Leviton VZH08-1L Installation Instructions

DI-000-VZH08-02C
WARNINGS AND CAUTIONS:
• To be installed and/or used in accordance with appropriate electrical codes and regulations.
• If you are unsure about any part of these instructions, consult a qualified electrician.
• To avoid overheating and possible damage to this device and other equipment, use only with the appropriate Lutron 120V Hi-lume® or Eco-10™ (EcoSeries)
electronic ballasts for controlling the specific fluorescent lamps.
• Vizia™ dimmers are not compatible with standard 3-way or 4-way switches. They must be used with compatible Vizia™ remotes for multi-location dimming.
• Use only one (1) Vizia™ dimmer in a multi-location circuit with up to 9 coordinating remotes without LEDs or up to 4 matching remotes with LEDs. The
remote(s) will turn the light on at the brightness level selected at the dimmer.
• Only use lamps listed on ballast label. Compact Fluorescent lamps must have four pins for dimming.
Tools needed to install your Dimmer
Slotted/Phillips Screwdriver Electrical Tape
Pliers Pencil
Cutters Ruler
Changing the color of your Dimmer:
Your Dimmer will include three color options. The Dimmer ships
with the White frame attached. To change color of frame, proceed
as follows:
Push in side Line up tabs and
at tab to release press in side to attach
Installing Dimmer by itself or with other devices
If installing Dimmer in a single device application, proceed with
the INSTALLING YOUR DIMMER section. If installing Dimmer in
a multi-device application, proceed as follows:
MULTI-DEVICE APPLICATION
In multi-dimmer installations, the side sections of the mounting
strap may require removal. Use pliers to carefully bend side
sections back and forth until they break off.
Remove
all inner
side
sections
Do not
remove
outer
side
Bend back and
sections
forth to remove
side section
Typically, removal of the side sections in multi-dimmer
installations requires a reduction of the dimmer's capacity.
However, there is no reduction necessary for this device.
Refer to the chart for maximum load per dimmer.
MAXIMUM LOAD PER DIMMER FOR MULTI-DEVICE
More than
Cat. No. Single Two Devices
2 Devices
VZHØ8
8A 8A 8A
Single Pole (One location) or 3-Way (Multi-location)
The maximum current rating is 6A, which can be measured from
Step 2 cont'd
the incoming Hot (Black) on the dimmer. Refer to the ballast
label to determine the total load on the dimmer circuit. The total CAUTION:
load is calculated by adding all of the ballast input currents for all
Before installing your dimmer, check new installation wiring for any
ballasts on dimmer.
shorts in the circuit.
• Turn OFF Power at circuit breaker or fuse.
INSTALLING YOUR DIMMER
• Using a standard switch, connect appropriate wires to Hot circuit
and ballast (refer to diagram).
NOTE: Use check boxes when Steps are completed.
• Turn ON Power. If lights do not turn ON, there is an open in the
circuit.
• If required, Turn OFF Power and correct wiring. Verify circuit
WARNING:
Step 1 TO AVOID FIRE, SHOCK, OR
again. Warranty of dimmer will be voided if dimmer is turned ON
DEATH; TURN OFF POWER at circuit breaker or
in a shorted circuit.
fuse and test that power is off before wiring!
120VAC, 60Hz
Preparing and connecting wires:
Step 2
Pull off pre-cut insulation from dimmer leads. Make
1) For Single-Pole Application, go to Step 3a.
sure that the ends of the wires from the wall box are
2) For 3-Way Coordinating Remote (no LEDs)
straight (cut if necessary). Remove insulation from
each wire in the wall box as shown.
3) For 4-Way Coordinating Remote (no LEDs)
4) For 3-Way Matching Remote (with LEDs) Application,
Strip Gage
5/8"
(measure bare
5) For 4-Way Matching Remote (with LEDs) Application,
(1.6 cm)
wire here)
Step 3
Connect wires per WIRING DIAGRAM as follows: Twist strands
of each lead tightly together and, with circuit conductors, push
For non-standard wiring applications, refer
firmly into appropriate wire connector. Screw connectors on
to Wire Nut and Conductor Size Chart
clockwise making sure no bare conductors show below the
wire connectors. Secure each connector with electrical tape.
WIRE NUT / # OF COND.
For all multi-location applications, the dimmer must be installed
COMBINATION CHART
in a wall box that has a Load connection. The remote must be
installed in a wall box with a Line Hot connection and a Neutral
1 - #12 w/ 1 to 3 #14, #16 or #18
connection.
2 - #12 w/ 1 or 2 #16 or #18
If you are unsure about any part of these instructions, consult a
1 - #14 w/ 1 to 4 #16 or #18
qualified electrician.
2 - #14 w/ 1 to 3 #16 or #18
NOTE: Maximum wire length from dimmer to all installed
remotes cannot exceed 300 ft.
Fluorescent Dimmer
Cat. No. VZHØ8-1L (Lighted)
8A-120VAC, 60Hz
INSTALLATION INSTRUCTIONS
WARNINGS AND CAUTIONS:
• Lamps must be burned in at full intensity for 100 hours prior to dimming for proper dimming performance.
• For new installations, wire a test switch before installing dimmer.
• Total minimum load must exceed 40W.
• Dimmer may feel warm to the touch during normal operation.
• Recommended minimum wall box depth is 2-1/2".
• Maximum wire length from dimmer to all installed remotes cannot exceed 300 ft.
• Disconnect power at circuit breaker or fuse when servicing, installing or removing fixture.
• Use this device only with copper or copper clad wire. With aluminum wire use only devices marked CO/ALR or CU/AL.
A
Switch
Hot
Black
Insulating label:
Ballast
This wire is used in 3-way installations only.
For single pole installations do not remove
Line Orange
this insulating label.
Hot (Black)
White
Neutral
Line
Application, go to Step 3b.
120VAC
60Hz
Application, go to Step 3c.
go to Step 3b.
Neutral (White)
go to Step 3c.
Wiring your Dimmer:
B
Coordinating Remote
Screw marked
3-Way Wiring with Coordinating
B
Single-Pole Wiring Application:
Remote (no LEDs) Application:
Coordinating Remote (no LEDs)
Black
Hot (Black)
White
Orange
Line
120VAC
Green
60Hz
Red
Yellow/
Red
Neutral (White)
4-Way Wiring with Coordinating
C
Remote (no LEDs) Application:
Dimmer
Yellow/
Insulating Coordinating Remote
Black Red Label
Terminal
Screw marked
White (WH)
White
Green
Ground
Orange
LOAD
Red
Orange
120V Hi-Lume ®
or
Black
ECO-10 TM
(EcoSeries)
Ballast
White
Terminal
Screw marked
Yellow/Red
(YL/RD)
3-Way Wiring with Coordinating
Remote (no LEDs) Application:
Dimmer
Hot (Black)
Terminal
Screw marked
White (WH)
Black
Line
White
120VAC
60Hz
Orange
Green
Neutral (White)
Red
Terminal
Yellow/Red
Yellow/Red
(YL/RD)
Dimmer
Black Orange
BK
(not used)
WH White
Green
Green
Ground
Yellow/
Ground
Red
LOAD
RD
YL/RD Red
Orange
(not used)
120V Hi-Lume ®
or
Black
ECO-10
TM
(EcoSeries)
Ballast
White
Coordinating Remote Dimmer
Terminal
Screw marked
White (WH)
Black
White
Orange
Green
Terminal Red
Screw marked
Yellow/Red
(YL/RD) Yellow/Red
Coordinating Remote Coordinating Remote
(no LEDs) (no LEDs) Dimmer
Black Orange
BK BK
(not used) (not used)
WH WH
White
Orange
Yellow/
Green Green Green
Ground Ground Ground Red
RD RD LOAD
YL/RD YL/RD Red
(not used) (not used)
120V Hi-Lume
or
Black
ECO-10
(EcoSeries)
Ballast
White
®
TM
