Linksys SRW248G4P Product Data

48-Port 10/100 switch with reliable,
intelligent, ACL, Security, QoS, SNMP
managed PoE for growing business
The Linksys Switch with WebView allows you to expand your network securely.
Configuration of the switch is secured using SSL for Web access. User control is
secured with 802.1X security using a RADIUS authentication mechanism and can also
be controlled using MAC-based filtering.
Extensive QoS features makes the solution ideal for real-time applications like voice and
video. The 4 priority queues together with the Weighted Round Robin and Strict Priority
scheduling techniques facilitate efficient coexistence of real-time traffic with data traffic
allowing them each to meet their QoS needs. Individual users or applications can be
prioritized above others using various Class of Service options - by port, layer 2 priority
(802.1p), and layer 3 priority (ToS or DSCP). Intelligent broadcast and multicast storm
controls minimize and contain the effect of these types of traffic on regular traffic. IGMP
snooping limits bandwidth-intensive video traffic to only the requestors without flooding
all users. Incoming traffic can be policed and outgoing traffic can be shaped allowing you to
control network access and traffic flow.
There are features that allow you to expand and grow your network of switches. Link
aggregation allows multiple high-bandwidth trunks between switches to be setup. This also
provides a level of reliability in that the system continues to operate if one of the links break.
Spanning Tree (STP), Fast Spanning Tree, Rapid Spanning Tree (RSTP), and Multiple Spanning
Tree (MSTP) allow you to build a mesh of switches increasing the availability of the system.
The rich management functionality of the WebView switches includes SNMP, RMON, Telnet, and
HTTP Management options, allowing you to flexibly integrate and manage these devices in your
network.
Power control circuitry (Automatic load sensing) automatically detects Power over Ethernet on
access points before providing power. Power feeding of Ethernet is limited for fixed 10BASE-T/
100BASE-TX ports. The solution can provide maximum output power per PoE port up to 15.4W on
24 ports simultaneously. The Switch provides independent overload and short-circuit protection
for each port, LED indicators for power status per PoE port, and supports IEEE802.3af MIB for Power
over Ethernet functionality. The Switch supports IEEE 802.1d spanning tree, IEEE 802.1w Rapid STP,
Fast Linkover, and IEEE 802.1s Multiple STP. Cable diagnostics can be performed using the Switch's
WebView utility.
Optimized to be your Standards-based IEEE
network core with 48 802.3af PoE - Up To 24
10/100 Ethernet, 2 shared ports @ 15.4W. Total PoE
Gigabit combo and 2 power is 375W
giga ports
48-Port 10/100 + 4-Port Gigabit
Switch with WebView and

Power over Ethernet

SRW248G4P
Model:
Solution ideal for voice/ Secure management
video with IGMP snooping, via SSH/SSL and secure
L2/L3 policy filters user control via 802.1X &
MAC-based filtering
SRW248G4P
PRODUCT DATA
BUSINESS SERIES
