoor Night Vision Cameras MODEL: SHS-4SM © Copyright 2006 LOREX Technology Inc. Instruction Manual www.lorexcctv.com English Version 1.0... - Page 2 Thank you for purchasing the SHS-4SM. Lorex is committed to providing our customers with a high quality, reliable security product. The SHS-4SM Video Surveillance System with 4 Indoor/Outdoor Night Vision Cameras is easy to set up (connects to any TV, VCR or Monitor) making this security system perfect for protecting your home, family and personal property.
-
Page 3: Important Safeguards
Important Safeguards In addition to the careful attention devoted to quality standards in the manufacture process of your video product, safety is a major factor in the design of every instrument. However, safety is your responsibility too. This sheet lists important information that will help to assure your enjoyment and proper use of the video product and accessory equipment. - Page 4 Important Safeguards Service 13. Servicing - Do not attempt to service this video equipment yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. 14. Conditions Requiring Service - Unplug this video product from the wall outlet and refer servicing to qualified service personnel under the following conditions.
-
Page 5: General Precautions
4. Keep enough space around the unit for ventilation. Slots and openings in the storage cabinet should not be blocked 5. During lightning storms, or when the unit is not used for a long time, disconnect the power supply, antenna, and cables to protect the unit from electrical surge LOREX TECHNOLOGY INC. http://www.lorexcctv.com General Precautions... -
Page 6: Shs-4Sm Features
• Adjustable autoscan dwell time for 2s, 5s and 10s • Adjustable alarm time from 5 - 30 s • 6 pin mini DIN input for any LOREX CMOS/CCD observation camera • Easy Setup (connects to any TV, VCR or Monitor) makes this security system perfect for protecting your home, family and personal property •... -
Page 7: Table Of Contents
Camera Stand Installation: ... 13 Connecting Cameras ... 14 Connecting the SHS-4SM A/V Cable ... 15 Connectivity Diagram ... 15 SHS-4SM System Specifications - Appendix #1 ... 16 Control Box Specifications ... 16 Camera Specifications ... 16 Table of Contents... -
Page 8: Getting Started
Getting Started Getting Started The SHS-4SM comes with the following components: 4 x Weatherproof Color Day/Night IR Cameras AV Cable CHECK YOUR PACKAGE TO CONFIRM THAT YOU HAVE RECEIVED THE COMPLETE SYSTEM, INCLUDING ALL COMPONENTS SHOWN ABOVE. 4-Channel Camera Switcher 4 x 57’... -
Page 9: Shs-4Sm - Front View
SHS-4SM - Front View 1. GREEN LED INDICATORS - Four green LED indicators display the current active camera (corresponding to the rear DIN inputs CAM1-CAM4).’ 2. AUTO/MANUAL SCAN BUTTON - Scans through the available cameras. When the switcher is initially powered on, the scan type is set to AUTO and will cycle through all available cameras (CAM1-CAM4), displaying one image at a time. - Page 10 SHS-4SM - Front View SHS-4SM - Front View 3. CAM SELECT BUTTON - Manually changes the camera view between available channels. If a channel is empty (a camera is not connected), then the switcher will move to the next detected channel (i.e.
-
Page 11: Shs-4Sm - Rear View
1. CAM OUT - Connects the switcher to a TV, Monitor or VCR using the supplied A/V Cable. Connect the DIN end of the cable to the SHS-4SM switcher, and the Yellow Video and White Audio plugs to the corresponding terminal on the TV. -
Page 12: Shs-4Sm Cameras
SHS-4SM Cameras SHS-4SM Cameras The SHS-4SM switcher includes 4 CCD Color IR Day/Night Indoor/Outdoor Cameras* INFRA-RED LEDs - Provides illumination for low light conditions CAMERA LENS MICROPHONE - Picks up sound near the camera and transmits to the SHS-4SM switcher... -
Page 13: Camera Installation
Camera Installation Before you install the camera, carefully plan where and how you will position the camera, and where you will route the cable that connects the camera to the SHS-4SM switcher. Installation Warnings: • Select a location for the camera that provides a clear view of the area you want to monitor, which is free from dust, and is not in line-of-sight to a strong light source or direct sunlight. -
Page 14: Connecting Cameras
2. Connect the male end of the supplied 65’ extension cable to an open DIN camera input on the back of the SHS-4SM switcher. Continue connecting additional DIN cameras. NOTE: The arrow on the DIN Camera should be facing up when connecting the DIN Extension... -
Page 15: Connecting The Shs-4Sm A/V Cable
Connecting the SHS-4SM A/V Cable Connecting the SHS-4SM A/V Cable Connect the DIN end of the A/V Cable to the SHS-4SM Switcher. Connect the RCA Video and Audio cables to the TV, VCR or Monitor. TV / VCR / MONITOR... -
Page 16: Shs-4Sm System Specifications - Appendix #1
SHS-4SM System Specifications - Appendix #1 SHS-4SM System Specifications - Appendix #1 Control Box Specifications Channels Alarm Time Scan Time Operating Voltage Camera Input AV Output Camera Specifications Image Sensor Input Voltage Lens Angle Resolution Minimum Illumination IR LEDs Operating Temperature... - Page 17 Connecting the SHS-4SM A/V Cable Connecting the SHS-4SM A/V Cable Connect the DIN end of the A/V Cable to the SHS-4SM Switcher. Connect the RCA Video and Audio cables to the TV, VCR or Monitor. TV / VCR / MONITOR...
