Page 1: Instruction Manual
4 Camera Video Surveillance System with Multi Camera Viewing Instruction Manual English Version 1.0 MODEL: SHS-4QM2 www.lorexcctv.com © Copyright 2006 LOREX Technology Inc. - Page 2 Thank you for purchasing the SHS-4QM2. Lorex is committed to providing our customers with a high quality, reliable security product. The SHS-4QM2 Video Surveillance System with 4 Indoor/Outdoor Cameras (2x Night Vision / 2x Daylight Only) is easy to set up (connects to any TV, VCR or Monitor) making this security system perfect for protecting your home, family and personal property.
-
Page 3: Important Safeguards
Important Safeguards In addition to the careful attention devoted to quality standards in the manufacture process of your video product, safety is a major factor in the design of every instrument. However, safety is your responsibility too. This sheet lists important information that will help to assure your enjoyment and proper use of the video product and accessory equipment. - Page 4 Important Safeguards Service 13. Servicing - Do not attempt to service this video equipment yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. 14. Conditions Requiring Service - Unplug this video product from the wall outlet and refer servicing to qualified service personnel under the following conditions.
-
Page 5: General Precautions
4. Keep enough space around the unit for ventilation. Slots and openings in the storage cabinet should not be blocked 5. During lightning storms, or when the unit is not used for a long time, disconnect the power supply, antenna, and cables to protect the unit from electrical surge LOREX TECHNOLOGY INC. http://www.lorexcctv.com General Precautions... -
Page 6: Shs-4Qm2 Features
SHS-4QM2 FEATURES SHS-4QM2 FEATURES • Indoor/Outdoor, Weather Resistant Color Cameras • IR illumination provides night vision up to 5 meters (on 2 Night Vision Cameras only) • Support various display modes: QUAD Split Mode, Full Screen Mode, PIP Screen Mode. -
Page 7: Table Of Contents
Camera Setup ... 19 Motion Setup ... 19 Motion Setup ... 20 Event Setup ... 20 Event Report ... 21 SHS-4QM2 System Specifications - Appendix #1 ... 22 Control Box Specifications ... 22 Camera Specifications ... 22 Table of Contents... -
Page 8: Getting Started
Getting Started Getting Started The SHS-4QM2 comes with the following components: Quad Processor / Switcher 4 x 60’ DIN Extension 2 x Weatherproof Color 2 x Weatherproof Color Cables Cameras with Stands Day/Night IR Cameras with Stands DIN Video Cable... -
Page 9: Shs-4Qm2 - Front View
SHS-4QM2 - Front View 1. LED INDICATORS: • POWER - Indicates the Power Status (On/OFF) • ZOOM - Indicates the system is in ZOOM Mode. • FREEZE/AUTO - Indicates the system is in FREEZE/AUTO SEQUENCE Mode. 2. CHANNEL 1 / UP BUTTON - •... - Page 10 SHS-4QM2 - Front View SHS-4QM2 - Front View 6. CHANNEL 4 / RIGHT BUTTON - • Changes the view to CAM 4 in Viewing Mode. • Navigates RIGHT in MENU Mode. 7. QUAD / MENU / ESC BUTTON - • Changes the view to QUAD in Viewing Mode.
-
Page 11: Shs-4Qm2 - Rear View
SHS-4QM2 - Rear View SHS-4QM2 - Rear View 1. DIN OUTPUT - Connects the DIN Video cable to a TV/Monitor. 2. CAM1 - CAM4 DIN INPUTS - Camera inputs (for cameras with 4 pin DIN connection). 3. DC 12V - Connects the 12V DC Power adapter... -
Page 12: Remote Control
Remote Control Remote Control Listed below is a quick reference for the Remote Control. For details on specific features, refer to the Menu Setup on page #. MENU BUTTON - Enters Menu Setup NAVIGATION / ENTER - The NAVIGATION / ENTER BUTTONS are used to move Left / Right / Up / Down. -
Page 13: Shs-4Qm2 Cameras
SHS-4QM2 Cameras The SHS-4QM2 Quad Switcher / Processor includes 4 CCD Color Indoor/Outdoor Cameras* (2x Night Vision / 2x Daylight Cameras Only. Cameras with a BLACK BAND indicate NIGHT VISION) INFRARED LEDs** - Provides illumination for low light conditions CAMERA LENS... -
Page 14: Camera Installation
Camera Installation Before you install the camera, carefully plan where and how you will position the camera, and where you will route the cable that connects the camera to the SHS-4QM2. Installation Warnings: • Select a location for the camera that provides a clear view of the area you want to monitor, which is free from dust, and is not in line-of-sight to a strong light source or direct sunlight. -
Page 15: Connecting Cameras
2. Connect the male end of the supplied 60’ extension cable to an open DIN channel on the back of the SHS-4QM2. Continue connecting additional DIN cameras. NOTE: The arrow on the DIN Camera should be facing up when connecting the DIN Extension Cable to the SHS-4QM2. -
Page 16: Connecting The Shs-4Qm2 Video Cable
Connecting the SHS-4QM2 Video Cable Connecting the SHS-4QM2 Video Cable Connect the DIN end of the Video Cable to the SHS-4QM2. Connect the RCA VIdeo cable to the TV, VCR or Monitor. TV / VCR / MONITOR Connect the Yellow Video Cable to an available video. -
Page 17: Menu Setup
Menu Setup • Press the MENU button for 3 seconds to enter Menu Mode. ⇐ ⇑ ⇒ ⇓ • Press the buttons to navigate within the Menu and choose the desired selection. • Press the OK Button to accept the selection (labelled as ENTER in menu options) •... -
Page 18: Display Setup
Menu Setup Display Setup • DISPLAY ONSCREEN - Press the ⇒ ⇓ buttons to navigate to the desired selection. Press the enter button to set the Display Options for Title, Date and Time to ON/OFF. • SCREEN POSITION - Changes the position of the screen. -
Page 19: Camera Setup
Camera Setup • SWITCH BETWEEN CAMERAS - Use ⇐ ⇒ buttons to switch between CAMERA 1~4. • TITLE - Sets the name for the individual ⇑ ⇓ Camera. Press the navigate, and press the to select a character (A-Z, 0-9). •... -
Page 20: Motion Setup
Menu Setup Motion Setup • SENSITIVITY - Sets the Motion ⇑ ⇓ Sensitivity. Press the navigate, and press the to set the values (min~max). • VELOCITY - Sets the Motion Velocity. ⇑ ⇓ Press the buttons to navigate, and ⇐ ⇒ press the buttons to set the values (min~max). -
Page 21: Event Report
• 6 Pages of EVENT REPORTS are available. • Reports can be deleted by selecting the LIST CLEAR option, and setting to YES • Press any button on the SHS-4QM2 (except the OK button) to stop the Audible Alarm EVENT REPORT... -
Page 22: Shs-4Qm2 System Specifications - Appendix #1
SHS-4QM2 System Specifications - Appendix #1 SHS-4QM2 System Specifications - Appendix #1 Control Box Specifications Channel Scan Period Video Format Current Consumption Power Supply Video Input AV Output Camera Specifications Image Sensor Pixels Video Format Horizontal Resolution Minimum Illumination Electric Shutter Speed... - Page 23 It’s all on the web Product Information User Manuals Quick Start Guides VISIT www.lorexcctv.com Lorex Technology Inc. Specification Sheets Software Upgrades Firmware Upgrades wwwlorexcctv.com...
